PVI XR10CX User manual

PV500-67 03/17
MODBUS-RTU Applied
to the XR10CX Control
WATER HEATER DIGITAL
OPERATING CONTROLLER
PVI INDUSTRIES, LLC - Fort Worth, Texas 76111 - Web www.pvi.com -Phone [phone]

Page 2 / 15 PV500-67 03/17
Table of Contents
1. THIS MANUAL ---------------------------------------------------------------------------------------------------------------- 3
2. MODBUS RTU: --------------------------------------------------------------------------------------------------------------- 3
2.1 OVERVIEW: --------------------------------------------------------------------------------------------------------------- 3
2.1.1 DEFINITIONS:---------------------------------------------------------------------------------------------------- 3
2.2 COMMUNICATION DETAILS: ---------------------------------------------------------------------------------------- 4
2.2.1 Normal Communication diagram----------------------------------------------------------------------------- 5
2.2.2 Communication with exception code------------------------------------------------------------------------ 5
2.3 SEQUENCE OF MODBUS RTU COMMAND AND RESPONSE:-------------------------------------------- 5
3. COMMANDS (MESSAGES) ----------------------------------------------------------------------------------------------- 6
3.1 READ OUTPUT COIL (0x01):----------------------------------------------------------------------------------------- 6
3.1.1 MASTER COMMAND TO READ COILS (0x01):--------------------------------------------------------- 6
3.1.2 SUCCESSFUL RESPONSE, READ COILS (0x01): ---------------------------------------------------- 6
3.1.3 EXCEPTION RESPONSE, READ HOLDING REGISTER (0x01): ---------------------------------- 6
3.2 WRITE SINGLE COIL (0x05):----------------------------------------------------------------------------------------- 7
3.2.1 MASTER COMMAND TO WRITE SINGLE COIL (0x05):---------------------------------------------- 7
3.2.2 SUCCESSFUL RESPONSE, WRITE SINGLE COIL (0x05): ----------------------------------------- 7
3.2.3 EXCEPTION RESPONSE, WRITE SINGLE COIL (0x05):-------------------------------------------- 7
3.3 READ HOLDING REGISTERS (0x03): ----------------------------------------------------------------------------- 8
3.3.1 MASTER COMMAND TO READ REGISTERS (0x03): ------------------------------------------------ 8
3.3.2 SUCCESSFUL RESPONSE, READ HOLDING REGISTERS (0x03):------------------------------ 8
3.3.3 EXCEPTION RESPONSE, READ HOLDING REGISTER (0x03): ---------------------------------- 8
3.4 WRITE SINGLE REGISTER (0X06): -------------------------------------------------------------------------------- 9
3.4.1 MASTER COMMAND TO WRITE SINGLE REGISTER (0x06): ------------------------------------- 9
3.4.2 SUCCESSFUL RESPONSE FROM WRITE SINGLE REGISTER (0x06)------------------------- 9
3.4.3 EXCEPTION RESPONSE FROM WRITE SINGLE REGISTER (0x06):--------------------------- 9
3.5 WRITE HOLDING REGISTERS (0x10): ---------------------------------------------------------------------------- 10
3.5.1 MASTER COMMAND TO WRITE HOLDING REGISTER (0x10):----------------------------------- 10
3.5.2 SUCCESSFUL RESPONSE FROM WRITE HOLDING REGISTERS (0x10):-------------------- 10
3.5.3 EXCEPTION RESPONSE FROM WRITE HOLDING REGISTERS (0x10): ---------------------- 10
3.6 EXCEPTION RESPONSE:--------------------------------------------------------------------------------------------- 11
4. XR10CX REGISTERS & COILS ------------------------------------------------------------------------------------------ 12
4.1 LIST OF REGISTERS IN THE XR10CX---------------------------------------------------------------------------- 12
4.2 TYPICAL PARAMETERS FOR ACCESS OVER MODBUS: -------------------------------------------------- 13
5. SERIAL CONFIGURATION------------------------------------------------------------------------------------------------ 13
5.1 PORT SETUP ------------------------------------------------------------------------------------------------------------- 13
6. WIRING-------------------------------------------------------------------------------------------------------------------------- 14
6.1 TYPICAL WIRING DETAIL--------------------------------------------------------------------------------------------- 14
6.2 PROPER WIRING EXAMPLE----------------------------------------------------------------------------------------- 14
6.3 IMPROPER WIRING EXAMPLE-------------------------------------------------------------------------------------- 14
6.4 LINE TERMINATION (LT)---------------------------------------------------------------------------------------------- 15
6.5 LINE BIASING------------------------------------------------------------------------------------------------------------- 15
6.6 SERIAL INTERFACE XJ485------------------------------------------------------------------------------------------- 15
7. REFERENCES ---------------------------------------------------------------------------------------------------------------- 15
7.1.1 MODBUS INFORMATION:------------------------------------------------------------------------------------ 15
7.1.2 APPLICATION DETAILS AND SENSOR LOCATIONS: ----------------------------------------------- 15
7.1.3 XR10CX FEATURES: ------------------------------------------------------------------------------------------ 15
7.1.4 MORE INFORMATION:---------------------------------------------------------------------------------------- 15

Page 3 / 15 PV500-67 03/17
1. THIS MANUAL
This is a supplemental manual to cover the communication interface capabilities of the XR10CX thermostatic module
using Modbus RTU. This manual will provide the particulars for the XR10CX, how the Modbus RTU protocol is
implemented on the XR10CX, and how to interface with the XR10CX. For details on how to operate or configure the
XR10CX, please refer to the XR10CX Manual.
This manual is not a complete or definitive guide to Modbus RTU communication. For detailed MODBUS and Modbus
RTU information, consult other sources such as (www.modbus.org).
2. MODBUS RTU:
2.1 OVERVIEW:
Modbus RTU This is a communication over twisted pair from a Master device (also called a client) to multiple slave
devices (also called servers). The master will send command to a particular slave. The slave will in turn process this
command and respond to the Master. All communication is initiated by the Master. The XR10CX is a slave device and
will not “talk” until a Master device talks to it first. Modbus RTU is widely used within Building Management Systems
(BMS) and Industrial Automation Systems (IAS). This wide acceptance is due in large part to Modbus RTU’s ease of
use. Modbus RTU is a low level communications that contain no unit type, data scaling, or data description. Simply put,
it is a list of addresses that can be read and/or written to. The type of data will have to be known by the receiving device
in order for the data to be useful. Data types and available registers are usually provided as device documentation
register list.
2.1.1 DEFINITIONS:
MODBUS Protocol: A messaging structure used for communication between devices, machines, sensors, and/or
computers.
Modbus-RTU: (Remote Terminal Unit) Implementation of the Modbus protocol on top of a serial line with an RS-232,
RS-485 or similar physical layer. The XR10CX uses 2-wire RS-485 Physical Layer and implements Modbus RTU.
Master Device: Also known as Client, this device initiates all communication on the RS-485 network. The Master will
send commands to Slave Devices.
Slave Device: Also known as Server, this device will respond only when addressed by the Master device. When the
Master sends the slave a command, it will perform the command and respond back to the Master with the data
requested, or if no data is required, then it will simply echo the command.
Slave Address: Each slave device in a network is assigned a unique address from 1 to 247. When the Master requests
data, the first byte it sends is the Slave address. This way each slave knows after the first byte whether or not to ignore
the message.
RS-485 (EIA-485): A 2 wire (twisted pair) multi drop network. Each device can send data by holding positive and
negative voltage on the line and reversing polarity on the 2 wires. When no devices are transmitting, the line will be tri-
state. The recommended arrangement of the wires is as a connected series of point-to-point (multi-dropped) nodes,
i.e. a line or bus, not a star, ring, or multiply connected network. The number of devices that can be connected to a
single line is defined in the RS-485 standard by the input impedance of 32 UNIT LOADs. The wire and circuits
interfacing on this 2 wire connection is considered the PHYSICAL LAYER. (RS-485 is the same physical layer as used
with BACNET MSTP.)

Page 4 / 15 PV500-67 03/17
Line Termination: (LT) On RS-485, ideally the two ends of the cable will have a termination resistor connected across
the two wires. This helps with reducing noise and interference on high speed and long line lengths. In practice, it is not
needed in low speed and short line lengths. When needed, adding a 150ohm resistor across the line at the end devices
will reduce electrical noise and reflections.
Biasing Resistors: One device on the RS-485 line should have biasing resistors. This holds the line in a known state
when no devices are transmitting (talking). Typically this would be the Master device.
XR10CX Implementation: Modbus RTU protocol, over RS-485 (EIA-485) physical layer using 2 wires. Each XR10CX
should be considers 1 UNIT LOAD for the network loading. The XR10CX devices do not have biasing resistors.
XR10CX will operate in slave mode and will only transmit when addressed by the Master device.
Registers: (Holding Registers) Each Register is 1 word defined as 2 bytes or 16 bits. See Table 2 for details of each
Register. Holding registers are typically READ/WRITE but can be READ ONLY or WRITE ONLY. The XR10CX uses
this type of register. All Registers are in the range of 40001-4999.
Coils: (Output Coils or Boolean Variables) The XR10CX support and uses Output Coils. Each coil is 1 bit and can
be read or written to. Despite the name, they can be digital outputs, Boolean variables, or digital inputs.
Register Numbers / Register Addresses: Modbus can be confusing when referencing registers and their addresses.
Modbus documentation is not consistent and terms are used interchangeably when they have different meanings.
Register Addresses always start at 0 and count up, and Register Numbers are the actual number/name of the Register.
Example the first Holding Register is 40001. This would be address 0. For each data type, the address would start at
0 again. To avoid confusion, this manual will reference Register Numbers only. Any reference to a Register less than
40000 simply needs the 40000 added to it. Setpoint ST1 is Register 769 or the actual Register Number 40769. For a
list of all available registers, see Table 2.
Input Registers, Discrete Inputs and Coils: MODBUS defines several types of data. The only data used by the
XR10CX ®is the Holding Register (40001 –49999) and Output Coils (00001 –09999). The XR10CX does not use
Input Registers, or Inputs Coils.
CRC ERROR CHECKING: Modbus-RTU includes an error-checking field that is based on a Cyclical Redundancy
Checking (CRC) method performed on the message contents. The CRC field checks the contents of the entire
message. The CRC field contains a 16-bit value as the last 2 bytes in any message. The low-order byte of the field is
appended first, followed by the high-order byte. The CRC value is calculated by the sending device, which appends
the CRC to the message. The receiving device recalculated a CRC during receipt of the message, and compares the
calculated value to the actual value it received in the CRC field. If the two values are not equal, the message will be
ignored. Most Energy Management software packages will automatically calculate the CRC values as a normal part of
the protocol.
2.2 COMMUNICATION DETAILS:
The MODBUS application data unit is built by the Master (client) that initiates a MODBUS transaction. The function
indicates to the slave (server) what kind of action to perform. The function code field of a MODBUS data unit is coded
in one byte. When a message is sent from a Master to a Slave device the function code field tells the Slave what kind
of action to perform. The message contains information that the Slave uses to take the action defined by the function
code. If no error occurs in receiving the message from the Master, the slave will respond to the Master. The response
(Slave to Master) message contains the data requested, if no data was requested, it will echo the Master’s command.
See Figure 1 for a diagram of a successful communication. If the slave is unable to execute the command (example:
invalid command, unreachable address), the message contains an error code and an exception code. See Figure 2 for
diagram of an exception response. See Table 1 for a list of exception codes.

Page 5 / 15 PV500-67 03/17
2.2.1 Normal Communication diagram
Figure 1
MODBUS Transaction (Error Free)
2.2.2 Communication with exception code
Figure 2 MODBUS Transaction (Error, Exception Code response)
2.3 SEQUENCE OF MODBUS RTU COMMAND AND RESPONSE:
1) Master (Automation System) Sends command to Slave devices (XR10CX)
2) After transmitting, the Master turns off the line driver and listens
3) All Slave Devices receives command. (They are in listen mode)
a) If address matches Slave address and the CRC is valid, that Slave will process command.
i) If command was successfully processed
(1) Slave responds with its own slave address, and echoes the command it received, and includes any data
that may have been requested by the Master.
(2) After sending, the Slave goes back to listen mode.
ii) If command was not successfully processed
(1) Slave will respond with and exception response and exception code indicating why it was not processed.
(a) Possible caused would be invalid address. See Table 1 Exception Codes
(2) After sending, The Slave goes back to listen mode.
b) If the command received fails the CRC validation, no response is given.
c) If the command received does not match the Slave address, no response is given.
d) If the command is incomplete, no response is given.
e) If no command is received, no response is given.
Initiate Request
Function Code
Data Request
Perform the action
Initiate the response
Receive the Response
Master
Slave
Initiate Request
Function Code
Data Request
Error Code
Exception Code
Error detected in the
packet, initiate an error
Receive the response
Master
Slave
Data Response
Function Code

Page 6 / 15 PV500-67 03/17
3. COMMANDS (MESSAGES)
Modbus standard has several commands used to access different types of data. The XR10CX only uses the data type
called Holding Registers (40001 –49999) and Output Coils (00001 –09999). There are only 3 commands needed to
access the Holding Registers, and 2 commands for the Output Coils. The Modbus specification allow reading and
writing to multiple sequential registers, but the maximum number of registers that can be read or written to in one
command is 5. The limit for reading Coils is 80 and writing coils is only 1 at a time. This is a limitation of the XR10CX
device. In the following commands, the actual address will be used, the command indicates the type of register it is.
For example, the first Register 40001 will have address 0 and the first Coil 00001 will also have address 0.
3.1 READ OUTPUT COIL (0x01):
Read Coils from device. Coil status will be packed into the data bytes in the response. Only requested Coil data is valid
and the extra bits that may be present for padding the bytes should be ignored.
3.1.1 MASTER COMMAND TO READ COILS (0x01):
Slave Address: (1 byte): Device address that receives the command. Range: 1-247.
Function Code: (1 byte): Code = 0x01 (Read Output Coil).
Coil Address: (2 bytes): The address of the first coil to be read, reading multiple registers is sequential.
Number of Coils: (2 bytes): Number of Elements (Coils) that the device has to return (3 = 3 Coils or bits). No more
than 80 Elements (Coils) allowed. (Each coil is 1 bit).
CRC: (2 bytes): CRC calculated for the frame data received and is used to verify the integrity of data received.
3.1.2 SUCCESSFUL RESPONSE, READ COILS (0x01):
Slave Address: (1 byte): The address of the slave responding. Same as the address in the initiating command.
Function Code: (1 byte): Code = 0x01 Echo from the initiating command.
Number of Bytes: (1 byte): Defines the number of bytes followed minus the CRC.
Data: Byte data buffer, length is “Number of Bytes” long. Coil data I contained in this data. The first 8 Coils will be the
first Byte.
CRC: (2 bytes):
3.1.3 EXCEPTION RESPONSE, READ HOLDING REGISTER (0x01):
Slave Address: (1 byte): The address of the slave responding. Same as the address in the initiating command.
Exception Response: (1 byte): Code = 0x01 Echo from the initiating command plus high bit 0x80 = 0x81.
Exception Code: (1 byte): Defines the number of bytes followed minus the CRC. See Table 1 for explanation of
exceptions.
CRC: (2 bytes):
Slave
Address
Function
Code 0x01
Coil
Address
(MSByte)
Coil
Address
(LSByte)
Number of
Coils
(MSByte)
Number of
Coils
(LSByte)
CRC
(LSByte)
CRC
(MSByte)
Slave
Address
Success
echo:
Code
0x01
Number
of
Bytes
Data 1
Data
n
CRC
(LSByte)
CRC
(MSByte)
Data …
Slave
Address
Exception
0x01 + 0x80
Error: 0x81
Exception
Code
see list
CRC
(LSByte)
CRC
(MSByte)

Page 7 / 15 PV500-67 03/17
3.2 WRITE SINGLE COIL (0x05):
Write to a single Coil. For multiple coils, use multiple commands. You SET (1) the coil by sending 0xFF00 in the Data
field. You RESET (0) the coil by sending 0x0000.
3.2.1 MASTER COMMAND TO WRITE SINGLE COIL (0x05):
Slave Address: (1 byte): Device address that receives the command. Range: 1-247.
Function Code: (1 byte): Code = 0x05 (Read Output Coil).
Coil Address: (2 bytes): The address of the first coil to be read, reading multiple registers is sequential.
Data: (2 bytes): 0x000 will RESET (0), and 0xFF00 will SET (1) the coil.
CRC: (2 bytes): CRC calculated for the frame data received and is used to verify the integrity of data received.
3.2.2 SUCCESSFUL RESPONSE, WRITE SINGLE COIL (0x05):
Slave Address: (1 byte): The address of the slave responding. Same as the address in the initiating command.
Function Code: (1 byte): Code = 0x05 Echo from the initiating command.
Coil Address: (2 bytes): Echo from initiating command.
Data: (2 bytes): Echo from initiating command.
CRC: (2 bytes):
3.2.3 EXCEPTION RESPONSE, WRITE SINGLE COIL (0x05):
Slave Address: (1 byte): The address of the slave responding. Same as the address in the initiating command.
Exception Response: (1 byte): Code = 0x05 Echo from the initiating command plus high bit 0x80 = 0x85.
Exception Code: (1 byte): Defines the number of bytes followed minus the CRC. See Table 1 for explanation of
exceptions.
CRC: (2 bytes):
Slave
Address
Function
Code 0x05
Coil
Address
(MSByte)
Coil
Address
(LSByte)
Data
(MSByte)
Data
(LSByte)
CRC
(LSByte)
CRC
(MSByte)
Slave
Address
Success
Echo
Code 0x05
Coil
Address
(MSByte)
Coil
Address
(LSByte)
Data
(MSByte)
Data
(LSByte)
CRC
(LSByte)
CRC
(MSByte)
Slave
Address
Exception
0x05 + 0x80
Error: 0x85
Exception
Code
see list
CRC
(LSByte)
CRC
(MSByte)

Page 8 / 15 PV500-67 03/17
3.3 READ HOLDING REGISTERS (0x03):
Read a single register or multiple registers from the XR10CX. Response will be the values stored in the registers.
3.3.1 MASTER COMMAND TO READ REGISTERS (0x03):
Slave Address: (1 byte): Device address that receives the command. Range: 1-247.
Function Code: (1 byte): Code = 0x03 (Read holding register).
Register Address: (2 bytes): The address of the first register to be read, reading multiple registers is sequential.
Number of Registers: (2 bytes): Number of Elements (Registers) that the device has to return (3 = 3 Registers). No
more than 5 Elements (registers) allowed. (Each register is 16 bits).
CRC: (2 bytes): CRC calculated for the frame data received and is used to verify the integrity of data received.
3.3.2 SUCCESSFUL RESPONSE, READ HOLDING REGISTERS (0x03):
Slave Address: (1 byte): The address of the slave responding. Same as the address in the initiating command.
Function Code: (1 byte): Code = 0x03 Echo from the initiating command.
Number of Bytes: (1 byte): Defines the number of bytes followed minus the CRC.
Data: Byte data buffer, length is “Number of Bytes” long.
CRC: (2 bytes):
3.3.3 EXCEPTION RESPONSE, READ HOLDING REGISTER (0x03):
Slave Address: (1 byte): The address of the slave responding. Same as the address in the initiating command.
Exception Response: (1 byte): Code = 0x03 Echo from the initiating command plus high bit 0x80 = 0x83.
Exception Code: (1 byte): Defines the number of bytes followed minus the CRC. See Table 1 for explanation of
exceptions.
CRC: (2 bytes):
Slave
Address
Function
Code 0x03
Register
Address
(MSByte)
Register
Address
(LSByte)
Number of
Registers
(MSByte)
Number of
Registers
(LSByte)
CRC
(LSByte)
CRC
(MSByte)
Slave
Address
Success
echo:
Code
0x03
Number
of
Bytes
Data 1
Data
n
CRC
(LSByte)
CRC
(MSByte)
Data …
Slave
Address
Exception
0x03 + 0x80
Error: 0x83
Exception
Code
see list
CRC
(LSByte)
CRC
(MSByte)

Page 9 / 15 PV500-67 03/17
3.4 WRITE SINGLE REGISTER (0X06):
Command to write a value to a single register. Response will be the data written.
3.4.1 MASTER COMMAND TO WRITE SINGLE REGISTER (0x06):
Slave Address: (1 byte): Device address that receives the command. Range: 1-247.
Function Code: (1 byte): Code = 0x06 (Write single register).
Register Address: (2 bytes): The address of the register to be written to.
Data: (2 bytes): The data to write.
CRC: (2 bytes): CRC calculated for the frame data received and has to be used to verify the integrity of data received.
3.4.2 SUCCESSFUL RESPONSE FROM WRITE SINGLE REGISTER (0x06)
Slave Address: (1 byte): The address of the slave responding. Same as the address in the initiating command.
Function Code: (1 byte): Code = 0x06 Echo from the initiating command.
Register Address: (2 bytes): The address of the register that was written.
Data: (2 bytes): Byte data buffer, will contain the same data that was sent in initiating command.
CRC: (2 bytes):
3.4.3 EXCEPTION RESPONSE FROM WRITE SINGLE REGISTER (0x06):
Slave Address: (1 byte): The address of the slave responding. Same as the address in the initiating command.
Exception Response: (1 byte): Code = 0x06 Echo from the initiating command plus high bit 0x80 = 0x86.
Exception Code: (1 byte): Defines the number of bytes followed minus the CRC. See Table 1 for explanation of
exceptions.
CRC: (2 bytes):
Slave
Address
Function
Code 0x06
Register
Address
(MSByte)
Register
Address
(LSByte)
Data
(MSByte)
Data
(LSByte)
CRC
(LSByte)
CRC
(MSByte)
Slave
Address
Success:
Code 0x06
Register
Address
(MSByte)
Register
Address
(LSByte)
Data
(MSByte)
Data
(LSByte)
CRC
(LSByte)
CRC
(MSByte)
Slave
Address
Exception
0x06 + 0x80
Error: 0x86
Exception
Code
see list
CRC
(LSByte)
CRC
(MSByte)

Page 10 / 15 PV500-67 03/17
3.5 WRITE HOLDING REGISTERS (0x10):
Command to write 1-5 registers. Limit is 5 registers. Response will be the number of registers written.
3.5.1 MASTER COMMAND TO WRITE HOLDING REGISTER (0x10):
Slave Address: (1 byte): Device address that receives the command. Range: 1-247.
Function Code: (1 byte): Code = 0x10 (Write holding registers 1-5).
Register Address: The address of the first register to write to.
Number of Registers: (2 bytes): Defines the number of Elements (Registers) to write to. No more than 5 Elements
allowed for the XR10CX.
Num Byte: (1 byte): Defines the number of bytes followed minus the CRC. The number of bytes has to be double the
number of addressed Elements (Number of bytes = 2 x number of Registers).
Data (Num Byte or 2 X Number of Registers): Data to be written in MSByte, LSByte order.
CRC: (2 bytes): CRC calculated for the frame data received and has to be used to verify the integrity of data received.
3.5.2 SUCCESSFUL RESPONSE FROM WRITE HOLDING REGISTERS (0x10):
Slave Address: (1 byte): The address of the slave responding. Same as the address in the initiating command.
Function Code: (1 byte): Code = 0x10 Echo from the initiating command.
Register Address: (2 bytes): The address of the register that was written.
Number Registers: (2 bytes): The number of registers written.
CRC: (2 bytes):
3.5.3 EXCEPTION RESPONSE FROM WRITE HOLDING REGISTERS (0x10):
Slave Address: (1 byte): The address of the slave responding. Same as the address in the initiating command.
Exception Response: (1 byte): Code = 0x10 Echo from the initiating command plus high bit 0x80 = 0x90.
Exception Code: (1 byte): Defines the number of bytes followed minus the CRC. See Table 1 for explanation of
exceptions.
CRC: (2 bytes):
Slave
Address
Function
Code 0x10
Register
Address
(MSByte)
Register
Address
(LSByte)
Number
Registers
(MSByte)
Number
Registers
(LSByte)
CRC
(LSByte)
CRC
(MSByte)
Num
Byte
Data
Slave
Address
Function
Code
0x10
Register
Address
(MSByte)
Register
Address
(LSByte)
Number
Registers
(MSByte)
Number
Registers
(LSByte)
CRC
(LSByte)
CRC
(MSByte)
Slave
Address
Error, Code
0x10 + 0x80
Error: 0x90
Exception
Code, see list
CRC
(LSByte)
CRC
(MSByte)
