SPECIFICATION FOR DOMESTIC WATER HEATERS
Power Combustion, Gas-Fired Water Heaters with Polymer-Lined Storage Tanks
Furnish and install the following MAXIM gas water heater(s) as manufactured by PVI INDUSTRIES, INC of Fort Worth,
Texas.
Model Btu/h GPH Recovery Storage
Qty Number Input 40° to _____°F Tank Size
___ ____________ __________ ________ _______ gallons
___ ____________ __________ ________ _______ gallons
___ ____________ __________ ________ _______ gallons
Gas and Electrical Consumption
The water heater will operate at 83% thermal efficiency.
Each water heater will have a burner motor with the following maximum electrical ratings:
Heater Model Number Heater Btu/h Input Motor Horsepower Voltage Amps
______________ ___________ _____ _____ ____
______________ ___________ _____ _____ ____
______________ ___________ _____ _____ ____
To conserve energy, the water heater will not utilize a continuously operating, integral circulation pump between the
storage and heating section.
Pressure Vessel and Heating Surfaces
The water heater will be a vertical fire tube design that is constructed and stamped in accordance with Section IV,
Part HLW of the ASME code. Both the storage and heating sections of the water heater will be National Board
Registered for a working pressure of 150 psi and will be pressure tested at 1-1/2 times working pressure. For maximum
thermal strength, the fireside of the heating surfaces will be of boiler-grade steel. For corrosion protection, the waterside
of the heating tubes will be sealed in copper. The heating tubes will be rolled, beaded, and seal welded into the tube
sheets. The combustion side of the tube sheet will be insulated by a layer of ceramic fiber that will protect the tube sheet
from both thermal stresses and failure that can result from the accumulation of scale and precipitants.
Tank Lining
The lining will:
be applied only after the tank is completely fabricated and all welding is completed.
consist of multiple applications of high-temperature fluoropolymer.
be continuous and nonporous with no interruptions or discontinuities.
require no sacrificial anode rods for protection.
(continued)

PV 1010b 5/99 2
SPECIFICATION FOR DOMESTIC WATER HEATERS
Power Combustion, Gas-Fired Water Heaters with Polymer-Lined Storage Tanks
(continued)
Burner and Venting
Combustion will be provided by a forced-draft power burner with a gas train meeting the specifications of:
___ UL (standard equipment) ___ FM ___ IRI ___ Other ______________________
Water heater will be a category I, non-condensing appliance. It will be UL listed for use with non-pressurized, type B
venting material.
Safety Controls
As a minimum, the heater will be equipped with the following:
•electronic flame monitoring with pre-purge (140,000 to 399,000 Btu/h) or electronic flame safeguard with pre-
purge and flame status indicating lights (540,000 to 1,400,000 Btu/h)
•two immersion operating thermostats
•an immersion temperature limiting device
•an ASME- or AGA-rated temperature and pressure relief valve
•and options as selected on form PV 6141
Warranty Summary
The burner and all heater parts will have a one-year warranty. Storage tank will have a five-year warranty covering
manufacturing or material defects, and/or the production of rusty water. Tank and heating surfaces will have a non-
prorated, three-year warranty against failure due to scale buildup with no provisions for periodic cleaning for warranty
coverage. If indicated here, the heater will also have a _____ first year or ____ long-life service policy, which will cover
replacement labor and freight costs under certain conditions. This summary is not a warranty. Consult warranty and
policies for full details. Complete copies of all warranties and service policies, including all exclusions and
conditions, will be presented to the owner as part of the submittal package.
Finishing
The storage and heating sections will be completely factory packaged and plumbed, requiring only job site hookup to
utilities, venting, and potable water inlet and outlet. The heater will be insulated to meet current ASHRAE standards,
jacketed with powder-coated steel panels, and mounted on heavy-duty channel skids. The heater will fit properly in the
space provided and installation will conform to all local, state, and national codes.
Start Up
Start up on the unit will be performed by factory trained and authorized personnel. A copy of the start up report will
be provided to the owner.
(continued)

PV 1010b 5/99 3
SPECIFICATION FOR DOMESTIC WATER HEATERS
Power Combustion, Gas-Fired Water Heaters with Polymer-Lined Storage Tanks
(continued)
Quality Certification • Safety and Performance Standards
The water heaters will be manufactured by a company that has achieved certification to the ISO 9001 International
Quality System, which requires regular external auditing of all order entry, engineering design, and product
manufacturing processes.
The heater will be U.L. listed and ULC listed to safety standard UL 795 “Commercial – Industrial Gas Heating
Equipment” or AGA listed to ANSI Z21.10.3 “Gas Water Heaters.”
The heater will satisfy current Federal Energy Policy Act (EPACT) standards for both thermal efficiency and standby
heat losses as established for gas-fired water heaters incorporating storage tanks.
