PV 6112b 6/03 1
SPECIFICATION FOR DOMESTIC WATER HEATERS
Power Combustion, Oil-Fired Water Heaters with Nickel-Plated Storage Tanks
Furnish and install TURBOPOWER® oil water heater(s) as manufactured by PVI INDUSTRIES, INC
of Fort Worth, Texas. Supply quantities and model numbers as indicated on the plumbing schedule.
Efficiency
The water heater will operate at a minimum of 83% thermal efficiency. The water heater will comply with paragraph
7.2.4.4, the thermal efficiency, the standby loss, and all other requirements of ASHRAE 90.1-1999.
Pressure Vessel and Heating Surfaces
The water heater will be constructed and stamped in accordance with Section IV, Part HLW of the ASME code.
The storage section of the water heater will be National Board Registered for a working pressure of ____ 125 psi
(standard) or ____ 150 psi and will be pressure tested at 1-1/2 times working pressure. The heating section of the water
heater will be National Board Registered for a working pressure of 150 psi and will be pressure tested at 1-1/2 times
working pressure.
The heat exchanger will be a firetube design with the combustion chamber and all heating surfaces completely
water-backed. The fireside of the combustion chamber will be of boiler-grade steel. The waterside of the combustion
chamber will be non-ferrous. The fire tubes will be solid copper. The heating surfaces will be removable by unbolting
from the pressure vessel, allowing 100% access to waterside surfaces. The tank will be accessible in the field through a
manway sized opening, allowing access to 100% of interior surfaces. All tank connection fittings will be nonferrous and
removable from the tank.
Tank Lining
The tank will be a plated with electroless nickel (EN). Plating will occur after the pressure vessel is completely
fabricated and all welding is completed. The EN plating will be a high-phosphorus (10%) and nonporous composition
suitable for submersion service (ASTM B733 standard may be used as a guideline). For additional protection against
galvanic corrosion, which may occur within the potable water system, the electroless nickel plating may have a high-
dielectric-strength polymer overcoat.
The lined tank will not require sacrificial anode rods and none will be used. Water heaters that use anode rods in a
vessel that contains non-ferrous heating surfaces will not be acceptable.
Burner and Venting
Combustion will be provided by a forced-draft power burner with an oil train meeting the following agency
requirement for the input specified:
___ UL (standard) ___ FM ___ IRI ___ Other ______________________
Burner will be configured to accept ____ room air _____ direct inlet combustion air.
(continued)

PV 6112b 6/03 2
SPECIFICATION FOR DOMESTIC WATER HEATERS
Power Combustion, Oil-Fired Water Heaters with Nickel-Plated Storage Tanks
(continued)
Safety Controls
As a minimum, the heater will be equipped with the following:
•electronic flame monitoring with pre-purge (140,000 to 399,000 Btu/h burners) or electronic flame safeguard
with pre-purge and flame status indicating lights (600,000 to 3,200,000 Btu/h burners)
•two immersion operating thermostats
•an immersion temperature limiting device
•an ASME- or AGA-rated temperature and pressure relief valve
•and options as selected on form PV 6004
Warranty Summary
Storage tank: _____ year (10 standard, 20 optional) Covers manufacturing or material defects,
leaks and /or the production of rusty water. Tank coverage will include
failure due to scale buildup for ____ full years (5 standard, 8 optional) and
____ prorated years (5 standard, 12 optional) with no provision or condition
for maintenance or inspections and no limitations on water chemistry.
Heat exchanger
and combustion chamber: 5 year. Covers manufacturing or material defects, leaks, and/or the
production of rusty water.
Burner and all heater parts: 1 year
The heater will have a _____ first year or ____ long-life service policy, which will cover replacement labor and freight
costs under certain conditions. Initiation and /or continuation of warranty coverage will not be dependent upon annual
inspections, regular replacement of anode rods, or water chemistry. Complete copies of all warranties and service
policies, including all exclusions and conditions, will be presented to the owner as part of the submittal package. These
summaries are not warranties. Consult warranty and policies for full details.
Finishing
The storage and heating sections will be completely factory packaged and plumbed, requiring only job site hookup to
utilities, venting, and potable water inlet and outlet. The heater will be insulated to meet current ASHRAE standards,
jacketed with powder-coated steel panels, and mounted on heavy-duty channel skids. The heater will fit properly in the
space provided and installation will conform to all local, state, and national codes.
Start Up
Start up on the unit will be performed by factory trained and authorized personnel. A copy of the start up report will
be provided to the owner.
Quality Certification • Safety and Performance Standards
The heater will be have an independent test laboratory listing to safety standard UL 732. The water heaters will be
manufactured by a company that has achieved certification to the ISO 9001 International Quality System.
