PYLE Audio PLVS720 User manual

PLVS720
INSTRUCTION MANUAL
7 INCHWIDE SCREENTFT LCDMONITOR

1.Never attempt yourown maintenance.If somethingappears strange,
please turn themonitor off andconsult the dealeror the company.The
monitor is composedof many delicateelectronic components thatcan
be damaged orbroken if youopen the itor attempt tomodify it.
2.Do not exposethe device tohigh humidity,dust,steam,oilysmoke,
direct sunlight etc.
3.Do not usethinners or otherchemical cleaners.Wipe theit off with a
soft cloth ifit gets dirty.
4.Do not leavethe device inexcessively hot orcold places.
Permissible storage temperaturesare within therange of -25 to +60 .
Permissible operation temperaturesare within therange of 0 to +40 .
5.Only use specifiedadaptors and powersources.
6.For your safety,turn power offwhen not inuse and unplugthe adaptor.
7.Avoid droppingand strong impact.
Caution:For your safety,driver shouldn`t watchor operatethe controls
while driving.
Note thatwatching and operatingit whiledriving isprohibited by law
in somecountries.
Special caution:It doesn`tmean theTV isbroken withbright ordark
colour dotson theLCD,as itis sometimesinevitable.
Never connect thecar adaptor tocigarette lighters for
such as trucksor buses whichuse 24V DCpower.
Always be sureto use thefittings with themonitor, using
any otherAC adaptor orcar adaptor cancause damage
to TV.
If you donot use theit for along time,be sureto discon-
necting the caradaptor from thecigarette lighter orthe
AC adaptor fromthe wall outlet.
CAUTIONS
A)CAUTIONS
Thank you forthe purchase ofthis TFTmonitor. Beforeoperating the unit,
please read thismanual thoroughly andretain it forfuture reference.

B)FRONT PANEL
PANEL
IMAGE UP/DOWN
IMAGE LEFT/RIGHT
B)WIRING
RED:DC 12V
BLACK:GND
YELLOW:VIDEO INPUT
FUSE
SPECIFICATIONS
Screen size: 7inch
Display method: TFTActive matrix
System: PAL & NTSC
Aspect ratio: 16:9
Power input: 12VDC
Power consumption: About 7W
Pixel: 1440X234
Dimension: 23X13.5X2.7mm
Weight: 450g
Note:Although theeffective pixelsfor theliquid crystalis givenas 99.98%
or more,0.02%of pixelsmay notlight ormay lightincorrectly.Itis avery
common phenomenonin activematrix displaytechnology,donot indicate
fault orbroken ofthe unit.
Contents and specificationscan be subjectto change withoutprior notice.
The monitor willbe automatically onif there issignal input.
