Owner's Manual

Your new Pyle Pro PWMA Series Wireless Amplifier
system is designed to enable you to have high-
quality, full-range audio amplification where
AC power is unavailable.
Each of these systems incorporates an FM
receiver for receiving signal from the Pyle Pro
PWMA-MIC Wireless Microphone.
In addition, each PWMA-series system accepts
( PWMA-600 or PWMA-3600 ) wired microphone
inputs, They also accomodate other such audio
signal sources as tape players, CD players, VCR
audio outputs or radios,which can be used alone
or simultaneously with the microphones.
TABLE OF CONTENTS
i F eatures and controls, PWMA-600
1 Features and controls, PWMA-3600
1 Setting up for use with a wireless microphone
1 Using the amplifier with a wired microphone
1 Using the amplifier with an auxiliary input source
2 Recharging the batteries
2 A dding an additional speaker (PWMA-3600)
2 Sending the audio to another destination (PWMA-3600)
2 Using the wireless mic PWMA-MIC
2 Inserting/changing the wireless mic batteries
2 Turning on the wireless mic
3 Caring for your Pyle Pro amplifier
3 Replacing the fuse
3 S p e cifications
Please read this manual thoroughly before you attempt to set up and use the amplifier. It
contains a range of installation suggestions as well as instructions to ensure safe usage.
Installed properly, you can expect years of trouble-free service from this product.
<5>pyLI:
FEATURES AND CONTROLS,PWMA-600
FRONT PANEL
Battery Charging Indicator
- Low Battery Indicator
-"On Air” LED
- Power LED
- On/Off Switch
PWIU
A-600 P „
able vhf wireless p.a. amplifier
_) low bettery on air
(0SI5QE
j power
La
* ©
- Q n
— 1 ©
©
c
^ charge
©
0 0 0
min^^^max min^^^max
wireless mic aux
0 0 Ifr
treble bass
\vOLUI\ IE TONE
/
— Wired Mic Bass Level Control
Wired Mic Treble Level Control
- Aux Input Volume Control
— Wireless Mic Volume Control
- Wired Mic Volume Control
«5>pyLF
= PRO
PYLE PRO PWMA 600/3600 Amplifier Owner’s Manual

SET UP GUIDELINES
Setting up for use with a wireless microphone
Since this system features a rechargeable battery for power,
you will never need to plug in before use, except when the
battery requires recharging. Follow these instructions when
setting up.
1. Before turning on power, turn all volume controls to the
"O” position.
2. Check that the flexible rubber antenna provided is
attached to the BNC connector on the rear panel (front
panel of PWMA-3600). For best results, start with the
antenna pointing up.
3. Turn the wireless microphone ON. The Power LED on the
mic will be illuminated.
4. Push the power switch on the front panel of the amplifier
to the ON position. The Power LED on the amplifier
will be illuminated.
When the receiver in the amplifier is receiving signal
from the mic, the "On Air” LED on the amplifier will
be illuminated. If this does not occur, it is possible that
the batteries need replacing in the mic.
5. Move the microphone to the location that speaking will
occur, and have an assistant increase the amplifier's
wireless mic volume control as the situation demands.
6. Adjust the bass and treble controls as needed.
Using the amplifier with a wired microphone
Follow set up guidelines above , except plug the wired
microphone into the wired mic input jack. These amplifiers
feature combo mic input jacks which can accept either XLR-
type or 1 /A' input jacks.
The PWMA-3600 feature two such connectors. In the case
of the PWMA-3600 they are located on the front left panel.
The PWMA-600 has a single combo jack located on the real
panel.
Adjust the microphone volume(s) with the wired
microphone volume control(s). Please note that you can
adjust the level of the wired mics separately from the
wireless mic, giving you a great deal of performance
flexibility.
Using the amplifier with an auxiliary input source
You can use these systems to amplify audio signals from
any high level source such as tape players, CD players,
VCR audio outputs, etc. (An audio product which has a
volume control is usually a high level audio source.)
Use RCA-type patch cords to connect the audio outputs
from the audio source to the RCA input jacks on the rear
of the PWMA-600,or the left front panel of the PWMA-3600.
Please note that you can adjust the auxiliary volume
independent of the two microphones, which opens up a
range of performance opportunities.
FEATURES AND CONTROLS. PWMA-3600
Aux Input Volume Control
Wired Micl Volume Control
Wired Mic2 Volume Control
RCA type AUX OUT jacks
RCA type AUX IN jacks
1/4”/XLR Combo Jack
for WIRED MIC 1
1/4”/X!R Combo Jack
for WIRED MIC2
|_ BNC jack for
flexible antenna
— Wireless Mic Volume Control
— Bass Level Control
— Treble Level Control
"On Air” LED
|— Battery Charging Indicator
Power LED
- On/Off Switch
- Fuse holder (for 3A fuse)
- DC Adapter input jack
(17V/1.5A)
«S>pyLF
= PRO
1 - PYLE PRO PWMA 600/3600 Amplifier Owner's Manual

Recharging the batteries
PWMA-600 model features a low battery indicator on the
front panel which advises you of a low battery condition
before it is too late. The LED will begin to flash when a
low battery condition occurs.
PWMA-3600 model features a power indicator on the front
panel which advises you of a low battery condition before it
is too late. The LED will begin to flash when a low battery
condition occurs.
Be sure to plug in the AC adapter to recharge when this
occurs. Batteries recharge in about 4 hours, and usually
last up to 10 hours between charges. During charging,
the Charge LED will glow RED, and will turn GREEN when
charging is complete.
Adding an additional speaker (PWMA-3600)
You can attach an additional speaker or pair of speakers
to the rear of the PWMA-3600 to the terminals found on the
rear panel. Be sure the total impedance across the
terminals resulting from the addition of these speakers is
in the 4-16 Ohm range.
Sending the audio signal to another destination
The PWMA-3600 feature a pair of RCA style audio output
jacks, which enable you to take an audio signal fees out to
another device.
This might be used, for example, in a situation where a
person is performing outdoors where power is unavailable,
but you also want to bring a feed indoors to a secondary
or PA amplifier.
You can also record the audio from these jacks, which
may be appropriate for a special occasion or event. When
you do so, be sure to keep an eye on the recording levels
on your recorder to avoid overdriving!
USE AND CARE OF THE PWMA-MIC WIRELESS MICROPHONE
Inserting/changing the batteries
The PWMA MIC uses a single 9v battery, which will provide
about 8 hours of continuous usage, 12 hours if you use an
alkaline battery.
To access the battery to change it, hold the mic by the
grille in one hand, and unscrew the lower portion of the
body. You will be able to slide the grille section away
from the body, exposing a rectangular well which holds
the battery.
Noting the polarity, slide the battery into this well in the
direction shown by an arrow on the label. Note that the
battery should be oriented such that you insert the side
with the (+) terminal first.
When the battery is fully contained within the well, slide
closed the mic and screw the body firmly to the grille
module.
Turning on the PWMA-MIC microphone
At the base of the mic (where the antenna protrudes) is a
small Power switch with ON/OFF markings. To turn the mic
on, slide the switch to ON. The red LED adjacent to the
switch will be illuminated, indicating the mic is now on.
When you are done using the mic, be sure to turn it off to
conserve battery power.
INSERTING THE BATTERY,PWMA-MIC
ss> py le
= PRO
2 - PYLE PRO PWMA 600/3600 Amplifier Owner's Manual

Caring for your Pyle Pro Amplifier
Your Pyle Pro Amplifier is an example of superior design
and craftsmanship. The following suggestions will help
you care for your amplifier so you can enjoy years of use:
• Keep the amplifier dry. If it gets wet, wipe immediately.
• Use the amplifier only in well-ventilated installations.
• Handle the amplifier gently and carefully - do not drop!
• Keep the amplifier away from dust and dirt.
• Wipe occasionally with a damp cloth to keep it looking
new. Do not use harsh chemicals, solvents or
detergents!
Replacing the fuse
Your amplifier employs a fuse for protection from power
surges and short circuits. If the amplifier suddenly turns
off or will not turn on, check the fuse, and if necessary,
replace with the same kind and rating.You should also
check and correct for a short or overload condition.
Amplifier Specifications
PWMA600
PWMA3600
Operating frequency
210-216 MHz
228.10 MHz
Frequency response 50Hz - 15 KHz +/- 2 dB
100Hz- 15 KHz +/ ■ 3 dB
THD, @ 15 kHz
< 0.1%
<1%
Dynamic range 90 dB
90 dB
Output power SOW
10W
Speaker type 6.5” full-range speaker
8” full range/2.5” tweeter
Internal battery
12V 3A
6V; 4Ax 3
Recharge time/usable time
4 hrs/10 hrs
4 hrs/ 8 hrs
Weight, lbs (kg)
17.6 lbs (8)
30.5 lbs(13.85)
Dimensions, HxWxD, inches
11.6 x 7.9 x 6.2
23.8x10.2x13.4"
(mm)
(295x200x157)
(605x260x340)
Wireless Mic Specifications
PWMAMIC
RF Power Output
< 5 mW
Operating frequency
228.10 MHz
Max, acoustic pressure
136 dB spl
Power source 9v battery
Battery Life
6 hours (10 hr alkaline)
Weight, with battery, oz. (g) 8.8 (250g)
<d?3> py LE
^PRO
3 - PYLE PRO PWMA 600/3600 Amplifier Owner’s Manual
