Pyle PLRM40F User manual

AM/FM/MP3/USB/AUX Stereo Receiver, Single DIN,
30 Preset Memory Stations, LCD Display
with Remote Control (Black)
PLRM40F
MP3StereoReceiverPowerAmplifier

www.PyleUSA.com
2
INSTALLATION
Preparation
The preparation kit is necessary to mount the radio on the dashboard, this kit is
available at electronics stores and car audio specialists, check the installation kit
before using it to make sure it is the right one for your vehicle.
INSTALL THE DEVICE
1. Lift the left or right top corner of the plastic outer trim ring
then pull it out to remove it.
2. Insert the two bracket keys into the left and right side of
the chassis to separate the chassis from the housing.
3. Install the mounting knob on the board. Check the
opening size of the sliding panel to be mounted. If the
measurement is not large enough, carefully cut it until it
slips easily on the opening. Do not force the handle in the
opening so as not to bend it. Locate the series of dubbing
tabs above, below and all sides to be mounted. Completely
insert it to the opening of the board, bend the tabs as
4. Slide the stereo into the opening in the dash, ensuring that
the wires behind are tucked and not pinched.
5. Follow the wiring diagram carefully.
Verify you’ve connected them correctly.
CAUTION! Connect the unit to a 12 Volt power source
with adequate ground.
6. Now that your wires are all completed, attach the front
panel and turn ON the unit (the vehicle must be switched on). If the unit does not
work, check the calibration again until the problem is solved. With the new car
stereo secured into the bracket, all you need to do is plug the wiring harness back
into the stereo and put the assembly back into place.
7. Slide the stereo into the opening in the dash, ensuring that the wires behind are
tucked and not pinched. Sometimes this may take a few times when the vehicle
has a tight dash opening. Tuck the wires back into an opening behind the unit.
8. Install the plastic outer trim ring
9. Snap all the pieces of trim back into place over the stereo. Double check that all
screws and trim pieces are securely in place.Try out the new stereo. Turn the car
power on again and play around with the stereo and its settings to be sure
everything is in working order.

www.PyleUSA.com
3
PUSH-TO-TALK
• Allows you to access SIRI or GOOGLE voice via Wireless BT.
• Your phone must support SIRI or GOOGLE voice. Once connected to BT, your
phone will ask for access to your contact list.
• Now you are ready to use PUSH-TO-TALK. Press the PUSH-TO-TALK icon.
You are ready to talk. Call "(CONTACT NAME)" The system will call without
having to use your phone.
WIRING CONNECTIONS
CONTROL PANEL BUTTONS
16
3
20 5 6 7 8
11
4
113 14
9
17
10 18
15
19 2112
15A
Front RCA Output(Left) Front RCA Output(Right)
Rear RCA Output(Left)
Rear RCA Output(Right)
SWC
SUBWOOFER
Antenna Jack
SUBWOOFER
ANT:RADIO ANTENNA JACK
F-L:Front RCA Output(Left)
F-R:Front RCA Output(Right)
R-L:Rear RCA Output(Left)
R-R:Rear RCA Output(Right)
Power/speaker Connector
FUSE 15A
PRECAUTION
+12V DC
NEGATIVE
EARTH

www.PyleUSA.com
4
CONTROL PANEL BUTTONS
1. (Power)/Press the SRC button to switch between the button RADIO, BT
(Bluetooth®), USB with a USB device inserted), AUX-IN mode (input assistant).
2. SEL (select/menu) button and VOL (volume) knob
3. Back to the previous conguration point.
4. Short press button display clock in all mode. In USB mode, Short press
to select All info/Elapsed time/File info/Track info/clock operation.
Press and hold button for 3 sec (LCD show DISP OFF) turn o illumination
on panel and touch any button to turn on illumination, Press and hold
button for 3 sec (LCD show DISP ON) to retrieve illumination.
5. Folder up
6. Folder down
7. RPT (repeat), button 3 preset
8. RDM (random), button 4 preset
9. (pause/start), preset station 5 button
10. INT (intro), preset button 6 station
11. Press and hold BND button to activate SIRI. Short press BND
button to change band. Short press BND button to pick up/cut o
phone call.
12. (tune back, search back, crawl back, fast reverse)
13. (tune forward, search forward, crawl forward, fast forward)
14. IR remote control sensor
15. LCD screen
16. AS (automatic storage/preset station search, automatic search)
17. USB port
18. AUX IN (auxiliary input)
19. MIC hole (integrated microphone)
20. In power on mode, press the MUTE button to toggle mute ON or OFF.
21. RESET

www.PyleUSA.com
5
CONTROL PANEL BUTTONS
1. (Power)/Press the SRC button to switch between the button RADIO, BT
(Bluetooth®), USB with a USB device inserted), AUX-IN mode (input assistant).
2. SEL (select/menu) button and VOL (volume) knob
3. Back to the previous conguration point.
4. Short press button display clock in all mode. In USB mode, Short press
to select All info/Elapsed time/File info/Track info/clock operation.
Press and hold button for 3 sec (LCD show DISP OFF) turn o illumination
on panel and touch any button to turn on illumination, Press and hold
button for 3 sec (LCD show DISP ON) to retrieve illumination.
5. Folder up
6. Folder down
7. RPT (repeat), button 3 preset
8. RDM (random), button 4 preset
9. (pause/start), preset station 5 button
10. INT (intro), preset button 6 station
11. Press and hold BND button to activate SIRI. Short press BND
button to change band. Short press BND button to pick up/cut o
phone call.
12. (tune back, search back, crawl back, fast reverse)
13. (tune forward, search forward, crawl forward, fast forward)
14. IR remote control sensor
15. LCD screen
16. AS (automatic storage/preset station search, automatic search)
17. USB port
18. AUX IN (auxiliary input)
19. MIC hole (integrated microphone)
20. In power on mode, press the MUTE button to toggle mute ON or OFF.
21. RESET
GENERAL OPERATION
Turn Unit ON/OFF
• Press the power /Mode button on the front panel to turn ON the unit,
and press and hold it again to turn OFF the unit.
• Press the power button on the remote control to turn the unit ON or OFF.
Adjust Volume (VOL)
• Rotate the VOL knob on the front panel or press the VOL+ /VOL- button
on the remote control to increase or decrease the volume level.
FUNCTION
• Press the Volume knob and Rotate to select Audio/Display/Tuner/Clock/
Beep/Animation/Demo mode function. Press the Volume knob again to
Select desire function mode.
AUDIO MODE
• Press the Volume knob and Rotate to select Manual EQ/X-Bass/Preset EQ/
Loudness/Subwoofer set/Fader/Balance.
MANUAL EQ
• Press the Volume knob and Rotate to select 10 band frequencies level.
X-Bass
• Rotate to turn on/off.
PRESET EQ
• Press the Volume knob and Rotate to select user/Flat/Classic/Rock/Pop/
Jazz/Country.
LOUDNESS
• Press the Volume knob and Rotate to Switch ON/OFF.
SUBWOOFER SET
• Press the Volume knob and Rotate to Switch ON/OFF.

www.PyleUSA.com
6
GENERAL OPERATION
Turn Unit ON/OFF
• Press the power /Mode button on the front panel to turn ON the unit,
and press and hold it again to turn OFF the unit.
• Press the power button on the remote control to turn the unit ON or OFF.
Adjust Volume (VOL)
• Rotate the VOL knob on the front panel or press the VOL+ /VOL- button
on the remote control to increase or decrease the volume level.
FUNCTION
• Press the Volume knob and Rotate to select Audio/Display/Tuner/Clock/
Beep/Animation/Demo mode function. Press the Volume knob again to
Select desire function mode.
AUDIO MODE
• Press the Volume knob and Rotate to select Manual EQ/X-Bass/Preset EQ/
Loudness/Subwoofer set/Fader/Balance.
MANUAL EQ
• Press the Volume knob and Rotate to select 10 band frequencies level.
X-Bass
• Rotate to turn on/off.
PRESET EQ
• Press the Volume knob and Rotate to select user/Flat/Classic/Rock/Pop/
Jazz/Country.
LOUDNESS
• Press the Volume knob and Rotate to Switch ON/OFF.
SUBWOOFER SET
• Press the Volume knob and Rotate to Switch ON/OFF.
FADER
• Press the Volume knob and Rotate to select Fader position.
BALANCE
• Press the Volume knob and Rotate to select Balance position.
DISPLAY
• Press the Volume knob and Rotate to select Color Set/Version.
COLOR SET
• Press the Volume knob and Rotate to select Variable/Red/Pink/Purple/Blue/
Cyan/Green/Yellow/Orange.
VERSION
• Press the Volume button to check software version.
TUNER
• Press the Volume button to select Local Seek/Mono Set/Regional/RDS Set.
CLOCK
• Press the Volume knob and Rotate to select Clock Format/Clock adjust/
Date Format/Date Set.
BEEP
• Press the Volume button to rotate switch ON/OFF.
ANIMATION
• Press the Volume knob and Rotate to select ON/OFF and time interval of
animation time.
DEMO MODE
• Press the Volume button to rotate switch ON/OFF.

www.PyleUSA.com
7
FADER
• Press the Volume knob and Rotate to select Fader position.
BALANCE
• Press the Volume knob and Rotate to select Balance position.
DISPLAY
• Press the Volume knob and Rotate to select Color Set/Version.
COLOR SET
• Press the Volume knob and Rotate to select Variable/Red/Pink/Purple/Blue/
Cyan/Green/Yellow/Orange.
VERSION
• Press the Volume button to check software version.
TUNER
• Press the Volume button to select Local Seek/Mono Set/Regional/RDS Set.
CLOCK
• Press the Volume knob and Rotate to select Clock Format/Clock adjust/
Date Format/Date Set.
BEEP
• Press the Volume button to rotate switch ON/OFF.
ANIMATION
• Press the Volume knob and Rotate to select ON/OFF and time interval of
animation time.
DEMO MODE
• Press the Volume button to rotate switch ON/OFF.
GENERAL OPERATION
USB port
The USB port on this stereo device is designed for playing media from USB memory
devices.
Integrated Microphone
For voice reception when making a call using the hands-free system.
Auxiliary Input Connector
3.5mm auxiliary input stereo is designed for devices with line output 3.5 mm or
hearing aids.
Reset System
The RESET button is used to reset all factory settings parameters, this function can
be used when the LCD screen does not work properly or if the sound is distorted, or
when some of the controls are disable. Press the RELEASE button to release the
front panel and remove it, use a thin object with a small tip to press the RESET
button over 6 second.
RADIO OPERATION
Change Bands (BAND)
Press the BAND button to switch between the AM1, AM2, FM1, FM2, FM3 bands.
Each band stores up to six preset stations.
Manual Tuning ( / )
Press and hold the or button on the front panel or on the remote control to
enter manual tuning mode. In manual tuning mode, press the or button to
move the radio frequency number up or down one step.
Auto Seek Tuning ( / )
In standby mode or while not in manual tuning mode, quickly press the or
button to move to the next/previous available station automatically.
To Store/Recall Preset Stations
The radio can store 6 pre-set stations for each band (AM1, AM2, FM1, FM2 and FM3)
for a total of 30 preset stations.
Memorize a station:
• Turn the radio on and select the desired band and station.
• Select a station by or button.

www.PyleUSA.com
8
• Press and hold the desired preset button (numbered 1-6 on the face of the radio)
for more than 2 seconds to save the station to that preset number.
To recall a preset station
• Select the desired band.
•
station.
Automatic Store station/ Preset station scan (AMS)
Press and hold the AMS button for more than 2 seconds to select six strong stations
and store them in the current band. The radio will automatically scan the current
frequency and enter the six strongest stations into the preset memory positions for
AMS button on the remote control to recall each preset
station that saved in the memories in each band.
LOCAL/DX
In urban areas, most stations are strong enough and“LOCAL ON” mode should be
selected. Switch to LOCAL OFF mode to search for stations with weaker signals.
Press the LOC button on the remote control to choose local or distant reception
mode.
STEREO/MONO
FM station is received in stereo mode. However, if the signal is weak or reception is
not as good as you would like, switching to MONO mode usually improves the
overall sound quality. Press the ST button on the remote control to choose FM
STEREO or MONO
USB OPERATION
Insert USB
into the port, the songs will begin to play automatically.

www.PyleUSA.com
9
EJECT/USB
• To eject a USB device, press the button to stop playback, then remove the
USB device.
Play/Pause
Press the (play/pause) button to pause or resume playback
Next/Previous Track
• To play the next track, press the button.
• To play the previous track, press the button.
Fast Forward/Backward
• To fast forward, press and hold the button.
• To fast backward, press and hold the button.
Introduction Scan
the introduction scan, and play the current track.
Repeating the same track
Press the RPT button to repeat the current track, press again to stop repeat
playback and resume normal playback.
Playing all tracks in random
Press the RDM button to play all tracks in random order, press again to cancel this
function.
Track/Folder Navigation
• During a disc, USB mode, press the 5/-10 button to go backward 10 tracks. Press
the 6/+10 button to jump forward 10 tracks.
• During a MP3 disc, USB mode, press and hold the 5/-10 button to go back the
previous folder. Press and hold the 6/+10 button to go to the next folder.
You can repeat this function depending on the number and level of folders.
• These buttons have no this function if the USB device has no folders.
a.
appear on the display.
b.
c.
button.

www.PyleUSA.com
10
AUXILIARY INPUT OPERATION
This receiver is equipped with an external auxiliary input jack (3.5mm) on the front
panel which is compatible with audio output from an MP3 music player.
Plug such a player into the AUX IN jack with a 3.5mm stereo audio cable and press
the MODE button to switch to AUX input mode. “AUX IN” appears in the display.
Listen to music from an external device through the speaker.
Note: Adjust the volume of the external device to a comfortable level with the
receiver volume control.
WIRELESS BT STREAMING OPERATION
Pair and Connect
Prior to using the Wireless BT device as a hands-free system for a Wireless BT-
devices as follows:
1. In any mode, prior to pairing and connecting, the BT logo in the LCD indicating
that no device is connected. To begin pairing, enable BT mode on your mobile
phone.
PYLE” name will be
displayed.
3. Choose the “PYLE”from the device list to pair and connect with this
4. When pairing is complete, the mobile phone audio will automatically transfer to
the ship/car audio system whenever a call is made or received, or when the
mobile phone plays music.
Make a Call
• To make a call, dial the call directly from the paired mobile phone.
• To make a call with this Wireless BT hands free system:
a. When linking up the Wireless BT-enabled mobile phone to this BT hands-free
system, press the button to access the dial telephone number mode, then
press the “0~9”, * and # button on remote control to input the telephone
number, and the entered number will be shown on the LCD display.
b. If a number has been incorrectly inputted, press the button to delete it.
c. Press the button to make outgoing call.
Redial Last Dialed Number
• Press and hold the button on the control panel to redial the last dialed phone
number
