Pyle PLCMTR26 User manual



Pleasereadinstructionscarefullybeforeinstallationanduse.Installationshouldbeperformedbyaprofessionalinstaller.

Toensureyoursafety,thedrivershouldnotwatchvideosoroperatefeaturesonthemonitorwhiledriving.Thereareno
serviceablepartsinthisunit,donotdisassembleortrytorepairthisunit.Ifunitmalfunctionspleasereturntoyourvendor
orsendtoaPylerepairfacility.Pleaseobserveandobeythelocallawsandregulationswheninstallingtheunit.Upon
Installation,pleasemakesureastonottointerferewithanyofthevehicle'ssafetyfeatures,wiring,components,etc.

Connection
Connectthecamera’sthreadedlocking4‐pincableconnectorsintothefemalereceivingconnectionoftheincluded4‐pin
extensioncables.Theextensioncablesthenconnecttoyourcompatiblevideomonitorswith4‐pinreceivingconnectors.
Thethreadedlockingcableconnectorsofthecameraservetoprovidepowerandvideoforbothcameras.
(camera1‐channel1/camera2‐channel2)































PLCMTR26
DualWeatherproofRearviewBackupCamera,IRNightVision,Waterproof,CommercialGrade,DC12‐24VforBus,Truck,
Trailer,Van

2‐in‐1DualCameraHousingBracket
CMDWeatherproofRearviewCameraSystem
LEDLightswithIRNightVisionIllumination
IndependentLensAngleAdjustableCameras
IPMarineGradeIP‐68Rating,Water&FogResistance
VersatileMountingOptions
LowLuxLightPerformance
ImageSensor:ColorCMD
System:PAL/NTSCAutoSwitching
VideoOutput1.0Vpp‐75Ohm
EffectivePixels:580x540
Resolution:420Lines
LensAngle:170Degree
Min.Illumination:0.2Lux
AutoImageAdjustment
DesignedforCar/Truckusewith12‐24VoltSystems
Includes(2)50Foot(15Meter)ConnectionCable
4‐PinSystemConnectivityJacks















