Pyle PLDCP12 User manual

1
Model: PLDCP12
12F Hybrid Super Cap (carbon and electronic capacitor)
With Blue Digital DC Voltage and Amperage Display,
Blue LEDS In Front
Capacitance .................................……...... 12,000,000 micro farad (12 Farad)
Working Voltage ...............................…….….. 16DC
Surge Voltage .......................................……… 18DC
E.S.R. (Equivalent Series Resistance)------ 0.0015 ohm @120hz/ 25°C
Capacitance Tolerance------------------------ ± 10%
DETAILED FEATURES:
a) 3 digits hi-end blue light display DC voltage meter that can measure 0.1
DCV range.
b) 3 digits hi-end blue light display DC amperage meter that can measure 1
DCA range.
c) Reverse polarity PCB audible warning function. If the capacitor is
connected incorrectly by reversing the positive and negative wires during
the installation process the PCB will issue a 45 second noise to warn you.
d) Hi-end platinum plated 100% brass solid parts and chrome plated metal
cover
e) Blue flash LED line on the front side of HYBRID SUPER CAPACITOR.
The LED’s chase to power discharge.
f) Over voltage limit and low battery voltage limit warning. When the system
voltage peaks over 17.5 DCV or LESS than 10 DCV. The buzzer on the
PCB will issue an audible noise warning.
g) Multiple small capacitance capacitors linked to provide the lowest inner
E.S.R. and largest moment discharge power.
2
INSTALLATION AND MOUNTING:
You must first attach the mounting tabs to the capacitor before mounting it.
Use the supplied hardware shown in the picture to the right. Notice the small
mounting screw hole in the capacitor chassis.
CHARGING THE CAPACITOR AND WIRING:
The capacitor must be charged before connecting the Power and Ground
cables to the capacitor. Failure to charge the capacitor will result in a large
spark generated from the rapid inflow of current.

3
To Charge the capacitor:
1. Make Capacitor positive terminal connections with amplifier and
tighten the bolt. Do not over-tighten the bolts!
Caution: Stripped terminals are not covered under the capacitor’s warranty.
2. Connect the ground cable with battery, amplifier, then refer to the
attached drawing.
3. Place the supplied charging bulb or resistor between the positive
terminal of the capacitor and the battery’s positive terminal. Do this for
30 seconds or until the charging bulb goes out.
Caution: The charging bulb will get hot!
4. Immediately after the charging process, take out the charging bulb from
the connecting wire. And connect the positive cable of the battery
directly to the positive terminal on the capacitor.
DISCHARGING THE CAPACITOR:
WHEN YOU WANT TO MOVE THE CAPACITOR FROM ORIGINAL
INSTALLED CAR AUDIO SYSTEM, YOU MUST FIRST FOLLOW
DISCHARGING PROCESS AFTER TAKING OUT THE CAPACITOR
FROM THE CAR AUDIO SYSTEM.
To Discharge the capacitor: With battery power disconnected, place the light
bulb or resistor across the capacitor’s positive and negative terminals until
light goes out or for three minutes if using a resistor.
4
Multiple Capacitor Wiring Diagram:
LIMITED WARRANTY
One Year Warranty from the date of purchase.
WARNING!!
THIS POWER CAPACITOR MAY EXPLODE AND CAUSE SERIOUS INJURY IF
ABUSED OR CONNECTED IMPROPERLY. PLEASE REFER TO THE INSTRUCTIONS
CONTAINED IN THIS MANUAL FOR CORRECT MOUNTING,
CHARGING/DISCHARGING AND WIRING CONNECTION FOR THIS CAPAPCITOR
PRIOR TO INSTALLATION.
