Pyle PDIC53T User manual

PDIC53T
5.25’’In-Wall/In-Ceiling70VSpeaker
Flush Mount Low-Profile Speaker
with 70 Volt Transformer (300 Watt)

www.PyleUSA.com
1
PDIC53T SPL
PDIC53T IMP
Frequency Response
Frequency Response
7.95 (202mm)
”
6.42 (163mm)
”
Side View
2.91 (74mm)
”
3.35 (85mm)
”
100 1K 10K20 20K
50.0
90.0
80.0
70.0
60.0
120.0
110.0
100.0
20HZ 100 1K 10K 20K
2.0
30.0
20.0
10.0
www.PyleUSA.com

• Speaker Installation
2
Cutting
guide
1 2
3 4
5 6
www.PyleUSA.com

3
1. Position the cutting guide against the required speaker
placement and trace around.
2. Cut out the traced area using a pad saw or other suitable tool.
3. Take the speaker unit out of the packaging and remove the
grille. Connect the speaker wire to the appropriate “+” and “-”
connections (select the desired tapping for 70V device).
4. Locate the speaker unit into the cut-out, ensuring that the 4
rotating xing clamps stay turned inward.
5. Once located, turning the 4 xing screws clockwise will cause
the xing clamps to rotate outward and tighten onto the
mounting surface.
6. Push the speaker grille into place by applying
even pressure around the rim.
www.PyleUSA.com

4
PDIC53T
5.25’’ In-Wall / In-Ceiling 70V Speaker
Flush Mount Low-Prole Speaker
with 70 Volt Transformer (300 Watt)
Features:
• In-Wall / In-Ceiling Speaker System
• Built-in 70 Volt Transformer Tapping
• Flush Mount, Slim Low-Prole Design
• 2-Way Full Range Stereo Sound
• High-Impedance, Line-Matching Transformer
• Used for Amplier / PA Speaker Public Address Systems
• Mounts Flush on Walls or Ceilings
• 1/2'' High Compliance Dome Tweeter
• Poly Mica Cone with High-Sensitivity Foam Edge
• Cut-Out Size Template for Easy Installation
• Environmentally Friendly ABS Construction
• Used for Home, Oce & Business Applications
Technical Specs:
• Power Output: 300 Watt MAX
• Speaker Size: 5.25’’ -inches
• 70V Transformer Tapping at 20W/15W/10W/5W/2.5W
and 8OHM
• Impedance: 8 Ohm
• Frequency Response: 85Hz-20kHz
• Sensitivity: 87 dB
• Magnet: 15 oz.
• Cut-0ut Diameter: 6.42'' -inches
• Mounting Depth: 2.91'' -inches
• Total Speaker Size (Diameter x Depth):
7.95" x 3.35" -inches
• Sold as: 1
