Pyle PMNGSP1BK User manual

PortableWirelessBTStreamingSpeaker
IPX6 Waterproof Wireless Speaker
with TWS Function for Outdoor Play, Built-in Microphone
PMNGSP1BK

WIRELESS BT SPEAKER AND ACCESSORIES
A. Wireless BT Speaker
B. Charging Cable
C. 3.5mm AUX Cable
D. User Manual
www.PyleUSA.com2
D
B
C
A
USER MANUAL

BASIC FUNCTIONS
1. Power Button
2. Volume- (press and hold for previous song)
3. Play/Pause Call
4. Volume+ (press and hold for next song)
5. TWS connection (short press)
BT disconnection (press and hold)
EQ mode (quick press 2 times to choose
dierent 3 EQ modes: Standard/ Extra bass/
Outdoor. There will be a "BEEP” sound when
you change the EQ successfully.)
6. Blue: BT indicator light
Green: AUX indicator light
7. White: TWS indicator light
Red: Charging/power indicator light
www.PyleUSA.com 3
10
8
54321
6 7
9

8. Microphone
9. AUX audio input port
10. USB charging port
OPERATION GUIDE
1. Power on/o: Press and hold power button “ ”
for 2-3 seconds to power on/o.
2. Wireless BT Mode: It will enter to BT mode after
power on, and the blue indicator light will ash.
Then choose ”PYLEUSA” from devices list. You will
hear voice prompt once connected, and the blue
indicator light will stay on. Now you can start to
play your music. Press and hold " " for 2-3
seconds to disconnect BT connection.
www.PyleUSA.com4
PYLEUSA
My Device
Power Button
BT indicator light

3. Volume control: Short press“ ”to increase
volume, short press “ ” to decrease volume;
when the volume is increased to maximum you
will hear a “Beep” voice prompt.
• Previous/Next song control: Press and hold ” ”
for 2 seconds to play next song, press and hold
” ” for 2 seconds to play previous song on BT
mode.
• Operation on playing status: Short press ” ” to
pause playing, press again to start playing on BT
mode; Short press ” ” to mute, press again to
un-mute on Aux mode.
4. Handsfree Call: Using your mobile phone to call
when connected with PMNGSP1BK.
PMNGSP1BK will enter handfree call mode
automatically. When you have incoming call, short
press ” ”to pick up call/short press again to
hang up call/press and hold to reject call.
When you picking up a call, short press “ ” can
transfer the handsfree call to your mobile phone,
which can protect your privacy in time.
Press“ ” again, your phone call will become
handsfree call again.
www.PyleUSA.com 5

5. TWS connection: If you have two PMNGSP1BK,
power on both of them, they will enter to BT mode.
Short press each of their " " button, the white
TWS indicator light will ash. Then they will connect
with each other automatically. After successful
connection, both of their white indicator light will
stay on. The master PMNGSP1BKs blue indicator
light will keep ashing, the sub-master speaker’s
blue indicator light will stay lit. After the two
PMNGSP1BK successful connection with your
phone, both of them will play music at the same
time.
www.PyleUSA.com6
88888888888 Power Button
Play/ Pause Call
TWS
TWS indicator light
BT indicator light

Remark:
a. This function needs two PMNGSP1BK, and both
of them should be powered on and into BT mode.
b. Do not connect with other BT devices if you want
to make TWS connection.
6. AUX audio input: Put the 3.5mm audio cable into
AUX port of PMNGSP1BK, it will turn into AUX
mode automatically and the green indicator light
will be on. Connect the other side with your phone
or PC, then you can start to play music.
7. Charging
Important tips:
• Do not use non-certicated power adapter to
charge.
• Suggest to use output 5V/2A (or above 2A)
adapter to charge.
www.PyleUSA.com 7
BT indicator light

1. Please charge your PMNGSP1BK ASAP after your
heard low battery voice prompt.
2. The red indicator light will be on while charging
and will turn off when charging is nished.
8. Energy Saving: If your PMNGSP1BK does not
connect with any BT devices in 10 minutes on BT
mode, it will power o automatically. You need to
press and hold “ ” for 2-3 seconds to power on.
FUNCTIONS INDICATOR
www.PyleUSA.com8
BT indicator light

Power ON
• Blue indicator light will be ON when powered ON
and enters BT mode automatically. Blue indicator
light will ash quickly (on BT searching devices
status).
• Green indicator light will ON when connected by
3.5mm audio cabIe.
Wireless BT mode
• Blue indicator light be ON once connected
successfully.
• Blue indicator light keeps ashing if your BT
device is out of range or disconnected.
(on searching status)
AUX mode
Green indicator light will on when connected by
3.5mm audio cable.
TWS mode
• TWS indicator light will ash quickly when it is on
TWS mode.
• TWS indicator light stays ON once connected
successfully.
www.PyleUSA.com 9

Charging mode
Red indicator light will on while charging; red
indicator light will off when charging nished.
Low battery
Red indicator light will quick ash when battery
low.
Low battery power o
PCMPSB1BK will power o automatically when
battery is lower than 10% . You will hear a power
o voice prompt.
Technical Specs:
• Speaker Unit: 20W*2/4Ω
• Frequency Response: 70Hz-18KHz
• S/N Ratio: ≥70dB
• Built-in Rechargeable Battery Capacity: Li-ion
7200mAh
• Charging Time: 3~4 hours)
• Working Time: 7~8 hours 70% volume level
• Charging Current: 5V/2A
• Dimensions (L x W x H): 12.48’’x 6.38’’ x 3.94’’ -in.
www.PyleUSA.com10

www.PyleUSA.com 11
FREQUENTLY ASKED QUESTIONS
Q: What kind of charger should we use for the
speaker?
A: All common USB chargers can be used, while we
suggest the ones 5V/2A or above 2A.
Q: What if there’s noise or discontinuous sound
during playing?
A: The speaker can be normally used within 10m
under no obstruction environment.
If it is beyond 10m or with obstruction, there
might be noise or discontinuous sound.
Q: Why the speaker powers o automatically after
power on but no BT disconnection?
A: When there is no BT pairing in 10 minutes, the
speaker will shut down automatically to reduce
power consumption.
Q: Why does the speaker cannot connect the once-
paired cellphone?
A: First, remove the speaker's paired name from
the cellphone's BT List and then restart pairing.
Q: What is the working sequence of the speaker?
A: Default mode is BT mode but when inserted in
AUX in cabIe, it will be AUX IN mode.

Q: The speaker doesn't start up in a normal situation.
A: Please plug-in the charger and try in a few
minutes or try to press and hold power button
10-30s to reset.
Notes:
1. Before using this product, please read this
manual carefully and keep it for future reference.
2. For the rst use, please fully charge the product.
3. Use certied adapter that has passed national
safety certication.
4. If you will not use the product for a long time, be
sure to charge it once a month at least to maintain
its performance.
5. Do not use this product in an extremely cold or
hot environment, such as temperature beyond
the range of 41°F-95°F. If using it beyond the
above range, the product may stop automatically
to protect the internal circuit.
6. When charging in a high temperature environment,
the product may automatically stop charging to
protect the battery. At this time, the charging
indicator usually ashes quickly to indicate that
the charging environmental temperature or the
product internal temperature is too high.
7. Storage environment temperature:
-41~95°F RH <70% (recommended 77°F ±5).
www.PyleUSA.com12

www.PyleUSA.com 13
Important Safety Instructions:
1. Do not disassemble or repair this speaker
personally, otherwise it may cause damage or
personal injury.
2. Do not use it in dusty, humid, dry, and high-
temperature environment.
3. Do not place this product near heat source, or a
place with direct sunlight, a lot of dust, or
mechanical vibration.
4. In order to reduce the risk of re, please do not
cover this product with newspapers, table cloths,
curtains etc., during use.
5. If the product has a waterproo feature, DO NOT
exceed the nominal parameter range when using it.
6. When the product is damaged such as the power
cord or plug is damaged, liquid enters or objects fall
into the device, unable to operate normally or falls,
it must be repaired.
7. When the product is fully charged, DO NOT
connect it to the charger for further long time
charging.
8. The maximum ambient temperature should not
exceed 104°F.

Questions? Issues?
We are here to help!
Phone: [phone]
Email: [email protected]
