Pyle PPHP266B User manual

Wireless BT Speaker & Microphone System
PPHP266B - PPHP288B
Portable Stereo Karaoke Speaker with Wired Mic,
Built-in LED Party Lights, MP3/USB/
Micro SD Readers, FM Radio
6.5’’ Subwoofers, 500 Watt MAX 8.0’’ Subwoofers, 600 Watt MAX

www.PyleUSA.com
3
WARNING
Illegal operation may cause personal injury, which could be fatal and may cause
damage to property.
1. DO NOT place objects on top of the device, as objects may
scratch the device.
2. DO NOT expose the device to dirty or dusty environments.
3. DO NOT insert any foreign objects into the device.
4. DO NOT expose the device to strong magnetic or electrical eld.
5. DO NOT use the device in the rain
6. Please check with your Local Authority or retailer for proper
disposaI of electronic products.
7. DO NOT disassemble the device. Only a certied service
technician should perform repair.
8. The device has apertures to disperse heat. DO NOT block the
device ventilation, the device may become hot and malfunction
as a result.
CONTROL BOARD FUNCTIONS
1. DC 9V/1.5A input
2. Charge LED indicator
3. Power button
4. LED button
5. USB and MICRO SD jack could support Mp3
6. 3.5MM audio input jack
7. 6.5MM microphone input jack
8. 6.5MM guitar input jack
9. Music volume knob
10. Play/Pause on USB/MICRO SD mode, scan channel on FM mode
11. Last music on USB/MICRO SD mode, last channel on FM mode
12. Short press for choosing dierent input signal, press and hold for voice cancelling
function on USB/MICRO SD/BT MODE
13. Record function on USB/MICRO SD mode
14. Next music on USB/MICRO SD mode, next channel on FM mode
15. Short press for repeat song function, long press for microphone priority ON/OFF
16. Microphone volume control knob
17. Music treble control knob
18. Music bass control knob
19. Microphone echo control knob
20. Guitar volume control knob
www.PyleUSA.com
2
1
2
34
10
9
11
12
8
7
6
5
13
14 15
16
17 18 19 20

REMOTE CONTROL FUNCTIONS
1. Standby button
2. Choose input AUX/FM/BT/USB signal
3. Mute button
4. Play/Stop button on MP3 mode,
scan function on FM mode.
5. Next song on USB/Micro SD card,
next channel on FM mode.
6. Previous song on USB/Micro SD card,
last channel on FM mode
7. EQ eect on MP3 mode
8. Increase speaker volume
9. Choose song number directly
on MP3 mode
10. Stop button
11. Decrease music volume
12. Repeat song on USB/Micro SD memory card
TROUBLESHOOTING
PPHP266B - PPHP288B
Wireless BT Speaker & Microphone System
Portable Stereo Karaoke Speaker with Wired Mic, Built-in LED Party Lights,
MP3/USB/Micro SD Readers, FM Radio
Features:
• High-Powered PA Speaker System
• Portable Stereo Boombox Speaker Style
• Wireless BT Music Streaming Ability
• Includes Wired Microphone for Home Karaoke Fun
• Multi-Color Flashing LED Party Lights
• Built-in Rechargeable Battery
• Dual Subwoofer Speaker Tower Design
• Full Range Stereo Sound Reproduction
• Ported Subwoofer Enclosure for Extended Bass
• FM Radio with Digital LCD Display
• Top Panel Audio Control Center
• Unique Audio Recording Mode
• Connect & Stream Audio from External Devices
• MP3 Digital Audio File Playback
• Aux (3.5mm) Input Jack
www.PyleUSA.com
5
www.PyleUSA.com
4
10
1
1
4
7
9
6
11
2
3
5
8
12 MODEL PPHP266B PPHP288B
Power Output 500 Watt MAX 600 Watt MAX
Sound System 6.5’’ -in. Subwoofer
Speakers (x2)
8.0’’ -in. Subwoofer
Speakers (x2)
1’’Tweeter
Total Speaker Size
(L x W x H)
9.5’’ x 9.1’’ x 18.5’’
-inches
11.4’’ x 10.4’’ x 23.2’’
-inches
1. The audio format in the U disc is
incorrect.
2. Improper operation has caused
a process disorder.
3. USB disc is disconnected.
1. Convert audio format into Mp3
format.
2. Reboot the machine.
3. Insert USB disc properly.
MP3
does not
play
Fault Possible Cause Solution
No sound
Distortion
of sound
Karaoke
does not
work
1. No input sound source.
2. Volume is too low.
1. Volume too high.
2. Speaker may be damaged
1. Microphone plug is not fully
inserted.
2. Microphone switch is not on.
3. Microphone volume knob is at
the lowest position.
1. Use a better music signal.
2. Adjust volume.
1. Turn down the volume.
2. If speaker is damaged, repair
or replace it.
1. Plug microphone properly into
the socket.
2. Turn on microphone switch.
3. Adjust microphone volume
properly.

• USB Flash Memory Reader
• Micro SD Memory Card Reader
• (2) 1/4’’ -inch (6.5mm) Microphone/ Guitar Instrument Inputs
• Master Volume, Mic Volume, Treble, Bass Adjustable
• Battery Level Indicator Light
• Convenient Integrated Carry Handle
• Rugged & Durable Molded Cabinet Design
• Used for Public Gatherings, Crowd Control, Home Karaoke
• For Indoor / Outdoor Use
Wireless BT Streaming:
• Built-in BT for Wireless Music Streaming
• Simple & Hassle-Free Pairing
• Works with All of Today’s Latest Devices
• Smartphones, Tablets, Laptops, Computers, etc.
• Wireless BT Version: 5.0
• Wireless BT Network Name: ‘PYLEUSA’
• Wireless Range: Up to 32’ ft.
Audio Recording Mode:
• It's Easy: One Button Record Activation
• Record Audio as Streamed through the Speaker System
• Ability to Record Vocals via Microphone
• Recording Files save via USB Flash & Micro SD Ports
• Can Also Record FM & Wireless BT Streaming Audio
• Audio File Type Created: MP3
What's in the Box:
• PA Speaker System
• Wired Microphone
• Remote Control
• Power Adapter
Technical Specs:
• Speaker Style: Molded PA Speaker Cabinet
• Wired Mic Cable Length: 9.8’ ft.
• Impedance: 3 Ohm
• Frequency Response: 55-20kHz
• S/N Ratio: 60dB +/-3dB
• SPL: 94dB (1W/M)
• T.H.D.: <1%
• USB Interface Type: 2.0
• Digital Audio File Support: MP3
• Maximum USB/Micro SD Flash Support: Up to 32GB
• Mic Nominal Current Drain: <100mAh
• LED Light Power Control Switch: ON / OFF
• Construction Material: Engineered Polypropylene (PP)
• Battery Life: Up to 2 Hours (Charge Time Approx. 4Hours)
• PA Speaker Rechargeable Battery: 7.4V Li-ion, 1800mAh - 13.3Wh, 120g
• Battery Operated Remote: (1) x CR-2025 Button Cell, Included
• Power Cable Length: 3.6’ f.t
• Power Supply: 120/240V (9V Power Adapter)
www.PyleUSA.com
7
www.PyleUSA.com
6
Questions? Issues?
We are here to help!
Phone: [phone]
Email: suppor[email protected]om
This product can expose you to a chemical or group of checmicals, which may include
“Lead and lead compounds” which is known in the state of California to cause cancer, birth
defects, or other reproductive harm. For more info, go to https://www.p65warnings.ca.gov/.
