1 Product introduction
1.1 Product features
The lithium iron phosphate battery adopts the modular series design, through the reliable
BMS system and high-performance equalization technology, the whole system has the
characteristics of flexible configuration and high reliability. It is widely used in home
energy storage, power grid energy storage, photovoltaic energy storage, data room and
other applications requiring high-voltage platform batteries.
Voltage platform: 12V;
High C rate: the output power reaches sustained 1C;
High safety: lithium iron phosphate battery is safe and reliable;
High reliability: interactive cooperative guarantee mechanism is adopted to improve
system reliability;
Minimalist design: bolt design of positive and negative terminals with strong adaptability；
Battery status information display, SOC display；
Ultra-long cycle life: 3000 cycles；
1.2 Product appearance

2
1.3 Scope and purpose of application
This battery is mainly used for RV battery (replacing traditional lead-acid battery), 12V
battery application, electric car, yacht.etc
2 Product parameters
2.1Battery module technical parameters
Table 4 -Technical parameters of battery module
NO
Item
Value
1
Nominal capacity
100 Ah
2
Nominal voltage
12.8Vdc
3
Voltage range
DC 10V ~14.8V
4
Continuous charging current
DC 50A
5
Continuous discharging current
DC 100A
6
Working temperature
-20℃～50℃
7
Humidity
5～95%
8
Cooling
Natural cooling
9
Dimension
300mm*173mm*220mm
10
Weight
≤15kg
11
IP rate
IP20
12
Communication
Optional
13
Parallel Connection
Support
14
Reverse Connection function
Support

3
2.2 Panel definition
Battery switch:
Press the Power Button for “1S” and the battery will start up.
Long press the Power Button “3S” to turn off the battery.
Self-check lamp status：When the initial self-check is completed, all lights will be turn on
for a while and then return to the normal display state.
Please refer to the table below for normal display state：
State
Soc
Status
SOC
Remark
●★
Run
● ★
ALM
SOC4
SOC3
SOC2
SOC1
Turn off
All off
Idle
0%-25%
●
●
All SOC Light
is solid
26%-50%
●
●
51%-75%
●
●
●
76%-100
%
●
●
●
●
Charge
0%-25%
●
★
The SOC top
one is
flashing,others
are solid
26%-50%
★
●
51%-75%
★
●
●
76%-100
%
★
●
●
●
discharge
100%-76
%
★
●
●
●
●
The Run light
is flashing
75%-51%
●
●
●
50%-26%
●
●

4
25%-0%
●
Alarm
Alarm
★
According to Soc state
The protected
state can be
released upon
reaching the
recovery
condition
Protect
Protect
●
Hardware
damaged
Indicator light description:
●：Green light solid
★：Green light flashing (2S flashing)
★★：Green light flashing (4S flashing)
●：Red light solid
★：Red light flashing (2S flashing)
★★：Red light flashing (4S flashing)
2.3 System wiring
2.3.1 Parallel connection
Before wiring the battery model, Make sure all batteries are turned off .Follow the steps
shown below for wiring, with all positive poles together and all negative poles together.
Then press any battery’ Power button and the other batteries will turn on automatically.
Notice:
1、The number of parallel connections is limited to 8 pcs.
2、Ensure that the voltage difference between the batteries should not
exceed 0.5V before connection.

5
3、Each set of the battery external cables should have the same wire
diameter and length. This keeps the current flow of each battery
consistent during operation.
4、When 2~4 battery are connected in parallel, the charge-discharge current
shall not exceed 0.5C of the Total current.
2.3.2 Series Connection
Before wiring the battery model, Make sure all batteries are turned off .Follow the steps
shown below for wiring.Then press any battery’ Power button one by one.
Notice:
1、The number of series connections is limited to 2 pcs，24V.
2、Each battery should have the same capacity and the same voltage.
Otherwise it will affect subsequent use.If not, please first connect the battery
in parallel to internal balance and then use it in series.
3、If one battery goes into protective mode, the whole system will shutdown.
4、Each set of the battery external cables should have the same wire diameter
and length. This keeps the current flow of each battery consistent during
operation.

6
3 Installation Environment
Battery operating environment requirements are as follows:
Working temperature：0℃ - 50℃
Humidity：5% - 95%
Altitude：＜4000m
The site environment ： Away from heat, no corrosive gas, no explosive gas, no damaging gas, no
damaging insulation Conductive dust.
4 Transportation and storage requirements
4.1 Product transportation requirements
Battery in the process of transportation should prevent violent vibration, impact or
extrusion, to prevent the sun and rain, can use cars, trains, ships, aircraft and other
means of transportation.
In the process of loading and unloading, the battery should be handled gently to prevent
throwing, rolling and weight.
4.2 Product storage requirements
Batteries should be stored in clean, dry and ventilated rooms where the ambient
temperature is -20℃~ 60℃and the relative humidity is no more than 85%.
Battery should avoid contact with corrosive substances, should be far away from the
source of fire and heat.
Battery storage SOC: 40% ~ 50%.
Long-term storage: before storage, the SOC should be more than 80%, and the battery
should be recharged every six months.The charging amount should exceed 80% of the
capacity.
