Pyramid SIMPLE SMART TIMETRAX Sync User manual

Don’t Forget: Register your product online:
www.pyramidtimesystems.com/support/product-registration
TimeTrax™ Sync Clock System
Quick Start Guide
Copyright Information
© 2021 Pyramid, LLC. All rights reserved.
Reproduction, adaptation or translation without prior written permission is prohibited,
except as allowed under the copyright laws.
The information contained herein is subject to change without notice.
The only warranties for Pyramid are set forth in the express warranty statements
accompanying such products. Nothing herein should be construed as constituting an
additional warranty. Pyramid shall not be liable for technical or editorial errors
or omissions contained herein.

1pyramidtimesystems.com TABLE OF CONTENTS
TABLE OF CONTENTS
PRODUCT OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . 2
SYSTEM REQUIREMENTS . . . . . . . . . . . . . . . . . . . . . 2
TRANSMITTERS . . . . . . . . . . . . . . . . . . . . . . . . . 2
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . 4
PYRAMID WIRELESS RF TRANSMITTER PORTS . . . . . . . . . . . . 5
BELL TONE SYSTEM . . . . . . . . . . . . . . . . . . . . . . 5
SOFTWARE SET UP . . . . . . . . . . . . . . . . . . . . . . 6
NAVIGATE TO BELL SCHEDULE . . . . . . . . . . . . . . . . . . 7
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . 8
SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
ANALOG CLOCKS . . . . . . . . . . . . . . . . . . . . . . . . 10
DIGITAL CLOCKS . . . . . . . . . . . . . . . . . . . . . . . . 11
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . 12
WARRANTY & TECHNICAL SUPPORT . . . . . . . . . . . . . . . 13
TimeTrax™ Sync Clock System
Quick Start Guide

2 888.479.7264PRODUCT OVERVIEW & FEATURES
TimeTrax™ Sync Clock System
Quick Start Guide
The Pyramid Wireless RF Transmitter controls BCD signals via auxiliary ports:
TimeTrax Sync™ Clock System is an engineered modular time system
able to synchronize wired, wireless or Power over Ethernet (POE)
devices using TimeTrax Sync™ software.
Wireless Synchronized Clock System
The Pyramid Wireless RF Transmitter uses 902-928MHz frequency-hopping
technology to wirelessly transmit synchronization signals from designated time
source to the following devices:
PRODUCT OVERVIEW
Analog
Clocks
Digital
Clocks
Analog Wire
5200 Clock
(8)
DIG 4B/DIG 6B
Wired Clocks (8)
Bell/Tone
Systems
Designated
Network
Time
PC Time
GPS
(with GPS Signal
Receiver)
The wireless transmitters are able to pull time from the following sources:
NTP
A list of Internet NTP Primary Servers is available with TimeTrax Sync™ software
and updated periodically by Pyramid Time Systems.
SYSTEM REQUIREMENTS
Part# SASDLCWDXX
Operating Windows 10 and higher
PC x64 Pentium IV 2.0 GHz or greater
Memory Minimum 4GB of RAM, recommended 8GB or greater
Free Space 10GB or greater
Internet Chrome or Firefox
CD-ROM 4x or faster

3pyramidtimesystems.com TRANSMITTERS
TimeTrax™ Sync Clock System
Quick Start Guide
Approximate coverage
250,000 sq ft
1
NTP
GPS
TIME SOURCE
Wirelessly
transmits time signal
to clocks utilizing
902MHz-928MHz
frequency hopping
X2
O
TT Sync Wireless RF Transmitter captures main time source vias GPS, NTP or PC TIME
O
Transmitter utilizes frequency-hopping technology to broadcast precise time between
902MHz-928MHz (128 signaling channels) every 20 seconds), to an unlimited number of
clocks.
O
TT Sync software synchronizes PoE clocks & enables Pyramid transmitters to be
designated time source for TimeTrax™ Sync Clock & Tone Systems.
O
Wireless RF Secondary Transmitter(s) may be added for additional coverage
Dependent upon building Structure
PC TIME
TRANSMITTERS
Part# DESCRIPTION
9T1W1 Shelf Transmitter with Software
S9DWXSLAUB Wall Transmitter with Software
S9DSX0LAUB Shelf Secondary Transmitter Without Software
42337 Wall Secondary Transmitter Without Software

4 INSTALLATION 888.479.7264
WIRELESS RF TRANSMITTER INSTALLATION
Choose appropriate location to install 9T1W1 Wireless RF Transmitter.
Attach supplied antenna to top of 9T1WI Wireless RF Transmitter by rotating
in clockwise direction.¹
Place or mount transmitter so antenna is positioned vertically. This is re-
quired for optimum performance.Drill holes using template as a guide.
Connect Ethernet Port to computer or network. The transmitter will be
conrgurable from anywhere on local network.
If GPS Receiver is to be used as time source, install and connect to GPS port
of transmitter.
Connect power supply (supplied) to transmitter and to any standard wall
outlet.
TTSync software controls more than one Wireless RF Secondary Transmit-
ter (42337 and/or S9DSXOLAUB). TTSync software will discover the device &
assign global setting.
2
3
4
5
6
1
7
Locate within 50ft cable
reach
Multi-Story Facility
Locate centrally
Locate on middle floor
Contact customer support
@ 888.479.7264 ext 1
GPS Time Source
More than 250,000 sq ft
250,000 sq ft or less
250,000 SQ FT
250,000 SQ FT
¹ Using anything other than included Power Supply or included Antenna in a horizontal
orientation may be unsafe, cause improper operation, and violates FCC regulations.
Locate indoors
in dry location
Do not locate where
people regularly
come within 8in
TimeTrax™ Sync Clock System
Quick Start Guide

BELL/TONE SYSTEM 5pyramidtimesystems.com
Pyramid Wireless RF Transmitter Ports
CONNECT Power
POWER AUX GPS ETHERNET
CONNECT Tone
Supply (included) System, legacy
wired BCD clocks
CONNECT
or controllers
#42328 GPS
Receiver when
selecting GPS
CONNECT Ether-
Time Source
net port to PC or
network
back view
Horn/Bell/Tone System
Transmitter 5300
Single Bell
Ringer Bell Bell Horn
+
-
24v
Each Transmitter controls a dierent bell/tone system
TimeTrax™ Sync Clock System
Quick Start Guide
Horn/Bell/Tone System

6 SOFTWARE SET UP 888.479.7264
SET UP SOFTWARE
4
2
5
6
3
1
Install TimeTrax Sync™ Software into a networked computer or one that is
able to be directly connected to transmitter via ethernet
Installation should automatically run once the software is downloaded and you open
the le.The software will self-guide you through initial stages of installation.
After software is successfully installed, run program by double clicking
Pyramid icon on your desktop. The Pyramid TimeTrax™ Sync Login
Screen will appear. You are now ready to sign in.
Enter the following User Name and Password (password is case sensitive):
User Name: ADMIN Password: PTI
Click the LOGIN button. TimeTrax Sync™ security is independent of Windows
Security, therefore user accounts need to be created for all users.
For security purposes, users of TimeTrax Sync™ are required to Login
to use software every time. In addition, it is advisable to change the
password for ADMIN user account to prevent unauthorized use of the
software to manipulate transmitter conguration settings.
The software will automatically discover & list any Pyramid Ethernet
device on network.
“User Account Control”, press “YES”.
7
TimeTrax™ Sync Clock System
Quick Start Guide
Contact Pyramid Time Systems for software access via download at:
Phone: [phone] Ext. 267 or Ext. 802
Email: [email protected]
8
*Note
The rewall ports required are TCP Ports 3330, 3331, and 3333. The
direction of the rewall access is both inbound and outbound which is needed
for communication between clock to/from software.

7pyramidtimesystems.com SPECIFICATIONS
TIME ZONE; DAYLIGHT SAVINGS TIME; TIME SOURCE; REFRESH INTERVAL AT
GLOBAL SETTINGS
NTP Time Source (MAX 3);Time Zone & Daylight Savings Time will automatically
default to Eastern Standard Time. To change global settings, follow these
steps:
Click on Edit Global Setting Tab.Press enter to conrm.
Click on arrow in Time Zone window to access drop down menu.
Select Time Zone.
Select Time Zone for automatic Daylight Savings Settings.
Click “Time Source”: NTP/NTP SERVERS or PC TIME.
Click “Refresh Interval”; Hr, Min, Sec.
Click “Save & Close”.
3
4
1
To change settings for individuals devices, follow these steps.
Click “EDIT” on device from discovery list.
Click on Custom Settings button.
Click on - NTP / NTP SERVERS or
-”PC TIME” or
-”GPS” (only if installed for Transmitter)
Click “DEVICE NAME” - set new one
Select “TIME ZONE” & “DAYLIGHT SAVINGS TIME”
Click “SAVE & CLOSE”
4
2
3
1
CUSTOM TIME SOURCE SETTING FOR INDIVIDUAL DEVICE
2
7
5
6
TimeTrax™ Sync Clock System
Quick Start Guide
5
6
NAVIGATE TO BELL SCHEDULE
Open an App - click “CLOCK” (top right corner) - click “BELL SCHEDULE”
-”ADD BELL SCHEDULE” - “SAVE & CLOSE”
Click “EDIT” - “ADD BELL EVENT”
After each event set click “SAVE & CLOSE”
To upload Bell Schedule to Transmitter(s) click “SAVE BELL SCHEDULE” - “SELECT” (unit)
- “SAVE & CLOSE”
To go back to the list all clocks - click “CLOCK” again then click “HARDWARE MANAGER”
4
2
3
1
5
Transmitter(s) must be “ACTIVE”

8 SPECIFICATIONS 888.479.7264
ETHERNET AUX GPS : SPECIFICATIONS
TT SYNC WIRELESS RF TRANSMITTER : SPECIFICATIONS
ETHERNET PORT (STANDARD RJ45 FEMALE CONNECTOR):
Auto Speed 10/100TX Any 10 or 100Mbs, Switch or PC
Auto MDI/MDIX No Crossover cable is needed
Auto Discovery No IP address or DHCP server is required to discover trans-
mitter, direct connect
DHCP IP Address, Subnet Mask, Gateway
NTP Source List from TTSync Software; pull time from Internet or
Intranet
NTP Server RFC2030 compliant Time Server; serve time to Internet or
intranet
ETHERNET:
NOTE: ANY IP SETTINGS ABOVE CAN BE SET OR OVERRIDDEN BY TIMETRAX SYNC™ SOFTWARE.
OPTIONAL AUXILIARY PORT (RJ45 COMPATIBLE FEMALE CONNECTOR) :
BCD out/AUX -Sends BCD signals to TimeTrax™ analog & digital clocks
(wired)
-Sends BCD signals to Pyramid Tone Systems
OPTIONAL GPS PORT (RJ45 COMPATIBLE FEMALE CONNECTOR) :
IEC RS232 Compatible 4800 Baud I/O to receive NMEA time and 1 second edge sync
signals
GPS Signal Receiver Part #42328
RF Power Output 1 watt (30dBm)
Frequency Range 902-928MHz Frequency Hopping Technology
Channel Spacing ~200KHz
Modulation Raised Cosine 2FSK Modulation; 10KHz Maximum Deviation
Data Encrypted 2400 BPS
Frequency Stability 10ppm
Clock Time Update Every 20 seconds
NTP Time Update 6 Hr Default (can be set)
GPS Time Update Once per second
Coverage Approximately 250,000 sq ft
Shelf Size (WxHxD)
Weight
6.5in x 2.5in x 6.5in (16.5cm x 6.5cm x 160.5cm)
2.2lbs (1.0kg)
Wall Size (WxHxD)
Weight
Antenna Length 5in (12.7cm)
Required Voltage Universal 100-240VAC 50/60Hz
Weight 4.3lbs (1.95kg)
TimeTrax™ Sync Clock System
Quick Start Guide
5.5in x 5in x 1.75in (13.9cm x 12.7cm x 4.4cm)
1.6lbs (0.73kg)

9pyramidtimesystems.com SPECIFICATIONS
Storage Temp -30°C to 80°C, 22°F to 176°F
Operating Temp 0°C to 70° , 32°F to 158°F
Condensing 95% RH non-condensing
Do not place transmitter in close proximity of life support systems or critical
safety systems.
To limit RF exposure, this transmitter must be installed to provide a separation
distance of at least 8in (20cm) from all persons.
Do not touch the antenna connector on top of enclosure when transmitter is in
operation.
Use only provided power supply & antenna.
Install transmitter indoors in dry area.
ENVIRONMENTAL : INDOOR USE ONLY
EQUIPMENT PRECAUTIONS
SAFETY
Antenna should be connected and oriented vertically before power is applied.
Using anything other than provided antenna is prohibited by FCC regulations.
There are no serviceable or adjustable parts inside the case of transmitter.
Opening transmitter case voids all warranties.
Any modications to transmitter, antenna, or stated operating conditions violates
FCC regulations and may be detrimental to health or safety.
TimeTrax™ Sync Clock System
Quick Start Guide

10 ANALOG CLOCKS 888.479.7264
Complete Transmitter installation and/or software set-up prior to
clock installation
Choose appropriate location to install clock(s).
Wired clock(s) should be hardwired to standard electrical box by
qualied electrician.
Mount clock(s) using any of the following options:
(1) Direct Wall Mount: Mount to surface using template (included) &
(2) #8 screws. Insert screws into keyhole slots in back of clock.
(2) Security Mount: Using security bracket & template (included),
screw bracket directly to surface with (2) #8 screws. To hang
clock, align holes on back of clock with security bracket hooks.
(3) Dual Clock Wall or Ceiling Mount: Use optional brackets.
2
3
1
ANALOG CLOCKS
4
5
Locate indoors in dry location unless
using weather cover (see p.11)
CLOCK MOUNTING BRACKETS
42320 Dual Clock Wall Bracket Kit, 13in Analog, 4 x 6 Digital
42443 Dual Clock Ceiling Bracket Kit, Analog & Digital
Clock(s) will automatically synchronize upon completion of transmitter
and/or software set-up. Clock(s) must be within approximately 250,000 sq. ft.
range of transmitter. Transmitter is necessary to update RF Clocks.
The battery operated clock(s) search for updated signal once per day at 2am and
after battery installation.
TimeTrax™ Sync Clock System
Quick Start Guide

11pyramidtimesystems.com DIGITAL CLOCKS
DIGITAL CLOCKS
Complete Transmitter installation & software set-up prior to clock
installation.
Choose appropriate location to install clock(s).
Wired clock(s) should be hardwired to standard electrical box by
qualied electrician.
Mount clock(s) using any of the following options:
(1) Direct Wall Mount: Mount to surface using template (included) &
(2) #8 screws. Insert screws into keyhole slots in back of clock.
(2) Security Mount: Using security bracket & template (included),
screw bracket directly to surface with (2) #8 screws. To hang
clock, align holes on back of clock with security bracket hooks.
(3) Dual Clock Wall or Ceiling Mount: Use optional brackets
Locate indoors in dry location unless
using weather cover (see p.11)
2
3
1
4
5
Clock(s) will automatically synchronize upon completion of transmitter
& software set-up. Clock(s) must be within approximately
250,000 sq ft range of transmitter. Transmitter is necessary to update RF Clocks.
CLOCK MOUNTING BRACKETS
42247 Security Mounting Bracket Kit, Digital
42320 Dual Clock Wall Bracket Kit, 13in Analog, 4x6 Digital
42321 Dual Clock Wall Bracket Kit, 2.5x6 & 3x4 Digital
42443 Dual Clock Ceiling Bracket Kit, Analog & Digital
B
DIG clocks search for updated signal every 20 seconds.
The battery operated DIG clock(s) search for updated signal once per day at 2am
and after battery installation.
To set “Time Format” - Global or custom, click “Edit” then “Advanced”
AM/PM (PM = Dot left top corner), Military (24HR)
TimeTrax™ Sync Clock System
Quick Start Guide
A

ACCESSORIES12 888.479.7264
ACCESSORIES
PART# ITEM DESCRIPTION
42337 Wall, Secondary Transmitter (without software)
S9DSX0LAUB Shelf, Secondary Transmitter (without software)
42328 Receiver, GPS Signal
41269 BCD Extension Cable, 50ft
41314 BCD Extension Cable, 100ft
41313 BCD In-line Cable Coupler
43193-1 Wire Guard Kit, Chrome, 13in Analog
Wire Guard Kit, Chrome, 17in Analog
43193-3
Wire Guard Kit, Chrome, 4X6 Digital
Wire Guard Kit, Chrome, 4X4 Digital
Wire Guard Kit, Chrome, 2.5X6 & 3X4 Digital
42320 Dual Clock Wall Bracket Kit, 13in Analog, 4x6 Digital
42321 Dual Clock Wall Bracket Kit, 2.5x6, 3x4 & 4x4 Digital
42443 Dual Clock Ceiling Bracket Kit, 13in Analog & all Digital
42247 Security Mounting Bracket 13in & all Digital
42496 Weather Cover, Digital
42533 Weather Cover, 13in Analog
42429-1 Replacement Key, Security Mount (analog)
42281 Replacement Key, Security Mount (digital)
41361 Bell, 6in 24 Volt DC
41392 Bell, 8in 24 Volt DC
41362 Horn, 24 Volt DC
5300 Bell Ringer, Single Zone, 24 Volt DC
41449 Bell Wire, 100ft Spool
41450 Bell Wire, 250ft Spool
TimeTrax™ Sync Clock System
Quick Start Guide

WARRANTY & TECHNICAL SUPPORT 13pyramidtimesystems.com
WARRANTY & TECHNICAL SUPPORT
3-YEAR LIMITED WARRANTY
Pyramid warranties its Synchronized Clock Systems to the original user against
defective material or workmanship for a period of 3 years from date of purchase.
The manufacturer’s responsibility under this Warranty is limited to repair or
replacement of defective part or parts.
Pyramid reserves the right to determine whether parts failed because of defective
material, workmanship, or other causes.
Failure caused by accident, alteration, misuse or improper packaging of returned
unit is not covered by this Warranty.
Any repair to equipment other than by Pyramid voids the Warranty.
Users in territories other than USA, Canada, South America & Australia should
contact the Dealer from whom the unit was purchased.
The rights under this Warranty are limited to original user and may not be
transferred to subsequent users.
3
4
1
2
5
6
TECHNICAL SUPPORT CONTACT US:
Should you need to speak live to one of our
representatives, please call Toll-free
(US/Canada): 888.479.7264 ext 802 during
regular business hours: 8:30am—5:00pm EST,
Monday-Friday.
If Customer Service cannot troubleshoot your problem over the
phone, we will replace your unit free of charge if it is within
warranty period.
Please contact Customer Support at
888.479.7264 for details.
ACTIVATE YOUR 3 YEAR WARRANTY:
https://www.pyramidtimesystems.com/support/product-registration-synchronized-clocks
TimeTrax™ Sync Clock System
Quick Start Guide

WARRANTY & TECHNICAL SUPPORT 14 888.479.7264
pyramidtimesystems.com
© 2011 Pyramid Time Systems, LLC.
All Rights Reserved.
9T1WI
Pyramid™ TimeTrax Sync™ seamlessly synchronizes
clocks and tone systems to promote productivity,
reliability and eciency in the workplace
• Time Selection
12 or 24 hour time format
and multiple time zone
selection capability.
• Automatic Adjustment
Automatically adjusts for
Daylight Savings Time &
power outages.
• Scheduling
Schedule bell/tone systems
with the click of a mouse.
TimeTrax™ Sync Clock System
Quick Start Guide

ACCESSORIES 15pyramidtimesystems.com
TimeTrax™ Sync Clock System
Quick Start Guide
Resources:
For more information, visit pyramidtimesystems.com
for digital guide copies, support resources, and accessories.
*When printing o copies of user guides for templates, please open
in Adobe Acrobat and follow the following print options:
Size: Actual (Measure template for accuracy before using when
printing)
Booklet (If printing just the template page, make sure it is set to
actual size and not shrink to t)
Front & Back Print
User Guide
stamp
+
3500ss/ 3600ss/3700ss

16 SPECIFICATIONS 888.479.7264
I2227 Rev F
CONTACT US:
For more information, visit pyramidtimesystems.com
or call our technical support team at 888.479.7264
during regular business hours: 8:30am-5pm EST,
Monday-Friday.
Copyright © 2021 Pyramid Time Systems, LLC. All rights reserved.
TimeTrax™ Sync Clock System
Quick Start Guide
