PZP WD-210 Guide

The PZP Adjustable Charger, The best matching of charging voltage and charging current makes
every charger charge safe and easy.It is probably the most convenient charger that can fit your
different batteries.
The PZP is designed for charging all types of 12V lead-acid batteries, including the charging of the
called "wet" maintenance-free valve batteries (for uninterrupted power supplies), absorbable glass
fiber battery, batteries with calcium and silver polar plates, most gel batteries as well as batteries of
3-150A-h and 12Vrecommended to charge by AGM and EFB chargers.
About PZP
User Manual & Warranty
PZ.P WD-210
Step 6. After fully charged, the voltage will automatic become larger to your set value and the current will become smaller to near 0.
How To Use
10% of the battery capacity is very good for your batteries health, you can also adjust to 10A If you need to charge quickly.
Step 1. Verify the voltage and chemistry of the battery,Set the charging voltage by referring to the label on the charger
Step 2. Connect the clip to the battery (Confirm that you have connected the battery clamps or eyelet terminal connectors properly)
Step 3. Plug in power source (AC 120V), press the power button to “ON”(Confirm the AC power plug is plugged into an electrical outlet.)
Step 4. The Charge Green LEDs will illuminate (depending on the health of the battery) indicating the charging process has started.) The
charger can now be left connected to the battery at all times to provide maintenance charging.
Step 5. Turn the ammeter according to the battery capacity (10% of the battery capacity)

1. Before using the charger, read the battery manufacturer's specific precautions and recommended charge rates for the battery. Be sure
to refer to the battery owner's manual to determine the voltage, amperage and chemistry of the battery prior to charging.
2. Obey all signs and instructions. Do not operate product in any area with a potentially explosive atmosphere, including fueling areas or
areas which contain chemicals or particles such as grain, dust or metal powders. Do not use or store your product in areas with high
concentrations of dust or airborne materials. Store your product on flat; secure surfaces so it's not prone to fling.
3. Applied batteries. Do not charge the damaged batteries or batteries having frozen electrolyte, or batteriesnot matching the charger. For
example: Batteries with voltage of 6V and 24V.
4. Before connecting the charger to the power source, please ensure that the insulations of the housing, the power cord and the electric
wires connecting the battery are not damaged.In addition, it is required to ensure that the electric wires will not fall onto the hot surface
andsharp edges.
5. Prevent any liquids and small foreign matters falling into the charger housing and theelectric wires.
6. Do not use the charger in humid environment. Waterproof grade IP20.
7. Do not dismantle and repair the charger at will, and only professional personnel are allowedto dismantle and repair the charger.
8. This product is designed to work in ambient temperatures between -4° F and 104° F (-20° C and 40° C). Do not operate outside of
temperature ranges. Do not charge a frozen battery. Discontinue use of product immediately if the battery becomes excessively warm.
9. If the charger is not disconnected with the AC power source, do not connect or disconnectthe battery and the charger.
10. During battery charging, do not start the engine.
11. Electrolyte is corrosive substances. When connecting the battery to the charger ordisconnecting the battery from the charger, please
wear safety goggles. Please do not wearsynthetic clothes. If acid contacts the skin or eyes, please immediately wash the infectedparts by
running water, and if the burning sensation exists continuously, please seek formedical help.
12. Accessories may present a choking hazard to children. Do not leave children unattended with product or any accessory. The product
is not a toy. If the product is intended by “Purchaser” to be used by a minor, purchasing adult agrees to provide detailed instructions and
warnings to any minor prior to use. Failure to do so is the sole responsibility of the “Purchaser,” who agrees to indemnify PZP for any
unintended use or misuse by a minor.
Important Safety Precautions

EN
DANGER
READ AND UNDERSTAND ALL SAFETY INFORMATION BEFORE USING THIS PRODUCT. Failure to follow
these safety instructions may result in ELECTRICAL SHOCK, EXPLOSION, FIRE, which may result in a SERIOUS
INJURY, DEATH, or PROPERTY DAMAGE.
Electrical Shock. The product is an electrical device and may be subject to electric shock and cause serious injury.
Do not cut the power cords. Do not immerse in water or get wet. Waterproof rating IP20.
Explosion. Do not leave this product unattended while using it. Use this product only with batteries of the
recommended voltage. Unmonitored, incompatible or damaged batteries may explode when used with the
product. Use this product in a well-ventilated area.
Fire. The product is an electrical device that generates heat and may cause burns. Do not cover product. Don’t
block the ventilation hole. Do not smoke or use any source of electrical spark or fire when operating product. Keep
product away from combustible materials.
Eye Injury. Wear goggles when handling the product. Batteries may explode, causing splinters. Electrolytes are
corrosive substances and battery acid can cause eye and skin irritation. If eyes or skin are contaminated, flush
the affected area with clean running water and contact poison control center
immediately.
Explosive Gases. Working in the vicinity of a lead-acid is dangerous. Batteries generate explosive gases during
normal battery operation. To reduce the risk of battery explosion, follow all safety information instructions and
those issued by the battery manufacturer and the manufacturer of any
equipment intended for use near the battery. Review cautionary markings on these products and on engine.

Stage 1: Diagnostics
Checks the voltage to make sure connections are good and the battery is in a stable condition before beginning the charge process.
Step 2: Recovery
Initializes the Recovery process, if needed, for deeply discharged or sulfated (desulfation) batteries by pulsing small amounts of
current.
Step 3: Soft Start
Begins Bulk charging process with a gentle (soft) charge.
Step 4: Bulk
The Bulk charging process continues and returns 80% of the battery capacity. The voltage reaches the value set by the voltage
stabilizer(the amp gradually becomes lower).
Step 5: Absorption
Brings the charge level to 90%. The charger will deliver small amounts of current to provide a safe, efficient charge and limit gassing.
Step 6: Trickle
The battery is charged under the voltage specified by the voltage stabilizer. The battery is fully charged and ready to use. In this step,
the charger will only deliver enough current (less than ,or equal to 0.5A)as it is required. If more current is needed, the charger will
switch to Maintenance.
Step 7: Maintenance
Continuously monitors the voltage to determine if a maintenance charge should be initiated. If the terminal voltage falls below a
specific value, the charger will start the Maintenance cycle until voltage reaches the proper value and then discontinues the charge
cycle. The cycle between Trickle and Maintenance is repeated indefinitely to keep a full charge, without overcharging. The charger
can be left connected indefinitely.
7-Stage Charging
Steps range from just charging and float modes to 7 steps,automatically switch from one stage to another stage, which gives
the flexibility to more finely control the charging process, for added precision, safety and battery life.

Charging Times.
The estimated time to charge a battery is shown below. The size of the battery (Ah) and its depth of discharge (DOD) greatly aect its
charging time. The charge time is based on an average depth of discharge to a fully charged battery and is for reference purposes only
.Actual data may dier due to battery conditions. The time to charge a normally discharged battery is based on a 50% DOD. Temperatu
re will also impact charging times.
Charging Times
Understanding Charge Screen and LEDs.
When the Screen shows the battery capacity is about 0.5A, it means the battery is fully charged.
If the reading of the amperemeter declines too fast, it may be caused by the following factors,showing that the battery has to be
replaced or repaired;
-- The battery panel may be sulfated;
-- One or more battery packs in the battery are short-circuited.
In this case, it can be observedthat the electrolyte in the normal battery pack is boiling.We can try to recover the battery
capacity by several times of charging and discharging of thebattery on the automobile lights with a capacity of about 50Vm. It
had better to control andregulate the density of electrolyte (when the battery is in the charging state, the density ofelectrolyte in
winter is 1.29, and that in summer is 1.27).
If it is failed in the setting of the suggested charging current, the reason may be the polarplate is sulfated. In this case, it is
suggested to use a current with battery capacity of 0.03 specified in the ex-factory certificate to charge the battery.This model
promotes the absorption of sulphate, but obviously increases the charging time.
The red“Error" indicator light turning on means the following errors: Short circuit, polaritydamaged, overheating. If one of the
above errors happens, the charger will stop charging, and'after the fault is eliminated; it will automatically continue charging.

3 Year Hassle-Free Warranty
InputVoltageAC:
WorkingVoltage AC:
Network power consumption:
ChargingVoltage:
Charging Current:
AmbientTemperature:
Type of Batteries:
Battery Chemistries:
Battery Capacity:
Cooling:
Dimensions (L x W x H):
Weight:
110-120 VAC, 50-60Hz
110-120 VAC, 50-60Hz
Not exceeding 230W
11-17V
0-10A
-20°C to +40°C
12V
Wet, Gel, CA, EFB, AGM.
Up to 100Ah, Maintains All
Battery Natural Convection
7.0 x 6.8 x 3.9 Inches
2.29 Pounds
Technical Specifications
PZP warrants that this product (the “Product”) will be free from defects in material and workmanship for a period of Three (3) years from
the date of purchase (the “Warranty Period”). For defects reported during the Warranty Period, PZP will, at its discretion, and subject to
PZP’s technical support analysis, either repair or replace defective products. Replacement parts and products will be new or serviceably
used, comparable in function and performance to the original part and warranted for the remainder of the original Warranty Period.
This Warranty is made solely for the beneft of the original purchaser of the Product from PZP or from a PZP approved reseller or
distributor and is not assignable or transferable. To assert a warranty claim, the purchaser must: (1) request and obtain a return
merchandise authorization (“RMA”) number and return location information (the “Return Location”) from PZP Support by emailing
[e-mail] (2) send the Product, including RMA number, and receipt to the Return Location. DO NOT SEND IN
PRODUCT WITHOUT FIRST OBTAINING AN RMA FROM PZP SUPPORT.

The original purchaser is responsible (and must prepay) all packaging and transportation costs to ship products for warranty service.
NOT WITH STANDING THE ABOVE, THIS HASSLE-FREE WARRANTY IS VOID AND DOES NOT APPLY TO PRODUCTS THAT: (a)
are misused, mishandled, subjected to abuse or careless handling, accident, improperly stored, or operated under conditions of extreme
voltage, temperature, shock, or vibration beyond PZP’s recommendations for safe and eective use; (b) improperly installed, operated or
maintained; (c) are/were modified without the express written consent of PZP; (d) have been disassembled, altered or repaired by anyon
eother than PZP; (e) the defects of which were reported after the Warranty Period.
THIS HASSLE-FREE WARRANTY DOES NOT COVER:
(1) normal wear and tear; (2) cosmetic damage that does not aect functionality;
HASSLE-FREE WARRANTY CONDITIONS
These conditions apply only to Product during the Warranty Period. The Hassle-Free Warranty is void either by elapsed time from date of
purchase (elapsed time from serial number date, if no proof of purchase) or from the conditions listed earlier in this document. Return
Product with the appropriate documentation.
With Receipt:
0-3 Years: NO Charge. With proof of purchase, The warranty period begins on date of purchase.
With NO Receipt:
0-3 Years: NO Charge. With NO proof of purchase, The warranty period begins on the serial number date.
