Qcells Q.PEAK DUO-G5 series User manual

Valid for North America
Q.PEAK DUO-G5.X SOLAR MODULE SERIES
INSTALLATION AND
OPERATION MANUAL

2 3INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA
Document Revision 01
This Installation Manual is valid for North America as of July 1st 2017 for Q.PEAK DUO-G5.X and Q.PEAK DUO BLK-G5.X solar modules, and replaces all
earlier versions.
This manual is subject to change. The data sheets and customer information valid at the point in time when the relevant module was manufactured apply to the
installation, mounting, and maintenance procedures for the respective solar modules, as far as no updated document is provided.
With solar modules from Hanwha Q CELLS (hereafter referred to as
"Q CELLS") you can directly transform the sun’s limitless energy into
environmentally-friendly solar electricity.
In order to ensure the maximum performance of your Q CELLS solar
modules, please read the following instructions completely and care-
fully and observe all guidelines. Non-compliance may result in damage
and/or physical injury.
This installation manual provides instructions for the safe installa-
tion of crystalline solar modules.
ÄPlease read these instructions carefully before proceeding with
your installation.
ÄPlease retain these instructions for the life of the solar modules.
ÄPlease ensure that this installation manual is available to the
operator at all times.
Ä
This installation manual should be given to all subsequent owners
or users of the solar modules.
ÄAll supplements received from the manufacturer should be
included.
ÄPlease observe all other applicable documents.
ÄIf your questions are not satisfactorily answered in the
manual, please contact your system supplier.
Additional information can be found on our website
at www.q-cells.com.
Intended Use
This manual is valid in North America for Q CELLS solar modules.
These instructions contain information regarding the safe handling
and use of quality crystalline solar modules from Q CELLS and their
installation, mounting, wiring, and maintenance.
Symbols and Labels
The following symbols and labels are used throughout the
installation manual for ease of use.
SYMBOL DESCRIPTION
ÄProcedure with one or more steps.
• Lists of items
Ensure that when carrying out a pro-
cedure, you check the results of said
procedure.
Prohibited.
Beware of possible danger or damage.
Categories:
• Danger: Risk of fatal injury
• Attention: Risk of serious injury
or damage to property
• Note: Risk of damage to product
Units
Where both Imperial and U.S. units (for example inches) are shown,
metric units are denitive. References to “Data Sheet” or “Module
Data Sheet” refer to the Module Data Sheet applicable to the module
being used.
Safety Regulations
The installer and solar module operator are responsible for
compliance with all applicable statutory requirements and
regulations.
ÄThe following regulations and standards must be upheld at all
times during the installation, operation, and maintenance of the
solar modules:
• Installation and Operation Manual.
•
Other applicable documents (such as country-specic regulations
for pressure equipment, operational safety, hazardous goods,
and environmental protection).
• Regulations and requirements specic to the system.
• Applicable country-specic laws, regulations, and provisions
governing the planning, installation, and operation of solar
power systems and work on roofs.
•
Valid international, national, and regional regulations governing
work with direct current, especially those applicable to the
installation of electrical devices and systems, and regulations
issued by the respective energy provider governing the parallel
operation of solar power systems.
• Accident-prevention regulations.
Certied Personnel
Both, the operator and installer are responsible for ensuring
that the installation, maintenance, connection to the grid, and
dismantling are carried out by trained and qualied electricians
and engineers with approved training certicates (issued by a state
or federal organization) for the respective specialist trade.
Electrical work may only be performed by an ofcially certied
tradesperson in accordance with the applicable safety standards,
accident prevention regulations, and the regulations of the local
energy provider.
TABLE OF CONTENTS
1 INTRODUCTION 3
2 PLANNING 5
2.1 Technical specications 5
2.2 Requirements 6
2.3 Mounting options 7
2.4 Electrical layout 9
3 INSTALLATION 10
3.1 Safety and transport 10
3.2 Preparation of installation 12
3.3 Module installation 13
4 ELECTRICAL CONNECTION 14
4.1 Safety 14
4.2 Electrical installation safety 15
4.3 Connection of modules 16
4.4 After installation 17
5 GROUNDING 18
6 FAULTS AND DEFECTS 19
7 DISPOSAL 19
8 MAINTENANCE AND CLEANING 20
1 INTRODUCTION

4 5INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA
For the electrical data and additional information of the solar modules please refer to the respective currently valid data sheets available at
www.q-cells.com.
PRODUCT LINE Q.PEAK DUO-G5.X
Q.PEAK DUO BLK-G5.X
Cell type Q.ANTUM
Length [in (mm)] 66.3 (1685)
Width [in (mm)] 39.4 (1000)
Height [in (mm)] 1.26 (32)
Area [yd² (m²)] 2 (1.69)
Weight [lbs (kg)] 41.2 (18.7)
Max. system voltage VSYS [V] 1000
Max. series fuse rating [A] 20
Permissible operating
temperature range [°F (°C)]
–40 to +185 (–40 to +85)
Junction box protection class IP67 with bypass diode
Connector protection class IP68 and IP65
Fire protection class C, Type 1
Push load [Pa]15,400
Pull load [Pa]14,000
Certicates UL 1703; VDE Quality Tested; CE-compliant; IEC 61215 (Ed.2)1 see page 9 et sqq.;
IEC 61730 (Ed.1) Application Class A
1 ‘Test Load’ in accordance with IEC 61215 and ‘Design Load × 1.5’ in accordance with UL 1703
Validity
These instructions are only valid for crystalline solar modules from
Q CELLS as specied at chapter „2.1 Technical specications“.
Q CELLS assumes no liability for damage resulting from failure to
observe these instructions.
ÄPlease observe the wiring and dimensioning of the system.
ÄThe installer of the system is responsible for compliance with all
necessary safety regulations during set-up and installation.
Q CELLS assumes no liability on the basis of these instructions.
Q CELLS is only liable in the context of contractual agreements or
in the context of accepted guarantees. Q CELLS accepts no other
responsibility for the functionality and safety of the modules.
Ä
Please observe the instructions for any other system components
that may be part of the complete solar power system. It may be
necessary to carry out a structural analysis for the entire project.
ÄIf your questions are not satisfactorily answered in the manual,
please contact your system supplier.
Additional information can be found on our website at:
www.q-cells.com.
Information for the Operator
ÄPlease keep this manual for the entire life of the solar power
system.
ÄPlease contact your system supplier for information concerning
the formal requirements for solar power systems.
Ä
Please be sure to contact the relevant local authorities and energy
providers regarding regulations and permit requirements prior
to installation of the solar power system. Your nancial success
depends on the fulllment of these requirements.
Other applicable documents
This installation manual is only valid in combination with the
following technical information.
DOCUMENT TYPE
Product data sheet
Packaging and transport information
MISUSE OR INCORRECT USE OF SOLAR MODULES VOIDS THE
LIMITED WARRANTY AND MAY CREATE A SAFETY HAZARD
AND RISK PROPERTY DAMAGE. THIS INCLUDES IMPROPER
INSTALLATION OR CONFIGURATION, IMPROPER MAINTENANCE,
UNINTENDED USE, AND UNAUTHORIZED MODIFICATION.
1 INTRODUCTION 2.1 Technical specifications
2 PLANNING
Fig. 1: External dimensions (in inch (mm)) and components for Q.PEAK DUO-G5.X, Q.PEAK DUO BLK-G5.X,
NA
DETAIL A 0.630" (16mm)
0.335" (8.5mm)
0.965" (24.5mm)
38.58" (980mm)
66.3" (1685mm)
4 × Mounting slots (DETAIL A)
Frame
39.4" (1000mm)
37.44" (951mm)
1.26" (32mm)
8 × Drainage holes
13.9“ (352.5mm)
6 × Grounding points ø 0.177" (4,5mm)
≥ 43.3“ (≥ 1100 mm)
≥ 43.3“ (≥ 1100 mm)

6 7INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA
Installation Site
Please note the following guidelines that apply to the installation
site:
• The modules have been tested according to UL 1703 and IEC
61215.
• Solar modules are not explosion-proof and are not suitable for
use in explosive environments.
ÄDo not operate solar modules near highly ammable gas and
vapors (e.g. gas tanks, gas stations).
ÄDo not install modules in enclosed space.
Ä
Do not install modules in locations where they may be submerged
in water.
ÄDo not use modules as a substitute for the normal roong
(e.g. modules are not watertight).
ÄDo not install modules in close proximity to air conditioning
systems.
ÄDo not install modules above 13120 ft (4000 m) altitude above
sea level.
ÄDo not allow any chemical substance (e.g. oil, solvent etc.) to
come into contact with any part of the panel. Only substances,
which are released by Q CELLS, are allowed to be used during
installation, operation and maintenance.
• In locations with increased salt content in the air (e.g. close to
the sea) special precautions must be taken (See “Grounding”
page 18 and “Maintenance” page 19).
Prevention of Shadowing Effects
Optimalsolar irradiation leads to maximum energy output:
ÄFor this reason, install the modules so that they face the sun.
Ä
Avoid shadowing (due to objects such as buildings, chimneys or trees).
Ä Avoid partial shading (for example through overhead lines, dirt, snow).
Limitations
The solar modules are designed for the following applications:
• Operating temperatures from –40 °F to +185 °F.
•
Pull loads and push loads according to chapter 2.3 (‘Test Load’ in
accordance with IEC 61215 and ‘Design Load ×1.5’ in accordance
with UL 1703).
• Installation using a mounting frame for solar modules.
• For locations close to the coast with constant salt water spray or
where crystalline salt will form, modules must be functionally
grounded (“Grounding“, page 18).
Mounting Structure Requirements
Requirements for the mounting frame:
• Conform to the necessary structural requirements.
• Compliant with local snow and wind loads.
• Properly fastened to the ground, the roof, or the façade.
•
Forces acting on the module are relayed to the mounting substructure.
• Ensures sufcient rear ventilation of the module.
• Guarantees long-term stability.
• Avoid of different metals to prevent contact corrosion.
•
Allows for stress-free expansion and contraction due to temperature
uctuations.
ÄEnsure that no mechanical stresses (e.g., caused by vibrations,
twisting, or expansion) applied to on the module.
ÄEnsure that the clamps and the mounting frame are compatible.
Clamp System Requirements
Use customary clamps that satisfy the following requirements:
• Clamp width: ≥1.57 in (40 mm).
• Clamp height compliant with a 1.26 in (32 mm) frame height.
• Clamp depth: 0.28-0.47 in (7-12 mm).
• Clamps are not in contact with the front glass.
• Clamps do not deform the frame.
•
Clamps that satisfy the structural requirements of the installation site.
• Long-term stable clamps that securely afx the module to the
mounting frame.
Module Orientation Requirements
• Vertical or horizontal installation is permitted.
• Installation with a junction box at the bottom is permitted for
modules with junction boxes classied as IP67.
ÄEnsure that rain and melting snow can run off freely. No water
accumulation.
ÄEnsure that the drainage holes in the frame are not covered. No
sealing.
2.2 Requirements
2 PLANNING 2.3 Mounting options
2 PLANNING
Fig. 2: Installation options for crystalline Q CELLS modules. All dimensions are given in inch (mm in brackets).
Also observe the maximum test loads and clamping range as specied on the following page.
The illustrated installation options apply for both horizontal and vertical module orientation.
Module Clamp Subconstruction Mounting prole
75°
3°
ÄMaintain the permissible angle of inclination.
• Minimum angle of inclination: 3°
• Inclination angles above 75° may be limited
by local regulations
Ä≥20°: self-cleaning effect
ÄFollow the directions for installation angles < 5°
(“Grounding”, page 18)
TYPE OF
INSTALLATION
MODULE POINT MOUNTING SYSTEM LINEAR MOUNTING SYSTEM
INSTALLATION
WITH CLAMPS
Q.PEAK DUO-G5.X
Q.PEAK DUO BLK-G5.X
HYBRID
CLAMPING
Q.PEAK DUO-G5.X
Q.PEAK DUO BLK-G5.X
INSTALLATION
ON MOUNTING
POINTS*
Q.PEAK DUO-G5.X
Q.PEAK DUO BLK-G5.X
INSTALLATION
WITH INSERTION
PROFILES
Q.PEAK DUO-G5.X
Q.PEAK DUO BLK-G5.X NOT PERMITTED
NA
13.58
(345)
10.79
(274)
FB2
4 × mounting
slots
4 × mounting
slots
FB2
4 x mounting
slots
4 x mounting
slots
FB1
NA
13.58
(345)
10.79
(274)
FB1
CL3 CL4
0 - 11.81
(0 - 300)
0 - 11.81
(0 - 300)
9.84 - 17.72
(250 - 450)
5.91 - 13.78
(150 - 350)
CL3 CL4
CL1
9.84 - 17.72
(250 - 450)
5.91 - 13.78
(150 - 350)
CL1
11.81 - 15.75
300 - 400
NA
0 - 9.84
(0 - 250)
CL5
CL2
CL2
0 - 9.84
(0 - 250)
0 - 9.84
(0 - 250)
IP1 IP2
IP1 IP2
IP1 IP2
IP1 IP2

8 9INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA
2 PLANNING 2.3 Mounting options
Module Selection
For detailed key electrical data, please refer to the product data
sheet for the respective product.
ÄFor maximum energy yields, mismatches of specied electric
current (I
MPP
) of more than 5 % should be avoided for all modules
connected in series.
Safety Factor
During normal operation, a module may generate a greater current
and / or higher voltage than that determined under standardized test
conditions. Accordingly, the values of ISC and VOC marked on the
module should be multiplied by a facot of 1.25 when determining:
• the component voltage ratings,
• conductor ampacities,
• fuse sizes,
• size of controls connected to the PV output.
Refer to Section 690-8 of the National Electrical Code for an
additional multiplying factor of 125 percent (80 percent derating)
which might be applicable.
ÄPlease follow the valid national guidelines for the installation
of electrical systems (refer to section 690-8 of the NEC for an
additional multiplying factor of 125 percent [80 percent derating]
which may be applicable).
Series Connection
Connection of modules in series is only permitted up to the
maximum system voltage as listed in the applicable data sheet.
Ä
Take into account all possible operating situations and all relevant
technical norms and regulations when designing the system.
This will ensure that the maximum system voltage, including all
necessary safety margins, is not exceeded.
Ä
Take the voltage limit of the inverter into account when determining
the maximum number of modules in the string.
Parallel Connection
Modules may be damaged by the occurrence of reverse currents
(caused by module defects, ground leaks, or defective insulation).
Ä
Ensure that the maximum reverse current load capacity indicated
in the data sheet is met.
In order to limit reverse currents that may occur, we recommend
using the following safety options:
1) Layout with a limited number of parallel connected strings:
Without undertaking further current blocking measures, a maximum
of two module strings may be operated in parallel on a single
inverter or MPP tracker.
2) Layout with string fuses:
Place fuses for each string of modules at the plus and minus ends.
Observe the maximum permitted number of strings as indicated
in the specications provided by the respective string fuse manu-
facturer and the technical guidelines.
NOTE!
When installing different product versions, the lowest minimum
permitted reverse current load capacity applies.
Inverters
Inverters with or without transformers may be used.
2.4 Electrical layout
2 PLANNING
Specications
MODULE TYPE MOUNTING
OPTION POSITION OF CLAMPS* [IN (MM)]
TEST LOAD
PUSH/PULL**
[PA]
DESIGN LOAD
PUSH/PULL**
[PA]
SAFETY
FACTOR
Q.PEAK DUO-G5.X
Q.PEAK DUO BLK-G5.X CL1 / CL3 9.84 - 17.72 (250 - 450)
5400/4000 3600/2670
1.5
FB1 / FB2 13.58 (345)
IP1 -
CL1 0 - 9.84 (0 - 250)
17.72 - 21.65 (450 - 550)
2400/2400 1600/1600CL2 0 - 9.84 (0 - 250)
CL4 0- 11.81 (0 - 300)
CL5 short side: 0 - 9.84 (0 - 250)
long side: 11.81 - 15.75 (300 - 400) 4000/4000 2670/2670
MODULE TYPE MOUNTING
OPTION POSITION OF CLAMPS* [IN (MM)]
TEST LOAD
PUSH/PULL***
[PA]
DESIGN LOAD
PUSH/PULL***
[PA]
SAFETY
FACTOR
Q.PEAK DUO-G5.X
Q.PEAK DUO BLK-G5.X IP2 - 2400/2200 1600/1470 1.5
*
**
***
Distance between outer edge of module and middle of the clamp.
Loads according to IEC 61215-2:2016 and UL 1703.
Test sequence according to IEC 61215-2:2016.
ATTENTION
ÄThe loads in the table are related to the mechanical stability of the solar modules. The mechanical stability of the mounting system
including clamps has to be evaluated by the system supplier. The system installer is responsible for the determination of location-
specic load requirements.
ÄEnsure, that the subconstruction does not touch the junction box (even under load).
ÄEnsure, that the connection cables of the junction box do not run between laminate and mounting rails.
ÄEnsure, minimum support depth of 15 mm on the back side of the module for IP2, CL2 and CL4. Ensure minimum support depth
of 10 mm on the front side of the module for IP2.
ÄModule bend under loads. Therefore, sharp objects (e.g. screws) must not be mounted near the module backside.
ÄUse M8 corrosion-proof screws and washers (diameter ≥15.8 mm or ≥0.62 in) for FB1 and FB2 mounting.

10 11INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA
ÄInspect the packaging for damages.
ÄContact the transport company regarding any
damage to the packaging and follow their
instructions.
ÄFollow any instructions on the packaging.
ÄEnsure that all personnel are aware of and adhere
to accident-prevention and safety regulations.
ÄWhile working wear clean gloves.
§
GB
§
I
§
D
WARNING! Fire Risk!
ÄDo not install modules indoors.
ÄDo not install modules on moving objects.
DANGER! Risk of fatal injury due to electric shock!
ÄCover the modules with an opaque material during
installation.
ÄLeave modules in their original packaging until
installation.
ÄStore the modules securely in cool and dry rooms.
The packaging is not weatherproof.
DANGER! Risk of fatal injury due to electric shock!
ÄDo not install damaged modules.
ÄInform your vendor of any damages
immediately.
3.1 Safety and transport
3 INSTALLATION
NOTE! Module damage may occur!
ÄDo not drop modules.
NOTE! Module damage may occur!
ÄOnly make modications to the module which have
been conrmed in writing by Q CELLS.
confirmation
letter
NOTE! Module damage may occur!
ÄDo not stack modules.
NOTE! Module damage may occur!
ÄDo not install modules near ammable
gas / vapors.
ÄDo not install modules in close proximity to air
conditioning systems.
NOTE! Module damage may occur!
ÄNever lift or move the module with the connection
cables or junction box.
ÄCarry modules upright and horizontally as
shown.
NOTE! Module damage may occur!
ÄNever step on modules.
ÄDo not subject modules to any mechanical
stress.
ÄDo not allow any objects to fall onto modules
3.1 Safety and transport
3 INSTALLATION

13INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA12 INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA
DANGER! Risk of fatal injury due to electric shock!
ÄBlock off the installation zone.
ÄKeep children and unauthorized individuals away
from the solar power system.
DANGER! Risk of fatal injury due to electric shock!
ÄEnsure that modules and tools are not subject to
moisture or rain at any time during installation.
WARNING! Risk of injury due to falling modules!
ÄSecure modules during installation.
ÄDo not install modules in windy or wet weather.
DANGER! Risk of fatal injury due to electric shock!
ÄOnly use dry, insulated tools.
ÄDo not carry out the installation alone.
• Only install undamaged modules and
components.
ÄDo not modify the module (e.g. do not drill any
additional holes).
3.2 Preparation of installation
3 INSTALLATION
ÄMaintain an interval of at least 0.39 in (10 mm)
between two modules along the short side and
0.20 in (5 mm) along the long side.
0.39 in (10mm)
0.20 in
(5 mm)
Option 2:
ÄInstall the module at the 4 mounting points, see
pagepage 7.
ÄTighten screws according to manufacturer’s
instructions.
NOTE! Module damage may occur!
ÄDo not subject modules to mechanical tension.
Max. torsion 0.12 in/ft (10 mm/m).
Option 3:
ÄInstall the module using mounting proles, see
pagepage 7.
Option 1:
ÄFasten the module with 4 clamps in the specied
clamping range, see pagepage 7.
ÄTighten clamps according to manufacturer’s
instructions.
3.3 Module installation
3 INSTALLATION

15INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA14 INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA
DANGER!
Risk of fatal injury due to electric shock!
When disconnecting an electric circuit carrying direct current,
electric arcs can occur that may result in life-threatening injuries.
ÄDo NOT unplug the cable when under load.
ÄDo NOT connect any exposed cable ends.
A solar module generates electrical current and voltage even at a
low intensity of illumination. Sparks and electric arcs may result
from the separation of a closed circuit. These can result in life-
threatening injuries. The danger increases when several modules
are connected in series.
ÄPlease be aware of that the entire open circuit voltage is active
even at low levels of solar irradiation.
Ä
Please follow the valid national regulations and safety guidelines
for the installation of electrical devices and systems.
ÄPlease make sure to take all necessary safety precautions. With
module or phase voltages of more than 120 V, the extra-low
voltage range is exceeded.
Ä
Carry out work on the inverter and the wiring with extreme caution.
ÄEnsure that the modules are disconnected at the inverter prior
to separation.
ÄBe sure to observe the time intervals specied by the inverter
manufacturer after switching off the inverter.
DANGER! Risk of fatal injury due to electric shock!
ÄNever open the junction box.
ÄDo not remove bypass diodes.
DANGER! Risk of fatal injury due to electric shock!
ÄNever touch live contacts with bare hands.
ÄCover connectors by suitable protective caps
until installation.
DANGER! Risk of fatal injury due to electric shock!
ÄInsulate any exposed cable ends.
ÄOnly connect cables with plugs.
DANGER! Risk of fatal injury due to electric shock!
ÄOnly use dry, insulated tools for electrical work.
4.1 Safety
4 ELECTRICAL CONNECTION
DANGER! Risk of fatal injury due to electric shock!
ÄEnsure correct polarity.
DANGER! Risk of fatal injury due to electric shock!
ÄBe sure to maintain the time intervals as specied
by the inverter manufacturer between switching off
the inverter and beginning any further work.
DANGER! Risk of fatal injury due to electric shock!
ÄNever plug or unplug the cable when under load.
Modules must not carry any current.
1. Switch off the inverter.
OFF
EN
3. Switch off the DC circuit breaker.
ÄDisconnect plugs by the use of appropriate
and qualied tools of the manufacturer.
2. Cover the modules to be connected or
disconnected.
4.2 Electrical installation safety
4 ELECTRICAL CONNECTION
ÄMaximum allowed bend of the cable is with a
radius of 8 times the width of the cable.
Q CELLS standard cable is < 7.5 mm, resulting
in a maximum bend with a radius of 60 mm.
NA
2.36in (60mm)

17INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA16 INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA
ÄUse solar cables for the connection at the junction
box outlet.
ÄUse the same, inverter-compatible plugs.
SOLAR
NOTE! Module damage may occur!
ÄEnsure that the cabling is not under stress.
ÄEnsure that the cables do not run between
module and mounting rail or structure
(danger of pinch).
ÄDo not connect modules with different orientations
or angles of inclination in the same string.
ÄEnsure for a tight connection between the plugs.
Plugs click together audibly.
EN
click
DANGER! Risk of fatal injury due to electric shock!
ÄEnsure that all electrical components are in a
proper, dry, and safe condition.
4.3 Connection of modules
4 ELECTRICAL CONNECTION
ÄTo avoid complex cabling arrangements, it is often
advantageous to rotate some modules 180˚.
ÄModule orientation can clearly be identied from
the front side by the serial number and barcode
labelled behind the module glass on the side with
negative connection cable.
Inverter
180° 180°
ÄEnsure that all necessary safety and functional
tests have been carried out according to applicable
standards.
NOTE! Module damage may occur!
ÄEnsure that the plug connections are secured away
from any water-channelling surface.
ÄIntegrate the system into the existing lightening
protection system in accordance with the
applicable local regulations.
WARNING! Fire Risk!
ÄDo not use light concentrators (e.g. mirrors or
lenses).
ÄEnsure that the cabling is not exposed and/or
hanging and is protected from dirt, moisture and
mechanical friction.
4.4 After installation
4 ELECTRICAL CONNECTION

19INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA18 INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA
5 GROUNDING
Functional grounding
• For installations located in tropic regions (between 23.5° N and
23.5° S) with a module tilt of < 5°, functional grounding at the
negative generator connection on the DC side must be implemented.
ÄEnsure that the difference of potential between the negative
generator connection and the PE(N) of every MPP tracker of the
respective inverters is 0 V.
ÄFollow the directions of the inverter manufacturer.
ÄOnly use inverters which include lincensed grounding kits.
ÄFunctional grounding has also to be implemented in installation
sites with increased salt content in the air (e.g. close to the sea).
Protective Grounding
In order to prevent electrical shock or re, the frame of the module
as well as any non-current-carrying metal parts of the system must
be grounded. While this section provides some information about
grounding the Q CELLS frames and modules, reference should be
made to local statutes and regulations for specic requirements
on grounding. The U.S. National Electrical Code addresses these
issues in Article 250. Proper grounding is achieved by bonding all
exposed non-current-carrying metal equipment to the appropriately
sized equipment grounding conductor (EGC) or racking system
that can be used for integrated grounding. Q CELLS frames are
protected from corrosion with an anodized coating, which has to
be penetrated in order to ensure proper bonding. The different
methods listed below are suggested methods for an appropriate
bond between the frame and the EGC or racking system (that will
have to be properly grounded). The method appropriate for any
individual installation will depend on multiple factors.
Option A: Use of a grounding lug
When a predrilled mounting hole is present in the module frame,
a listed grounding lug can be bonded to the frame. These holes
• Dimensions shown are in inches.
0.177” (+0.008/-0)
±0.08
0.79”
0.47”
±0.08
PV Laminate
Backing Nut (Stainless Steel)
Toothed Lock Washer (Stainless Steel
or tin-plated metal)
Grounding Lug (Stainless Steel)
Equipment
Grounding
Conductor
Aluminum
Frame
Screw (Stainless Steel)
are marked with a ground symbol, as shown below on the frame
section drawing: To install the grounding lug, follow the specied
instructions of the manufacturer. The grounding lug should be
made of stainless steel or tin plated metals such as aluminum to
avoid corrosion. The grounding lug should be attached to the frame
grounding hole using a stainless steel screw, toothed lock washer
or KEPS nut (in order to penetrate the anodized layer) and backing
nut. Care should be taken to avoid the use of grounding hardware
of dissimilar metals, which may lead to corrosion
Option B: Integrated grounding methods
The Q CELLS modules can be bonded with the racking system
using UL1703 or UL2703 certied integrated grounding methods.
The racking system will then have to be grounded so that the
overall system is properly grounded. The listed racking system
and grounding device should be installed in accordance with
the manufacturers’ instructions. An example of such integrated
grounding method is the use of a WEEB clip or Schletter plate
between the module and the racking system, when mounting
the module. The WEEB washers are generally compatible with
Q CELLS modules, however each combination module / racking
system requires a specic WEEB washer size. Note that WEEB clips
are intended for single use only; they must not be reused after
removal or loosening. Refer to Wiley’s installation instructions for
the specic use of WEEB washers.
An example of such integrated grounding method is the use of a
washer recognized as meeting UL2703 requirements between the
module and the racking system, when mounting the module. For
example, WEEB washers are generally compatible with Q CELLS
modules, however each combination module / racking system
requires a specic WEEB washer size. Note that WEEB washers
are intended for single use only; they must not be reused after
removal or loosening. Refer to Wiley’s installation instructions for
the specic use of WEEB washers.
6 FAULTS AND DEFECTS
DANGER!
Risk of fatal injury due to electric shock!
ÄDo not attempt to x any problems yourself (e.g., glass
cracks, damaged cables).
ÄPlease contact an installer or Q CELLS Technical Customer
Service Department.
ÄDo not disconnect modules yourself.
ÄPlease commission a trade specialist.
ÄDispose of modules in accordance with the local disposal
regulations.
7 DISPOSAL

21INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA20 INSTALLATION AND OPERATION MANUAL SOLAR MODULES DUO-G5.X – HANWHA Q CELLS – NA
Q CELLS solar modules are known for a long operating
life and minimal maintenance effort and expense. Dirt
and grime are usually washed away by rain. If the module
is fully or partially shaded by dirt or debris (e.g., plants,
bird droppings), it needs to be cleaned to prevent a loss
of performance.
Maintenance
ÄThe PV system has to be inspected regularly by certied
personnel
Ä
The time intervals and extent of the inspection can depend
on local circumstances (e.g. salt, ammonia content in
the air, high humidity etc.). The customer/operator must
inform himself about time intervals and extend of necessary
inspections.
Ä
Inspections have to be performed especially after extraor-
dinary events (e.g. storm, hail, high snow loads etc.)
ÄDuring the inspections it has to be checked that the
components are secure, undamaged and clean
Cleaning
WARNING!
Risk of injury due to hot and
live modules!
ÄOnly clean modules that have cooled down.
ÄDo not carry or wear any electrically conductive parts.
WARNING!
Risk of falling due to unsecured
access!
ÄNever access the installation area alone or without
taking adequate security precautions.
ÄPlease commission a trade specialist.
NOTE!
Module surface damage may occur!
ÄRemove snow and ice without force (e.g. with a very
soft broom)
ÄDo not scratch off dirt.
ÄRinse dirt off with lukewarm water (dust, leaves, etc.)
ÄUse a soft cellulose cloth (kitchen roll) or sponge to
carefully wipe off stubborn dirt. Do not use micro eece
wool or cotton cloths.
Ä
Use an alcohol based glass cleaner. Do not use abrasive
detergents or surfactants.
Isopropyl alcohol (IPA) can be used selectively to remove
stubborn dirt and stains within one hour after emergence.
ÄPlease follow the safety guidelines provided by the IPA
manufacturer.
ÄDo not let IPA run down between the module and the
frame or into the module edges.
ÄFree the substructure from any dirt and debris
(leaves, bird nests, etc.).
ÄRemove dirt with lukewarm water, a broom, or a
soft cloth.
ÄDo not use surfactants, scrapers, or any high-
pressure water cleaning equipment.
NOTE! Module damage may occur!
ÄDo not clean modules with water if there is a risk
of frost.
0°
8 MAINTENANCE AND CLEANING

CONTACT
HANWHA Q CELLS AMERICA INC.
300 Spectrum Center Drive
Suite 1250
Irvine, CA 92618
USA
TEL [phone]
EMAIL [email protected]
WEB www.q-cells.us
Subject to change without notice. © Hanwha Q CELLS Installation manual solar modules DUO-G5.X_2017-10_Rev01_NA
