Qdis QPI-BM12 V1.4 Manual

Your best partner for better driving
Release Date
2013.06.25
Model
QPI-BM12-Main-V1.4 IF
Product Code
QPI-BM12-1306-009

Warning
When installing the main unit, do not remove or alter existing
vehicle fasteners, including nuts, bolts, screw, clips, and fittings.
Never detach, move or alter existing vehicle wiring, including
electrical grounds and straps. Alteration of existing vehicle
components may make vehicle unsafe to operate. Should be
no any electronic devices or magnetic pole around installation
place.
Air bags are vital part of a safety system. Never install main unit
in a way which will alter air bag wiring or interfere with air bag
deployment. Air bags must function properly in the event of an
accident.
Before installing, check the location of pipe, tank, electrical
cables and others.
Read and follow the instruction manual.
Wiring location must not interfere driving, get in or out from car.
Use electrical tape to insulate the ends of all wires, even if they
are not used. Proper insulation prevents arcs, shocks and fires.
When installation is complete, test all vehicle electrical systems
to ensure they operate correctly, including lights, horn, brake
lights, and emergency flashers.
According to our sales policy, any problems caused by user’s
mistake, careless can not be guaranteed.
Caution
All steps of installation should be done by well-trained specialist.
During installation ignition key should be taken off and after all
installation finish connect power cable with interface for the last
step.
Do not install the main unit in places where it ma be exposed to
dew condensation (around the air conditioning hose, etc), or in
locations where it may come in contact with water, high levels of
moisture, dust or oily smoke
Install wiring in a manner in which cables will not come in contact
with metal parts. The wiring may be damaged by contact with
metal parts, resulting in fire and shocks. Avoid all contact with hot
surfaces when wiring the main unit. High temperatures may
damage wiring, causing shorts, arcing and fires.
Kindly check all parts are in the box, when receiving the product, if
anything missing, inform to the supplier or manufacturer.
Warning / Caution

Table of Contents
1. Specifications
1.1 Main Specifications
1.2 Features
1.3 System Diagram
1.4 Components
1.5 Exterior
2. Installation
2.1 Installation Diagram
2.2 Installation
3. Settings
3.1 DIP Switch
3.2 Remote Control
3.3 Car Model and Navi Model
3.4 Factory Mode
3.5 DVD, DTV I-DRIVE input
3.6 Original Button Usage
3.7 Rear Camera
3.8 Rear Parking Guidelines
3.9 OSD
4. Trouble Shooting
1
2
3
4
5
6
7
9
10
11
12
15
17
19
22
23
25

1. Specifications
-1-
1.1 Main Specifications
1. Car Compatibility
BMW New 1,3,5,7 series 6.5’’ & 8.8’’ & 10.2”
2. Components
Interface* 1EA
3. MULTIMEDIA INTERFACE input specification
3 * A/V input (video external input)
1 * CVBS(Rear Camera) input
1 * Analog RGB input (Navigation system output)
1 * LCD input (Car system input)
4. MULTIMEDIA INTERFACE output specification
1 * LCD output
5. Power specification
Input power : 8VDC ~ 18VDC
Consumed power : 5WATT
6. Switch input mode
- External display skip function : through DIP switch, can
control each video input
- Through remote control, can change input mode
- Through CAN or rear lamp cable, rear camera can be
detected

1. Specifications
-2-
Easy installation through connection with commander
Able to control NAVI, DVD, DTV function by using I-Drive
Controller
Able to adjust DVD, NAVI display on screen
Improved Screen Display (user-oriented interface)
Mode change through original button (I-DRIVE MENU
BUTTON)
Provide power cable to connect with rear camera
Support PIP display –show original Navi and other source
display at the same time (Picture in Picture)
Dynamic PAS(Parking assistance system), moving parking
line according movement of steering wheel
1.2 Features

1. Specification
-3-
1.3 System Diagram
DISPLAY
A/V 1
NAVIGATION Input
(Analog RGB)
CVBS
(Rear camera)
Car Screen Input
(CAR MAIN BOARD)
A/V 2
A/V 3
VIDEO
CIRCUIT
VIDEO MUX
MCU
Power Input
(+8VDC ~ +18VDC)
POWER
CIRCUIT
Dip S/W
A/V OUT HEADREST
MONITOR
Remote control Switch for source toggle
OEM Button (Can Signal)
Car Installation
OEM LCD
Rear Camera

1. Specification
-4-
1.4 Components
A/V cable * 1EA
Mode cable * 1EA
IR cable * 1EA
R-CAM POWER cable * 1EA
POWER cable (7P) * 1EA
(HPOWER0002)
(HARETC0002)
(HAVCAB0002)
Remote control * 1ea
(REMOTE0001)
(HARETC0001)
(HIRCAB0002)
TOUCH OUT cable * 1ea
(HTOUCH0004)
LCD Cable * 1ea
(HLCDCA0019)
TOUCH IN cable * 1ea
(HTOUCH0010)
RGB cable * 1ea
(HRGBCA0013)
LVDS Extension Cable * 1ea
(HLCDCA0022)(Optional)
Extension Sub-board * 1ea
(QCPASS0414)(Optional)

1. Specifications
-5-
1.5 Exterior
①⑥⑦⑧
①MODE
②IR
③POWER
④TOUCH OUT TO NAVI
⑤TOUCH IN FROM LCD
⑥R-CAM
⑦RGB-IN
⑧AV IN/OUT
⑨LCD-OUT
⑪TEST
Dimension
Width 150.4mm
Length 99.4mm
Height 2.3.2mm
⑩LCD-IN
②③④⑤
⑫LED
⑬DIP S/W
⑨⑩⑪⑫⑬

2. Installation
-6-
2.1 Installation Diagram
Original LCD Cable
Control Box
Provided
LCD cable
Original CAN
OEM
Monitor
AV1 AV2 AV3 REAR C
Audio L
Audio R
AV/OUT Video
REAR-C
SAFE
F-CAM-DET
CAN-L
CAN-H
ACC (12V ~24V)
GND
※Connect Interface CAN High
(green + brown) with car’s
yellow + red cable.
※Connect Interface CAN Low
(green) with car’s yellow +
brown cable.
R DATA (red) G DATA (green) B DATA (blue)
NAVI
SYNC (white)
GND (black)
DVD
REAR (12V OUT)
GND
Control box
Green+Brow
n
CAN
Green

2. Installation
-7-
2.2 Installation / Monitor and Interface connection
①See left picture. Remove
original LCD cable from
monitro and connect with
provided LCD cable.
②Connect the original LCD
cable with LCD-IN on the
interface.
※Precaution : Do not connect power cable with accessory
power, connect with backside of command or cigar jack.

2. Installation
-8-
2.2 Installation / connect CAN cable
Provided CAN-Low
See picture above. Connect provided CAN-H cable (green
+ brown) with original CAN-H cable (yellow + red). Connect
CAN-L cable (green) with original CAN-L cable (green +
brown).
Provided CAN-High
Power Cable
Control box
original CAN-High
original CAN-Low

3. Settings
-9-
3.1 DIP Switch
PIN
Function
Dip S/W Selection
1
Displaying RGB input
ON : RGB mode skip
OFF : RGB mode display
2
Displaying A/V 1
ON : A/V 1 mode skip
OFF : A/V1 mode display
3
Displaying A/V 2
ON : A/V 2 mode skip
OFF : A/V2 mode display
4
Displaying A/V 3
ON : A/V 3 mode skip
OFF : A/V3 mode display
5
Setup of monitor size
ON : 6.5”
OFF : 8.8”, 10.2”
6
Setup of car type
ON : Solid GUI model
OFF : Standard GUI model
7
Setup of rear camera use
ON : CVBS4
OFF : MAIN
8
Reset factory settings
(not use for user)
ON : Product factory reset
OFF : DEFAULT
※ON : DOWN / OFF : UP
Default : DIP S/W 8 OFF
※Example DIP S/W usage
- Use input mode : A/V2, A/V3
- Use original navigation
- External rear camera
▷DIP S/W : 1,2 ON (hide INPUT MODE)
▷DIP S/W : 3 OFF (A/V2 display)
▷DIP S/W : 4 OFF (A/V3 display)
▷DIP S/W : 5 OFF (8.8” & 10.2”)
▷DIP S/W : 6 OFF (Standard PDC model)
▷DIP S/W : 7 ON (display external rear cam)
▷DIP S/W : 8 OFF

3. Settings
-10-
3.2 Remote Control
Key
Function
POWER & PIP Unavailable
MENU Activating OSD menu
OK Making a selection, changing image display
▲
Moving upward
(If you press this button 2 seconds long, “Hot key” function will
activate/ deactivate.)
▼Moving downward
◀
Moving leftward
(If you press this button 2 seconds long, you can access the factory
mode.)
▶
Moving rightward
(If you press this button 2 seconds long, you can reset all the
data about user environment.)
What is Hot Key function ?
You can use this function via pressing number “1”
button next to the radio button. You can change
audio source to the external AUX with this
function. (original function of BMW) Our device
let it change to an external video source for
driver to use this function via this button. So, you
can change sources (audio<->video) by pressing
this button without any other install process.

3. Settings
-11-
3.3 Car Model and Navi Model
IMAGE
Adjust navigation position and size
H-POSITION : Move display horizontally
V-POSITION : Move display vertically
H-SIZE : Adjust navi size horizontally
UTIL1 - CAR MODEL
Selecting model of the car
F20 : 1, 3, 5, 7 series 6.5” & 8.8”
New UI 8.8” 10.2”
* Set pin#5 of DIP switch to the
right size of the monitor after
selecting model of the car.
(Refer to page9.)
UTIL1 –NAVI MODEL
Definition of the navigation
resolution
DEFAULT : default, 400X234, low
resolution
KD-900(WVGA) : 800x480 in high
resolution, for Chinese
LS-901(WQVGA) : 800x480 in high
resolution, for Chinese, Taiwan
WP9200(WVGA) : 800x480 in high
resolution, for Israel
GI-8000N 3D(WVGA) : 800x480 in
high resolution, for Korea
GI-5000A(WVGA) : 800x480 in
high resolution, for Korea
I-ONE(WVGA) : 800x480 in high
resolution, for Korea
HDMI (when SMI installed):
800x480 in high resolution
* Go into FACTORY/ IMAGE (as
shown right) and adjust the
position and the size of the
navigation after setting the
definition of the navigation
FACTORY mode –Press ◀button 2 seconds long on the remote control.
Setup for car model Setup for navigation

3. Settings
-12-
3.4 FACTORY Mode
UTIL1 –AVOUT SELECT
Selecting background sound
After
returning navigation or original
mode
DEFAULT : Selecting AV sound
just before changing
navigation or original mode
from the AV mode
AV 1~3 : Sound of the selected
AV source 1~3
UTIL1 - FACTORY RESET
FACTORY MODE RESET
FACTORY mode –Press ◀button 2 seconds long on the remote control.

3. Settings
-13-
3.4 FACTORY Mode
UTIL2 - I_DRV CONTROL
Selecting whether to use I_DRV
function or not
ON / OFF
UTIL2 - I_DRV REMOTE
Choose DTV and navi model
to be control I_DRV function
LI-1DISC
NEC-6DISC
USER(when using IR MEMORY)
•Select navigation model:
Setting on RGB Mode
•Select DVD model : Setting on
A/V mode
FACTORY mode –Press ◀button 2 seconds long on the remote control.

3. Settings
-14-
3.4 FACTORY Mode
FACTORY mode –Press ◀button 2 seconds long on the remote control.
UTIL2 –HANDLE KEY
Whether to use voice button
on handle for mode change
ON / OFF
UTIL2 –IR MEMORY
To register DVD, DTV remote control,
the remote control value must be
registered and can be control with
I-Drive
※To use this function, in I_DRV-
I_DRV REMOTE select USER mode
DVD / DTV
UTIL2 –MEMORY KEY
Wheter to use car audio
button #8 (mode change +
aux change)
ON / OFF
UTIL2 –CALIBRATE
Touch Calibration
YES / NO

3. Settings
-15-
3.5 DVD, DTV I-DRIVE input
①First of all, press ◀button on
remote controller 2 seconds
long or press
UP→DOWN→UP→MENU
button in order to access
Factory mode. Choose IR
MEMORY on I-DRV.
In IR MEMORY, you can choose
AV source of DTV and DVD you
want to use.
②Picture above shows DVD
remote control button value
input, select menu you want
to save. (To register DVD
remote control button value,
select IR MEMORY –DTV and
follow below instructions.
Example)
a. After select OK button on
OSD menu, press intended I-
Drive button
b. Indicated part above will
flicker, and press POWER on
DVD remote control.
(continue to next page)
What is IR-MEMORY Mode?
Is to allow I-Drive to control other DVD or DTV (besides the existing,; for
example : SANYO, NECVOX) by register remote control value.

3. Settings
-16-
3.5 DVD, DTV I-DRIVE input
example) continued..
c. The values that you
registered will appear as
green text in the marked
area on pressing the button.
And the values will be saved
automatically.
d. Register remain buttons’
value in OSD menu like the
above-mentioned.
③After register, select “INPUT”
in OSD menu and press “OK”.
Then you can see
confirmation window as
shown above. At the
moment, if you choose “YES”,
all the values that you
entered will be saved.
If you select “NO”, the values
won’t be saved.
(If data is saved, DVD TYPE and
DTV TYPE will be changed to
“USER” automatically.)
If you see “SUCCESS” on
screen, the data is saved
clearly and you can control
DVD via touch screen. BUT,
you MUST change the option
in DVD(DTV)/UTIL/FACTORY
to “USER”.

3. Settings
-17-
3.6 Original Button Usage/ 6.5”
Mode
Key
Operation
Function
Whole
mode
TEL
Press longer
Change mode
Press shorter
Go back to Original image
MENU
Press shorter
Making Selection
Press shorter
Change mode
Audio
Button #8
Press shorter
Change mode + Change Car Aux
Reverse
mode
(Steering
wheel)
Press shorter
Operate PIP function
I-Drive Button (6.5”)
