QFX PBX-1211 User manual

User Manual
PBX-1211
PORTABLE BATTERY SPEAKER
3
Specifications:
Power: 20W
Frequency Response
for main speaker: 55Hz-20KHz
Power Supply: DC9V
(4)
Press to enter into FM radio mode, press SCAN to enter into radio program
automatic scan. Press for radio program manual scan, Top and bottom
trimming, Turn the TUNER button radio station can be adjusted. Slide around to
adjust radio frequency between 87.5MHz~108.0MHz.
(5) Bluetooth connection
Press to enter into Bluetooth Control connection page, then click "Speaker
Pro BLE" to connect to the speaker.
(6)Line In input - mute
Press to enter into Line IN input page, press to mute music, press
insert a line continue play. Press "Back" to main page.
(7) Equalizer regulation
FM Radio
Press to enter into Sound Set page, and then turn volume or bass or treble to
adjust the volume. There are 4 pre-set EQ modes: dance, Classical, Jazz and Rock.
You can also press G-Eq to access the graphic equalier to set up your preferred
equalize specification.
（7）（6）（5）
（4）
FM Operation
Lightly press Power/Input button to switch to FM mode, long press PLAY/PAUSE
button to automatically scan radio station, by pressing PREVIOUS or NEXT you
can select a previous or next song.
Bluetooth:
Press the POWER/INPUT button on the panel control to select Bluetooth mode.
Simultaneously open the Bluetooth setting on your phone, tablet or any other
Bluetooth enabled audio device and select "QFX PBX-1211". The unit and device
will then connect via Bluetooth.To control the device via your phone, tablet etc
please download the App "Speaker Pro".
Once the unit and device are connected via Bluetooth, open the "Speaker Pro" App
on your phone, tablet etc and press the Bluetooth button. This will enable you to
control the following five modes on the device from your phone: Music, Light,
USB Card, Bluetooth and Equalizer. To cancel the app, press the exit button.

1
BASIC OPERATION
1. POWER/INPUT button: long press POWER/INPUT button for about 3 seconds,
the machine displays “HI” and then “bLUE” to start; long press POWER/INPUT
button for about 3 seconds and the machine turns off. During working state, short
press POWER/INPUT button to select the mode, the sequence is USB (when USB
device is connected), FM, LINE, BT.
2. Bass/Treble/Mic/VOLUME: adjust volume; PUSH knob enter menu: turn left and
right to adjust the volume from 0 to 30. To press and then turn left and right, you can
adjust the Treble and Bass volume, Microphone volume, and switch 12 kinds of Light
Modes.
3. PLAY/PAUSE: to play or pause the music. During FM state, long press PLAY/
PAUSE to automatically search radio and save.
4. PREVIOUS/NEXT: to switch the song and radio.
5.
6.Brightness of LED light mode: The product has LED light brightness adjust function,
press LIGHT to choose the effect.
7. USB: USB Player/Power Bank 5V 1A output.
TWS Wirless Bluetooth Connection: under bluetooth mode, press TWS button for
around 3 seconds to pairing another TWS speaker;Under FM mode, lightly press
TWS to enter into automatic scan and all the scanned radio stations will be saved
automatically.)
BT pairing between a cellphone and one QFX PBX-1211 TWS speaker firstly and play
music from cellphone. Turn on another QFX PBX-1211 TWS speaker and Press TWS
function button, then it will play the same music you are playing in the first unit.
PANEL LAYOUT & FUNCTIONS
1.
Previous song
Next song
LED display.
2.POWER/INPUT button.
3.
4.Brightness of LED light mode button
5.Bass/Treble/Mic/VOLUME: Master
volume adjustment&Menu selection
button&PUSH knob enter menu.
6.LINE IN.
7.USB: USB Player/Power Bank 5V
1A output
8.MIC: Microphone signal input.
9. .
10.Play/Pause (In FM mode,hold for
3 seconds the device will enter into
automatic scan).
11. .
12.LED CHARGE STATUS:
RED = Charging
GREEN = Fully charged
13.DC 9V external input.
TWS Wirless Bluetooth Connection
2
To control the device via your phone, please find and install the app " Speaker Pro ".
Open the App "Speaker Pro" on your phone, there are 7 function icons on the main
page :
1.Bluetooth Music play
2.USB card play
.Light control colour, brightness and light flash mode
4.
5.Control Bluetooth connect
6.Line In input - mute
.Equalizer,volume adjustment for music.
(1) Bluetooth Music play
Press to enter into Bluetooth Music play page, Press "Pick songs to play"
to Pick Song page to choose the song you want to play, press "Done" to return to
Bluetooth Music play page, also you can operate pause, play, backward, forward&
volume adjustment, repeat, random play. Press "Back" to return to the main page.
(2)USB card play
When inserting a USB into the speaker, press to enter the USB Card play
page. To choose a song and play music on the USB card, press "Play" to enter into
the play control page ,where you can operate pause, play, backward, forward &
volume adjustment. Press "List" to return to USB list page, press "Back" to return
to the main page.
(3) Light control colours, brightness and colour change mode
Press to enter into Light Control page, you can select any colour to show the
light colour on the speaker, as well as adjust the brightness of the light. To go back
to main page, press " " in the left corner.
Press "Profiles" to enter into Light Effect mode page, you can choose from a total
of 12 pre-set light effect modes. To return to Light Control page, press "Light"
in the left corner.
3
FM Radio
7
（1） （2） （3）
1
2
3
4
5
6
7
1
2
3
4
5
8
6
7
9
10
11
13
12
TWS
DC 9V
Bass/Tr ebl e/Mi c
Volume
