Qimarox Prorunner PR15 User manual

User Manual
Prorunner PR15
Version 1.0 - 07/06/2022
For serial number PR15 2200000 and higher
(Always check Specification sheet of machine for applicable version)

About this manual
2
UM Prorunner PR15 v1.0 EN
Qimarox B.V.
Nobelstraat 43
3846 CE Harderwijk
The Netherlands
Tel: [phone]
E-mail: [e-mail]
Internet: www.qimarox.com
Copyright © Qimarox B.V.
All rights reserved. No part of this publication may be reproduced, stored in a computer
database or published in any form or in any way electronically, mechanically, by means of
photocopying, recordings or in any manner without prior written permission from Qimarox.

About this manual
UM Prorunner PR15 v1.0 EN
3
Table of contents
1About this manual 5
1.1 Introduction..............................................................................................................5
1.2 Machine documentation..........................................................................................6
1.3 Source language.....................................................................................................6
1.4 Symbols used in the manual...................................................................................6
1.5 Terminology list.......................................................................................................7
1.6 Further support and information..............................................................................7
2General 8
2.1 Machine identification..............................................................................................8
2.2Machine layout drawing and specifications.............................................................8
2.3 CE Installation instructions......................................................................................9
2.4 Warranty..................................................................................................................9
2.5 Liability ....................................................................................................................9
2.6 CE ........................................................................................................................ 10
3Safety 11
3.1 Intended use of the machine................................................................................ 11
3.2 User types and qualifications............................................................................... 11
3.3 Safety instructions................................................................................................ 13
3.4 Safety provisions.................................................................................................. 14
3.5 Electrical safety.................................................................................................... 18
3.6 Sound level........................................................................................................... 18
3.7 Personal safety..................................................................................................... 18
3.8 Residual risks....................................................................................................... 19
3.9 Machine end of life and disposal.......................................................................... 20
3.10 Overload tests...................................................................................................... 20
4Description 21
4.1 General overview ................................................................................................. 21
4.2 Function determination......................................................................................... 23
4.3 Sensors................................................................................................................ 23
4.4 Machine set in a conveyor system....................................................................... 23
5Installation 25
5.1 Unpacking ............................................................................................................ 25
5.2 Location................................................................................................................ 25
5.3 On-site transport .................................................................................................. 25
5.4 Preparations for a Qimarox installation (optional)................................................ 25
5.5 Installing the machine .......................................................................................... 26
6Maintenance 29
6.1 General................................................................................................................. 29
6.2 Specific safety regulations ................................................................................... 29
6.3 Preventive maintenance schedule....................................................................... 29
6.4 Cleaning............................................................................................................... 30

About this manual
4
UM Prorunner PR15 v1.0 EN
7Troubleshooting 31
8EC declaration of conformity 32
CE Installation instructions............................................................................................. 34
9Electrical drawings 36

About this manual
UM Prorunner PR15 v1.0 EN
5
1 About this manual
1.1 Introduction
This manual provides information about the Prorunner PR15 (vertical conveyor)
machine that is used for transporting and sorting products such as carton boxes and
crates in a distribution system. Henceforth the Prorunner PR15 will be referred to as
the ‘machine’.
The machine is an assembly of two separate modules, the Qimarox vertical conveyor
Prorunner mk1 and continuous vertical conveyor Prorunner mk5. This manual deals
only with issues concerning the combination of the two machines. For specific
information about these machines refer to their own manual. See section 1.2
Note
Make sure this manual is always available with the machine.
This manual is intended for:
•Retailers/Original Equipment Manufacturers (OEM), project engineers and
mechanics.
•Operators, installation and maintenance engineers and other users.
It is important to carefully read this manual as soon as possible after purchase of the
machine. Before operating the machine this manual should be read by all users.
System integrators/OEMs
This manual explains machine configurations that can be used to set up the machine.
It also provides mandatory installation instructions for the System integrator/OEM,
necessary for the machine to comply with EU regulations (CE) and instructions for
installation of the machine on site.
Note
The text of this manual was written assuming that the integrator followed
the EC Installation instructions completely...
Users
This manual gives safety and maintenance instructions and instructions for
troubleshooting. Operating instructions are found in the operating manual (OM) of the
system, provided by the System integrator/OEM.

About this manual
6
UM Prorunner PR15 v1.0 EN
1.2 Machine documentation
Document
Reference
Machine manual (this document)1
UM Prorunner PR15 v1.0 EN
Machine Prmk5 Manual 1
UM Prorunner mk5 v2.1 EN
Machine Prmk1 Manual 1
UM Prorunner mk1 v4.1 EN
Conveyor Prmk5 Manual 1
UM Roller conveyor RDC v1.1 EN
Conveyor Prmk1 Manual 1
UM Roller conveyor RDC prmk1 1_6_7
v1.1 EN
Machine layout drawing 2
Layout drawing [serial number]
Specification sheet 2
Specifications [serial number]
Electrical drawings1or 2
Electrical drawing [serial number]
1Generic information 2Machine specific information
Note
The operating instructions are found in the Operating manual (OM),
which is supplied by the System integrator/OEM.
CAUTION
Make sure you use the correct version of the documentation for the
machine. The correct version is found in the Specification sheet.
1.3 Source language
This manual is an “Original manual” and was originally written in the English language.
1.4 Symbols used in the manual
The following symbols are used in this manual.
WARNING
Risk of serious injury to the user and/or serious damage to the machine
if the instructions are not accurately followed.
CAUTION
Risk of light or medium injury and/or damage to the machine if the
instructions are not accurately followed.
Note
To provide additional information to the user about a task or issue.

About this manual
UM Prorunner PR15 v1.0 EN
7
1.5 Terminology list
The table below explains common terms used in this manual.
Term
Definition
Machine
The vertical conveyor Prorunner PR15
Conveyor
RDC2-PR15 or RDC6 st75
Transportation
surface
A surface intended for transportation of products. For example: a
roller conveyor
Transport
system
Combination of machines that is used for transporting products
Fenced area
Area around the machine that unauthorized personnel cannot
enter for safety reasons.
1.6 Further support and information
Qimarox can supply additional expertise and support services, for:
Training
Global support
Service contracts
For more information, please contact Qimarox.

General
8
UM Prorunner PR15 v1.0 EN
2 General
2.1 Machine identification
The machine identification for the Prmk5 and the Prmk1 are given on their type plates.
The type plate for the PR15 is at the left side of the bottom frame of the PRmk5 right
next to the PRmk5 type plate. Refer to the specification sheet of this serial number, for
specifications of this machine.
2.2 Machine layout drawing and specifications
After a machine order is placed, a machine drawing and specification sheet is sent for
approval. After approval the machine drawing and specification sheet are sent as a
reference for this manual. The machine drawing and specification sheet include:
•Machine serial number
•Product dimensions and mass
•Machine dimensions and mass
•Machine configuration
•Machine capacity
•Maximum load
The machine can only be used according to the specifications given in this manual, in
the machine layout drawing and in the specifications sheet. If you want to use the
machine outside these specifications, you must contact Qimarox to check if this is
possible. Inappropriate and/or modified use of the machine can result in dangerous
safety issues and/or damage. You must obtain written confirmation from Qimarox
before using the machine in a modified or unspecified manner. Qimarox cannot be

General
UM Prorunner PR15 v1.0 EN
9
held liable for any accidents and/or damages that may occur through inappropriate
unauthorized use of the machine.
Machine maximum load (WLL) is the maximum product weight per carrier and, for the
continuous vertical conveyor Prmk5, the maximum product weight of all products in
the vertical conveyor Prmk5 combined.
Both maxima have to be observed. The type plate and a max load sticker indicate on
both Prmk1 and Prmk5 the values. The max load stickers must be easily visible.
2.3 CE Installation instructions
The machine is intended to be integrated into a transport system by a System
integrator/OEM. Certain items, such as emergency stops, safety controls, safety
fencing, and a control cabinet are logically part of the transport system, and are not
supplied with the machine. The System integrator/OEM has to add these items
following the CE Installation instructions on the EC Declaration of conformity, for the
machine to comply with EU regulations (CE).
For the CE installation, instructions see chapter 8.
WARNING
Before the CE Installation instructions have been met completely, the
machine must not be used.
The scope of supply and CE installation instructions are agreed upon between
Qimarox and the System integrator/OEM at the time of sale of the machine.
2.4 Warranty
The scope and duration of the warranty is agreed upon agreed upon at order
placement of the machine. The warranty only applies if the machine is used according
to the specifications and if the user and maintenance instructions are observed. The
warranty does not cover wearing parts.
The machine warranty is null and void in cases of:
Unskilled use.
Inadequate maintenance.
Unskilled maintenance.
Modifications made to the machine without prior written permission from
Qimarox.
2.5 Liability
Qimarox believes to the best of its knowledge that the information in this user manual
is accurate. In the event that technical or typographical errors exist, Qimarox reserves
the right to make changes to subsequent editions of this user manual without prior
notice to holders of this edition. The reader should consult Qimarox if errors are
suspected. In no event shall Qimarox be liable for any damages arising out of or

General
10
UM Prorunner PR15 v1.0 EN
related to this user manual or the information contained in it. Except as specified
herein, Qimarox makes no warranties, express or implied, and expressly disclaims
any warranty of non-infringement, merchantability or fitness for a particular purpose.
Customer’s right to recover damages caused by fault or negligence on the part of
Qimarox shall be limited to the amount paid to Qimarox by the customer. Qimarox
shall not be liable for damages resulting from loss of data, profits, use of products, or
incidental or consequential damages, even if advised of the possibility thereof. This
limitation of liability of Qimarox will apply regardless of the form of action, whether in
contract or tort, including negligence. Any action against Qimarox must be brought
within one (1) year after that cause of action accrues. Qimarox is not liable for
damages, accidents, unsafe conditions, defects, malfunctions, or service failures
caused by the following:
Owner’s or user’s failure to follow Qimarox’s installation, operation and
maintenance instructions, including but not limited to neglecting warnings or
regulations as shown on the machine or in this manual.
Usage of the machine for other applications, or under other circumstances
than indicated in this user manual. This includes abuse, misuse or negligent
acts.
Modifications of any kind to the machine. This includes the replacement of
parts with parts that are not specified in this manual.
Insufficient or improper maintenance.
2.6 CE
Qimarox has determined the design of the machine and therefore supplies the EC
declaration of conformity of the machine. The declaration is only valid after the CE
Installation instructions on the EC declaration of conformity have been met completely.
An example of the declaration is given in chapter 8.
For the specific declaration of the machine, refer either to the Specifications sheet or
to the separate document supplied with the documentation of the machine.

Safety
UM Prorunner PR15 v1.0 EN
11
3 Safety
3.1 Intended use of the machine
The machine is exclusively intended for the de-stacking or stacking of empty pallets
described in this manual. Refer to chapter 4 for a detailed description of the
specifications of use.
The machine is always set up within a larger transport system in which empty pallets
are loaded on and off the machine.
WARNING
Any other use of the machine is strictly forbidden.
WARNING
It is strictly forbidden to lift persons with the machine or to stand on a
product carrier.
WARNING
It is strictly forbidden to overload the machine with too much weight or
with too many products. See specification sheet or type plate and
sticker “Max load” on the machine.
WARNING
It is strictly forbidden to use the machine with Products out of spec or
of insufficient quality. See specification sheet.
3.2 User types and qualifications
The following user types are referred to in this manual:
The operator
The mechanical installer
The electrical installer
The maintenance engineer
Only qualified personnel may operate the machine. A qualified operator has
experience with operating machinery and is informed about the contents of this
manual. An operator must be familiar with the contents of Chapters 1, 2, 3 and 4 and
with the Operating Manual.
An electrical installer is only qualified if a person has attended appropriate training
and/or attained appropriate industry standard recognized qualifications. Qimarox can
provide training if required.

Safety
12
UM Prorunner PR15 v1.0 EN
The maintenance engineer must be familiar with the full content of this manual and
with the Operating Manual. All maintenance work should be performed by qualified
maintenance personnel
Qimarox can also give advice about actions and tasks to be carried out on the
machine.

Safety
UM Prorunner PR15 v1.0 EN
13
3.3 Safety instructions
3.3.1 General
Comply with the safety regulations given in this manual. Deviation from these
regulations can lead to unacceptable risks.
Never close doors (if present) of the fenced area of the machine, when a person is
inside this area.
Switch off the machine, secure the main power supply switch in the off position
with a padlock off to prevent the machine from being switched on while personnel
is working within the fenced area.
For the Prorunner Prmk1: Place the safety locking pin before going under the
carrier of the Prorunner mk1. For specific instructions see the user manual of the
Prmk1.
Comply with all relevant local legislation and regulations.
Always wear the prescribed personal protective equipment when working on the
machine. See section 3.7
Be aware that unexpected movements in automatic mode of the machine can
occur.
Check the correct operation of the safety devices regularly.
For the Prorunner Prmk1: Make sure that the safety pin is removed before the
machine is turned on.
Do not set the main switch to the ON position when persons are in contact with
the machine.
Never start the machine if persons are in contact with the machine or are inside
the fenced area.
3.3.2 Set up
Connect the machine in accordance with the local laws and regulations
concerning health and safety.
Before putting the machine into use, check if the machine has been set up in
accordance with the instructions in this manual and with the layout drawing.
Make sure that the system into which the machine is integrated, complies with all
relevant health and safety directives and regulations and that the hazards that
may be present at the transitions between the machine and system or other items,
are sufficiently removed.
3.3.3 Starting the machine
Do not switch the main power supply on when persons are in contact with the
machine.
Do not switch the air service unit on when persons are in contact with the
machine.
Do not start the machine when persons are in contact with the machine.
Do not start the machine when persons are present in the fenced area of the
machine.
Before the machine is put into operation, all machine parts must comply with all
relevant health and safety directives and regulations.
3.3.4 During machine operation

Safety
14
UM Prorunner PR15 v1.0 EN
Keep your hands and feet away from danger zones.
Make sure you do not wear loose clothing and secure long or loose hair.
Make sure that no persons or objects are within the range of any moving parts of
the machine.
Make sure that users know and observe all safety rules with regard to the machine
and the environment in which it operates.
3.3.5 Maintenance and repair
See also the specific safety regulations for maintenance and repair in section 6.3
For the Prorunner Prmk1: Place the safety locking pin before starting any
maintenance or repair tasks. For specific instructions see the user manual of the
Prmk1.
Turn off the power supply to the machine with the main power supply switch
before starting any maintenance or repair tasks. Secure the main power supply
switch in the off position with a padlock.
Replace damaged or defective parts before putting the machine back into
operation.
Changes and modifications that may affect the safety of the machine can only be
carried out when these changes and modifications comply with the relevant
regulations, legislation, directives and recognized industry standards.
If changes and modifications are outside the scope of specifications given by
Qimarox in this manual and Qimarox has not granted permission changes and
modifications, then the changes and modifications will entirely be the responsibility
of those persons responsible for carrying out the changes and modifications.
Electrical installation tasks must only be carried out by qualified personnel.
Safety devices should never be bypassed or removed.
Remove any tools or objects left on or in the machine before starting the machine.
For the Prorunner Prmk1: Make sure that the safety pin is removed before the
machine is turned on.
prevent damage to the machine.
After having completed maintenance activities, always put all safety provisions
(fencing, covers and other) that have been removed in place again.
Take the appropriate measures for safety when working at heights.
3.3.6 Product quality
A good quality of Product essential for the efficiency and safety of the machine.
Products should be suitable for automated handling. No parts or contents sticking out
that might disrupt the handling or of the Product.
WARNING
Danger of products falling. Unsuitable Products might cause that
product fall from the forks or cause collision
3.4 Safety provisions
3.4.1 Safety equipment
Check the correct operation of the safety devices monthly.

Safety
UM Prorunner PR15 v1.0 EN
15
You must not disassemble, bypass or disable any safety equipment on the
machine.
The machine must not be started and must be immediately taken out of operation
if even a single item of machine safety equipment is defective.
After maintenance tasks are completed, always replace all safety equipment that
has been removed from the machine.
The following safety equipment is part of the machine:
Covers
Safety labels
Emergency stops
Area safety fencing
Safety circuits
Interlocking door switches (and possibly safety light screens)
Some part of the safety equipment may be supplied by the System integrator/OEM.
See the CE installation instructions in in chapter 8. Before the CE Installation
instructions have been met completely, the machine must not be used.
In case of non-compliance with the required safety measures, the EC Declaration of
Conformity will become null and void.
3.4.2 Safety labels
Note
See also the sections about safety labels in the user manuals of the
separate modules.
WARNING
Replace labels on the machine if they become unreadable or damaged.
The following safety labels are present near apertures in the area fencing:
Note
These labels are supplied by System integrator/OEM.

Safety
16
UM Prorunner PR15 v1.0 EN
No entry. Authorised personnel only
oat safety light curtains that can be interrupted during operation.
oat doors that can be opened during operation.
No reaching in
oAt single pallet infeed and outfeed openings (only when necessary).
The following labels icons are present on the control cabinet:
Note
The labels on the control cabinet are supplied by System
integrator/OEM.
Electrical hazard
oif hazardous electrical voltage is present.
Read the Manual before use
oat the main switch of the machine

Safety
UM Prorunner PR15 v1.0 EN
17
3.4.3 Safety fencing
Qimarox requires a protection fenced area around the machine. Any access doors
must be secured with interlocking door switches. When a person enters the fenced
area, the machine must stop immediately.
Openings in the fenced area must be designed such that they protect persons against
reaching the danger zone. When this is not possible, these openings must be
equipped with a safety light curtain.
Interlocking door switches and (if present) safety light curtains must be included in the
safety circuits. Unsafe access must stop the machine immediately.
The safety fencing must be strong enough against the force of a product falling down.
For specific requirements to the safety fencing, see the CE installation instructions in
in chapter 8.
Make sure that the fenced area complies with local law and rules for protection against
danger.
If Qimarox supplies the safety fencing, the specifications will be included in the
machine layout drawing.
Here are examples of the default fencing according to the CE installation instructions:
Default Fening set for
Top in-/outfeed level below 2700mm
Default Fening set for
Top in-/outfeed level above 2700mm

Safety
18
UM Prorunner PR15 v1.0 EN
3.4.4 Safety controls
Performance level
Emergency stops and safety circuits must be designed according to a so-called
Performance Level (PL) corresponding with the current standard for safety functions of
a machine or a machine. For required PL of this machine see the CE installation
instructions in in chapter 8.
Emergency stops
The machine must have one or more emergency stops included in the safety circuits.
When one of the emergency stop buttons is pressed, the main power and air supply
and the control current of the machine are switched off immediately. For specific
requirements, see the CE installation instructions in in chapter 8.
Safety circuit
The machine must have safety circuits. Unsafe access must stop the machine
immediately. For specific requirements, see the CE installation instructions in in
chapter 8.
3.5 Electrical safety
Motor protection relay
Motor protection devices must be set to the nominal motor current. A relay set too low
prevents optimum use of the motor. A relay set too high does not guarantee full
thermal protection.
Thermistor protection (TF contact)
For motors that are frequently started and stopped, intermittently operated, use a high
switching frequency or power controller, it is essential to use a motor protection relay
and thermistor protection. This is to avoid prematurely switching the motor protection
relay or overheating of the motor winding in these operational conditions.
3.6 Sound level
The A-weighted emission sound pressure level LpA at workstations does not exceed
70dB(A).
Note
The sound pressure level applies to typical products made of cardboard
or plastic. Products made of other materials might increase the sound
level.
3.7 Personal safety
For your own safety use personal protective equipment.
Always wear proper personal protective equipment when working with, on or near the
machine.
The following table gives an overview of the required personal protective equipment

Safety
UM Prorunner PR15 v1.0 EN
19
Safety sign
Description
When required
Protective clothing. No
loose clothing or long
hair.
Maintenance
Cleaning
Foot protection
Production
Maintenance
Cleaning
3.8 Residual risks
The machine is intended to be integrated into an automated palletizing or pallet
conveyor system.
Qimarox has attempted to protect against as many hazards as possible, either though
inherent safe design or by shielding off the dangers. Machine users should be aware
of the following residual risks before working with the machine:
3.8.1 Falling of products
Products can fall from the vertical conveyor's carrier and from the infeed and outfeed
conveyors. The risk of this happening is determined by the combination of product
(nature and quality), the way of stacking (stacking pattern), and the setup and settings
of the machine.
In spite of the mandatory area fencing, products can fall outside the fences. The can
also be deflected and change direction by other product or machine parts during their
fall. The danger is also present during the correction of faults, when the area fencing is
accessed by an operator.
The system integrator and operator must determine, before putting the machine into
operation, whether the risk of falling products acceptable.
The following influences ensure that the risk of falling product remains small:
A stable, good quality product suitable for automatic handling and transport. See
specification sheet.
A well set up machine (horizontal transportation surfaces, no height differences).
A machine properly set up for the product.
Low speeds and accelerations.
The following influences increase the risk of a falling pallet or pallet load:
Product outside the machine's specifications. See specification sheet.
Products unstable or of poor quality.
High speeds and accelerations. An abrupt stop due to motor brake application.

Safety
20
UM Prorunner PR15 v1.0 EN
One can reduce the risk of injury with the following measures:
Area fencing (mandatory) of sufficient height and strength. If necessary, shielding
or nets on the underside of high level conveyors as well.
Area fencing (mandatory) at a sufficient distance of the falling products. Entering
the fencing must block the machine.
Wearing a safety helmet when entering the fenced area at floor level, near the
pallet elevator.
3.9 Machine end of life and disposal
Proper use and maintenance of the machine will not involve any environmental risks.
When the machine is no longer useable, the machine should be dismantled and
disposed of in an environmentally responsible manner.
WARNING
Observe all relevant legislation, regulations, instructions and
precautions with regard to health and safety when dismantling the
machine.
Observe all relevant legislation, regulations, instructions and
precautions with regard to the disposal of products in the environment.
3.10 Overload tests
Before first putting into service, a static and dynamic overload test on the vertical
conveyors Prorunner Prmk1 and Prorunner Prmk5 must be carried out. See for details
the user manuals of these machines.
A new static and dynamic overload test may be necessary after complete disassembly
of the machine or after replacing critical parts.
