QIWU iGPSPORT iGS10 User manual

1
USER MANUAL
iGS10 GPS CYCLING COMPUTER
www.igpsport.com
WUHAN QIWU TECHNOLOGY CO., LTD

2
1. STANDARD PACKAGE INCLUDES
iGS10 x1
Micro USB Cable x1
User Manual x1
Standard Bike Mount x1
Bike Mount Pad x1
O-Ring Band x2
2. BUTTONS
Display in metric unit Display in imperial unit
Power on
Select left button
Record/Pause
Select left button to Record/Pause
Power off
Hold left button more than 2 seconds
Forced shutdown
Hold left button more than 10 seconds
Switch display
Select right button to switch data pages
Enter the setting mode
Hold right button more than 2 seconds to enter the setting mode

3
STATUS ICONS
Full battery
Mid-capacity battery
Low battery
out of battery and will shut off automatically soon
Recording
Pause
No satellite signals
Normal satellite signals
Strong satellite signals
Bluetooth
Speed sensor
3. INSTALLATION OF BIKE MOUNT

4
4. ACQUIRING SATELLITE SIGNALS AND TIME SETTING
Please make sure iGS10 is outdoor and under a clear view of the sky.
Usually it may take 5 to 120 seconds to locate satellite signals.
Remain stationary when acquiring satellite signals.
The time and date will be calibrated automatically after locate satellite signals.
5. SMART BACKLIGHT
iGS10 will automatically calculate the sunrise and sunset time based on the GPS
position.
Backlight turns on before sunset and turns off after sunrise automatically.
When backlight is off, select any button to turn on backlight for 15 seconds.
6. BATTERY
Warning: Keep iGS10 far away from the fire.
Battery type
Rechargeable, built-in lithium-ion battery
Battery life
About 25 hours, typical usage
Operating temperature range
From -10ºto 50 ºC (14ºto 122 ºF )
Charging temperature range
From -10ºto 50 ºC (14ºto 122 ºF )
Input
DC5V, 500mA
Charging time
2.5 Hours
Note：
1) Please use DC 5V power adapter for charging.
2) As the temperature drops, the battery life will decrease.
3) iGS10 support charging during use.
4) Do not overstretch the USB plug for keeping waterproof and dustproof.
7. SEARCHING AND CONNECTING ANT+ SENSORS (SETTING MODE E1)

5
iGS10 can be used with ANT+ sensor as below: heart rate monitor, cadence sensor, speed
sensor, cadence and speed combined sensor
Please search the ANT+ sensors When first time using ANT+ sensors.
Steps：
1) Wake up ANT+ sensors.
Heart rate monitor should be worn directly on skin just around the chest
Cadence sensor should be installed on the crank arm of no-drive side, then rotate the
crank arm
Speed sensor should be installed on the top of front wheel hub, then rotate the front
wheel
2) Hold right button more than 2 seconds to enter the setting mode.
3) Select right button to scroll setting mode from E1 to E4.

6
4) Select left button to enter E1 mode when E1 is flashing.
5) iGS10 will search ANT+ sensors automatically.
5) When sensors are connected, the icons will light up.
6) iGS10 will exit searching sensors mode in 20 seconds.
Note：
1) iGS10 will automatically connect the sensors that have been connected.
2) It is required to search the sensor again after battery is replaced.
8. SETTING THE WHEEL SIZE & CIRCUMFERENCE (SETTING MODE E2)
Please set the wheel circumference if you use a speed sensor.
Default wheel circumference: 2096mm
Steps:
1) Hold right button more than 2 seconds to enter the setting mode.
2) Select right button to scroll setting mode from E1 to E4.
3) Select left button to enter E2 mode when E2 is flashing.
4) Select left button to change numerical digits, select right button to change numerical
value.
5) Hold right button more than 2 seconds to save and exit.

7
Note:
1) The unit of wheel circumference is mm.
2) The setting will be automatically saved if no operation in 10 seconds.
Common wheel size and circumference:
Wheel Size
L (mm)
Wheel Size
L (mm)
12 × 1.75
935
26 × 1.75
2023
14 × 1.5
1020
26 × 1.95
2050
14 × 1.75
1055
26 × 2.00
2055
16 × 1.5
1185
26 × 2.10
2068
16 × 1.75
1195
26 × 2.125
2070
18 × 1.5
1340
26 × 2.35
2083
18 × 1.75
1350
26 × 3.00
2170
20 × 1.75
1515
27 × 1
2145
20 × 1-3/8
1615
27 × 1-1/8
2155
22 × 1-3/8
1770
27 × 1-1/4
2161
22 × 1-1/2
1785
27 × 1-3/8
2169
24 × 1
1753
650 × 35A
2090
24×3/4 Tubular
1785
650 × 38A
2125
24 × 1-1/8
1795
650 × 38B
2105
24 × 1-1/4
1905
700 × 18C
2070
24 × 1.75
1890
700 × 19C
2080
24 × 2.00
1925
700 × 20C
2086
24 × 2.125
1965
700 × 23C
2096
26 × 7/8
1920
700 × 25C
2105
26 × 1(59)
1913
700 × 28C
2136
26 × 1(65)
1952
700 × 30C
2170
26 × 1.25
1953
700 × 32C
2155
26 × 1-1/8
1970
700C Tubular
2130
26 × 1-3/8
2068
700 × 35C
2168
26 × 1-1/2
2100
700 × 38C
2180
26 × 1.40
2005
700 × 40C
2200
26 × 1.50
2010

8
9. SETTING TIME ZONE (SETTING MODE E3)
Default time zone: UTC/GMT+08:00.
Steps:
1) Hold right button more than 2 seconds to enter the setting mode.
2) Select right button to scroll setting mode from E1 to E4.
3) Select left button to enter E3 mode when E3 is flashing.
4) Select left button to change digits of hour and minute, select right button to change
value.
5) Hold right button more than 2 seconds to save and exit.
Note:
The setting will be automatically saved if no operation in 10 seconds.
10. SETTING METRIC AND IMPERIAL UNITS (SETTING MODE E4)
Default unit: metric (kilometer)
Steps:
1) Hold right button more than 2 seconds to enter the setting mode.
2) Select right button to scroll setting mode from E1 to E4.
3) Select left button to enter E4 mode when E4 flashing.
4) Select right button to switch metric (kilometer) and imperial (mile) unit.

9
5) Hold right button more than 2 seconds to save and exit.
Note:
The setting will be automatically saved if no operation in 10 seconds.
11. CONNECTING TO SMART PHONE APP
Android Smart Phone
Requirements: Android 5.0 or above, built-in Bluetooth 4.0 BLE.
Download "iGPSPORT" App in Google Play App Store.
iPhone:
Requirements: iPhone 5s/iOS 9.0 or above (incompatible with iPad).
Download "iGPSPORT" APP in Apple App Store.
Steps:
1) Power on iGS10, its Bluetooth is always ready for connection.
2) Turn on smart phone’s Bluetooth, then open “iGPSPORT” App.
3) Enter the Device menu, click , found "iGS10" and click it to connect.
4) iGS10's Bluetooth icon lights up means it is connected with smart phone.
5) Then choose the files to upload.
12. UPLOAD FILES TO COMPUTER AND WEBSITE
1) Power off iGS10.
2) Connect iGS10 to your computer via USB cable.
3) Select left button to enter connection mode, then battery icon lights up.
4) Computer will recognize iGS10 as a new disk, then copy the activity files in folder as
below :\iGPSPORT\Activities\***.fit to computer.
5) Login http://i.igpsport.com, select fit format files to upload.
Note:
1. iGS10 can store about 90 hours’ riding files, when memory is not enough, it will delete the
earliest file automatically. Please upload, backup and delete the files regularly.
2. The files can be upload to www.strava.com or other website which support fit format files.
13. FACTORY RESET
Steps:
1) Power off iGS10.
2) Connect iGS10 to power adaptor by USB cable.

10
3) Hold left and right button at the same time more than 5 seconds until “FA”display on
the screen.
4) Disconnect iGS10 to power adaptor.
Note:
Factory reset will clear out all data, please backup activity files before factory reset.
14. SPECIFICATIONS
GPS
High sensitive GPS
Screen
3.0x3.8cm, High brightness, high contrast, anti-glare screen
Temperature
-10°C ~50°C (14 ºto 122 ºF )
Weight
About 57.3g
Physical dimensions
48×75×20mm
Waterproof
IPX6
Data display
12 items of data: Speed、Average Speed、Max Speed、Time、
Trip Time、Date、Distance、Calorie、Odometer、Gradient、
Temperature、Altitude
when sensors connected, add 6 items of data: Cadence, Average
Cadence, Max Cadence, Heart Rate, Average Heart Rate, Max
Heart Rate, hide 2 items of data:Trip Time, Date
Memory
About 90 hours data (Depend on the memory usage)
Battery
About 25 hours, typical usage
ANT+
Support ANT+ Heart Rate, Speed Sensor, Cadence Sensor, Cadence
and Speed Combined Sensor
Note: do not support Power Meter
Interface
Micro USB
Wireless
transmission
Bluetooth 4.0
Support connecting to smart phone App, do not support
connecting to Bluetooth sensors
Package include
iGS10 x1、Micro USB Cable x1、User Manual x1、

11
Standard Bike Mount x1 、Bike Mount Pad x1、
O-Ring Band x2
15. ABBREVIATION
AVG
Average
CAL
Calories
TEM
Temperature
MAX
Maximum
ODO
Odometer (Total distance)
ALT
Altitude
DST
Distance
GRA
Gradient
16. CONTACT US
Official Website: www.igpsport.com
Manufacturer: Wuhan Qiwu Technology Co., Ltd
ADD: Hongshan District, Wuhan City, Hubei Province, China.
Tel：[phone]
Email: [e-mail], servi[email protected]
statement :
The user manual is only for users’ reference, if any differences between it and device, please
subject to device. We reserves the right to change or improve our products and to make changes
in the content of this manual without obligation to notify any person or organization of such
changes or improvements. All rights reserved by Wuhan Qiwu Technology Company, Ltd.
