Qlight SN-1 User manual

5025
55
100
HORN
1
Small Size Electric Horn
SN-1
SN-1 - 12
[Model number] [Voltage]
| |
• SN-1 • 12 - DC12V
• 24 - DC24V
Please scan the QR code for more
detailed product information.
www.qlight.com
Product SpecicationsOrdering Specications
Precautions for Safety
Failure to follow the instructions below may cause a loss of life or serious physical injury.
1. Please remove any objects that can interrupt ventilation around the product.
2. Please turn o-• the power of the product immediately if it fails to operate properly.
3. Carefully wire the product according to each product’s speci¿cation.
4. Please be careful in preventing chemicals such as thinner, benzene, etc. in contact with the surface of the product.
5. Do not apply excessive force/impact to the product.
6. Failure to follow any of the instructions above may cause malfunction or damage to the product, ¿re, and electric shock.
Precautions for Correct Use
Failure to follow the proper instructions may cause damage to property, the product, or malfunction of the product
that would void the warranty.
1. During wiring or maintenance, please completely turn o-• the power of the product. (Failure to follow this may lead to an electric shock.)
2. Do not install the product in locations that subjects it to excessive dust or water other than the conditions designated by the IP protection
    ratings indicated for each product. (Failure to follow these instructions may cause a ¿re to the product, electric shock, physical injury,
    malfunction or damage to the product.)
3. Do not alter or repair this product. If maintenance or repair service is required, please contact your local Qlight contact point. (Failure to
    follow these instructions may lead to ¿re, electric shock, or product damage.)
4. Please apply the correct voltage to the product. (Failure to follow these instructions may lead to ¿re, electric shock, or product damage.)
5. When the product is applied to a condition that may impact lives or property, please make sure to have a double safety device. (Failure to
    follow this may cause damage to property, ¿re, electric shock and loss of life.)
Thank you for purchasing Qlight’s products. Please read this user manual carefully
prior to installation and operation to ensure safe and correct use.
Model
number
Voltage Current Sound pattern and volume Certi¿cate Weight
SN-1
DC12V 0.170A
• WS-1 Warning Sounds
: Max.100dB
-0.88kg
DC24V 0.220A
• Protection rating : IP55
• Ambient operating temperature : -25°C to +50°C

2
SN-1
SN-1
Ø133
Ø10 CABLE ENTRY
4-Ø5 HOLES
141
5
8
104.5
64
48
72 88
71
• First, machine taps or holes on the mounting surface .
• The mounting hole of this product is 5 mm in diameter.
• When machining taps, fasten the bolt through the mounting hole
of the product.
• When machining holes, insert the bolt through the hole of the
product, and tighten the nut from the opposite side of the mounting
surface
• When assembling using bolt and nut, please make sure to use at
washer and spring washer.
• When adjusting the phase and lower angle of the mixed housing (signalling angle) after product cancellation Loosen the bracket
  ¿xing bolts(
①
) on the side of the product slightly to adjust the desired angle.
■ Adjusting the Angle of the Horn housing
Housing
(Steel)
Bracket(Steel)
①
Housing ring
(Steel)
Dimensions
(Units : mm)
Parts Denition/ Installation/ Adjusting the Angle of the Horn housing
■
Parts Denition
/
Installation
Wiring Instructions
• External power line - UL1015 AWG18(0.75sq) x 2C 400m m
PowerFuse
White(W)
Black(BK)
DC

3
Installation Environment and Protection Rating
• This product is designed for use with protection rating of IP55.
• If the product is installed in locations that subject it to excessive dust or water other than the designated IP protection rating
   indicated(IP55), it may cause malfunction or damage to the product.
• For further information, please visit our website (vwww.qlight.com).
Mounting Hole Specications
• Machine holes on the mounting surface referring to the diagram below.
4-Ø6 HOLES
72
48
Precautions for installation
• In case of outdoor applications, install the product in the upright
position. Do not install the product horizontal or upside-down
positions where water can potentially penetrate into the product
and impact it’s operation.
Left directionReverse direction Right direction



[Installation]
