CX254
CX SPECIFICATIONS
–
8 ohms 0.05% THD 20 Hz-20 kHz
4 ohms 0.05% THD 20 Hz-20 kHz
2 ohms 1% THD 1 kHz
70V 0.05% THD 20 Hz-20 kHz
70V 0.05% THD 1 kHz
70V 1% THD 1 kHz
16 ohms 0.1% THD 20 Hz-20 kHz
8 ohms 0.1% THD 20 Hz-20 kHz
4 ohms 1% THD 1 kHz
140V 0.1% THD 20 Hz-20 kHz
140V 0.05% THD 1 kHz
140V 1% THD 1 kHz
Distortion (SMPTE-IM)
–
– 450 Watts not recommended
250 Watts 400 Watts†
170 Watts 250 Watts
200 Watts –
–
–
220 Watts
300 Watts
400 Watts
440 Watts
600 Watts
–
–
–
–
–
–
–
–
–
CX404
Stereo Mode (all channels driven)
Bridge Mono Mode
–
–500 Watts 800 Watts†
– 900 Watts not recommended
340 Watts 500 Watts
Less than 0.02% Less than 0.01% Less than 0.01%
Noise (20Hz-20kHz)
Input Sensitivity
Gain (for full-rated output power)
Input Clipping
Output Circuitry
-105 dB -106 dB -106 dB
1.26 Vrms 1.22 Vrms 1.22 Vrms
35 dB @ 70.7v
10 Vrms (+22 dB)
29 dB @ 8 ohms
10 Vrms (+22 dB)
31 dB @ 8 ohms
10 Vrms (+22 dB)
Class AB+B Class AB+B Class AB+B
CX204V
Continuous Average Output Power Per Channel
Bridge-Mono Mode Operation
Distortion (typical)
Frequency Response
Damping Factor
Input Impedance
Connectors
Cooling
20 Hz-20 kHz: 10 dB below rated power
1.0 kHz and below: full rated power
Less than 0.01% THD
Less than 0.01% THD
20 Hz-20 kHz, ± 0.2 dB 8 Hz-50 kHz, +0/-3 dB
Greater than 500 (1 kHz and below)
6 KΩunbalanced, 12 KΩbalanced
Input: 3 position Euro-style detachable barrier block, Ch 1,2,3 & 4 DataPort: HD-15 Connector, Ch 1+2, Ch 3+4
Output: Six-position barrier strip with monitor connections, Ch 1+2, Ch 3+4
Variable speed fan, rear-to-front airflow through tunnel heat sink
All models All models
Amplifier Protection
Load Protection
Dimensions
Weight
Power Requirements
Full short circuit, open circuit, thermal, ultrasonic, and RF protection. Stable into reactive or mismatched loads
On/off muting, DC-fault power supply shutdown
19" (48.3 cm) rack mounting, 3.5" (8.9 cm) tall (2 rack spaces), 14" (35.6 cm) deep (from front mounting rails)
21 lb (9.5 kg) net, 27 lbs (12.3 kg) shipping
100, 120, 230 Vac, 50-60 Hz
Controls
Indicators
Front: AC switch, Ch.1 and Ch.2 gain knobs
Rear: DIP switch for Ch.1 and Ch.2: clip limiter on/off, LF filter on/off, LF filter freq select 33 Hz or 75 Hz
for non-V models; 50 Hz or 75 Hz for V models; inputs parallel or stereo; bridge mode
PWR-ON: Green LED LEVEL -20 dB: Green LED (1 per channel)
BRIDGED: Yellow LED LEVEL -10 dB: Green LED (1 per channel)
PARALLEL INPUTS: Yellow LED CLIP/PROT: Red LED (1 per channel)
SIGNAL -35dB: Green LED (1 per channel)
QSC Audio Inc. 1675 MacArthur Boulevard • Costa Mesa, CA 92626 •Ph: 800/854-4079 or 714/957-7100 •Fax: 714/754-6174 • www.qscaudio.com
† (0.1% THD 1 kHz)
Idle
1/8 Average Power*
(typical of program material
at maximum unclipped power)
*Pink noise
1/3 Average Power*
(typical of program material
with severe clipping)
*Pink noise
8 ohms
8 ohms
4 ohms
4 ohms
2 ohms
70 Volts
2 ohms
70 Volts
0.7 A
5.8 A
9.2 A
14.3 A
8.8 A
14.2 A
21.7 A
–
–
–
–
–
–
–
–
12.7 A
8.3 A
0.8 A
CX204V CX254 CX404
8.1 A
12.4 A
not rated
12.2 A
19.3 A
not rated
–
0.7 A
–
120V CURRENT CONSUMPTION
Multiply currents by 0.5 for 230V units.
CX 4-Channel Spec Sheet 11/08/01
