QSC YM-300 User manual

Yoke Mount Bracket
User Manual
QSC Cinema Surround Loudspeakers Mounting Yokes
YM-300 for SR-8101, SR-8100, SR-18 and SR-110B loudspeakers
YM-360 for SR-26 loudspeakers only
YM-46 for SR-8200, SR-26 and SR-46 loudspeakers
YM-400 for SR-1020 and SR-1030 loudspeakers
TD-000376-00-A
*TD-000376-00*

2
TD-000376-00-A
EXPLANATION OF SYMBOLS
The term “WARNING!” indicates instructions regarding personal safety. If the instructions are not followed the result may be bodily injury or death.
The term “CAUTION!” indicates instructions regarding possible damage to physical equipment. If these instructions are not followed, it may result in
damage to the equipment that may not be covered under the warranty.
The term “IMPORTANT!” indicates instructions or information that are vital to the successful completion of the procedure.
The term "NOTE" is used to indicate additional useful information.
The intent of the lightning flash with arrowhead symbol in a triangle is to alert the user to the presence of un-insulated "dangerous"
voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to humans.
The intent of the exclamation point within an equilateral triangle is to alert the user to the presence of important safety, and operating
and maintenance instructions in this manual.
IMPORTANT SAFETY INSTRUCTIONS
WARNING!: Before placing, installing, rigging, or suspending any speaker product, inspect all hardware, suspension, cabinets,
transducers, brackets and associated equipment for damage. Any missing, corroded, deformed or non-load rated component
could significantly reduce the strength of the installation, placement, or array. Any such condition severely reduces the safety
of the installation and should be immediately corrected. Use only hardware which is rated for the loading conditions of the
installation and any possible short-term unexpected overloading. Never exceed the rating of the hardware or equipment. Consult
a licensed, professional engineer when any doubt or questions arise regarding a physical equipment installation.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Clean only with a dry cloth.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
• Only use attachments/accessories specified by the manufacturer.
• Adhere to all applicable, local codes.
• Consult a licensed, professional engineer when any doubt or questions arise regarding a physical equipment installation.
Warranty (USA only; other countries, see your dealer or distributor)
QSC Audio Products 3 Year Limited Warranty
QSC Audio Products, LLC (”QSC”) guarantees its products to be free from defective material and/or workmanship and will replace defective parts
and repair malfunctioning products under this warranty when the defect occurs under normal installation and use, provided the unit is returned to
our factory, one of our authorized service stations or an authorized QSC International Distributor via pre-paid transportation with a copy of proof
of purchase (i.e., sales receipt). This warranty provides that the examination of the return product must indicate, in our judgment, a manufacturing
defect. This warranty does not extend to any product which has been subjected to misuse, neglect, accident, improper installation, or where the
date code has been removed or defaced. QSC shall not be liable for incidental and/or consequential damages. This warranty gives you specific legal
rights. This limited warranty is freely transferable during the term of the warranty period. The warranty on QSC products is NOT VALID if the products
have been purchased from an unauthorized dealer/online e-tailer, or if the original factory serial number has been removed, defaced, or replaced in
any way. Damage to, or loss of any software or data residing on the product is not covered. When providing repair or replacement service, QSC will
use reasonable efforts to reinstall the product’s original software configuration and subsequent update releases, but will not provide any recovery or
transfer of software or data contained on the serviced unit not originally included in the product.
Customers may have additional rights, which vary from state to state or from country to country. In the event that a provision of this limited warranty is
void, prohibited or superseded by local laws, the remaining provisions shall remain in effect.
The QSC limited warranty is valid for a period of three (3) years from date of purchase in the United States and many (but not all)
other countries.
For QSC warranty information in countries other than the United States, contact your authorized QSC international distributor. A list of QSC
International distributors is available at www.qscaudio.com.
To register your QSC product online, go to www.qscaudio.com and select ”Product Registration”. Other questions regarding this warranty can be
answered by calling, e-mailing or contacting your authorized QSC distributor.
Phone: [phone] within US and Canada, [phone] international, Email: [email protected], Website: www.qscaudio.com.

3TD-000376-00-A
Unpacking
Quantity Description
1Bracket, YM-300, YM-360, YM-400 or YM-46
2Gasket, self-adhesive
The following is included with the loudspeaker
2Socket head cap screw, low-head
YM-300 for SR-8101, SR-8100, SR-18 and SR-110B loudspeakers
YM-360 for SR-26 loudspeakers only
YM-46 for SR-8200, SR-26 and SR-46 loudspeakers
YM-400 for SR-1020 and SR-1030 loudspeakers
Installation Instructions
These brackets are designed for QSC’s SR-series cinema surround loudspeakers. Read the instructions before
beginning. Follow these instructions carefully.
Installing loudspeakers must be performed by experienced professionals. Incorrectly installed loudspeakers may
result in property damage, injury or death.
WARNING!: Before placing, installing, rigging, or suspending any speaker product, inspect all
hardware, suspension, cabinets, transducers, brackets and associated equipment for damage.
Any missing, corroded, deformed or non-load rated component could significantly reduce the
strength of the installation, placement, or array. Any such condition severely reduces the safety
of the installation and should be immediately corrected. Use only hardware which is rated for the
loading conditions of the installation and any possible short-term unexpected overloading. Never
exceed the rating of the hardware or equipment. Consult a licensed, professional engineer when
any doubt or questions arise regarding a physical equipment installation.
1. Locate mounting area where the loudspeaker will be installed. It must be a structurally sound area with adequate
strength to support at least five times the weight of the loudspeaker.
2. Using the bracket as a template, mark the bracket's slots onto the mounting surface. Select and install the appropriate
mounting hardware (not included). If you are not sure about the correct hardware for the mounting surface, consult a
hardware specialist. Ensure the bracket is secured to the mounting surface before attaching the loudspeaker.
3. Decide which mounting holes to use for attaching the loudspeaker. For wall mounted installations use the
open slots. For ceiling mounted applications, do not use the open arm slots. Attach the loudspeaker to the
bracket using the captive holes only for ceiling installations.
4. Remove the non-stick backing from each gasket and stick the gasket to the inner surface of each arm of the
bracket with its holes and slot aligned (Figure 1).
5. Do one of the following:
a. If using the open slots, install the mounting screws, washers and split lock washers by threading the screws
in about half way. Lift the loudspeaker into place and align the screws with the open slots (Figure 2); set in
place and hand-tighten the screws. Tilt the loudspeaker to the desired angle and tighten screws securely. For
more permanent installation use the captive holes.
b. If using the captive holes, have an assistant lift the loudspeaker into place and install the screws through the
appropriate captive holes (Figure 3) and hand-tighten. Tilt the loudspeaker to the desired angle and tighten
the screws securely.
— Figure 1 —
— Figure 2 —
— Figure 3 —

4
TD-000376-00-A
Mailing Address:
QSC Audio Products, LLC
1675 MacArthur Boulevard
Costa Mesa, CA 92626-1468 USA
Telephone Numbers:
Main Number: [phone]
Sales & Marketing: [phone] or toll free (USA only) [phone]
Customer Service: [phone] or toll free (USA only) [phone]
Facsimile Numbers:
Sales & Marketing FAX: [phone]
Customer Service FAX: [phone]
World Wide Web:
www.qscaudio.com
E-mail:
[email protected]
[email protected]
© 2011 QSC Audio Products, LLC. All rights reserved. QSC™ and the QSC logo are registered trademarks of QSC Audio Products, LLC in the U.S. Patent and Trademark office and
other countries. All other trademarks are the property of their respective owners. US and Worldwide Patents pending.
