USER GUIDE
The Qstik VQ660 Stereo Bluetooth® Headset
With Revolutionary User Exposure Alert and Bass-Boost Features
Thank you for purchasing the Qstik VQ660 Bluetooth® A2DP Stereo Headset. We hope you
have hours of fun listening to your favorite music without missing a call from your mobile!
Please make the most of your headset by reading this instruction manual.
Qstik plc
A Clement Clarke Company
Unit A, Cartel Business Estate
Edinburgh Way
Harlow
Essex CM20 2TT
United Kingdom.
Tel: [phone]
Fax: [phone]
Email: [email protected]

© Copyright 2005 – 2007 Qstik plc. www.qstik.com
The Bluetooth word mark and logos are owned by the Bluetooth SIG Inc. and any use of such marks by Qstik is under licence.
Contents:
Contents:............................................................................................................................... 2
Warnings: ............................................................................................................................. 3
Notes: ................................................................................................................................... 3
Looking after your headset:................................................................................................... 3
Qstik VQ660 headset at a glance… ....................................................................................... 4
Specification: ........................................................................................................................ 4
1. Getting started ............................................................................................................... 5
1.1. Headset operating features: .................................................................................... 5
2. Charging your headset................................................................................................... 5
2.1. Low battery warning.............................................................................................. 5
3. Powering your headset .................................................................................................. 6
4. Pairing your headset ...................................................................................................... 6
4.1. Pairing your VQ660 with a mobile phone .............................................................. 6
4.2. Pairing your VQ660 with a music device or PC/Laptop ......................................... 6
4.3. Delete all pairing data............................................................................................... 7
5. Using your headset ........................................................................................................ 7
5.1. Volume control .......................................................................................................... 7
5.2. Telephony functions .............................................................................................. 7
5.3. Music streaming functions ..................................................................................... 8
5.4. VQ660 special feature – User Exposure Alert ........................................................ 9
5.5. VQ660 special feature – Base-Boost...................................................................... 9
5.6. Answering a call while playing music.................................................................... 9
5.7. Headset status indicator light ................................................................................. 9
6. Troubleshooting .......................................................................................................... 10
7. Certification & Safety approvals.................................................................................. 11
8. Warranty ..................................................................................................................... 12
Qstik plc reserves the right to change the contents of this user guide without prior notice.

© Copyright 2005 – 2007 Qstik plc. www.qstik.com
The Bluetooth word mark and logos are owned by the Bluetooth SIG Inc. and any use of such marks by Qstik is under licence.
Warnings:
Driving: use of stereo headset covering both ears while driving is not permitted in many
countries and many states in the USA. Please ensure you comply with local law and drive
safely. If you are driving in difficult road conditions then please park the car in a suitable
place before using your mobile phone.
Excessive noise exposure: Using Bluetooth® headsets at high volume levels can damage
your hearing. The risk to hearing damage increases substantially when listening to high
volume levels for extended periods of time. The VQ660 headset has digital sound level
monitoring and alert technology to maximise your hearing protection. The User Exposure
Alert (UEA) feature constantly calculates the overall sound output through the headset
speakers and gives a warning (an alert) when the average daily exposure through the headset
reaches a pre-defined level. The warning is in the form of a notification with a short message.
The message is repeated every 5 minutes until the UEA feature is either acknowledged or
deactivated by the user.
Notes:
Other Qstik products, such as the AS360 USB dongle, referred to in this user guide are
available for sale at the time of launching the VQ660 headset. Such products may
subsequently be out of stock or obsolete.
Looking after your headset:
Your headset is manufactured to the highest standards for comfort and durability. You can
extend the life of your headset by taking the following steps:
If you are not using your VQ660 headset for a period of time, then ensure your
headset is powered off and stored in a safe and dry place.
Avoid exposing your headset to extreme conditions including very high temperatures
such as direct sunlight in a car; very low temperatures (-10°C/14°F); or continuous
exposure to moisture or high humidity. Such conditions can shorten battery life,
degrade performance and adversely affect the operation of your headset.
Do not submerge your headset in water or expose your headset to heavy rain.

© Copyright 2005 – 2007 Qstik plc. www.qstik.com
The Bluetooth word mark and logos are owned by the Bluetooth SIG Inc. and any use of such marks by Qstik is under licence.
Qstik VQ660 headset at a glance…
The Qstik VQ660 lets you connect wirelessly to one or two devices for telephony and high
quality A2DP music streaming.
Specification:
Talk-time Up to 10 Hours
Music streaming time > 9Hours (dependent on volume levels)
Standby time Approx. 220 Hours
Recharge time Approx. 3Hours *
Bluetooth® technology Bluetooth® Ver 2.1+EDR
Bluetooth® device classification Class II
Operating range Up to 10 meters
Bluetooth® profiles supported Advanced Audio Distribution Profile (A2DP)
Audio Video Remote Control (AVRCP)
Headset Profile(HSP)
Hands-Free Profile (HFP)
Microphone type Omni-Directional **
Battery capacity & type 300mAh Li-Polymer
Weight 120 grams
* Recharge time may take longer if charged via USB port on PC/Laptop.
** The microphone is positioned in the right-hand ear-cup.
Multi-Function Button (MFB)
play / pause / stop button
answer / end button
Volume up / down
(Vol+/-)
Next track / fast-forward
(FF)
P
revious track
/ r
ewind
(RW)
Indicator light
Speaker / ear-cushion
Microphone
channel
Reset button
Mini-USB charging socket

© Copyright 2005 – 2007 Qstik plc. www.qstik.com
The Bluetooth word mark and logos are owned by the Bluetooth SIG Inc. and any use of such marks by Qstik is under licence.
1. Getting started
1.1. Headset operating features:
Your VQ660 headset is Bluetooth® Ver 2.1+EDR compliant. The VQ660 headset supports
the following music and telephony functions.
Music streaming features Telephony features
play, pause, stop, next / previous track
fast forward, rewind
pause music to answer call
answer / end / reject call
reject call, last number redial
voice dialing, call waiting
Please note some mobile phones (services) or some music devices (including some
applications on the PC may not support all the features available on your VQ660 headset.
The operation of buttons on the Qstik VQ660 is designed to be intuitive and easy to
remember. The buttons perform different functions depending on how long and how many
times you press the buttons as shown in the following table:
Action Method
Once Press momentarily and release
Twice Press twice repeatedly
2 seconds Press and hold for 2 seconds
5 seconds Press and hold for 5 seconds
10 seconds Press and hold for 10 seconds
(Only used to delete all pairing data)
2. Charging your headset
Please ensure your Qstik VQ660 headset is on charge for at least 4hours before first use.
Subsequent charges should take approximately 3hours. Use only the USB cable (or mains
charger) provided with your headset.
Connect the charger cable to the mini-USB charging socket on your headset first (see Figure
above) before connecting the USB cable to your PC/Laptop (or connecting the mains charger
to the wall socket). The indicator light on your headset turns to solid Red when the headset is
charging, and turns off when the battery is fully charged.
You can use your headset for listening to music or telephony while your headset is on charge.
In this case the headset will charge at a slower rate than normal.
2.1. Low battery warning
A slow flashing Red light indicates when your battery is low and needs re-charging. When
the Red light starts flashing, the headset has approximately 15 minutes talk time (or music
streaming time) remaining.

© Copyright 2005 – 2007 Qstik plc. www.qstik.com
The Bluetooth word mark and logos are owned by the Bluetooth SIG Inc. and any use of such marks by Qstik is under licence.
3. Powering your headset
Press and hold the MFB (multi-function button) for 2seconds to turn the headset ON. The
headset is ready for use when the status indicator light flashes Blue 3times repeatedly. If you
are wearing the headset, you will hear a beep when the power turns on. The status indicator
then continues to flash Blue every 3seconds to confirm your headset is “ready-to-use”.
Press and hold the MFB for 5seconds to turn the headset OFF. The headset will be switched
off when the status indicator flashes Amber. If you are wearing your headset, you will hear a
beep when it turns off. The status indicator light then remains off.
4. Pairing your headset
Your headset can be paired with several Bluetooth®-enabled devices such as mobile phones,
MP3 players or other music devices, but cannot simultaneously interact with more than one
device at a time when using telephony profile or music streaming profile. Your headset
prioritizes the telephony function over the music, automatically switching to the phone when
you make or receive a call. Once the call has ended, the headset reverts back to music
automatically.
4.1. Pairing your VQ660 with a mobile phone
•Start with your headset turned off. Press and hold the MFB for 5 seconds until the
indicator light flashes Amber repeatedly confirming your headset is in pairing mode. You
have about 2minutes to complete the pairing process. You can end pairing mode at any
time by pressing the MFB momentarily.
•Set your Bluetooth®-enabled mobile phone to discover the Qstik VQ660 headset and
complete the pairing process by following the instructions in your phone user guide.
These are normally found under “Bluetooth® > Setup > Add device > Connect” menus.
•Your phone should find your headset and display the name “QstikVQ660”. Select and
accept your headset. If asked for a PIN or passkey, enter “8888”.
•On successful pairing, the indicator light reverts to flashing Blue every 3seconds to
confirm your headset is “ready-to-use”. If paired and successfully connected with your
mobile phone, all voice communications will be diverted through the Bluetooth®
interface to your headset. If pairing was unsuccessful then repeat the steps above.
4.2. Pairing your VQ660 with a music device or PC/Laptop
Once paired with your mobile phone, you need to pair the headset with your music device
such as Bluetooth®-enabled MP3 player or Bluetooth® stereo adaptor for your PC/Laptop.
Pairing with a music device uses the A2DP and the AVRCP profiles, which enables high
quality music streaming to your headset as well as remote control features. This is only
possible if the music streaming device and application support these profiles.
You can use your VQ660 headset with your PC/Laptop for Voice over IP (VoIP)
communication or listening to high quality stereo music by using an A2DP-compliant
Bluetooth® USB adapter (dongle) and software, such as Qstik’s AS360 USB dongle.

© Copyright 2005 – 2007 Qstik plc. www.qstik.com
The Bluetooth word mark and logos are owned by the Bluetooth SIG Inc. and any use of such marks by Qstik is under licence.
•Start with your headset turned off. Press and hold the MFB for 5 seconds until the
indicator light flashes Amber repeatedly confirming your headset is in pairing mode. You
have about 2minutes to complete the pairing process. You can end pairing mode at any
time by pressing the MFB momentarily.
•Set your Bluetooth®-enabled music device (MP3 player or Bluetooth® stereo adaptor) to
discover the Qstik VQ660 headset and complete the pairing process by following the
instructions in your device user guide regarding pairing/connecting a second device.
•Your music device should find your headset and display the name “QstikVQ660”. Select
and accept your headset. If asked for a PIN or passkey, enter “8888”.
•On successful pairing, the indicator light reverts to flashing Blue. If paired and
successfully connected with your music device, all music streaming will be diverted
through the Bluetooth® interface to your headset. If pairing was unsuccessful then repeat
the steps above.
4.3. Delete all pairing data
You can delete ALL pairing information on your headset by pressing and holding the FF and
RW buttons simultaneously for 10 seconds.
5. Using your headset
5.1. Volume control
How to… Method
To increase the volume Push & release vol+/- switch forward #1
To decrease the volume Push & release vol+/- switch backward #1
#1 a stretched tune is played to confirm maximum or minimum volume reached.
Note: continuously holding the vol+/- switch in forward or backward position does not
increase or decrease the volume. The switch must be released for every step increase or
decrease in volume.
5.2. Telephony functions
Using your phone’s keypad, dial as normal. If your headset and phone are paired and
connected, the call will automatically transfer to your headset.
How to… Method
Accept incoming call Press the MFB once momentarily
Reject incoming call Press the MFB for 2seconds #2
Ending a call Press the MFB for 2seconds #2
Cancel outgoing call Press the MFB once momentarily #2
Redial last outgoing call Press the FF button for 2seconds
Redial last incoming call Press the RW button for 2seconds
Voice dialing Press the MFB for 2seconds #3
Enable / disable automatic answer Press FF and RW buttons simultaneously for

© Copyright 2005 – 2007 Qstik plc. www.qstik.com
The Bluetooth word mark and logos are owned by the Bluetooth SIG Inc. and any use of such marks by Qstik is under licence.
2seconds (not available during active call)
Mute / un-mute microphone Press FF or RW button twice repeatedly
(only available during active call)
Transfer the call between headset and
handset
Press the MFB twice repeatedly
(only available during active call)
End pairing mode Press the MFB once momentarily
(only available during pairing)
#2 a short tune is played to confirm the action.
#3 your voice dialing may operate more accurately if you record the voice tags while wearing
the headset. Please see your phone’s user guide for more information on voice dialing.
Call-waiting & voice dialing features:
Call-waiting lets you put a call on hold during conversation to answer an incoming call.
Please note these features are device-dependent. Your phone and service must support call-
waiting and voice-dialing functionalities. If call-waiting is supported, you will hear a series of
bleeps when a second call comes through.
How to… Method
Put active (current) call on hold and
accepting incoming call
Press the MFB once momentarily
Toggle between active call & held call Press the MFB once momentarily
Reject incoming call & keep active call Press the MFB for 2seconds #2
Drop active call & keep held call Press the MFB for 2seconds #2
#2 a short tune is played to confirm the action.
5.3. Music streaming functions
Your Qstik VQ660 stereo headset is A2DP (Advanced Audio Distribution Profile) and
AVRCP (Audio Video Remote Control Profile) compliant. The A2DP profile is designed for
high quality stereo music streaming via Bluetooth®. For best performance your music source
device and application must also support A2DP and AVRCP profiles. Ensure your headset is
paired and connected with your music streaming device.
How to… Method
Start music play Press the MFB once momentarily
Pause music Press the MFB once momentarily
Resume music play Press the MFB once momentarily
Stop music streaming Press the MFB for 2seconds
Skip forward / next track Press the FF button once momentarily
Start of current track Press the RW button once momentarily
Skip backward / previous track Press the RW button twice repeatedly
Fast forward current track Press the FF button for min 2seconds
Rewind current track Press the RW button for min 2seconds
If the device you are connecting to does not support the Bluetooth® AVRCP profile, then
some (or all) of the functionalities listed above may not work.
Please note: the music streaming may be interrupted or interfered with if: a) your headset is
too far from your music source; b) your headset is obstructed by materials, especially metal;

© Copyright 2005 – 2007 Qstik plc. www.qstik.com
The Bluetooth word mark and logos are owned by the Bluetooth SIG Inc. and any use of such marks by Qstik is under licence.
and c) your music source such as your PC/Laptop is simultaneously supporting several
Bluetooth® devices.
5.4. VQ660 special feature – User Exposure Alert
Using Bluetooth® headsets at high volume levels can damage your hearing. The risk to
hearing damage increases substantially when listening to high volume levels for extended
periods of time. The VQ660 headset has digital sound level monitoring and alert technology
to maximise your hearing protection. The User Exposure Alert (UEA) feature constantly
calculates the overall sound output through the headset speakers and gives a warning (an
alert) when the average daily exposure through the headset reaches a pre-defined level. The
warning is in the form of a notification with the following short message: “daily hearing
exposure reached”. This message is then repeated every 5 minutes until either the UEA
feature is deactivated, or the headset is powered off, or the reset button is pressed. You can
deactivate/reactivate the UEA during music play (or pause) by pressing the FF and RW
buttons simultaneously for 2seconds.
Please note: the UEA calculation is based on daily sound exposure through the headset and
therefore it auto-resets itself after every 24 hours lapsed following headset power on. Power
cycling or resetting the headset deletes the existing User Exposure data.
5.5. VQ660 special feature – Base-Boost
You can activate/deactivate the Base-Boost feature during music play (or pause) by pressing
the MFB twice repeatedly.
5.6. Answering a call while playing music
You can receive a call while listening to music if your VQ660 headset is paired and
connected to your mobile phone as well as your music device. Simply press the MFB once
momentarily to answer the call. On call termination the music resumes automatically. The
time taken to resume music streaming may differ depending on your device.
Please note that your headset can only be connected with two devices simultaneously using
different profiles, i.e., HSP/HFP (telephony profiles) for mobile phone and A2DP/AVRCP
(music profiles) for music device. A given Bluetooth® profile can not be used by more than
one device at a time.
5.7. Headset status indicator light
When your headset is… The status indicator light…
Turned on Flashes Blue 3 times repeatedly
Turned off Turns Amber before switching off
In pairing mode Flashes Amber repeatedly for a maximum of
2 minutes to complete pairing
Ready to use but not connected to a device Flashes Blue every 5 seconds
Connected to device (telephony or music) Turns off
Receiving a call (except during call waiting) Toggles between Red & Blue during ring
tone and turns off when answered
Low battery Flashes Red for 2 minutes
On charge Turns Red while charging and turns off once
fully charged

© Copyright 2005 – 2007 Qstik plc. www.qstik.com
The Bluetooth word mark and logos are owned by the Bluetooth SIG Inc. and any use of such marks by Qstik is under licence.
6. Troubleshooting
SYMPTOM SOLUTION
I cannot turn my headset on. Check the battery is sufficiently charged.
I cannot charge my headset. Check USB cable (or mains adaptor) is powered and
connected to headset correctly.
My headset isn’t paired with my
phone or my music device.
Check the pairing procedure on your mobile phone
or music device user guide and try pairing again.
I cannot hear music from my MP3
player or my PC.
Check your music device and application support
Bluetooth® version 1.2 (or higher), and A2DP is
active. Please consult the other devices’ user guide.
I can hear music but the remote
control functions do not work.
Check your music device and application support
Bluetooth® AVRCP profiles.
I can hear crackling noises during
the call or music. Caller’s voice is
breaking up.
Check your headset is not obstructed by objects
especially metal.
Check headset is within specified range.
My headset doesn’t work with my
phone.
Check headset is powered on, paired and connected
to your mobile phone.
Check phone hands-free is enabled.
Check headset is within specified range.
I cannot hear caller’s voice or listen
to my music.
Check headset is paired & connected to the correct
phone or music device. Increase the volume.
Callers cannot hear me. Check Mute function is turned off.
Call reject, redial, waiting or voice
dialing do not work.
Check these functions are supported and enabled on
your phone and by your service provider.
My headset is not responding. Check headset is powered on and is sufficiently
charged. If symptom persists, press the reset button
& turn headset on as normal.
Note: resetting or power cycling your headset resets
the User Exposure Alert data.
I cannot listen to radio through my
mobile phone.
Your mobile phone may require a corded headset to
use the wire as an antenna!
I need more help. Email Qstik:
Technical support: [e-mail]
General enquiries: [email protected]

© Copyright 2005 – 2007 Qstik plc. www.qstik.com
The Bluetooth word mark and logos are owned by the Bluetooth SIG Inc. and any use of such marks by Qstik is under licence.
7. Certification & Safety approvals
The Qstik VQ660 headset is Bluetooth® version 2.1 + EDR compliant. It supports the
Headset Profile (HSP), the HandsFree Profile (HFP), the Advance Audio Distribution Profile (A2DP), and the
Audio Video Remote Control Profile (AVRCP).
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Qstik is
under license.
0681 The Qstik VQ660 headset is CE marked according to the provisions of the Radio equipment
and Telecommunications Terminal Equipment (R&TTE) Directive (1999/5/EC). Qstik plc hereby declares that
the EVOQ is in full compliance with the essential and other relevant requirements and provisions of R&TTE
Directive 1999/5/EC.
This product must not be disposed of with your other household waste. It is your responsibility to dispose
of your waste equipment and products according to local standards and regulations by handing it over to a
designated collection point for the recycling of Waste Electrical and Electronic Equipment (WEEE).
Storage: If you wish to store your EVOQ for a period of time, then always ensure it is powered off before
storage. Your EVOQ should not be stored at high temperatures, such as in very hot vehicles or under direct
sunlight. High temperatures of greater than 45°C (113°F) can adversely affect battery life.
Federal Communications Commission
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
The device and its antenna should not be collocated or operating in conjunction with any other antenna or
transmitter.
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
Warning: Changes or modifications made to this equipment not expressly approved by Qstik will void the
user’s authority to operate this equipment.
Industry Canada
Operation is subject to the following two conditions: (1) This device may not cause interference and (2) This
device must accept any interference, including interference that may cause undesired operation of the device.
The term “IC:” before the certification/registration number only signifies that registration was performed based
on a Declaration of Conformity indicating that Industry Canada technical specifications were met. It does not
imply that Industry Canada approved the equipment.

© Copyright 2005 – 2007 Qstik plc. www.qstik.com
The Bluetooth word mark and logos are owned by the Bluetooth SIG Inc. and any use of such marks by Qstik is under licence.
8. Warranty
Warranty Information
This product contains no user-serviceable parts. Refer servicing only to Qstik authorized
distributor. If this Product requires maintenance, contact the dealer from whom you originally
purchased the Product to obtain advice, service and/or a Return Material Authorization
(RMA). If it is determined that the Product may be defective, you will be given an RMA
number and instructions for Product return. An unauthorized return (i.e., one without RMA
number) will be returned back to you at your expense. Authorized returns must be in original
box and packaging materials and shipped in appropriate packaging, prepaid and insured, to
the address provided on your return paperwork.
Limited Warranty
Qstik values your business and always attempts to provide you the very best of service. Qstik
warrants to Purchaser that the Product, in the course of its normal use, for a period of one (1)
year after the date of purchase on the receipt, will substantially conform to Qstik’s published
specifications for the Product on the date of purchase by the Purchaser, subject to the terms
herein. Purchaser shall notify Qstik of any nonconformance during the Warranty Period and
obtain a written RMA and an RMA number for the nonconforming Product from Qstik and
return the nonconforming Product to Qstik, with a statement describing the nonconformity.
Qstik’s exclusive obligation with respect to nonconforming Product shall be, at Qstik’s sole
discretion and option, to either repair or replace such Product so that it substantially conforms
to its published specifications on the date of purchase. The foregoing warranty of Qstik shall
extend to repaired or replaced Products for the balance of the applicable period of the original
warranty or ninety (90) days from the date of shipment of a repaired or replaced Product,
whichever is longer.
The warranty set forth above shall not apply to any Product that a) is sold by a private party
or an unauthorized distributor or reseller; b) has not been properly used or handled in
accordance with the instructions supplied by Qstik; c) has been modified, repaired or altered
(including removing any parts, obliterating labels or opening enclosures), other than by Qstik
authorized services; d) has been subjected to faulty installation, misuse, or abuse; e) is stolen,
lost or misplaced; f) is purchased through private parties as a re-sale or open-box-purchase; g)
has failures as a result of damages beyond the reasonable control of Qstik. This warranty is
available only to Purchaser, and does not extend to any distributors, retailers, or resellers of
the Product.
The foregoing limited warranties are Qstik’s sole warranties, expressed or implied, and are
applicable only to products sold as new and purchased from authorized distributors and
resellers. Qstik disclaims all other remedies and warranties, whether expressed, implied or
statutory, including but not limited to, a) any warranty of merchantability or fitness for a
particular purpose, and b) any incidental, consequential, or special damages, or any financial
loss, lost profits or expenses out of or in connection with the purchase, use, or performance of
the Product, even if Qstik has been advised of the possibility of such damages. THE
LIABILITY OF QSTIK HEREUNDER FOR ALL CLAIMS SHALL NOT EXCEED THE
AMOUNT PAID BY PURCHASER FOR THE PRODUCT GIVING RISE TO QSTIK’S
LIABILITY.
