Qtel E220 User manual
Quick Start Guide.indd 1 9/18/07 1:53:54 PM
14%,).4%2.%4/.4(%-/6%
º q
²¾dG ¹JÄÇc fêfEG
Quick Start Guide.indd 2 9/18/07 1:53:56 PM
TABLE OF
CONTENTS
Getting Qtel Internet E220 Ready 5
Install Guide 5
Introduction to the Qtel Internet E220 Interface 7
Internet Service 7
SMS 8
Contacts Service 9
Safety Information 10
Quick Start Guide.indd 3 9/18/07 1:53:56 PM
14%,).4%2.%4/.4(%-/6%
º q
²¾dG ¹JÄÇc fêfEG
Quick Start Guide.indd 4 9/18/07 1:53:57 PM
E220 USB modem - Quick start guide | 5
2) Insert the slot into E220, as shown in the
following figure.
INSTALL GUIDE
The installation procedures of the Qtel
Internet E220 may differ under different
operating systems (OS) such as Windows XP
and Windows 2000. Refer to the actual install
tips if there is any difference.
Note:
• For Windows XP, it is recommended to install
patches such as Service Pack 2 or above.
•For Windows 2000, it is recommended to
install patches such as Service Pack 4 or above.
• For Mac operating systems download the
driver from the Qtel website: www.qtel.com.qa
Welcome to Qtel Internet E220 USB Modem
Quick Start Guide.
E220 provides the following functions:
•Accessing the Internet
•SMS
•Contacts
Note: This manual only briefly introduces
the basic functions of E220. For detailed
functions as well as warnings and
precautions, refer to Qtel Internet E220 USB
Modem User Manual.
GETTING QTEL INTERNET
E220 READY
1) Take out the SIM card slot from E220,
and then place the SIM card into the slot, as
shown in the following figure. Make sure that
the SIM card is fully in place.
Quick Start Guide.indd 5 9/18/07 1:53:59 PM
E220 USB modem - Quick start guide | 6
1.Connecting E220 with a PC
Note: First, start up your computer. Then
connect E220 with the computer. Otherwise, the
normal installation of your E220 can be affected.
The sketch map for the data cable is as shown.
1)Insert the Mini-USB-connector of the data
cable into E220.
2) Insert A connector of USB data cable into
the USB interfaces of the PC/Laptop.
3) The system auto detects and recognizes
the new hardware and displays on the
status area of the desktop, indicating the
connection between E220 and the PC is
successful.
2. Installing the Qtel
Internet E220
1) Connect E220 to a PC.
2) The install program will auto start. If the
auto-run program does not respond, go to
the driver path. Find and double-click the
AutoRun.exe file, and then the program will
auto run.
3) Install the program according to the
prompts on the screen.
Note: Do not plug or unplug E220 in the
installation process.
4) After successful installation, a shortcut
icon for E220 appears on
the desktop.
Quick Start Guide.indd 6 9/18/07 1:54:01 PM
E220 USB modem - Quick start guide | 7
: Access the SMS window.
: Access the contacts window.
INTERNET SERVICE
1.Network Connection Settings
No need for any settings in order to connect
to Qtel Internet E220, however you can do it
as below:
To create a new profile:
1) Select Settings > Network Connection
Settings.
2) Click New.
3) Enter the profile name and the
parameters, like APN, Phone number,
Username and password.
4) Click Save.
Note: For the detailed parameters, consult
the local network operator.
2. Connecting to
the Internet
1) Click to connect to the network.
2) When the connection is created, the current
connection information will be displayed on the
right panel of the window, including connect
3. Removing E220
To remove E220 from the system, please
follow the steps below:
1) Double-click on the status area of
the desktop; the “Safely Remove Hardware”
prompt will be displayed.
2) Stop the E220 hardware «Huawei Mass
Storage USB Device».
3) At the prompt, pull E220 out.
INTRODUCTION TO THE QTEL
INTERNET E220 INTERFACE
1.Accessing the E220 Manager
Interface
Double-click on the desktop to
start E220 Manager.
If the system prompts you to enter a PIN,
enter the correct one.
2. Introduction to
the Icons
/ : Connect/Disconnect the
network connection.
: Open the Internet.
Quick Start Guide.indd 7 9/18/07 1:54:03 PM
E220 USB modem - Quick start guide | 8
duration, data volumes, received and sent
volumes, rate and the top rate.
3) Click to open the Internet.
4) Click to disconnect the network
connection.
SMS
1. Creating SMS
1) Click to access the SMS window.
2) Click Write.
3) Enter one or more telephone numbers,
separated by semicolon (;) and the SMS
contents.
4) Click Send.
Note: While entering telephone numbers,
you can click Contacts to search for and add
numbers.
2. Viewing SMS
You can select Settings > Options > SMS
Alerts to set the prompt methods for a new
message. You can select Alert tone or
Alert window.
If Alert tone is selected, when there is a new
message, you will hear a prompt.
1) Click to access the SMS window.
2) Click Inbox to view the messages.
If Alert window is selected, when there is
a new message, a prompts window will be
displayed.
Click View to view the message or click Close
to view it later.
3. SMS Settings
Select Settings > SMS Settings for the
following settings.
• Reports: to set whether ask for a delivery
report.
• Use the same SMS center for reply: to set
the receiver to use the same SMS center
number for reply.
•SMS Bear Domain: to set the bear domain
for sending messages.
•Validity: to set the valid period during which
messages can be stored in the SMS center.
•SMC number: E220 will auto read the
number preset in the SIM card.
Quick Start Guide.indd 8 9/18/07 1:54:05 PM
E220 USB modem - Quick start guide | 9
CONTACTS SERVICE
1.Creating a New Contact
1) Click to access the Contacts window.
2) Click New.
3) Enter the name, telephone numbers,
email address and comments.
Then click Save.
2. Modifying Contacts
1) Click to access the Contacts window.
2) Select a contact to modify and then
double-click it or click Edit.
3) After the modification, click Save.
3. Deleting Contacts
1) Click to access the Contacts window.
2) Select one or more contacts and then
click Delete.
3) At the prompt, click OK.
4. Sending SMS
1) Click to access the Contacts window.
2) Select one or more contacts and then
click Send.
3) In the pop-up window, select the
telephone numbers you want to send a
message to and then select OK. The program
will jump to the window for creating a
message.
4) The selected contact numbers will be
displayed in the blank column of Contacts.
Enter the contents of the message and then
click Send.
5. Searching for a Contact
1) Click Search.
• Select the search range in the Field
drop-down box.
• Enter the search conditions in the Value
text box.
• Select the matching type, such as “Match
Whole Word Only” and/or “Match Case”.
2) Click Search Now to begin searching.
3) Click Stop Search to stop searching.
Quick Start Guide.indd 9 9/18/07 1:54:06 PM
E220 USB modem - Quick start guide | 10
SAFETY INFORMATION
Please read the safety information carefully
to ensure the correct and safe use of your
wireless device.
General Recommendations for Use
Always handle your wireless device with care
and keep it in a clean and dust-free place.
Do not expose your wireless device to open
flames or lit tobacco products.
• Always keep your wireless device dry.
• Do not drop, throw or try to bend your
wireless device.
• Do not paint or scratch your wireless device.
• Do not attempt to disassemble your wireless
device. Doing so will void warranty. Only
authorized personnel are allowed to do so.
• This product requires a minimum distance
of 1.5 cm from the body when in operation.
• Keep your wireless device in normal
temperature. Your wireless device can only
operate between -5ºC and +55 ºC.
• Use approved accessories only. Do not connect
your wireless device to any incompatible products.
Obey Laws and Regulations
Do not operate your wireless device where
it may be unsafe to do so or where you are
required not to do so.
To deactivate your wireless device, close all
applications using the wireless device first and
then remove the wireless device from your PC.
Obey all local laws, regulations, rules, orders,
signs and notices while using the wireless
device. Signs about the use of mobile phones
should also be obeyed as referring to other
wireless equipment including wireless devices.
Deactivate in Explosive Areas
Deactivate your wireless device where the air
is potentially explosive. It is rare, but your PC
could generate sparks.
Deactivate in Blasting Areas
Deactivate your wireless device where
blasting is in progress. Remote-controlled RF
devices are often used at construction sites
to set off blasting.
Deactivate in Aircrafts
Deactivate your wireless device before
boarding or in any aircraft. Wireless devices
can cause interference in aircrafts.
Quick Start Guide.indd 10 9/18/07 1:54:08 PM
E220 USB modem - Quick start guide | 11
Deactivate at Hospitals
Obey regulations or rules at hospitals.
Deactivate your wireless device near medical
equipment. Wireless devices can cause
interference to cardiac pacemakers, implanted
defibrillators or other medical equipment.
Deactivate near Hearing Devices
Deactivate your wireless device near hearing
devices. People with hearing aids may experience
interfering noises near wireless devices.
Recommendations for Children
Do NOT allow children to play with your
wireless device. They could hurt themselves
or others, or could accidentally damage the
wireless device. Your wireless device contains
small parts with sharp edges that may cause
an injury or a choking hazard.
Deactivate While Driving
Do not use the wireless device while driving.
Immunity to Interference
Your wireless device is immune to
interferences caused by audible signals.
Cleaning and Maintenance
• Before you clean or maintain the wireless
device, close all applications using wireless
device and remove your wireless device
from your PC.
• Clean your wireless device with a piece of
soft antistatic cloth.
• If the wireless device or any of its
accessories does not work, turn to an
authorized service center for help.
Environmental Protection
Observe the local regulations regarding the
disposal of your packaging materials, old
wireless device and its accessories. Please
promote their recycling.
SIM/USIM Cards
While inserting or removing the SIM card,
protect yourself against electrostatic discharge
(ESD). Do not touch the connector of the SIM
card. As a precaution, always make sure that
the wireless device is already in your hand
before you insert or remove the SIM card.
Restart on ESDs
Software will attempt to re-initialize a
connection once a substantial electrostatic
Quick Start Guide.indd 11 9/18/07 1:54:09 PM
E220 USB modem - Quick start guide | 12
discharge causes the device to reset. If the
software is not operational after an ESD,
restart the modem software application.
Agency/Regulatory Information
The wireless device is approved for use
in many regions of the world. In these
regions, the device meets all radio frequency
exposure requirements. The following
approvals and notices apply in specific
regions as noted.
CE Approval (European Union)
The wireless device is approved to be used
in the member states of the EU. Huawei
declares that the wireless device is in
compliance with the essential requirements
and other relevant provisions of the Radio
and Telecommunications Terminal Equipment
Directive 1999/5/EC (R&TTE Directive).
Radio Frequency Exposure
To ensure compliance at all times with the
R&TTE Directive* 1999/5/EC, the wireless
device can be held in the hand but still
requires a minimum distance of 1.5 cm from
the body when in operation. For body-worn
use, it must be suitably mounted so that
it is at least 1.5 cm away from the body.
Mounting accessories (for example, belt
clips) cannot be made of metal. Do not put
the wireless device in your pocket.
•The general public RF exposure limits
referenced in the R&TTE Directive are
consistent with the published Guidelines
of the International Commission on Non-
Ionizing Radiation Protection (ICNIRP)
1998. ICNIRP is a formally recognized non-
governmental organization in Non-Ionising
Radiation Protection for the World Health
Organisation (WHO), the International Labour
Organisation (ILO) and the European Union
(EU). For more information, visit the ICNIRP
website at www.icnirp.de.
Certification Information (SAR)
THIS DEVICE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO
FREQUENCY ELECTROMAGNETIC FIELD.
Your wireless device is a low-power radio
transmitter and receiver. When it is running,
it emits low levels of radio frequency
energy (also known as radio waves or radio
frequency fields).
Quick Start Guide.indd 12 9/18/07 1:54:11 PM
E220 USB modem - Quick start guide | 13
Governments around the world have
adopted comprehensive international
safety guidelines, developed by scientific
organizations, e.g. ICNIRP (International
Commission on Non-Ionizing Radiation
Protection) and IEEE (Institute of Electrical
and Electronics Engineers Inc.), through
periodic and thorough evaluation of scientific
studies. These guidelines establish permitted
levels of radio wave exposure for the public.
The levels include a safety margin designed
to assure the safety of all persons, regardless
of age and health, and to account for any
variations in measurements.
Specific Absorption Rate (SAR) is the unit
of measurement for the amount of radio
frequency energy absorbed by the body
when using a wireless device. The SAR
value is determined at the highest certified
power level in laboratory conditions, but the
actual SAR level of the wireless device while
operating can be well below the value. This
is because the wireless device is designed to
use the minimum power required to reach
the network.
All models of Huawei’s wireless device
are designed to meet radio frequency
exposure guidelines such as European
Council Recommendation and Federal
Communications Commission Notice (United
States).
European Council Recommendation: Before
a wireless device model is available for sale
to the public, it must be tested according to
the technical standard-EN 50361 and not
exceed the limit established by the European
Council Recommendation: 1999/519/EC for
safe exposure.
The SAR limit adopted by the 1999/519/EC is
2.0 watts/kilogram (W/kg) averaged over ten
gram of tissue. The highest SAR value for this
device type when tested is 1.20 W/kg.
[EN 50361 scope states “This basic standard
applies to any electromagnetic field (EM)
transmitting devices intended to be used with
the radiating part of the equipment in close
proximity to the human ear including mobile
phones, cordless phones, etc. The frequency
range is 300 MHz to 3 GHz. Therefore, the
above text does not address primary use of
the wireless device product.]
Federal Communications Commission
Notice (United States): Before a wireless
device model is available for sale to the
public, it must be tested and certified to
Quick Start Guide.indd 13 9/18/07 1:54:12 PM
E220 USB modem - Quick start guide | 14
the FCC that it does not exceed the limit
established by the government-adopted
requirement for safe exposure.
The SAR limit adopted by the USA and
Canada is 1.6 watts/kilogram (W/kg)
averaged over one gram of tissue. The
highest SAR value reported to the FCC and
IC for this device type when tested for use
is 0.59W/kg. [There is no reference to the
specific reference standard or its applicability
to the intended use of the product]
FCC Statement
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there
is no guarantee that interference will not
occur in a particular installation. If this
equipment does cause harmful interference
to radio or television reception, which can
be determined by turning the equipment
off and on, the user is encouraged to try to
correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/
TV technician for help.
This device complies with Part 15 of the
FCC Rules and with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions: (1) this device may not cause
harmful interference, and (2) this device
must accept any interference received,
including interference that may cause
undesired operation.
Warning: Changes or modifications made to
this equipment not expressly approved by
HUAWEI may void the FCC authorization to
operate this equipment.
Quick Start Guide.indd 14 9/18/07 1:54:14 PM
E220 USB Modem - |
1.6
SAR
0.59
FCC
IC
FCC ¿É«H
B
FCC15
•
•
•
•
FCC15
IC210RSS
1
)2
FCC
14
Quick Start Guide.indd 15 9/18/07 1:54:15 PM
E220 USB Modem - |
ICNIRP
IEEE
SAR
SAR
SAR
50361 EN
1999519EC
SAR
2.0 يه 1999519EC
10
SAR
50361 EN1.20
EM
300
3
äÉj’ƒdG) á«dGQóØdG ä’É°üJ’G áæ÷ QÉ©°TEG
:(IóëàŸG
FCC
SAR
13
Quick Start Guide.indd 16 9/18/07 1:54:17 PM
E220 USB Modem - |
(»HhQhC’G OÉ–’G) CE
EC/5/1999 R&TTE
1.5
EC/5/1999 R&TTE
1.5
•
R&TTE
1998ICNIRP
ICNIRP
ILO ،WHO
EU
ICNIRP
www.icnirp.de
(SAR)
12
Quick Start Guide.indd 17 9/18/07 1:54:18 PM
E220 USB Modem - |
•
•
•
SIM
SIM
SIM
SIM
11
Quick Start Guide.indd 18 9/18/07 1:54:20 PM
E220 USB Modem - |
•
•
•
•
•
1.5
•
555
•
10
Quick Start Guide.indd 19 9/18/07 1:54:21 PM
E220 USB Modem - |
1
1
.Contacts
.New2
3
.Save
2
1
.Contacts
2
.Edit
.Save3
3
1
.Contacts
2
.Delete
OK3
SMS4
1
.Contacts
2
.Send
3
OK
4
.Contacts
.Send
5
Search1
Field •
•
.Value
•
Match Whole Word Only
.Match Case
Search Now2
Stop Search3
9
Quick Start Guide.indd 20 9/18/07 1:54:23 PM
Table of contents
Languages:
