OWNER'S MANUAL
2,500 LB
(1,250 LB / RAMP
QUADLITE XTREME
ARCH RAMPS
(Model Number 565148

Owner's Manual
QUADLITE XTREME ARCH RAMPS
Page 2 Check for parts online at www.quadboss.com or call 877-847-1558
WARNING
READ, UNDERSTAND AND FOLLOW ALL ASSEMBLY,
INSPECTION, & USE INSTRUCTIONS PROVIDED
BEFORE EACH USE. FAILURE TO FOLLOW ALL INSTRUCTIONS,
WARNINGS & LOAD CAPACITY RATING COULD RESULT IN
SERIOUS INJURY OR DEATH.
IF ANY INSTRUCTIONS ARE NOT UNDERSTOOD OR IF YOU HAVE
A PARTS ISSUE CALL 8778471558 BEFORE USING.
DO NOT USE AN ATV ON THIS RAMP IF THE ATV HAS SNOW
CHAINS ON TIRES. CHAINS WILL CAUSE DAMAGE TO YOUR
RAMP AND IS HAZARDOUS!
BE CAREFUL OF PINCH POINTS AT RAMP TAB LOCATIONS WHILE
SECURING RAMP TO TAILGATE.
THIS RAMP IS FOR USE WITH 4WHEELED ATV’S OR UTV'S ONLY.
DO NOT USE WITH 2 OR 3WHEELED VEHICLES OR VEHICLES
EXCEEDING 2,500 LBS.
SAFETY STRAPS MUST BE SECURELY HOOKED UPTO VEHICLETO
PREVENT RAMPS FROM SLIDING OFF TAILGATE. TEST BEFORE
USING OR YOU COULD BE SERIOUSLY INJURED. BE SURE YOUR
TRUCK IS IN PARK AND EMERGENCY BRAKE ENGAGED.
BE SURE 4WHEELED ATV OR UTV IS CENTERED ON RAMPS. DO
NOT USE WITH ANY VEHICLE THAT HAS WIDER TIRES THAN THE
RAMP WIDTH.
MAXIMUM USABLE HEIGHT, GROUNDTO LOADING POSITION, IS
NO MORE THAN ONE HALF THE LENGTH OF THE RAMP.
BE SURE RAMP IS PROPERLY PLACED AND SECURED AS
DESCRIBED IN LOADING INSTRUCTIONS.
QUADBOSS offers a full line of ATV/UTV accessories. We appreciate
your purchase of one of our world class Ramps. Follow these few
simple instructions and your product will be sure to give you many
years of trouble free pleasure. Instructions should be kept in a safe
place and reviewed at least annually.
If for any reason you have a problem with your product, DO NOT
return to the retailer; contact the QUADBOSS customer service
department at 877-847-1558 or [email protected] for
assistance.
ASSEMBLY INSTRUCTIONS:
1. Attach the two provided securing straps to the center brace,
approximately 16" from the tailgate end (one on each ramp). Wrap
the loop end of each strap around the center brace and thread
the buckle and “S”hook end thru the loop. This permanently
attaches straps to the ramp. SEE FIGURE 1.
USE INSTRUCTIONS:
TO LOAD YOUR 4WHEELED ATV OR UTV
1. On level ground, rest ramps on tailgate. SEE FIGURE 2. Be
sure ramps are centered on tailgate and aligned correctly to your
4-wheeled ATV or UTV’s wheel width.
2. Hook the “S”hooks of both straps to bumper and pull on loose end
of straps until straps are tightly holding ramp to tailgate. Be sure
ramps have not moved location when tightening straps. Double
check to make sure ramps are still aligned correctly. To remove,
simply push the thumb release on strap buckle.
3. Using an electric or manual winch, draw the ATV or UTV up the
ramps. DO NOT drive the ATV or UTV up the ramps.
4. Once vehicle is in truck bed, be sure to set brake & securely tie
down vehicle. Ramp can now be removed, folded up, and stored.
1. Reverse loading procedures to unload your ATV or UTV.
TO UNLOAD YOUR 4WHEELED ATV OR UTV
S
s-hook loop
bumper
tailgate
FIGURE 1
FIGURE 2
straps tight

Page 3
Owner's Manual
QUADLITE XTREME ARCH RAMPS
Check for parts online at www.quadboss.com or call 877-847-1558
ALWAYS…
• Use on level ground and securely attach ramp to truck.
• Be careful of pinch points at ramp tab locations while securing
ramp to tailgate.
• Use as 4-wheeled ATV or UTV ramp only.
• Inspect before each and every use to be sure there is no
product damage or loose/missing bolts & hardware.
NEVER…
• Exceed load capacity of 1,250 lbs per ramp (2,500 lbs total),
evenly distributed over four wheels.
• Use a damaged ramp; replace with new
• Use while under the influence of alcohol or drugs.
• Load ATV/UTV on ramp with any gear on racks of ATV/UTV.
• Use with 2- or 3-wheeled vehicles.
• Use carelessly -- Think Safety!
• Use in slippery conditions.
REPLACEMENT COMPONENTS
A306 Rubber tab cover
A677 Rubber tab cover, center
23017 Ramp strap, complete
WARRANTY
QUADBOSS offers a two year limited warranty to be free from
defects in materials and workmanship for the service life of the
product, not to exceed twenty-four consecutive months from the
date of purchase. This warranty applies to the original owner with
a proof of purchase and is not transferable.
This warranty applies only to products which have not been
subjected to negligent use, misuse, alteration, accident or if
repairs have been made by anyone outside our factory. This
warranty supersedes all other warranties either expressed or
implied and all other obligations or liabilities on our part.
QUADBOSS, does not assume, and does not authorize any
other person to assume for us, any liability in connection with
the sale of our products. Warranty work must be sent directly
to QUADBOSS or one of our authorized service centers and
performed by them.
To obtain warranty service and/or replacement
instructions, you must have prior approval from
QUADBOSS before shipping your package to us by calling
our customer service department at 877-847-1558. All
items must be shipped prepaid. QUADBOSS will at no charge,
repair or replace, at their discretion, any defective part which falls
under the conditions stated above. QUADBOSS retains the right
to change models, specifications and price without notice.
For replacement parts, phone [phone] or go online to
www.quadboss.com.
WARNING
DO NOT USE ON SOFT SURFACES OR UNLEVEL TERRAIN.
REAR ENGINE EQUIPMENT SHOULD BE LOADED IN REVERSE TO
AVOID FRONT END REARUP.
DO NOT EXCEED THE CAPACITY OF YOUR LOADING SURFACE
I.E. TAILGATE, BUMPER. IF UNKNOWN, CONSULT THE
MANUFACTURER TO FIND LOAD CAPACITIES.
IF LOADING OR UNLOADING FROM A TRAILER, MAKE SURE THE
TRAILER IS PROPERLY COUPLED TO THE TOW VEHICLE.
NEVER STAND IN THE PATH OF EQUIPMENT WHEN LOADING/
UNLOADING WITH THE RAMP, AND KEEP BYSTANDERS AWAY
FROM THE RAMPS.
DO NOT STEP BETWEEN RUNGS. THIS MAY CAUSE A PERSON
TO FALL THROUGH AND POSSIBLY RESULT IN SERIOUS BODILY
INJURY.
RAMPS ARE INTENDED FOR LOADING/UNLOADING EQUIPMENT
ONTO A TRAILER OR PICKUP TRUCK. DO NOT USE RAMP
SECTIONS AS A LADDER, BRIDGE, SCAFFOLDING, OR FOR ANY
OTHER PURPOSE.
