QuadBoss QBRT18552 User manual

OWNER’S
MANUAL
1602 CORPORATE DRIVE, WARRENSBURG MISSOURI 64093
PHONE [phone] FAX [phone]
Manufacturing quality lawn care equipment since 1945
Assembly
Operation
Service and Adjustment
Repair Parts
Made In The
USA
REV 12-016
swisherinc.com
MODEL NO.
STARTING SERIAL #:
L112-016001
QBRT18552
QBRT18552-CA
14365
52” ROUGH CUT
TRAIL CUTTER

2
In the event you have a claim under this warranty, you must return the product to an authorized
service dealer. All transportation charges, damage, or loss incurred during transportation of parts
submitted for replacement or repair under this warranty shall be borne by the purchaser. Should you
have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The
model number, serial number, date of purchase, and the name of the authorized Swisher dealer from
whom you purchased the mower will be needed before any warranty claim can be processed.
THIS WARRANTY DOES NOT APPLY TO ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES AND ANY IMPLIED WARRANTIES ARE LIMITED TO THE SAME TIME
PERIODS STATED HEREIN FOR ALL EXPRESSED WARRANTIES. Some states do not
allow the limitation of consequential damages or limitations on how long an implied warranty may
last, so the above limitations or exclusions may not apply to you. This warranty gives you specific
legal rights and you may have other rights, which vary from state-to-state. This is a limited warranty
as defined by the Magnuson-Moss Act of 1975.
LIMITED WARRANTY
The manufacturer’s warranty to the original consumer purchaser is: This product is free from defects
in materials and workmanship for a period of one (1) year from the date of purchase by the original
consumer purchaser. As required by § 1060.120, the fuel system related components, which have
been certified to this equipment by SAI are to be free of defects in material and workmanship for a
period of two (2) years from the date of purchase by the original consumer purchaser. We will repair
or replace, at our discretion, parts found to be defective due to materials or workmanship. This
warranty is subject to the following limitations and exclusions:
TABLE OF CONTENTS
WARRANTY………………....….2
INTRODUCTION………………..3
SAFETY..……………………….3-4
ASSEMBLY………………..…….4
OPERATION……………………5-7
CUTTER MAINTENANCE..…….…..8
TROUBLESHOOTING………………9
DECALS…..………….………………10
PARTS BREAKDOWN……………11-17
1) Engine Warranty All engines utilized on our products have a separate warranty extended
to them by the individual engine manufacturer. Any engine service
difficulty is the responsibility of the engine manufacturer and in no
way is Swisher or its agents responsible for the engine
warranty. The Briggs & Stratton Engine Service Hot-Line is 1-800-
233-3723. The Tecumseh Engine Service Hot-Line is 1-800-558-5402.
The Honda Engine Service Hot-Line is 1-800-426-7701.
2) Commercial Use This product is not intended for commercial use and carries no
commercial warranty.
3) Limitation This warranty applies only to products which have been properly
assembled, adjusted, and operated in accordance with the instructions
contained within this manual. This warranty does not apply to any
product of Swisher, that has been subject to alteration,
misuse, abuse, improper assembly or installation, shipping damage, or
to normal wear of product.
4) Exclusions Excluded from this warranty are normal wear, normal adjustments, and
normal maintenance.

SAFETY PRECAUTIONS
This Safety Alert Symbol indicates important messages in this
manual. When you see this symbol, carefully read the message that
follows and be alert to the possibility of personal injury.
Read this manual completely. This machine can amputate hands and feet, and
throw objects. Failure to observe the following safety instructions could result in
serious injury or death.
Thank you for choosing Swisher’s 52 ‘’ Trailcutter. Before operating
your cutter, please read, understand and follow all of the safety precautions
and other instructions explained in this manual . As with all power
equipment, lawn mowers,and cutters can be potentially dangerous if
improperly used.
3
• Read the manual. Learn to operate this machine safely.
• Always disconnect the spark plug wire and place the wire where it cannot contact the
spark plug, to prevent accidental starting the engine when setting up, transporting,
adjusting or making repairs.
• Keep all shields and guards in place.
• Understand the speed, steering and stability of this machine. Know the positions and
operations of all controls before you operate this machine. Check all of the controls in
a safe area before starting to work with this machine.
• Allow only responsible adults who are familiar with these instructions to operate this
machine. Never allow children to operate this machine.
• Clear the area of objects such as rocks, toys, wire, etc. that can be picked up and
thrown by the blade.
• Be sure the area is clear of other people before mowing. Be aware of the cutters
discharge direction and do not point at anyone. Stop the machine if anyone enters the
cutting area. Children are often attracted to the machine and the mowing activity.
Never assume that children will remain where you last saw them. Keep children
under the watchful care of another responsible adult.
•No riders!
• Do not put hands or feet near or under rotating parts.
• Do not mow in reverse. Always look down and behind before and during backing.

• Turn off the blades when not cutting. Before leaving the machine, turn off the blades
and stop the engine.
• Watch for traffic when operating near or crossing roadways.
• Do not operate the cutter if it has been dropped or damaged in any manner or if the
mower vibrates excessively. Excessive vibration is an indication of damage.
Repair cutter as necessary.
• Dress properly. Do not operate the cutter when barefoot or wearing open sandals.
Wear only solid shoes with good traction when cutting.
• Never allow operation by untrained persons.
• Do not operate the machine while under the influence of alcohol or drugs.
• Do not operate on slopes greater than 15 degrees.
• Never tamper with safety devices. Check their proper operation regularly.
• Stop and inspect the equipment if you strike an object. Repair, if necessary, before
restarting. Never make adjustments or repairs with the engine running.
• Cutter blades are sharp and can cut. Wrap the blades or wear gloves, and use extra
caution when servicing them. Do not operate at too fast a rate.
• Return lever to its vertical position to disengage blades.
• The braking system is applied when the blades become disengaged. It is designed to
bring the blades to a quick stop (approximately 7 seconds). Each Trailcutter brake
system has been set at the factory. For safety, the consumer should not alter the
braking system.
• Disengage spark plug wire and place where it cannot make a connection.
• Attach tow bar to front of mower. Refer to Figure 2 p.11.
• Check engine oil. All engines are filled with oil at the factory. Verify oil level and
add if necessary before starting engine. (See Engine Owner’s Manual)
• Verify fuel level and add if necessary before starting engine.
• Check the battery (if so equipped). If battery is put into service after the “month & year” of the
date on the battery, then it may need to be charged with a 12 volt battery charger for a minimum
of 1 hour, but no more than 2 hours at a rate of 6 to 10 amps.
• Attach battery cable(s) to battery. ( if so equipped ) Red
wire to positive (FIRST) and black wire to
negative (SECOND).
• Reconnect spark plug wire.
• (Refer to Owner’s Manual p. 5) For proper operating procedures.
ASSEMBLY
4

5
OPERATING YOUR TRAILCUTTER
The operation of any mower can produce foreign objects to be thrown into the eyes, resulting in severe eye
damage. Always wear certified safety glasses or wide-vision safety goggles over spectacles before starting
any cutting machine and while operating such a machine.
The operation of any cutter produces sound waves that are damaging to the human ear. Ear protection is
recommended.
CAUTION! Tragic accidents can occur if the operator is not alert to the presence of children.
Children are often attracted to the machine and the mowing activity. Never assume that children will
remain where you last saw them.
INTENDED USE
The 52” Rugged Cut Trailcutter is designed to clear dense areas of grass and cut saplings
up to 2-1/2 inch thick on meadows and small estates. It is not intended to create a finish
cut on lawns.Your Trailcutter should be towed behind an ATV, golf cart, lawn tractor or
other approved vehicle. It is not recommended for speeds exceeding 5 MPH.
ATTACHING TRAILCUTTER TO TOW VEHICLE
• Back vehicle up to desired towing position. (Tow bar may be attached to
center location or either side)
• Attach 2” ball coupler to vehicle with corresponding ball.
TRANSPORTING CUTTER
• Stop Trailcutter.
• When transporting unattached from tow vehicle, remove spark plug wire and
place it where it cannot contact the spark plug.
STOPPING THE ENGINE
• Make sure the tow vehicle parking brake is set
• Disengage cutting Blades
• Reduce engine to idle speed and allow engine to run momentarily for cooling
• Turn the key to the off position

6
ENGAGING BLADES
Note: Do not attempt to start the unit with the engage switch console in the ‘’ ENGAGED ’’ position.
• Engage blades by pulling out on the PTO switch.
• Push PTO switch in to disengage blades. See detail on page 16 figure – 8
•The braking system is applied when the blades become disengaged. It is designed to bring the blades
to a quick stop ( approximately 7 seconds. ) The electric clutch comes with an internal brake.
BREAKING IN YOUR CUTTER
• Set the vehicle parking brake and chock the wheels to prevent accidental rolling.
• While the engine is running, engage blade control.
• In a safe environment, (i.e. no children or pets) allow blades to rotate and engine to
idle for 5 minutes, breaking in the belt for a longer life.
• Stop cutter.
CAUTION: SHUT OFF THE CUTTER ENGINE AND REMOVE SPARK
PLUG WIRE FROM SPARK PLUG BEFORE MAKING ANY
ADJUSTMENTS TO THE CUTTER.
STARTING THE ENGINE
See engine manufacturer’s recommendations for the type and amount of oil and fuel used.
• Make sure the tow vehicle parking brake is set, mower is level, and blades are
disengaged. Engine must be level to accurately check and fill oil. Do not overfill.
• Check spark plug wire, oil, and fuel.
• Check all electrical connections for build-up of debris.
• Set engine idle to “CHOKE” position.
• (12V models only) Turn key to the “RUN” position, then to the “START” position.
• Set engine idle at maximum RPM for best performance.
• Allow engine to run a few moments before engaging blades.

7
CUTTER HEIGHT ADJUSTMENT
• There is approximately 3 inches of height adjustment.
• Dense areas of material should be cut twice.]
STARTING TO CUT
• Adjust the cutting height to desired height.
• Double check vehicle connection to cutter attachment.
• Start mower engine and set throttle to “FAST” for best cutting performance.
• Carefully mount tow vehicle and start mowing at a slow travel speed.
STOPPING THE CUTTING SESSION
• Bring tow vehicle to a complete stop, set the parking brake and disengage blades.
• Turn key switch to the “OFF” position.
• Always remember to remove keys to avoid irresponsible usage.
SUGGESTED CUTTING PRACTICES
• Operate cutter engine at full throttle to assure the best cutting performance and
maximum material discharge.
• Allow wet grass to dry. Wet grass will clump and collect under the mowing deck.
• Cutter should be started with tow vehicle in low gear and increased only as safe
mowing conditions permit. Cutting speed should not exceed 5 MPH.
• Reducing the travel speed will help cut dense growth. This allows the blades the
time necessary to make its initial cut, and regain momentum to continue cutting and
discharging debris properly. The engine may stall if you are mowing too fast!
• Do not attempt to cut areas that the tow vehicle cannot maneuver through and/or
slopes that you do not feel comfortable riding.

8
GENERAL RECOMMENDATIONS
The warranty on this cutter does not cover items that have been subjected to operator
abuse or negligence. To receive full value from the warranty, operator must maintain
unit as instructed in this manual.
Some adjustments will need to be made periodically to maintain your unit properly.
BEFORE EACH SEASON
A new spark plug and clean air filter assure proper air fuel mixture and help your engine
run better and last longer.
• Replace the spark plug.
• Clean or replace the air filter.
• Check blades and belts for wear.
BEFORE EACH USE
• Check engine oil level. (Do this twice to ensure an accurate reading.)
• Check condition of air filter and clean or replace if necessary.
• Check blade operation.
• Check for loose fasteners.
DAILY MAINTENANCE
Make sure all nuts and bolts are tight and cotter pins and retainer springs are secure.
Keep blades sharp. Observe all safety precautions.
BLADE CARE AND SERVICE
For best results cutter blades must be kept sharp. The blades can be sharpened with a
few strokes of a file or grinding wheel. Do Not attempt to sharpen while on the cutter.
Important: Replace blades that have been damaged or deeply nicked.
Important: Check blade and spindle hardware on a regular basis to make sure
nuts are tight.
CAUTION: DO NOT HANDLE CUTTER BLADES WITH BARE HANDS.
CARELESS OR IMPROPER HANDLING MAY RESULT IN SERIOUS
INJURY.
CUTTER MAINTENANCE

The unit is not cutting level.
• Check for bent or broken blades
• Without the engine running, make certain blades are installed identically.
The engine will not start.
• Disengage blades, turn key switch to the “OFF” position, check battery and
all other electrical connections and inspect spark plug and wire.
• Contact engine manufacturer or qualified mechanic.
Engine runs poorly.
• See engine manual.
• Check the throttle adjuster.
• Replace fuel, clean fuel filter and fuel line.
• Check spark plug and gap.
Cutter bounces excessively while towing.
• Tow at a lower speed.
IF PROBLEMS PERSIST HAVE A QUALIFIED MECHANIC SERVICE
THE CUTTER. NEVER ATTEMPT TO MAKE AN ADJUSTMENT THAT
YOU ARE NOT SURE IS CORRECT. DOING SO CAN CAUSE OTHER
PROBLEMS.
9
GENERAL TROUBLESHOOTING

SAFETY AND OPERATIONAL DECALS
Replace decal immediately if damaged. Order by part number from
Swisher 1-800-222-8183,8-5 CT M-F
OD29-DANGER DECAL
OD39-SWISHER FLAG DECAL
OD33-5MPH DECAL
OD36-Deflector Decal
OD55-DANGER DECAL
OD45-WARNING DECAL
OD10-ENGAGE DECAL
OD99-OFF/RUN DECAL OD28-OFF/RUN/START DECAL
10

FIGURE 1
11
FIGURE 2
FRONT SKIRT ASSEMBLY
ITEM NO. PART NO. DESCRIPTION
1NB596 Bolt - Serr Flange, 5/16-18 X 3/4 Gr 5
2NB181 Nut - Nyloc 5/16-18 ZY
313856TC Front Guard Support
413857 Front Debris Flap; RT52
510548 Bolt - Serr Flange, 5/16-18X1GR5 ZY
613861TC Clamping Plate-Front Debris Guard; RT52
7NB170 Nut - Serr Flange 5/16-18 ZY Case Hrd
8 NB275 Washer - SAE Flat 5/16 ZY
HITCH BAR ASSEMBLY
ITEM NO. PART NO. DESCRIPTION
1 14333 Pin - Click, 5/16"
2 13851 Front Axle Weldment; RT52
3 NB272 Washer - SAE Flat 3/8 ZY Carbon Steel
4 NB182 Nut - Nyloc 3/8-16 ZY
5 13917 Weldment - Hitch
6 NB150 Bolt - 3/8-16 X 3 HCC GR5 ZY
7 7365 Coupler - 2" Ball
When ordering replacement parts
* = USE PAINT CODE: TC=TEX.RED,TK=TEX.BLACK

FIGURE 4
FIGURE 5
When ordering replacement parts
* = USE PAINT CODE: TC=TEX.RED,TK=TEX.BLACK
GAS TANK ASSEMBLY
12
ITEM NO. PART NO. DESCRIPTION
1NB612 Nut - Nyloc 1-8 ZY
213863 Pulley - 14" X 1" ID; RT52
3NB555 Washer - USS Flat, 1/2 ZY
4NB281 Nut - Nyloc 1/2-13 ZY Standard Pattern
5NB596 Bolt - Serr Flange, 5/16-18 X 3/4 Gr 5
613840TC Plate - RT52, Blade Driver Support
713836TC DECK - RT52, CENTER
84845 BEARING - BLADE; RT44
9BB105SL Spacer - Lower For Engine Pulley
10 NB170 Nut - Serr Flange 5/16-18 ZY Case Hrd
11 4858TK Blade Driver Housing
12 NB614HT Washer - 1 X 1 1/2 10GA
13 NB509 Bolt - 1/2-13 X 2 HCC GR5 ZY
14 14318 Spacer - 1" ID x 1.590
15 NB609 Nut - 3/4-10 Nyloc ZY GR2
16 13864TK STUMP JUMPER PLATE WELDMENT; RT-52
17 NB738 Washer - Bllville, 1"ID X 2"OD X 14GA ZY
18 NB179 Washer - 3/4 ID X 1 1/4 OD 18 GA ZY
19 10358 Blade - (off -set) RT44 2005
20 NB611 Bolt - 3/4-10 X 2 1/2 GR8 Alloy ZY
21 13867 Bolt, 1"-8 x 9", GR 8
22 4049 Spacer - Tube, Blade Driver
BLADE DRIVER ASSEMBLY
ITEM NO. PARTNO. DESCRIPTION
1 18221 Cap, Fuel - 2.50 Gallon, Carb Sealed
2 18214 Fuel Tank - 2.5 Gallon, Carb
3 18333TC Bracket - Gas Tank, RT52
4 18331TC Mount - For EPA/CARB Gas Tank, Txt Red
5 NB780 Bolt - Serr Flange, ZY3/8-16X3/4 Gr5
6 NB779 Nut - Serr Flange, Hex ZY3/8-16
7 NB147 Bolt - 5/16-18 X 7.5 HCC GR2 ZP
8 1002004 Solenoid - 3 Pole
9 14000 Battery - Tie Down
10 13841TC Idler Cover - RT52
11 13868TC Motor Base - RT52
12 26X249 Screw - .312-18X.75
13 NB275 Washer - SAE Flat 5/16 ZY
14 NB181 Nut - Nyloc 5/16-18 ZY
15 EBAT230 HAZ MAT- DON'TSHIP UPS. Battery230
16 13961TC Deck - RT52, Left
17 NB161 Screw- HX Tek 14 X 3/4 ZP
18 14316 Clamp - Conduit,3/8" x1/4" Hole
19 NB180 Nut - Nyloc 1/4-20
20 18236 Bolt - Serr Flange 1/4-20 X 1 3/4 GR5 ZY
21 18225 Bracket - Fuel Tank
22 NB274 Washer - SAE Flat 1/4 ZY
22

FIGURE 6
FIGURE 7
ENGINE, CLUTCH ASSEMBLY
ITEM NO. PART NO. DESCRIPTION
1EBS18.5 Engine - B&S 18.5 Intk W/Fltr&Prss. Lub.
2689S Spacer - Short, Engine Pulley, .687
3689S Spacer - Short, Engine Pulley, .687
413868TC Motorbase Weldment - RT52
5NB253 Bolt - Serr Flange, 5/16-18 X1 1/4ZY Gr5
6699 Washer - Belleville 7/16 X 1 1/4
7NB685 Bolt - 7/16-20 X 2 1/2 HCS GR5 ZP NYLOC
83813 Clutch - Electric; ZTR 50
9 NB253 Bolt - Serr Flange, 5/16-18 X1 1/4ZY Gr5
10 NB170 Nut - Serr Flange 5/16-18 ZY Case Hrd
NOT ACTUAL
ENGINE USED
(REF. ONLY)
BELT ENGAGE CONFIGURATION
13
When ordering replacement parts
* = USE PAINT CODE: TC=TEX.RED,TK=TEX.BLACK
ITEM NO. PART NO. DESCRIPTION
1B527 Pulley - Idler, OD-3.25", ID-3/8"
2NB693 Bolt - HTC, 3/8-16 X 2 1/4 GR5 ZY
3NB618 Bolt - 3/8-16 X 1 1/4 GR5 ZY
46040Z Washer For Idler
513876TK Idler Arm - RC52
66037 Bushing - Idler
7NB182 Nut - Nyloc 3/8-16 ZY
810177
Washer - Fender 3/8X1 1/2, Crbn Stl GR 2
93609 Spring - Tapered
10 10546 Eyebolt - Turned 3/8-16 X 5 ZY STD
11 NB280 Nut - 2 Way Lock 3/8-16 ZY&Wax Gr A
12 NB207 Nut - Jam, Nylok 3/8-16 ZY
13
NB272
Washer - SAE Flat 3/8 ZY Carbon Steel

14
When ordering replacement parts
* = USE PAINT CODE: TC=TEX.RED,TK=TEX.BLACK
COVER – GUARD ASSEMBLY
FIGURE 8
ITEM NO. PART NO. DESCRIPTION
113836TC Deck - RT52; Center
213962TC Weldment - Right; RT52 Deck
3NB253 Bolt - Serr Flange, 5/16-18 X1 1/4ZY Gr5
4NB170 Nut - Serr Flange 5/16-18 ZY Case Hrd
5NB596 Bolt - Serr Flange, 5/16-18 X 3/4 Gr 5
613961TC Weldment - Left; RT52 Deck
726X249 Screw - .312-18X.75
813871TC Cover - Engine Pulley; RT52
913868TC Motorbase Weldment - RT52
10 13841TC Idler Cover - RT52
11 13870TC Cover - Stump Jumper Pulley; RT52
ITEM NO. PART NO. DESCRIPTION
1 13843TC Rear Axle Support - RT52, Right
2 13997 Nut - 3/4-10; 2 Way Locking
3 13845TC Rear Axle Weldment; RT52
4 13862 Bolt; 1 1/4"-10 x 1; GR 8
5 13844TC Rear Axle Support - RT52, Left
6 NB184Z Washer - 3/4ID X 1 1/4OD 10 GA.
7 NB126 Pin - Cotter, 1/8 X 1, Crbn Stl Ext Prng
8 13842TC Front Axle Support - RT52
9 NB624 Bolt - 5/8-11 X 7 HCC GR5 ZY
10 663L Spacer
11 NB178 Washer - 5/8 ID X 1 OD 10 GA ZY
12 B98 Bearing - Blade
13 665TK Caster - Text Black; T50
14 NB178 Washer - 5/8 ID X 1 OD 10 GA ZY
15 NB195 Washer - 13/16 X 1 1/4 X 1/8 ZY; Mild
16 NB122 Nut - Jam, Nylok 3/4-16 ZY Gr2
17 13851TC Front Axle Weldment; RT52
18 NB146 Washer - SAE 3/4 ZP
19 14314K Tire, Rear, 13/500, 5/8 BB, Hollowmatic
20
14313K
Tire, Front, 13/500, 3/4 BB, Hollowmatic
AXLE - WHEEL ASSEMBLY
FIGURE 9

ITEM NO. PART NO. DESCRIPTION
113842TC Front Axle Support - RT52
213962TC Weldment - Right; RT52 Deck
313961TC Weldment - Left; RT52 Deck
4NB170 Nut - Serr Flange 5/16-18 ZY Case Hrd
513844TC Rear Axle Support - RT52, Left
6NB596 Bolt - Serr Flange, 5/16-18 X 3/4 Gr 5
713843TC Rear Axle Support - RT52, Right
813836TC Deck - RT52; Center
9 13992TC Angle - Deck Support; RT52
AXLE SUPPORT ASSEMBLY
FIGURE 8
REAR DEBRIS GUARD
FIGURE 10
ITEM NO. PART NO. DESCRIPTION
113859 Rear Debris Flap
2NB170 Nut - Serr Flange 5/16-18 ZY Case Hrd
313858 Rear Flap Support
4NB181 Nut - Nyloc 5/16-18 ZY
513962 Weldment - Right ; RT52 Deck
6NB596 Bolt - Serr Flange, 5/16-18 X 3/4 Gr 5
713836 Deck - RT52; Cent er
813860 Clamping Plat e - Rear Debris Guard; RT52
913961 Weldment - Left; RT52 Deck
10 10548 Bolt - Serr Flange, 5/16-18X1GR5 ZY
15
When ordering replacement parts
* = USE PAINT CODE: TC=TEX.RED,TK=TEX.BLACK

16
CONSOLE ASSEMBLY
FIGURE 8
When ordering replacement parts
* = USE PAINT CODE: TC=TEX.RED, TK=TEX.BLACK
26
20 21
22
23
26
27
28
Item No. Description Part #
20 THROTTLE KNOB 686K
21 PTO SWITCH 3605
22 KEY SWITCH 3623
23 PLASTIC CONSOLE COVER 686C
CONSOLE ENGAGE 686C mod
24 8-32 X KEP NUT NB201
26 1/4'' SAE WASHER NB274
27 8-32 X 1/2'' PHIL TRUSS NB197
28 CONSOLE PLATE WELDMENT 6108TK
WIRING SCHEMATICS
Description Part #
WIRING HARNESS [BRIGGS] 13927
BATTERY [ U 1 R ] SOLD SEPARATELY
BATTERY CABLE- RED BCSR
BATTERY CABLE- BLACK BCLB
SOLENOID 9043
BATTERY STRAP BHOLD
KEYS KSK
BATTERY CABLE BOOTS BCBT
PARTS NOT SHOWN

17
ENGINE TO BLADE PULLEY
CONFIGURATION
FIGURE 9
ITEM NO. PART NO. DESCRI PTION
13813 Clutch - Elect ric; ZTR 50
2B527 Pulley - Idler, OD-3.25", ID-3/8"
313863 Pulley - 14" X 1" ID; RT52
414276 Belt, 5/8" x 64" (RT52)

18
When ordering replacement parts
* = USE PAINT CODE: TC=TEX.RED,TK=TEX.BLACK
COMMON REPAIR PARTS
Your 52
’’ Trailcutter has been produced with components designed specific to this machine. Although standard V-belts,
springs, bearings, blades, pulleys, hardware, etc. look similar to parts used on other machinery, they may in some cases be
made of a different construction and/or materials.
2
3
5
1
ITEM NO. PART NO. DESCRI PTION
1 1002004 Solenoid - 3 Pole
2 18214 Fuel Tank - 2.5 Gallon, Carb
3 NA NOT INCLUDED
4 13928 Harness & Console - RT52
5 7365 Coupler - 2" Ball
NOT SHOWN BCSR Cable - Battery (10" Red)
NOT SHOWN BCS Cable - Battery (Black 10")
NOT SHOWN BCBT Boot - Rubber, Small, Batt ery Cable
NOT SHOWN 14276 Belt, 5/8" x 64" (RT52)
NOT SHOWN AS069 Electrical - 10 Amp Fuse
4
ITEM NO. PART NO. DESCRI PTION
1 18224 Carbon Canister - 2.50 Gallon, 3/16 Line
2 18219 Cable Tie - Carbon Canister
3 024900 Nut - 10-24 Nylon Lock
4 17127 Bracket - Carbon Canister, ZT
5 024203 Screw - 10-24 X 3/4 Phil Truss Head ZP
CARBON CANISTER ASSEMBLY - Only included on “CA” models.

19
YOUR WARRANTY RIGHTS AND OBLIGATIONS: The California Air Resources Board and Swisher, is pleased to explain the
evaporative emission control system (EECS) on your model year 2006 and later Swisher Product. In California, new Outdoor Power
Equipment, must be designed, built and equipped to meet the State’s stringent anti-smog standards. Swisher must warrant the
EECS on your Power Equipment, for the period of time listed below provided there has been no abuse, neglect, or improper
maintenance. For model year 2006 the EECS on your mower includes the liquid fuel lines, fuel line connectors, and fuel line
clamps. Where a warrantable condition exists, Swisher will repair at no cost to you. Expenses covered under warranty include
diagnosis, parts, and labor.
MANUFACTURER’S WARRANTY COVERAGE: For a period of two years, any evaporative emission-related part included in the
list of EECS parts for your mower is defective, the part will be repaired or replaced by Swisher.
OWNER’SWARRANTY RESPONSIBILITIES: As the owner of this Power Equipment, you are responsible for performance of the
required maintenance listed in your owner’s manual. Swisher recommends that you retain all receipts covering maintenance on
your Power Equipment, but Swisher cannot deny warranty solely for the lack of receipts. As the Power Equipment owner, you
should be aware that Swisher, may deny you warranty coverage if your Power Equipment, or a covered part has failed due to
abuse, neglect, or improper maintenance, unapproved modifications, or the use of parts not made or approved by the equipment
manufacturer. You are responsible for presenting your Power Equipment to an authorized Swisher Service center as soon as the
problem exists. Warranty repairs should be completed in a reasonable amount of time, not to exceed 30 days. If you have a
question regarding your warranty rights and responsibilities, you should contact the Swisher Service representative at 1-800-222-
8183.
WARRANTY COMMENCEMENT DATE: The warranty period begins on the date the Power Equipment Is purchased.
LENGTH OF COVERAGE: This warranty shall be for a period of two (2) years from the initial date of purchase.
WHAT IS COVERED: Warranted parts include the Liquid fuel line, fuel line connectors, and fuel line clamps.
REPAIR OR REPLACEMENT OF PARTS: Repair or replacement of any evaporative warranted part will be performed at no charge
to the owner at an authorized Swisher Service Center. If you have a question regarding your warranty rights and responsibilities,
you should contact your nearest authorized service center or call the Swisher Service representative at 1-800-222-8183.
WARRANTY PERIOD: Any warranted part is not scheduled for replacement as required maintenance, or which is scheduled only
for regular inspection to the effect of “repair or replace as necessary” shall be warranted for two (2) years. Any warranted part that
is scheduled for replacement as required maintenance shall be warranted for the period of time up to the first scheduled
replacement point for that part.
DIAGNOSIS: The owner shall not be charged for diagnostic labor that leads to the determination that a warranted part is defective if
the diagnostic work is performed at an authorized Swisher Service Center.
CONSEQUENTIAL DAMAGE: Swisher, may be liable for damages to other engine or equipment components caused by the failure
of a warranted part still under warranty.
WHAT IS NOT COVERED: All failures caused by abuse, neglect, or improper maintenance is not covered.
ADD-ON OR MODIFIED PARTS: The use of add-on or modified parts may be grounds for disallowing a warranty claim. Swisher is
not liable to cover failures of warranted parts caused by the use of an add-on or modified part.
HOW TO FILE A CLAIM: If you have a question regarding your warranty rights and responsibilities, you should contact your nearest
authorized service center or call Swisher Service representative at 1-800-222-8183.

OWNER’S
MANUAL
52”ROUGH CUT
TRAILCUTTER
Each mower has its own model number. Each engine has its
own model number. The model number for the mower will be
found on the right hand side of the motor mount. The model
number for the engine will be found on the top of the valve
cover.
All mower parts listed herein may be ordered directly from
Swisher or your nearest Swisher dealer.
All engine parts may be ordered from the nearest dealer of the
engine supplied with your mower.
WHEN ORDERING PARTS, PLEASE HAVE THE
FOLLOWING INFORMATION AVAILABLE:
* PRODUCT – 52’’ TRAILCUTTER
* SERIAL NUMBER - _______________
* MODEL NUMBER - _______________
* ENGINE MODEL NUMBER - _______________
TYPE - _______________
* PART NUMBER
* PART DESCRIPTION
TELEPHONE - 1-800-222-8183
FAX - 1-660-747-8650
SWISHER
1602 CORPORATE DRIVE
WARRENSBURG, MO 64093
www.swisherinc.com
PRINTED IN U.S.A.
QBRT18552
QBRT18552-CA
