QUAIR Plasma Go PG-0221 User manual

Plasma Go
www.quair.co
Model: PG-0221
Portable Air Purifier
User Manual

In The Box
Battery
Pack
Cupholder
Insert
USB-C Cable
Front Back
GERMAGICTM
HEPA13 Filter
Air Quality
(AQ) Display
Product Overview
Air Quality
(AQ) Sensor
Air Inlet
Rotatable
Top
Air Outlet
USB-C Port
1

1. Turn the filter cap on the bottom of the device counter-clockwise
to unlock.
2. Insert or remove the filter inside the device.
3. Align the unlocked icon (o) on the filter cap with the arrow behind
the device and rotate the filter cap clockwise to lock.
Note: Do not wash and reuse the filter. Dispose the filter and replace with a new filter
every 2 to 3 months.
Product Overview
Filter Installation / Removal
2

Colour
Blue
Orange
Purple
Red
Good
Fair
Poor
Very Poor
0 - 40
41 - 200
201 - 500
>501
Air Quality Levels (μg/m3)
Touch Control
Filter
Replacement
AQ Level
AQ Light
Fan Speed
Plasma
Ions
Wired/
Wireless Mode
Getting Started
Air Quality (AQ) Display
AQ Light
3

Connect the USB-C cable to the port located on the back of
the device and turn device on using the touch control.
Note: In wired mode, the device can be operated with or without the battery pack.
For safety reasons, the device will automatically turn off when the USB-C cable is
plugged/unplugged while operating.
Hold the touch control for 1 second
to turn the device on and off
Tap the touch control once to change
between fan speeds (Auto, 1, 2, 3)
Double tap the touch control to turn
ions on and off
Triple tap the touch control three
times rotate AQ display
Hold the touch control for 5 seconds
while the device is off to reset filter
On/Off
Fan Speed
Plasma Ions
Screen Flip
Filter Reset
How to Use
Touch Control
Wired Mode
4

1. Align the unlocked icon (o) on the battery pack with the arrow
behind the device.
2. Turn the device clockwise to lock the battery pack into place.
Connect the USB-C cable to the port located on the back of the
device with the battery pack attached.
Note: It is recommended that the battery be reduced to 1 bar before the next charge to
optimize the lifetime of the battery.
[4 Bars]
[Blinking Bars]
Fully Charged
Charging
Wireless Mode
How to Use
Battery Charging
5

Airflow Change
Turn the rotatable top clockwise 180oto change the angle of airflow.
Turn the rotatable top counter-clockwise 180oto revert the angle of
airflow back to the original.
Note: Do not turn the rotatable top beyond 180oor in the incorrect direction. Doing so may
damage the device’s functions.
How to Use
6

1. Place the cupholder insert inside the cupholder and rotate the top
clockwise to lock the cupholder insert into place.
2. Align the unlocked icon (o) on the cupholder insert with the arrow
behind the device.
3. Turn the device clockwise to lock the device into place.
Note: Before locking the device into place, adjust the cupholder insert towards the
preferred air flow direction.
How to Use
Cupholder Insert
7

• Do not dismantle or modify the device. Doing so will void
the warranty.
• When in use, please be careful of hair or unknown objects
entering the fan. Do not insert objects into the fan.
• Do not block the air inlet and air outlet areas.
• Do not expose the battery pack to high temperatures/heat for
extensive periods.
• In case of overheating, stop using the device.
• Do not forcefully and/or excessively turn the rotatable top of
the device.
• Do not throw the device from high altitudes. Doing so will
damage the device’s internal and external components.
• Do not run the device under water.
• Do not wash and reuse filter. Dispose the used filter and
replace with a new filter.
• Do not charge the product with a voltage exceeding the
specified voltage.
• Do not use a damaged USB-C cable
• Keep the product out of reach of infants and young children.
The device should not be operated by children.
Precautions
8

Odour Plasma ions
• Small charges may cause
slight odour
• Turn ions off
Fan noise Particles lodged
inside
• Hold device bottom-up
and shake lightly to
dislodge
Long charge
time Continuous use • Turn device off while plugged in
Not charging USB cable type • Use USB-A to USB-C only
Unable to
turn on No power • Connect USB-C cable to outlet
Issue Possible Cause Solution
Troubleshooting
9

Dimension w/o Battery Pack
Dimension w/ Battery Pack
Weight w/o Battery Pack
Weight w/ Battery Pack
Input
Noise Level
Battery
Usage Time
Recharge Time
Charging Type
Clean Air Delivery Rate (CADR)
Airflow Angle
Filter Life
74 x 74 x 200 mm
74 x 74 x 171 mm
4,000 mAh Li-Ion
40 – 51 dB(A)
USB-C
0.26kg
0.37kg
5Vdc 2A
Up to 11 hrs
6 hrs
7m3/hr
0° ~ 30°
2 - 3 months
Specifications
10

www.quair.co
Quair Company Limited
7B, 160 Wai Yip Street
Kwun Tong,
Hong Kong
Scan here for
warranty terms
