Qualcast QGTP25 User manual

Original Instructions
IMPORTANT! Please read these instructions fully before starting assembly.
October 2018
38cm 25.4cc
Petrol Grass Trimmer 495408
GTP25
These instructions contain important information that will help you get the best
from your product, ensuring it is assembled correctly and safely. If you need help
or have damaged or missing parts, call the Customer Helpline on 01904 727 500.

2
Contents
General safety warnings
Intended use
Warning symbols
In the box
Assembly
Preparation
Operation
Maintenance
Storage
Troubleshooting
Technical data
Disposal and recycling
Getting help
Warranty
3
8
8
10
11
13
14
20
25
28
29
30
30
30

3
General Safety Warnings
Safety warnings
WARNING! Read all safety warnings and
instructions.
Failure to follow the warnings and instructions
may result in serious injury.
WARNING! Read all safety warnings and
instructions designated by the symbol.
Save all warnings and instructions for future
reference.
• Always ensure anyone intending to operate this
machine is fully conversant with the contents of this
instruction manual prior to assembling, maintaining or
operating the machine.
• Perform assembly operations as described in this
manual. Failure to observe this warning may lead to
serious injury, death, or damage to the machine.
• Always take care when removing the packaging, to
prevent damage to you or to the machine.
IMPORTANT! Before assembling the machine, check all
the parts indicated in the manual are in the box. Inspect
all the parts for signs of damage. Do not assemble the
machine if you observe any damaged components.
NOTE! This machine complies with the Noise Emission
Directive 2000/14/EC.

4
General safety
• Keep this operating and maintenance manual in a safe
place for reference at a later date.
• Read the instructions carefully. Be familiar with the
controls and the proper use of the equipment.
• Never allow children or people unfamiliar with the
instructions to use the machine. Local regulations can
restrict the age of the operator.
• Never trim while people, especially children or pets,
are nearby. Keep in mind that the operator or user is
responsible for accidents or hazards occurring to other
people or their property.
• This appliance is not intended for use by people
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning the use of the appliance by a
person responsible for their safety.
• Do not touch the rotating spool.
Personal safety
• Do not allow children or untrained individuals to use
this unit.
• Never start or run the engine in an enclosed or poorly
ventilated area; breathing exhaust fumes can kill.
• Clear the work area before each use. Remove all
objects, such as rocks, broken glass, nails, wire, or
other such debris, which can be thrown or become
entangled in the cutting line.

5
• Wear safety glasses or goggles when operating this
unit.
• Wear heavy, long trousers, boots, and gloves. Do not
wear loose tting clothing, shorts, or go barefoot. Do
not wear jewellery of any kind.
Operation safety
• Never operate this unit on the operator’s left side.
• Secure long hair below shoulder level, to prevent
entanglement in moving parts.
• Keep all bystanders, children, and pets at least 15m
(50ft.) away.
• Do not operate this unit when you are tired, ill, or under
the inuence of alcohol, drugs, or medication.
• Do not operate it in poor lighting.
• Keep rm footing. Do not overreach. Overreaching can
result in loss of balance or exposure to hot surfaces.
• Keep all parts of your body away from any moving
parts.
• To avoid hot surfaces, never operate the unit with the
bottom of the engine above waist level.
• Do not touch the area around the exhaust or cylinder of
the units; these parts get hot during operation.
• Always stop the engine and remove the spark plug wire
before making any adjustments or repairs, except for
carburettor adjustments.
• Inspect the unit for loose fasteners, fuel leaks, etc.,
before each use. Replace any damaged parts before
use.

6
• The string head will rotate during carburettor
adjustments and engine starting.
• It has been reported, in certain individuals, that
vibrations from hand-held tools may contribute to a
condition called Raynaud’s Syndrome. Symptoms may
include tingling, numbness and blanching of the ngers,
usually apparent upon exposure to cold. Hereditary
factors, exposure to cold and dampness, diet, smoking
and work practices are all thought to contribute to
the development of these symptoms. It is presently
unknown what, if any, vibrations or extent of exposure
may contribute to the condition. There are measures
that can be taken by the operator to possibly reduce
the effects of vibration:
a) Keep your body warm in cold weather. When
operating the unit, wear gloves to keep the hands
and wrists warm. It is reported that cold weather is
a major factor contributing to Raynaud’s Syndrome.
b) After each period of operation, exercise to increase
blood circulation.
c) Take frequent work breaks. Limit the amount of
exposure per day.
d) Keep the tool well maintained, fasteners tightened
and worn parts replaced.
• If you experience any of the symptoms of this condition,
immediately discontinue use and see your doctor about
these symptoms.

7
• Mix and store fuel in a container approved for petrol
clearly identied as 2-stroke.
• Mix fuel outdoors where there are no sparks or ames.
Wipe up any fuel spillage. Move 10m (30ft.) away from
the refuelling site before starting the engine.
• Stop the engine and allow to cool before refuelling or
storing the unit.
• Allow the engine to cool; empty the fuel tank and
secure the unit from moving before transporting in a
vehicle.
• Replace the string head if cracked, chipped, or
damaged in any way. Be sure the string head is
properly installed and securely fastened. Failure to do
so can cause serious injury.
• Make sure all guards, straps, and handles are properly
and securely attached.
• Use only the manufacturer’s replacement string in the
cutting head. Do not use any other cutting attachment.
To install any other brand of cutting head to this string
trimmer may result in serious personal injury.
• Never operate the unit without the grass guard in place
and in good condition.
• Maintain a rm grip on both handles while trimming.
Keep the string head below waist level. Never cut with
the string head located over 76cm (30in.) above the
ground.
• Do not use metal cutting blades.

8
Intended Use
This machine is designed to be used as a machine for trimming grass and light foliage.
For non-commercial use!
Non-intended use:
This machine is not designed for trimming hedges or any other job task whereby the
machine has to be raised over a 30° angle.
Residual risks:
The machine uses a rotating cutting tool. Through this rotational motion, debris can be
thrown from the cutting head of the unit, e.g. stones and sticks.
Warnings Symbols
The following warning symbols appear through this manual and indicate the appropriate
safety measures you should take when operating and maintaining the machine.
Wear protective glasses, hearing protection, and a safety helmet (PPE).
Wear protective gloves.
Wear safety shoes.
Read the instructions for use prior to operating the machine.
When starting and working, keep the filament head away from foreign
materials.
When working, maintain a safe distance of 15m from other people and
from animals.

9
Only the filament trimmer may be used as a tool.
Maximum permitted rotational speed of the cutting tool.
Warning! Hot surface, do not touch.
No naked flames.
Conforms to all relevant safety standards.
Guaranteed sound power level data (114dB), in accordance with
Directive 2000/14/EC.
7500 min-1
114

10
In the Box
Parts
1. Line spool with cutting line
2. Safe guard
3. Lower tube
4. Steady grip
5. Switch On/Off
6. Throttle lock
7. Throttle lever
8. Choke lever
9. Starter
4
3
2
1
5
2
8
6
7
12
14 11
10
13
9
16
17
15
10. Spark plug boot
11. Air lter housing cover
12. Petrol tank
13. Housing for engine cooler
14. Fuel pump
15. Belt
16. Fuel mixer
17. Spark plug wrench

11
Assembly
WARNING!
Take care when removing packaging to prevent damage to the machine.
Make sure that you have sufcient space to put the machine down. Keep
your feet apart so that you have a stable position; bend at the knees and
keep your back straight.
Always recycle the packaging in accordance with local recycling schemes.
When assembling this machine, please follow the instructions.
Assembling the handle
Position the handle in the middle of the shaft.
Attach the handle holder and tighten using the wing screws.

12
Mounting the shaft
Push the lower part of the shaft (b) right down until the stop pin (a) slots into the hole (c) in
the shaft. This is easier to do if you rotate the bottom of the shaft (b) slightly in both direc-
tions. The pin (a) is in place when it is completely lodged in the hole. Lastly, tighten the
knob (d) securely.
Assembling the safety guard
Remove the screws from the cutting head holder.
Assemble the safety guard and tighten the screws using the accessory provided.
b
ca
d

13
Fitting the belt
Place the harness so that it runs over the left shoulder, crossing the chest and back.
In case of emergency, pull the rope of the quick-release mechanism. The metal locking bar
will be released automatically from the securing clip.
WARNING! Always attach the product to the harness! Do not carry it
only with your hands!
Preparation
Filling with engine fuel
Danger of injury! Fuel is explosive!
Turn off and cool the motor down before filling the tank with fuel. You must observe
all safety instructions relating to handling fuel.
Risk of device damage!
The device is supplied without motor or gearbox oil.
ATTENTION! Before operating, you must fill it with fuel.
WARNING! Always switch the engine off before fuelling. Never add fuel to
a machine with a running or hot engine. Move at least 30ft. (9m) from the
refuelling site before starting the engine. Do not smoke!
IMPORTANT! Keep the bottle at while lling and use a funnel.
This product is powered by a 2-stroke engine and requires pre-mixing of petrol and
2-stroke oil. Mix a high quality 2-stroke engine oil, according to JASO FC classic. Do not
use automotive oil or 2-stroke outboard oil. DO NOT mix quantities larger than usable in a
30-day period.

14
1a. Fuel mixture:
1 Litre (1000ml) petrol: 25cc (25ml) 2-stroke engine oil (40:1 ratio).
Using a funnel and keeping the bottle level, pour the fuel to the line marked PETROL; and
pour engine oil to the line marked OIL. Shake vigorously to mix the two products prior to
pouring into the tank of the grass trimmer.
1b. Filling tank
Clean the surface around the fuel cap to prevent contamination. Loosen the fuel cap slowly.
Rest the cap on a clean surface. Carefully pour fuel into the tank, avoiding spillage. Prior to
replacing the fuel cap, clean and inspect the seal located inside the fuel cap. Immediately
replace the fuel cap and hand tighten. Wipe up any fuel spillage.
NOTE: It is normal for smoke to be emitted from a new engine after rst use.
Emptying engine fuel
Only ever empty the tank outdoors or in well-ventilated rooms. Make sure not to spill fuel or
chain oil into the soil (environmental protection). Use a proper base.
Hold a collection container beneath the fuel drain bolt.
Unscrew the tank cap and remove it.
Allow the fuel to run out completely.
Screw the tank cap rmly by hand.
Operation
When working with the equipment, the appropriate plastic guard hood for ‘cutting blade
mode’ or ‘cutting line mode’ must be tted to prevent objects being thrown out by the
equipment.
The integrated blade in the cutting line guard hood automatically cuts the line to the
optimum length.

15
Start the engine
Do not start the unit until it has been completely assembled.
Danger of injury!
Do not operate the device unless you did not find any faults. If a part has become
defective, be sure to replace it before you use the device again.
Check before use!
Check the safe condition of the device.
Check the device for leaks.
Check the device for visual defects.
Check that all parts of the device have been securely tted.
Check that all safety devices are in proper condition.
Danger of injury!
Before starting work, always check the ground and remove all objects which could be
thrown by the device.
Once the machine has been set up properly, start the engine as follows:
1. Set the equipment down on a hard, level surface.
2. Push the engine switch to the ‘1’ position.

16
3. Put the choke lever on the position.
4. Press the fuel pump more than 5 times.
5. Press and hold the machine then, pull the recoil starter handle 5-6 times until the engine starts.
6. Adjust the choke lever to position. Pull the recoil starter again to start the engine.

17
7. Run the machine for 30 seconds at idle speed, clutch lock-off lever and throttle lever at
the same time.
8. Adjusting line length while working:
9. This machine is tted with a ‘Tap & Go’ head.To release more line, tap the cutting
line head against the ground with the engine at top speed, the line will be released
automatically and the knife will cut off the excess length.
If you experience any problems, turn off the engine and the machine will stop running. To
stop the cutting head, release the throttle lever.
The further you push the throttle lever, the higher the motor speed. When releasing the
throttle lever, the motor becomes idle and the cutting tools will stop.
If the machine is hot, the choke level can be adjusted to position directly when restart
the machine.
NOTE: If the engine does not start up after several attempts, refer to the section
‘Troubleshooting’.
NOTE: Always pull the starter cord out in a straight line. If it is pulled out at an angle,
friction will occur on the eyelet. As a result of this friction, the cable will become frayed and
will wear away faster. Always hold the starter handle when the cable retracts. Never allow
the cable to snap back when it has been pulled out.
NOTE: Do not start the motor in tall grass.

18
Stop the engine
Push the engine switch to the ‘0’ position
ATTENTION: When the engine has been switched off, the cutter continues running for
several seconds; therefore, do not touch the cutting head of the brush cutter until it has
come to a complete stop!
Working instructions
Extending the cutting line
CAUTION! Do not use any kind of metal wire or metal wire encased in plastic in the line
spool. This may cause serious injury to the user. To extend the cutting line, run the engine
at full speed and tap the line spool on the ground. This will automatically extend the line.
The blade on the safety shield will cut the line to the appropriate length.
IMPORTANT: Remove all grass and weed remnants at regular intervals to prevent the shaft
tube overheating. Lawn, grass and weed remnants become trapped under the safety shield
and prevent the shaft tube from receiving adequate ventilation. Remove these remnants
using a tool not bare hands.
Different cutting methods
When the equipment is correctly assembled, it will cut weeds and long grass in places
which are difcult to access, e.g. along fences, walls and foundations, and trees. It can also
be used for ‘mowing’ vegetation to prepare a garden for other applications.

19
ATTENTION: Even if it is used carefully, cutting around foundations, stone or concrete
walls will result in the line suffering more than normal wear.
Trimming/mowing
Swing the trimmer from side to side in a scything motion. Always keep the line spool
parallel to the ground. Check the site and decide which cutting height you require. Guide
and hold the line spool at the required height to obtain an even cut.
Low trimming
Hold the trimmer right in front of you at a slight angle so that the underside of the line spool
is above the ground and the line strikes the correct target. Always cut away from yourself.
Never draw the trimmer towards yourself.
Cutting along fences/foundations
Approach wire mesh fences, lath fences, natural stone walls and foundations slowly so that
you can cut close to them without striking the obstacle with the line. If, for example, the line
strikes stones, stone walls or foundations, it will wear or fray. If the line strikes wire fencing,
it will break.
Trimming around trees
When trimming around tree trunks, approach slowly so that the line does not strike the
bark. Walk around the tree, cutting from left to right. Approach grass or weeds with the tip
of the line and tilt the line spool forwards slightly.
WARNING! Take extreme care during mowing work. When doing such work,
keep a distance of 30 metres between yourself and other people or animals.
Mowing
When mowing, you want to cut all the vegetation down to the ground. To do this, set the
line spool at an angle of 30° to the right. Place the handle in the required position. Take into
consideration the danger of objects being thrown by the machine.
WARNING! Do not use the equipment to remove objects from footpaths,
etc. The equipment is a powerful tool and can throw small stones and other
objects a distance of 15 metres or more, causing injuries and damage to
cars, houses and windows.

20
Jamming
If the cutting blade jams as a result of attempting to cut vegetation that is too dense, switch
off the engine immediately. Remove the grass from the equipment before you restart it.
Maintenance
WARNING: Always wear protective gloves when working on or around
cutting tools.
When not in use, transport or storage, always install the transport protection on all cutting
tools.
Before performing any maintenance or cleaning work, always turn off the engine and pull
out the spark plug boot.
1. Do not spray the unit with water. It damages the engine.
2. Clean the unit with a cloth or brush, etc.
Maintenance schedule
12 hours of use 24 hours of use 36 hours of use
Air lter clean clean replace
Spark plug check clean replace
Expert inspection is required:
If the brush cutter strikes an object.
If the motor stops suddenly.
If the gears are damaged.
Replacing the line spool/cutting line
1. Unscrew the line spool.
