9520 Series Pulse Generator
Operating Manual
Version 5.6
Quantum Composers, Inc.
212 Discovery Drive
Bozeman, MT 59718
Phone: [phone]
Fax: [phone]
www.quantumcomposers.com
Your distributor:

1-2
1 Table of Contents
1Table of Contents .......................................................................................1-2
2Introduction.................................................................................................2-6
Technical Support........................................................................................................2-6
Warranty ......................................................................................................................2-6
Package Contents.........................................................................................................2-6
3Safety Issues..............................................................................................3-7
4Front Panel Overview.................................................................................4-8
9520 Front Panel..........................................................................................................4-8
Display Layout and Indicators.................................................................................4-8
Description of Front Panel Area..............................................................................4-8
5Pulse Concepts and Pulse Generator Operations....................................5-10
Counter Architecture Overview.................................................................................5-10
System Timer Functions............................................................................................5-10
Channel Timer Functions...........................................................................................5-11
Digital Output Multiplexer ........................................................................................5-11
Dependent & Independent Timing Events.................................................................5-11
Navigating the 9520 Front Panel ...............................................................................5-12
Selecting Menus.....................................................................................................5-12
Selecting Menu Items ............................................................................................5-12
Numeric Input Mode..............................................................................................5-12
Entering Non-Numeric Parameters........................................................................5-12
Alphanumeric Input Mode.....................................................................................5-13
Enabling System Output........................................................................................5-13
Enable/Disable Channel Output.............................................................................5-13
Rearming the Channel Timers...............................................................................5-13
Setting Pulse Timing Parameters...........................................................................5-14
Setting Pulse Output Parameters............................................................................5-14
Using the Output Multiplexer................................................................................5-14
Setting System Internal Rate Parameters...............................................................5-14
69520 Menu Structure................................................................................6-16
System Mode Menus (FUNC + MODE key) ............................................................6-16
Setting System Mode of Operation........................................................................6-16
Channel Menus (A, B, C, D, E, F, G, or H key)........................................................6-16
Timing Menu .........................................................................................................6-16
Output Configuration Menu...................................................................................6-16
Mode Menu............................................................................................................6-17
Wait Menu .............................................................................................................6-17
Enabling Channel Output.......................................................................................6-17
Setting the Channel Timing Parameters ................................................................6-17
Setting Pulse Configuration Output Type..............................................................6-17
Setting Channel Mode of Operation ......................................................................6-17
Delaying the Start of Channel Output....................................................................6-18
Advanced Channel Menus (FUNC + A, B, C, D, E, F, G or H key).........................6-18
Multiplexer Menu ..................................................................................................6-18

1-3
Configuring the Channel Multiplexer....................................................................6-18
Channel Gate Menu ...............................................................................................6-18
Setting the Sync Source .........................................................................................6-18
Setting Channel Gate Control................................................................................6-18
Clocks/Rate Menus (FUNC + RATE key) ................................................................6-19
Internal Reference Menu........................................................................................6-19
Setting the Internal Reference Source and Rate ....................................................6-19
Reference Out Menu..............................................................................................6-20
Setting the Output Reference.................................................................................6-20
Trigger Menus (TRIG key)........................................................................................6-20
Enabling System Trigger .......................................................................................6-20
Gate Menus (GATE key)...........................................................................................6-20
Standard Gate Menu ..............................................................................................6-20
Enabling System Gate............................................................................................6-21
System Configuration Menus (FUNC + SYSTEM key) ...........................................6-21
Communication Interface Menu ............................................................................6-21
Setting System Communication Parameters..........................................................6-21
User Options Menu 1.............................................................................................6-21
Setting Keypad Parameters....................................................................................6-21
User Options Menu 2.............................................................................................6-22
Setting the Auto Start Mode ..................................................................................6-22
Setting the Display Decimal Mark.........................................................................6-22
Setting the Display Brightness...............................................................................6-22
Store Menu (FUNC + STORE key)...........................................................................6-22
Storing a Configuration..........................................................................................6-22
Recall Menu (FUNC + RECALL key)......................................................................6-23
Recalling System Configurations ..........................................................................6-23
Counter Menu (FUNC + AUX1 key) ........................................................................6-23
Using the Counter Function...................................................................................6-23
Information Menus (FUNC + 0 key).........................................................................6-23
Information Menu A..............................................................................................6-23
Information Menu B ..............................................................................................6-23
7Operating the 9520...................................................................................7-24
Quick Start - Normal Internal Rate Generator Operation..........................................7-24
Quick Start - Normal External Trigger Operation.....................................................7-24
System Timer Overview ............................................................................................7-25
To Use Continuous Mode......................................................................................7-25
To Use Single Shot Mode......................................................................................7-25
To Use System Burst Mode Function....................................................................7-25
To Use System Duty Cycle Function.....................................................................7-26
Channel Timer Overview...........................................................................................7-26
To Use Channel Normal Mode Function...............................................................7-26
To Use Channel Single Shot Function...................................................................7-27
To Use Channel Burst Mode Function ..................................................................7-27
To Use the Channel Duty Cycle Function.............................................................7-27
To Use the Channel Gating Function.....................................................................7-28

1-4
External Input Overview............................................................................................7-28
To Generate a Pulse on Every Trigger Input.........................................................7-28
To Generate a Burst of Pulses on Every Trigger Input..........................................7-29
To Start a Continuous Stream of Pulses Using the External Trigger ....................7-29
To use the External Gate to Control the System....................................................7-30
8Programming the 9520 .............................................................................8-31
Personal Computer to Pulse Generator Communication...........................................8-31
RS232 Interface Overview.........................................................................................8-31
USB Interface Overview............................................................................................8-32
GPIB Interface Overview ..........................................................................................8-32
Ethernet Interface Overview......................................................................................8-32
Programming Command Types and Format..............................................................8-33
Line Termination .......................................................................................................8-33
IEEE 488.2 Common Command Format...................................................................8-33
SCPI Command Format.............................................................................................8-34
SCPI Command Keywords....................................................................................8-34
SCPI Command Format.........................................................................................8-34
SCPI Keyword Separator.......................................................................................8-34
SCPI Optional Keywords.......................................................................................8-35
SCPI Specific and Implied Channel ......................................................................8-35
SCPI Parameter Types...........................................................................................8-35
Error Codes............................................................................................................8-35
Programming Examples.........................................................................................8-36
9520 INSTrument Commands (SCPI Command Summary).................................8-37
9520 System PULSe[0] Commands (SCPI Command Summary)........................8-38
9520 Channel PULSe[n] Commands (SCPI Command Summary) ......................8-39
9520 SYSTem Commands (SCPI Command Summary) ......................................8-40
9520 DISPlay Commands (SCPI Command Summary) .......................................8-41
IEEE 488.2 Common Commands..........................................................................8-41
INTERNAL RATE GENERATOR............................................................................A-1
PROGRAMMABLE TIMING GENERATOR..........................................................A-1
SYSTEM EXTERNAL TRIGGER/GATE INPUT(S)...............................................A-1
MODULE SPECIFICATIONS...................................................................................A-2
TTL/ADJUSTABLE DUAL CHANNEL OUTPUT MODULE (Standard)..............A-2
TRIGGER INPUT ..................................................................................................A-2
GATE INPUT.........................................................................................................A-3
OPTICAL OUTPUTS.................................................................................................A-3
OPTICAL INPUTS.....................................................................................................A-3
EXTERNAL CLOCK IN/OUT ..................................................................................A-3
GENERAL..................................................................................................................A-3
OUTPUT MODULES ................................................................................................A-4
Standard ..................................................................................................................A-4
Optional...................................................................................................................A-4
INPUT MODULES ....................................................................................................A-4
Standard ..................................................................................................................A-4
Optional...................................................................................................................A-4

1-5
System Options.......................................................................................................A-4
Safety Marking Symbols............................................................................................. B-5
COM Overview........................................................................................................... C-8
GPIB Interface............................................................................................................ C-8
Ethernet Interface........................................................................................................ C-8
IP Address and Raw TCP/IP Connection ............................................................... C-8
Determining IP Address.......................................................................................... C-8
DT15 Overview ........................................................................................................D-10
DT15 Menus .............................................................................................................D-10
Trigger 1 Menu (TRIG key) .................................................................................D-10
Enabling System Trigger ......................................................................................D-10
Trigger 2 Menu (GATE key) *.............................................................................D-10
DT15 SCPI Command Summary..............................................................................D-11
DT15 IEEE 488.2 Command Summary ...................................................................D-11
AT35 Description.......................................................................................................E-12
AT35 Specifications...................................................................................................E-12
TZ50 Overview..........................................................................................................F-13
TZ50 Specifications...................................................................................................F-13
TTL/CMOS Mode .................................................................................................F-13
Adjustable Mode....................................................................................................F-13
Increment Overview..................................................................................................G-14
Increment Menus ......................................................................................................G-14
System Mode Menu 1 Extensions (FUNC + MODE key) ...................................G-14
System Mode Menu 2 Extensions (FUNC + MODE key) ...................................G-14
Setting System Increment Modes of Operation....................................................G-14
Advanced Channel Menu Increment Extension (FUNC + channel key)..............G-15
Setting the Channel Increment Parameters...........................................................G-15
Increment SCPI Command Summary.......................................................................G-15
Increment Initialization and Reset (FUNC + CLR)..................................................G-15
Increment Specifications...........................................................................................G-15
AT45 Option Overview ............................................................................................H-17
AT45 Protection Error Messages..............................................................................H-17
Module Errors.......................................................................................................H-17
System Limit Error ...............................................................................................H-17
Voltage Change Timing........................................................................................H-17
AT45 Channel Menus...............................................................................................H-18
Channel Output Configuration Menu ...................................................................H-18
AT45 SCPI Command Extension Summary.............................................................H-18
AT45 Specifications..................................................................................................H-18

2-6
2 Introduction
This manual is a reference designed to familiarize you with the Quantum
Composers 9520 series pulse generator and is arranged so that you can easily
find the information you’re looking for. Generally, each topic has its own section
and no section assumes that you’ve read anything else in the manual.
Technical Support
For questions or comments about operating the 9520 -- our technical staff can be
reached via one of the following methods:
Phone: [phone]
Fax: [phone]
Online: www.quantumcomposers.com
Warranty
In addition to a 30-day money back guarantee, the 9520 has a two-year limited
warranty from the date of delivery. This warranty covers defects in materials and
workmanship. Quantum Composers will repair or replace any defective unit.
Contact us for information on obtaining warranty service.
Package Contents
The box you receive should contain the following:
9520 Pulse Generator
AC Power Cord
Disc that includes
oOperating Manual
oSoftware Drivers
oCommunication Software
Contact Quantum Composers [phone] if any parts are missing.

3-7
3 Safety Issues
Normal use of test equipment presents a certain amount of danger from electrical
shock because testing must be performed where exposed voltage is present. An
electrical shock causing 10 milliamps of current to pass through the heart will
stop most human heartbeats. Voltage as low as 35 V (DC or RMS AC) should
be considered dangerous and hazardous since it can produce a lethal current
under certain conditions. Higher voltages pose an even greater threat because
such voltage can easily produce a lethal current. Your normal work habits should
include all accepted practices that will prevent contact with exposed high voltage,
and steer current away from your heart in case of accidental contact with a high
voltage. You will significantly reduce the risk factor if you know and observe the
following safety precautions:
If possible, familiarize yourself with the equipment being tested and the
location of its high voltage points. However, remember that high voltage
may appear at unexpected points in defective equipment.
Do not expose high voltage needlessly. Remove housing and covers only
when necessary. Turn off equipment while making test connections in
high voltage circuits. Discharge high voltage capacitors after shutting
down power.
When testing AC powered equipment, remember that AC line voltage is
usually present on power input circuits, such as the on-off switch, fuses,
power transformer, etc.
Use an insulated floor material or a large, insulated floor mat to stand on,
and an insulated work surface on which to place equipment. Make certain
such surfaces are not damp or wet.
Use the time proven “one hand in the pocket” technique while handling an
instrument probe. Be particularly careful to avoid contact with metal
objects that could provide a good ground return path.
Never work alone. Someone should always be nearby to render aid if
necessary. Training in CPR first aid is highly recommended.

4-8
4 Front Panel Overview
9520 Front Panel
Display Layout and Indicators
A 4 line x 20 character vacuum fluorescent display module displays parameters
and status information. The status information is located in the upper-left corner
of the display, between the two brackets. There are four enunciators:
↕A vertical arrow indicates there are additional pages
to the current menu.
☼An alternating hollow and then solid circle indicates
the unit is actively generating pulses, or armed and
waiting for an external trigger.
♪A musical note indicates the function key has been
pressed.
?In external oscillator operation, a question mark
indicates the internal pll is not yet locked with the
external clock signal.
The upper-right side of the display contains the title of the currently displayed
menu. The rest of the display is used for system parameters. The display
brightness may be adjusted, allowing the instrument to be used under various
lighting conditions.
Description of Front Panel Area
Keypads
Three keypad areas provide fast access to various menus and easy editing of
system parameters.
Channel Keypad Provides one touch access to the menus for setting
up the channel parameters. Pressing the appropriate
letter will display the parameters for the
corresponding channel. Example: Pressing the Akey
will access the Channel A menus.
Arrow Keypad The up (UP) and down (DOWN) arrow keys are used
to increment/decrement the current parameter
(indicated by the blinking cursor). The position of the
cursor controls the step size for each increment. The

4-9
right (RIGHT) and left (LEFT) arrow keys moves the
cursor to different positions within the current
parameter. The NEXT key selects the next parameter
in the currently displayed menu.
Numeric Keypad Allows numbers and alphanumeric values to be
entered. When entering alphanumeric values,
pressing a key will display the first letter shown on the
key. The yellow FUNC key allows the keys to select
the yellow functions.
Repeated key presses will toggle through all the letters, both upper and lower
case, shown on the keycap. To enter two letters which appear on the same
keycap, select the first character, then use the right arrow to shift to the next
position and enter the next letter. When data entry is complete the ENTER key
must be pressed.
Rotary Adjustment Knob
As an alternative to the Arrow Keypad, the Rotary Adjustment Knob may be used
to adjust the current parameter. The step size is controlled by the position of the
cursor; however turning the knob faster will increase the step size. Pushing the
knob will perform functions similar to the NEXT key and switch to the next
parameter in the currently displayed menu.
Second Level Menus (Function Key)
The second level menus (indicated in yellow above certain keys) are accessed
through the use of the yellow function (FUNC) key. Pressing the FUNC key once
and then pressing the desired menu key will display the specified second level
menu. Pressing the FUNC key twice in succession will put the unit into “Function
Lock” mode, where the second level menus can be accessed without repeatedly
pressing the FUNC key. Pressing the FUNC key a third time will exit “Function
Lock” mode.

5-10
5 Pulse Concepts and Pulse Generator
Operations
Counter Architecture Overview
*Start source is: RUN/STOP key in Internal Modes
External input in External Trigger modes
*TRG command via Serial/GPIB access
**Channels are armed by the RUN button. In single shot and burst modes
channels may be rearmed by pressing the RUN button.
System Timer Functions
The System Timer functions as a non-retriggerable, multi-vibrator pulse
generator. This means that once started, depending on the mode, the timer will
produce pulses continuously. Before pulses can be generated, the timer must be
armed and then receive a start pulse. Arming the counter is done by pressing
the RUN/STOP key. With external trigger disabled, the RUN/STOP key also
generates the start command for the counter. With external trigger enabled, the
external trigger provides the start pulse. In either case, once started, the counter
operation is determined by the System Mode Generator. Standard modes
include:
Continuous Once started T0pulses are generated continuously.
Single Shot One T0pulse is generated for each start command.
Burst ‘n’ T0pulses are generated for each start command.
Duty Cycle Once started T0pulses cycle on and off continuously.

5-11
The T0pulses are distributed to all of the start inputs of the Channel Timers and
Mode Generators
Channel Timer Functions
The Channel Timer functions as a non-retriggerable, delayed, one shot pulse
generator. This means that the timer will only generate one delayed pulse for
every start pulse received. Once the channel timer has started counting,
additional start pulses will be ignored until the pulse has been completed
(non-retriggerable). The start pulse for each channel is provided by the internal
T0pulse generated by the Internal System Timer. Whether or not a pulse is
generated for each T0pulse is determined by the Channel Mode Generator.
Standard modes include:
Normal A pulse is generated for each T0pulse.
Single Shot One pulse is generated at the first T0pulse, after
which output is inhibited.
Burst A pulse is generated for each T0pulse, 'n' times, after
which output is inhibited.
Duty Cycle ‘n’ pulses are generated for each T0pulse after which
the output is inhibited for ‘m’ times. The cycle is then
repeated.
Different modes may be selected for each output, allowing a wide variety of
output combinations. Each output may also be independently disabled or gated
(using the external gate input).
Digital Output Multiplexer
The outputs of the Channel Timers are routed to a set of multiplexers. This
allows routing of any or all Channel Timers to any or all of the unit outputs. In the
normal mode of operation, the output of the TnChannel Timer is routed to the Tn
output connector. As an example, if a double pulse is required on Channel A
output, one can multiplex the Channel A timer with the Channel B timer adjusting
each timer to provide the necessary pulses.
Dependent & Independent Timing Events
The 9520 allows the user to control the relationship between the Channel Timers
by setting the sync source for each timer. Independent events are all timed
relative to the internal T0start pulse. Dependent events may be linked together
by setting the sync source to the controlling event. This allows the instrument to
match the timed events and adjustments can be made in one event without
detuning the timing between it and a dependent event.

5-12
Navigating the 9520 Front Panel
Selecting Menus
Parameters are grouped in menus, selectable using menu keys. To select the
output channel parameters press the letter key corresponding to the desired
channel. To select second level menus press the FUNC key and then the key
corresponding to the desired function. To select advanced channel menus press
the FUNC key followed by the desired channel key. Menus may include a
number of different pages with each page containing up to four parameters. The
status block in the upper-left corner of the display shows a vertical arrow if the
current menu contains additional pages. To select the next page, press the
channel button again or select the same second level menu by pressing the
FUNC key and the channel/menu key again.
Selecting Menu Items
Within a menu, the blinking cursor indicates the current menu item for editing.
The NEXT key or pressing the adjustment knob will select a different menu item.
Numeric Input Mode
When the current item is numeric, the system enters the Numeric Input Mode. In
this mode data may be edited in one of three ways. Using the arrow keypad, the
left (LEFT) and right (RIGHT) arrow keys are used to select a digit to edit. The
selected digit blinks to identify itself as the active digit. The UP and DOWN arrow
keys are then used to increment or decrement this digit. Alternately, after using
the LEFT and RIGHT arrow keys to select an active digit, the adjustment knob
may be used to increment and decrement this digit. The adjustment knob
features speed dependent resolution. Slow rotation will increment or decrement
the active digit by one. As you increase the speed of rotation, the parameter will
be 10 to 1000 times faster depending on the speed.
An additional entry mode is using the numeric keypad. Enter the number,
including decimal point using the numeric keypad. Complete the number using
the ENTER key. To clear number entry and/or start over press the clear key
(CLR). Pressing the CLR key a second time will exit the numeric keypad mode
and restore the original number.
The last entry mode is a modified form of scientific notation. The FUNC button
acts as 10-in this case. Type in the value followed by FUNC then the number
button that represents the power desired. For example 64us is entered as 6, 4,
FUNC, and then 6.
Entering Non-Numeric Parameters
When the current item is non-numeric, the UP and DOWN arrow keys are used
to select among different options for the parameter. The adjustment knob may
also be used to change the selection. If the item is an on-off toggle, the UP arrow

5-13
(CW adjustment knob) enables the item and the DOWN arrow (CCW adjustment
knob) disables the item.
Alphanumeric Input Mode
When the current item is alphanumeric, the system enters the Alphanumeric
Input Mode. In this mode, data is entered using the alphanumeric keypad.
Pressing a key will display the first letter shown on the keypad. Repeated key
presses will toggle through all the letters, both upper and lower case, shown on
the key cap. To enter two letters which appear on the same key cap, select the
first character, then use the right arrow to shift to the next position and enter the
next letter. The Left and Right arrow keys may be used to position the cursor to
edit any character. When data entry is complete, the ENTER key must be
pressed. The keys contain the following characters:
1 1 2 3 4 5 6 7 8 9 0
2 A B C a b c 2
3 D E F d e f 3
4 G H I g h i 4
5 J K L j k l 5
6 M N O m n o 6
7 P Q R S p q r s 7
8 T U V t u v 8
9 W X Y Z w x y z 9
0 0 1 2 3 4 5 6 7 8 9
. . , # $ % & ? • -- + * / space
Enabling System Output
The RUN/STOP key is used to arm the system. With external trigger disabled,
the key will arm and start pulse output. With external trigger enabled, the key will
arm the pulse generator. Pulse output then starts after the first valid trigger input.
Pressing the RUN/STOP key a second time disables the pulse generator.
Enable/Disable Channel Output
At the top of each channel menu page is a parameter to enable or disable the
output of the channel. Each channel may be individually enabled or disabled. An
illuminated channel key indicates that the channel is enabled.
Rearming the Channel Timers
In the channel single shot mode and burst mode, the Channel Timers may be
rearmed after completing the initial output by pressing the FUNC key followed by
the RUN/STOP key. If there are channels currently running in normal mode,
single shot and burst channels can be re-armed without affecting the timing on
normal mode channels by pressing function RUN/STOP button.

5-14
Setting Pulse Timing Parameters
Pulses are defined by a delay, from their sync or start pulse to the active edge,
and a width.
Wid: Sets the width of the active portion of the pulse.
Dly: Sets the delay from the sync source to the start of the pulse.
NOTE: If Wid + Dly + 75ns (hardware reset time) > T0Period, the correct pulse
width will be generated but at a slower rate.
Setting Pulse Output Parameters
There are three basic types of outputs available on the 9520: (a) TTL/CMOS
compatible outputs; (b) adjustable amplitude outputs; (c) optical outputs.
Out: Selects between TTL/CMOS mode and Adjustable mode
when both are available on a single output.
Pol: Sets the voltage polarity of the pulse, active high or active
low. Note: All outputs are positive - negative voltages are
not supported.
Ampl: In adjustable mode, it sets the unloaded output voltage. The
actual output voltage will depend on the load impedance. For
example: If the load is 50 ohms, the output will be 50% of the
stated voltage.
Using the Output Multiplexer
Each output channel includes a multiplexer which allows routing any or all of the
timer outputs to the physical output. This allows double pulses and other complex
pulse trains to be generated. Only timing parameters are multiplexed together,
not amplitudes.
-HGFEDCBA-
Mux: -00000101-
The multiplexer is represented by an “n” bit binary number as shown above. “n” is
the number of channels. Each bit represents a channel timer, which is enabled
by setting the bit to one. In the above example, timers A and C are combined on
the current output.
Setting System Internal Rate Parameters
The internal T0period controls the fundamental output frequency of the system.
Each channel may operate at submultiples of the fundamental frequency using
their duty cycle mode.
Source: Sets the reference source for the internal T Period.
Per: Sets the internal T Period.

5-15
To set the system Internal Rate press the yellow FUNC key, then press the
RATE key, and then use the dial or number pad to specify the T0Period.

6-16
6 9520 Menu Structure
System Mode Menus (FUNC + MODE key)
MODE:
Continuous
MODE: Single
Shot
MODE: Burst
MODE: Duty
Cycle
#/On
#/Burst
#/Off
Setting System Mode of Operation
The MODE menu sets the T0system timer mode. The menu will show the extra
set parameters (Burst, On & Off) only when they are appropriate.
Mode: Selects the T0mode: Continuous, Single Shot, Burst or Duty
Cycle mode.
Burst: Sets the number of pulses to be generated when in Burst
mode.
On: Sets the number of pulses to be generated during each on
cycle.
Off: Sets the number of pulses to skip each during off cycle when
in the Duty Cycle mode.
*NOTE: Any mode may be started by either the RUN/STOP key in the internal
trigger mode or armed by the RUN/STOP key and started by an external trigger
in the external trigger mode. In the single shot and burst modes, (internally
triggered) the unit disarms itself at the end of the pulse train. Pressing the
RUN/STOP key after the unit has been disarmed will generate a new pulse train.
Channel Menus (A, B, C, D, E, F, G, or H key)
Timing Menu
Channel Enable
Sync Source
Pulse Width
Delay
Output Configuration Menu
Channel Enable
Channel Enable
Channel Enable
Channel Enable
Channel Enable
Output Type:
TTL/CMOS
Output Type:
Adjustable
Output Type:
Optical
Output Type:
High Z
Output Type:
Low Z
Polarity
Polarity
Polarity
Polarity
Output Level
Output Level
Output Level

6-17
Mode Menu
Channel Enable
Channel Enable
Channel Enable
Channel Enable
Mode: Normal
Mode: Single
Shot
Mode: Burst
Mode:
Duty Cycle
#/On Pulses
#/Burst Pulses
#/Off Pulses
Wait Menu
Channel Enable
#/Wait Pulses
Enabling Channel Output
At the top of each of the channel menu pages is a parameter to enable or disable
the channel. Each channel may be individually controlled. When enabled, the
channel key will illuminate.
Setting the Channel Timing Parameters
To define a pulse requires two parameters: the delay to the active edge and the
width of the pulse.
Wid: Sets the channel pulse width.
Dly: Sets the channel delay until the active edge.
Setting Pulse Configuration Output Type
The 9520 supports two types of outputs: a high speed TTL/CMOS compatible
output and for applications which require different voltage levels or higher
current, an adjustable voltage output. The pulses can also be defined to be active
high or active low.
Out: Selects the output mode; TTL/CMOS, Adjustable, Optical,
High Impedance (Hi Z), or Low Impedance (Lo Z)
Pol: Sets the pulse polarity, active high or active low.
Ampl: Sets the output voltage level when in the Adjustable mode.
Setting Channel Mode of Operation
Each channel may be set independently to operate in one of four modes: normal,
single shot, burst, or duty cycle (within the CHANNEL menus):
Mode: Selects the mode for the current channel. Additional
parameters are provided for the burst mode and the duty
cycle mode.
Brst: Sets the number of pulses in the burst mode to gener-ate
before inhibiting output.

6-18
On: Sets the number of pulses to generate before inhibiting
output in Duty Cycle Mode.
Off: Sets the number of pulses to inhibit before repeating the On
Cycle in Duty Cycle Mode.
Delaying the Start of Channel Output
Within any channel mode, the output of the channel can be delayed using the
wait parameter (within the CHANNEL menu):
Wait: Sets the number of T0pulses to wait until enabling the
channel output.
Advanced Channel Menus (FUNC + A, B, C, D, E, F, G or H key)
Multiplexer Menu
-HGFE DCBA-
Multiplexed
Channels
Configuring the Channel Multiplexer
To define which channels are fed into the channel multiplexer, the corresponding
bit for the desired channel to add should be set to 1. All desired omitted
channels should have the corresponding bit set to 0.
Mux: Enable/disable bit field.
Channel Gate Menu
Channel Enable
Channel Enable
Channel Enable
Ch Gate Mode:
(Gate Menu)
Ch Gate Mode:
Pulse Inhibit
Ch Gate Mode:
Output Inhibit
Logic Level
Logic Level
Setting the Sync Source
Although each channel receives its start pulse from the internal T0pulse, the start
pulse can be assigned such that the delay entered is relative to the T0pulse or
any other channel pulse. This allows dependent events to link. The unit will not
allow a circular chain of sync sources that would result in a channel triggering
itself. The delay entered is relative to the selected sync source.
Sync Source: Selects the channel sync source.
Setting Channel Gate Control
When the global gate is set (Chan Menu), the channel can then use the gate
input with independent behavior from other channels.

6-19
Gate: Enables the GATE input for the channel by setting the
method of output control used with the gating
function.
Logic: Sets the logic level used with the gating function,
either active high or active low.
“Pulse Inhibit” method
The gate prevents the channel from being triggered by the channel’s
trigger source pulse. If a pulse has already started when the gate disables
the channel, the pulse will continue normal output but will not restart on
the next trigger pulse.
“Output Inhibit” method
The gate leaves the base triggering alone and enables/ disables the
output directly.
Clocks/Rate Menus (FUNC + RATE key)
Internal Reference Menu
Source:
System Osc
Source:
10MHz Ext
Source:
20MHz Ext
Source:
25MHz Ext
Source:
40MHz Ext
T0Period
T0Period
T0Period
T0Period
T0Period
Source:
50MHz Ext
Source:
80MHz Ext
Source:
100MHz Ext
T0Period
T0Period
Setting the Internal Reference Source and Rate
Source: Selects the internal or external clock source from
which the unit will operate.
To: Sets the T0period which determines the fundamental
output frequency of the unit.

6-20
Reference Out Menu
Ref Out: T0
Pulse
Ref Out:
100MHz
Ref Out: 50MHz
Ref Out:
33.33MHz
Ref Out: 25MHz
T0Period
T0Period
T0Period
T0Period
T0Period
Ref Out: 20MHz
Ref Out:
16.67Mhz
Ref Out:
14.2857MHz
Ref Out:
12.5MHz
Ref Out:
11.11MHz
T0Period
T0Period
T0Period
T0Period
T0Period
Ref Out: 10MHz
T0Period
Setting the Output Reference
Ref Out: Selects the frequency of the output reference for
synchronizing with external system components.
Trigger Menus (TRIG key)
Mode: Disabled
Mode:
Triggered
Threshold Level
Trigger Edge
Enabling System Trigger
Enable the use of the TRIG input by the system timer as a trigger source.
Mode: Selects between disabling/enabling the trigger mode.
Level: Sets the trigger threshold. Edge: Selects between
rising and falling edges as the trigger source when a
trigger mode is enabled.
Gate Menus (GATE key)
Standard Gate Menu
Mode: Disabled
Mode: Pulse
Inhibit
Mode: Output
Inhibit
Mode: (Chan
Menu) *
Threshold
Level
Threshold
Level
Threshold Level
Logic Level
Logic Level
* Gate Mode is controlled on a per channel basis from the Advanced Channel
Gate Menu
