G300 Gateway Appliance
StorNext G300 Gateway
Appliance Site Planning
Guide
Product Overview
The StorNext G300 Gateway Appliance combines industry-proven
Quantum hardware and StorNext software into one convenient, out-of-
the-box solution. Your StorNext G300 system software has been pre-
installed and is ready to operate with a minimum of additional
configuration required at time of installation. This guide provides an
overview of site characteristics, physical requirements, and environmental
specifications essential for the installation of the StorNext G300 Gateway
Appliance.
Note: Make sure to take the online training for the StorNext G300
Gateway Appliance in order to make the best use of your product.
The online training is available at www.quantum.com/
ServiceandSupport/StorageCareLearning/Index.aspx
Contents
Product Overview................................... 1
Included With Your StorNext G300
Gateway Appliance ................................ 2
Installation Requirements...................... 2
Rack Compatibility............................. 2
StorNext G300 Gateway Appliance
Setup.................................................. 2
Installation and Integration Services. 2
Hardware Description ............................ 3
Service .................................................... 6
StorNext G300 Gateway Appliance
Warranty ............................................ 6
Service Package Upgrades ................. 6
StorNext G300 Shipping Information.... 7
StorNext G300 Specifications ................ 7
EMI Certification ................................ 7
Physical Characteristics...................... 7
Environmental Specifications ............ 9
Quantum Customer Suport ................. 10

2Included With Your StorNext G300 Gateway Appliance
G300 Gateway Appliance Site Planning Guide
Included With Your StorNext G300 Gateway Appliance
The StorNext G300 Gateway Appliance is fully configured to your specifications and pre-
tested in the factory. Every StorNext G300 Gateway Appliance configuration arrives with
all necessary parts included. Each system comes with an accessory kit containing rack-
mount hardware and ships with StorNext G300 Gateway software installed from the
factory.
Installation Requirements
Rack Compatibility Nearly all standard four-post EIA 19” server racks are compatible with the StorNext
G300 Gateway Appliance rack mount kits. See Physical Characteristics on page 7 for
system rack space requirements.
StorNext G300 Gateway
Appliance Setup
After the system has been installed and configured, you are ready to use your StorNext
G300 Gateway Appliance.
Required Network Information
• DHCP (Dynamic Host Configuration Protocol) is not supported. You must provide a
static IP address at the time of installation.
• The default IP Address is: 10.1.1.1
Installation and
Integration Services
Installation and integration of the StorNext G300 Gateway Appliance will be performed
by Quantum Professional Services. Phone support for the installation process is available
via the Quantum support number for your area. Quantum World Wide phone support is
as follows
Americas:
800-284-5101 (toll free) or 949-725-2100
Europe, Middle East and Africa:
00800-4-782-6886 (toll free) or [phone]
Asia Pacific:
[phone] (toll free) or [phone]

Hardware Description 3
G300 Gateway Appliance
Hardware Description
The StorNext G300 Gateway Appliance ships with two 3.5” 500GB 7.2K RPM SATA hard
disk drives (HDD) in a 1+1 RAID 1 configuration for the G300 platform software.
StorNext G300 Gateway servers include the following components:
• Two 2.4 GHz 6-core CPUs
• 24 GBs of memory (12GB/CPU)
• Redundant cooling fans and power
Note: The server ships with one 2-port 8 GB FC PCIe card in slot 4; two embedded 1
GbE Ethernet ports; and two expansion PCIe Ethernet cards that differ
depending on the StorNext G300 model.
StorNext G300 Gateway Appliance models differ with regard to type and number of
Ethernet expansion cards.
• G301 ships with two 4-port 1 GbE Ethernet PCIe expansion cards in slots 1 and 2.
• G302 ships with one 2-port 1 GbE Ethernet PCIe expansion card in slot 1, and one 2-
port 10 GbE Ethernet PCIe expansion card in slot 2.
G301 Gateway
Appliance Ports
For the StorNext G301 Gateway Appliance, the MDC network is always a bonded
(bond0) network. Physical ports 3 and 4 are dedicated to the MDC network. Ports 5
through 10 are dedicated to the LAN client network. The LAN client network is either
bonded (bond1) or configured as individual network interfaces. When bonded, the
G301 Gateway’s LAN client network includes the on-board embedded Ethernet port 2
for a total of 7 network ports (see Ta bl e 1 on page 4 for port descriptions).
See Figure 1 below to view port assignments (ethernet ports denoted in yellow) and
(fiber channel ports denoted in green) for the G301 Gateway Appliance.
Figure 1 G301 Port Numbers

4Hardware Description
G300 Gateway Appliance Site Planning Guide
Table 1 G301 Network Ports
G302 Gateway
Appliance Ports
For the StorNext G302 Gateway Appliance, the MDC network is always a bonded
(bond0) network. Physical ports 3 and 4 are dedicated to the MDC network. Physical
ports 5 and 6 are dedicated to the LAN client network. The LAN client network is either
Physical
Ethernet
Port
Number
Logical
Ethernet Port
Number
Port Physical
Location Port Function Network Bonds
S eth0 Embedded
Port 1
Reserved for
Quantum Service
n/a
2 eth1 Embedded
Port 2
LAN Client Network
(1 GbE)
Bond 1 – This port can be
bonded alongside the
other LAN client ports
(Eth6 - Eth11) or
configured as a standalone
port. ALL connected LAN
ports must be bonded
together OR not bonded
and assigned individual IP
addresses.
3 eth2 PCIe Slot 12
Port 1
Metadata Network
(1GbE)
Bond 0 - The MDC network
is always a bonded (Bond
0) network. The customer
doesn’t have the option to
break the bond.
4 eth3 PCIe Slot 12
Port 2
Metadata Network
(1GbE)
5 eth6 PCIe Slot 12
Port 3
LAN Client Network
(1 GbE)
Bond 1 – The default is for
all the LAN client ports to
be bonded. ALL connected
LAN ports must either be
bonded together (Bond 1)
OR not bonded and
assigned individual IP
addresses.
6 eth7 PCIe Slot 12
Port 4
LAN Client Network
(1 GbE)
7 eth8 PCIe Slot 23
Port 1
LAN Client Network
(1 GbE)
8 eth8 PCIe Slot 23
Port 2
LAN Client Network
(1 GbE)
9 eth10 PCIe Slot 23
Port 3
LAN Client Network
(1 GbE)
10 eth11 PCIe Slot 23
Port 4
LAN Client Network
(1 GbE)

Hardware Description 5
G300 Gateway Appliance
bonded (bond1) or configured as individual network interfaces (see Tab le 2 on page 5
for port descriptions).
See Figure 2 on page 5 to view port assignments (ethernet ports denoted in yellow) and
(fiber channel ports denoted in green) for the G302 Gateway Appliance.
Figure 2 G302 Port Numbers
Table 2 G302 Network Ports
Physical
Ethernet
Port
Number
Logical
Ethernet Port
Number
Port Physical
Location Port Function Network Bonds
S eth0 Embedded Port
Port 1
Service n/a
2 eth1 Embedded Port
Port 2
Unused/
Unavailable
The OS does not recognize
this port as in use, so it is
unused and cannot be
configured nor bonded to
the LAN client or MDC
network.
3eth2PCIeSlot12
Port 1
Metadata Network
(1GbE)
Bond 0 - The MDC network
is always a bonded network.
These 1GbE ports and the
customer doesn’t have the
option to break the bond.
4eth3PCIeSlot12
Port 2
Metadata Network
(1GbE)
5eth4PCIeSlot23
Port 1
LAN Client (10GbE) Bond 1 – The default is for
all the LAN client ports to be
bonded. The ports are either
bonded or given individual
IP addresses.
6eth5PCIeSlot23
Port 2
LAN Client (10GbE)

6Service
G300 Gateway Appliance Site Planning Guide
Service
StorNext G300 Gateway
Appliance Warranty
The StorNext G300 gateway appliance’s warranty includes one year of Quantum’s
Bronze Support Plan. This includes next business day on-site response, 5x9 telephone
support, and on-line resources.
This warranty covers the StorNext G300 gateway Appliance and all drives, and includes
firmware downloads, telephone support, and Internet access to Quantum’s online
Customer Support web site.
The Quantum Customer Support web site features online service request processing,
Web-based event status tracking, and a comprehensive Knowledge Base. Quantum’s
Knowledge Base gives you 7x24 real-time electronic access to complete product and
support resources and the expertise of Quantum’s Global Services organization.
Service Package
Upgrades
Quantum’s Global Services organization is geared towards delivering the fastest possible
response and root cause resolution, helping you maximize your backup investments,
better manage processes, and make the best use of your resources. We ensure total
customer satisfaction by providing comprehensive, responsive services on a worldwide
basis.
A variety of support options are available to you via Quantum’s tiered hardware support
plans to meet a range of budget and availability requirements.
Quantum’s Support Plans include:
•Next Business Day Gold – (Next Business Day Onsite, 7x24 Phone Support)
•Gold – (7x24x4 Hr on-site, 7x24 phone support)
•Customized Platinum offering –A Warranty extension of Bronze (5x9xNBD on-site,
5x9 phone support) is also an option for the second and third year of ownership.
Features of these plans include: 24-hour telephone support, on-site response, access to
strategic account management (available with select service packages), priority call
handling, strategically located spares parts, online resources, and software/firmware
upgrades.
For more information on these service plans, please visit www.quantum.com or contact
your Quantum Sales Representative.
Quantum service engineers are available around the world and are deployed to respond
to on-site service demands. In addition, spare part depots are strategically located
around the globe so that service technicians have access to the parts and equipment
necessary to maintain or repair your StorNext G300 gateway appliance.

StorNext G300 Shipping Information 7
G300 Gateway Appliance
StorNext G300 Shipping Information
The StorNext G300 is delivered in the following configuration (see Ta b l e 3 ).
Table 3 StorNext G300
Shipping Configurations
StorNext G300 Specifications
This section lists characteristics and specifications of the StorNext G300 Gateway
Appliance. These characteristics and specifications are categorized as follows:
•EMI Certification
•Physical Characteristics
•Environmental Specifications
EMI Certification This product is certified under the regulatory model name E19S.
Physical Characteristics The following tables provide dimensions and other physical characteristics of the
StorNext G300 Gateway Appliance system components:
•Physical Characteristics
•Cable Drops
•Power Requirements
•Environmental Specifications
Table 4 Physical Characteristics
G300 Configuration
Number of
Shipping Boxes
Shipping Box
Weight
1 StorNext G301 169.3 lbs (31.4 kg)
1 StorNext G302 164.6 lbs (29.3 kg)
StorNext G300 Chassis
Height 2U, 3.5 inches (8.89 cm)
Width (side to side) 17.25 inches (43.8 cm)

8StorNext G300 Specifications
G300 Gateway Appliance Site Planning Guide
Table 5 Cable Drops
Table 6 Power Requirements
Caution: To safeguard continuous operations in the event of a power outage,
Quantum recommends that you connect the StorNext G300 gateway
appliance to a UPS (uninterruptable power supply). Two circuits should be
used (one per power supply).
Depth (front to back) 24.5 in (62.2 cm)
Weight (stand alone) 37 lbs (16.78 kg)
Rack Space Required 2U
Air clearance Open 4 in (10.2 cm) behind unit for proper air flow
StorNext G300 Cable Drops
Ethernet Cable Drops Gateway LAN Client direct Ethernet connections, Ethernet switch
connections, and Ethernet connections for SAN metadata.
Power Outlets System - 2 USA type 3-prong power outlets (Nema 5-15) or 2 C13 type
3-prong power outlets (IEC320 C13).
StorNext G300 Power Requirements
Power Supplies and Cords Two (2) hot swappable redundant power supplies
Two (2) USA type 3-prong power cords with IEC320 C13 to Nema 5-15
connectors
Two (2) C13 to C14 type 3-prong power cords with IEC320 C13 to
IEC320 C14 connectors
Input Voltage 100–240 VAC
Input Frequency 50–60Hz
Rated Current 10-5 amps
Maximum Operating Current 2.5-1.0 amps
Inrush Current 5.2-5.1 amps
Maximum Operating Wattage 242 watts
Maximum Operating BTUs 825 BTU/hr

StorNext G300 Specifications 9
G300 Gateway Appliance
Environmental
Specifications
Tab l e 7 provides various StorNext G300 gateway appliance environmental specifications.
Table 7 Environmental
Specifications
Climatic Environment
Temperature and Altitude Operating 10 to 35°C (50 to 95°F) with a maximum temperature
gradation of 10°C per hour
Note: 35 °C (95 °F) is the maximum temperature for the
StorNext G300 Gateway Appliance at sea level.
For altitudes above 2,950 ft (899.2m), decrease
the operating temperature 0.9°C for every 1,000
ft (304.8m) of altitude.
Shipping and storage -4 to 140°F (-20°C to 60°C)
Relative humidity Operating 20% to 80% (non-condensing)
Shipping and storage 5% to 95% (non-condensing)
Altitude Operating 0 to 10,000 ft (0 to 3,048m)
Shipping and storage 0 to 35,000 ft (0 to 10,688m)
Vibration and Shock
Maximum Vibration Operational: 0.26 G’s random vibration, 5 to 350Hz
Non-operational: 0.5 G’s random vibration, 5 to 350Hz
Maximum Shock Operational: 2 G’s for 11ms, ½ Sine
Non-operational: 3.5 G’s for 11 ms, ½ Sine
Acoustic
Acoustic output Operating < 67 dBA at 1 meter, room temperature (20C)
Agency Approvals
Safety IEC 60950-1, CSA 60950-1-03/UL 60950-1
Emissions EN55022 Class A, FCC Part 15 Class A, ICES-003 Class A, VCCI Class A, CISPR 22 Class A,
CNS13438 Class A, KN22 Class A

For assistance, contact the Quantum Customer Support Center:
USA: 1-800-284-5101 (toll free) or [phone]
EMEA: [phone] (toll free) or [phone]
APAC: [phone] (toll free) or [phone]
Worldwide: http://www.quantum.com/ServiceandSupport
About Quantum
Quantum is a proven global expert in Data Protection and Big Data
management, providing specialized storage solutions for physical,
virtual and cloud environments. From small businesses to major
enterprises, more than 50,000 customers trust Quantum to help
maximize the value of their data by protecting and preserving it over
its entire lifecycle. With Quantum, customers can Be Certain they’re
able to adapt in a changing world—keeping more data longer,
bridging from today to tomorrow, and reducing costs. See how at
www.quantum.com/BeCertain.
©2015 Quantum Corporation. All rights reserved. Quantum and the Quantum logo are registered
trademarks of Quantum Corporation and its affliates in the United States and/or other countries. All
other trademarks are the property of their respective owners. Protected by Pending and Issued U.S.
and Foreign Patents.
*6-67594-02*
10 6-67594-02 Rev C, April 2016
G300 Gateway Appliance Site Planning Guide
Quantum Customer Suport
Immunity EN55024/KN24:
EN 61000-3-2 - Harmonic current emissions test
EN 61000-3-3 - Voltage fluctuations and flicker in low-voltage supply systems test
EN 55024:1998 - Information technology equipment - Immunity characteristics - Limits
and methods of measurements
EN 61000-4-2 - Electrostatic discharge immunity test
EN 61000-4-3 - Radiated, radio-frequency, electromagnetic field immunity test
EN 61000-4-4 - Electrical fast transient/burst immunity test
EN 61000-4-5 - Surge immunity test
EN 61000-4-6 - Immunity to conducted disturbances, induced by radio-frequency fields
EN 61000-4-8 - Power frequency magnetic field immunity test
EN 61000-4-11 - Voltage dips, short interruptions and voltage variations immunity test
