Quantum UC1000 User manual

Quantum UC1000
Premium Quality
Drinking Water System
Installation Guide
UC1000 / 4000

UC1000 Installation Guide
www.danamark.com
DANAMARK WATERCARE
90 Walker Drive, Brampton, ON L6T 4H6 | 1 888 DANAMARK | T 905 792 2353 | F 905 792 2986
Item
Part Number
Description
Qty
A
Q1000
Quantum 1000 Filter Cartridge
1
B
QH3
Quantum Head
1
C*
3046-44
Mounting Bracket
1
D*
3081-31
Restrictor Fitting (Outlet)
1
E*
PI011223S
Male Connector (Inlet)
1
F
CI3208U7S
Faucet Connector
1
G
FCTT8-520
Teflon Tape
1
H
PPASV121208W
Angle Stop Adaptor
1
I
MS1034
SS Mounting Screws (Phillips)
2
J
TBL14
¼” Blue Waterline
10’
K
9970-56
Designer Series Chrome Faucet
1
*Installed on (B) Quantum Head
Item
Description
Qty
K1
Brass Escutcheon (with O-Ring)
1
K2
Black Locating Washing
1
K3
Lock Washer
1
K4
Nut
1
K5**
Compression Nut
1
K6**
Tube Support/Insert
1
K7**
Delrin Sleeve
1
**Used in place of (F) CI3208U7S for compression fitting installations
A
B
C
E D K
F
H
G I
J
(K1) Brass Escutcheon &
Rubber O-Ring
Countertop
(K3) Lock Washer
(K4) Nut
(F) Faucet Connector
(K2) Black locating washer
Use tapered side down for ½” hole
Contents
Contents of Designer Series Chrome Faucet
(Part # 9970-56)
Thank you for purchasing a Danamark Quantum Under Counter
Drinking Water System. Rest assured that you have purchased the very
finest in point-of-use water purification. Should you have any questions
or concerns, please call us at:
1-888-DANAMARK (1-888-326-2627)
Preparation For Installation: *Important: Use only on cold water supply*
1. Shut off cold water supply to sink.
2. Relieve line pressure by opening the cold water tap for a few seconds until water stops; then close the tap.
3. Select a suitable location to mount (B) Quantum Head and (A) Cartridge, leaving approximately 2” of space
below cartridge for ease of future cartridge changes.
4. Select a suitable location to mount (K) Chrome Faucet, minimum of 1” from edge of the sink.
Tools Required:
-Phillips screwdriver
-½” Drill bit and drill
-Adjustable wrench
Installation of Faucet:
1. When drilling the countertop; place the (K1) Escutcheon plate,
with dome face up, 1/8” from the back of the countertop and a
minimum of 1” from the edge of the sink. Use as a template to
drill a ½” hole.
2. Assemble faucet as shown on diagram to the right.
3. Wrap threaded faucet stem with the provided (G) Teflon tape.
4. Tighten (F) Faucet Connector to the threaded faucet stem.

Connecting Inlet Water Line
1. Locate and close the cold water Angle Stop Valve under
your kitchen sink. Open cold water faucet to release water
pressure. (Fig. 2)
2. Unscrew and disconnect the braided tubing on top of the
Angle Stop Valve. (Fig. 3)
3. Attach the bottom of the (H) Angle Stop Adaptor to the
existing Angle Stop Valve. (Fig. 4)
4. Attach the braided tubing to the top of the (H) Angle Stop
Adaptor. (Fig. 5)
5. Close side valve on (H) Angle Stop Adaptor (Fig. 6) and
open cold water Angle Stop Valve to return water service
to kitchen sink. Check for leaks.
6. Measure length of tubing needed to connect (H) Angle Stop
Adaptor to (E) Inlet Fitting on (B) Quantum Head. Allow
adequate tubing to avoid sharp turns.
7. Cut desired tubing length with a sharp knife or tube cutter
at a 90oangle. Make sure the cut is flush or a leak may
form.
8. Insert ends of tubing from (H) Angle Stop Adaptor to the
(B) Quantum Head Inlet. (Fig. 7)
9. Push tubing all the way into fitting and gently pull to
confirm a tight fit. (See Figure 8 for how the John Guest
Quick Connect fitting works)
UC1000 Installation Guide
www.danamark.com
DANAMARK WATERCARE
90 Walker Drive, Brampton, ON L6T 4H6 | 1 888 DANAMARK | T 905 792 2353 | F 905 792 2986
Mounting Filter Head:
1. After selecting a suitable location to allow for future cartridge
changes (Extra 2” under cartridge), mount the (B) Quantum
Head with installed bracket to wall under sink.
2. Use the provided (I) SS Mounting Screws and ensure a secure
mount. (Fig. 1)
Fig. 3 Fig. 4 Fig. 5
Fig. 7 Fig. 8
Fig. 2
Closed
Fig. 6
Open
Fig. 1

UC1000 Installation Guide
www.danamark.com
DANAMARK WATERCARE
90 Walker Drive, Brampton, ON L6T 4H6 | 1 888 DANAMARK | T 905 792 2353 | F 905 792 2986
Connecting Outlet
1. Measure length of tubing needed to connect (D) Outlet of
the (B) Quantum Head, to the (F) Faucet connector
installed on (K) Faucet. Allow adequate tubing to avoid
sharp turns.
2. Cut desired tubing length with a sharp knife or tube cutter
at a 90oangle. Make sure the cut is flush or a leak may
form.
3. Insert one end of tubing into (F) Faucet Connector. (Fig. 8)
4. Insert other end of tubing into (D) Outlet of (B) Quantum
Head. (Fig. 9)
Installing Filter Cartridge
1. Remove plastic wrapping from new (A) Q1000 Filter Cartridge.
2. Align one of the extruded lugs at the top of the (A) cartridge, with the label
on the (B) Quantum Head. (Fig. 10)
3. Push cartridge up into the head, you will feel a little click as the O-Rings sit
into place.
4. Turn cartridge to the right about ¼” turn until it stops and locks into place.
5. Open up the (H)Angle Stop Adaptor to allow water to flow to the filter
cartridge. (Fig. 11)
6. Turn faucet to the on position to allow water to flow at full force.
7. Allow the water to run for at least 5 minutes to purge the cartridge before
using.
For more information please feel free to contact us at 1-888-DANAMARK (326-2627)
Fig. 8 Fig. 9
Fig. 10
Closed
Fig. 11
Open
