Quark-Elec QK-G022 User manual

Quark-elec Manual
https://www.quark-elec.com 1of 31 2018
V2
QK-G021/22 GSM Remote Controller Manual
Features
Remote monitoring and control by mobile phone GSM SMS message
Connects to up to 2 alarm inputs and 3 Relay outputs
Automatic alarm by SMS message when alarm input is triggered
Status request and response by SMS
Remote control of 3 Relay outputs by SMS message
Automated control of 2 Relay outputs by SMS message (activated by alarm input)
Scheduled control of 2 Relay outputs by SMS message
Remote manual override
Android and iOS APP interface
Monitor and Control through text message input or phone APP
Up to 4 mobile phones can monitor and control through each unit
In-built clock for programming the switch state
Easy to install and configure via SMS or APP (no PC required)
Compatible with all major 2G SIM networks (Tri-band GSM for use in Europe & USA)
Other specialized units available:
G022G also includes GPS receiver allowing you to track the location of the unit
G022P also includes wireless passive infrared (PIR) motion detector as an additional alarm input

Quark-elec Manual
https://www.quark-elec.com 2of 31 2018
V2
Contents
1. Set up overview....................................................................................................................................................................... 3
2. Introduction...............................................................................................................................................................................4
3. Hardware.................................................................................................................................................................................. 5
4. Enclosure..................................................................................................................................................................................6
5. Preparing SIM card................................................................................................................................................................. 7
5.1. Insert SIM into the SIM card slot............................................................................................................................. 7
6. Configuration............................................................................................................................................................................8
7. Status LED’s.............................................................................................................................................................................8
8. Alarm function and digital connection.................................................................................................................................. 9
9. Relay working modes........................................................................................................................................................... 10
9.1. Normal open/ normal closed wiring options........................................................................................................ 10
9.2. Daily timer setting.................................................................................................................................................... 10
9.3. Self-lock vs. latching mode.................................................................................................................................... 11
9.4. Delay time setting on latching mode.................................................................................................................... 12
10. APP.....................................................................................................................................................................................13
10.1. Setup..................................................................................................................................................................... 14
10.2. Set QK controller SIM number.......................................................................................................................... 15
10.3. Register SIM cards............................................................................................................................................. 16
10.4. Setting the clock on the QK controller............................................................................................................. 17
10.5. Check relay working mode................................................................................................................................ 18
10.6. Rename control terminals..................................................................................................................................20
10.7. Control panel........................................................................................................................................................21
10.8. Track and trace....................................................................................................................................................22
11. Command and response SMS....................................................................................................................................... 23
12. Specification...................................................................................................................................................................... 26
13. Specialized units...............................................................................................................................................................27
13.1. Wireless PIR detector (G022P variant)........................................................................................................... 27
13.2. GPS receiver (G022G variant)..........................................................................................................................28
14. Order options.................................................................................................................................................................... 30
15. Limited warranty and notices..........................................................................................................................................30

Quark-elec Manual
https://www.quark-elec.com 3of 31 2018
V2
1. Set up overview
You will need:
SIM card:
The SIM must operate on the GSM (2G) network. Most network providers provide 2G cover, check
with your supplier.
Credit on the SIM (we recommend automatic top-ups)
The SIM is not PIN protected
The SIM is set to disable voicemail
Avoid SIM cards that deactivate automatically if the SIM is not used often (If your SIM will do this
and if your G021/22 is likely to be unused for long periods of time you will have to send the G021/22 an
update request periodically to keep the SIM card active.)
Power supply cable: make sure it is long enough to reach your device in its final location.
Check there is mobile network reception for your SIM card in the location that your device will be installed
(you can check by putting the SIM card in a mobile phone)
Installation:
1. Download and install the app for mobile phones. https://www.quark-elec.com/downloads/apps/
2. Select G021/22 location: location must be indoors and not exposed to water or high humidity.
3. Connect the relay output (if required): check relay setup for whether you want relays in normal open (NR) or
normal closed (NC) position. Think about length of wires needed to connect.
4. Connect alarm inputs (if required): alarm inputs must send signal as switches closing circuit to input 1/2 or by
sending low voltage signal to input 1/2. Think about length of wires needed to connect.
5. Insert your SIM into the G021/22 device (make a note of the SIM number first for reference)
6. Connect to power: Check LEDs are working correctly.
Red LED: will flash at 1 second intervals once the system has finished initialization. It will then flash every time it is
operating a command
Blue LED: LED will flash blue at start up as it looks for a network signal. Once a signal has been found the LED will
flash much slower, every 3 seconds.
7. Register the main phone number that will control the device within 10 minutes of powering up the
G021/22. Register the main mobile terminal with G021/22 module by texting ‘888888’ from your chosen phone to
G021/22 SIM card. If registration is successful, the module will reply with “Your phone has been registered”. If
unsuccessful, the module will reply with ‘registered disabled’. If registration is unsuccessful, restart the device
and reattempt registration within 10 minutes of powering up the device.
The network LED will flash after registration is completed. You can add up to 3 secondary control mobile phones
using text/APP codes (check the manual for full list of text codes).
8. You can now send commands and receive messages either by text or through the text generating APP.
Remember; the device processes one command at a time. Each command will have a reply to confirm the
command has been received and executed. You must wait for a reply message before sending another command.
If G022P (PIR version):
Batteries: the PIR device uses a 9.0 volt D-shape battery.
Location: Think about location of sensor and whether there is anything in between the PIR sensor and the
G021/22. Some obstructions will make the signal weaker for example metal structures and concrete walls.
If G022G (GPS version) :
Location: The GPS antenna cable length is 2 metres.
The G021/22G device itself must be somewhere indoors and not exposed to a lot of water or high humidity.
(This is an overview only. Familiarize yourself with the manual before installation.)

Quark-elec Manual
https://www.quark-elec.com 4of 31 2018
V2
2. Introduction
The G021/22 series remote controller is a versatile device which can be connected to many electronic devices in
homes, offices, factories or wherever required. The standard G021/22 includes two digital alarm inputs, three
independent relay switches.
It allows operators to control and monitor remote equipment or machines using SMS (Short Message Service) via
the GSM network. Up to 4 mobile phone numbers (SIM card numbers) can be linked to each G021/22 remote
controller (1 main control terminal, and up to 3 additional control terminals). These mobile phones can belong to
technicians, engineers or individuals who have a requirement to control and/or monitor corresponding devices.
The G021/22 includes:
Two digital alarm inputs connections: for connection to various inputs to be monitored (an alarm SMS can
be received when either alarm input is triggered. The alarm input can also be set to trigger automated control of the
machinery connected to the Relay outputs 1 and/or 2)
Three relays output connections: for connection to the machinery to be controlled (two with daily timers
and automated control options manual options and one with manual SMS function)
Android and iOS APP: the device can be controlled by either SMS text message codes or an APP for
Android and iOS (iPhone) phones. This is a touch sensitive, user friendly interface.
Four control mobile phones - one main control terminal and up to 3 additional control terminals can be registered
with G021/22.
Figure 1: System diagram
Three specialized modules available:
G021/22 includes the main controller unit
G022G includes G022 plus a GPS receiver allowing you to track the location of the unit
G022Pincludes G022 plus a wireless passive infrared (PIR) motion detector as an additional alarm input

Quark-elec Manual
https://www.quark-elec.com 5of 31 2018
V2
3. Hardware
Figure 2: General view of the control module (V1.9)
Figure 3: G021 mechanical drawing (V1.5)

Quark-elec Manual
https://www.quark-elec.com 6of 31 2018
V2
4. Enclosure
The enclosure is made of IP56 Insulation Class 2 plastic. External dimensions: 145 x 90 x 41
mm.
Figure 4: GK-G022 (with enclosure)
Figure 5: Enclosure drawing. Measurements in mm

Quark-elec Manual
https://www.quark-elec.com 7of 31 2018
V2
5. Preparing SIM card
Please ensure:
The SIM must operate on the GSM (2G) network. Most network providers provide 2G cover, check with
your supplier.
There is credit on the SIM (we recommend automatic top-ups)
The SIM is not PIN protected
The SIM is set to disable voicemail
Avoid SIM cards that deactivate automatically if the SIM is not used often (usually after 3 months
inactivity).If you’re SIM will do this and if you’re G021/22 is likely to be unused for long periods of time; send the
G021/22 an update request periodically to keep the SIM card active.
Register the SIM card; ensure there is sufficient credit on the card for programming confirmation texts to be sent
from G021/22 module.
The PIN request option should be disabled from the SIM card before inserting it into the G021/22 module. To check
the PIN request status of your SIM card, place the card in an unlocked mobile phone and switch the phone on. If
normal calls can be made without entering a PIN number, then it is disabled. Please also make sure voicemail is
disabled before inserting the SIM card into the module.
If a ‘pay as you go’ (PAYG) SIM card is used, it is recommended that users choose to automatically ‘Top-Up’ when
the credit falls below a certain limit. Some PAYG SIM cards will be de-activated by the network if they are not used to
make an outgoing voice call or send an SMS text message within a specific period. To prevent this, simply send the
G021/22 a text ‘DQSJ’ (this can be done through the APP) and G021/22 will reply with the local time by text
message. This should be done once a month to keep the SIM card active.
5.1. Insert SIM into the SIM card slot
Write down SIM number before inserting into G021/22
The SIM card should be inserted into the SIM card slot before applying the power.
Power Up
The G021/22 module can be powered by 12V to 24V DC power supply).
Connect a 12V DC power supply to the power screw terminals 1 & 2, ensuring positive is connected to terminal 1
and switch on the power supply.
The red power LED will flash at 1 second intervals once the system has finished initialization.
The blue network LED indicator will initially flash quickly and, once logged onto the network, it will flash more
slowly, approximately once every 3 to 4 seconds.

Quark-elec Manual
https://www.quark-elec.com 8of 31 2018
V2
6. Configuration
The following steps are required to configure G021/22 for first time use:
Insert the SIM card into controller box
Power up
Send ‘888888’ as SMS to the G021/22 controller. If successful, the user will receive the message ‘Your
phone has been registered’.This command should be received within the first 600 seconds after powering
up G021/22. Otherwise “registered Disabled” message will be sent back to inform the failure of the main SIM
registration. If this happens, turn off the device and start again.
If additional mobile terminals are required, the operator should send “BDn(mobile terminal number)F” to the
G021/22 controller. The user will receive the message “Your phone has been registered”. Up to 3 additional
terminals can be configured (the main mobile number registered with the device won’t show up when “WHORED” is
sent).The operator is now ready to use G021/22. Details about the SMS command and response messages can be
found in chapter 10
You can control the device by either:
Manually entering the codes by SMS text message
Using the phone APP (android and iOS) interface. Using the APP, you simply select the action you want and
the APP formulates and sends the SMS message for you. This App does not allow you to send messages to
your device for free nor does it work over WiFi.
7. Status LED’s
The device has two working LED’s to notify the user of its current operations. The network LED and the system LED.
Both these LED’s flash depending on their operating status.
Network LED – LED will flash blue at start up as it looks for a network signal. Once a signal has been found
the LED will flash much slower, every 3 seconds.
System LED - will flash at 1 second intervals once the system has finished initialization. It will then flash
every time it is operating a command

Quark-elec Manual
https://www.quark-elec.com 9of 31 2018
V2
8. Alarm function and digital connection
G021/22 has two external alarm input connectors and various inputs can be connected to them. For example,
door/windows sensors, smoke alarms, carbon dioxide detectors, motion sensors, thermostats, temperature/wind
detectors, and moisture detectors.
Using these sensors/detectors, G021/22 can be set up as a protection/alarm and response system.
G021/22 external alarm inputs are active when a trigger pulse or a constant level of 0 V is applied.
If the sensor/detectors are triggered (they send the low level signal (0 V) to G021/22); G021/22 will send out an SMS
to the registered mobile terminals. Meanwhile, the corresponding relays you set up will also be activated. (Alarm
function can be disabled so as not to activate relay or timer; it will still send message to say alarm triggered)
Alarm input port
Corresponding relay number
External alarm 1 (INT1)
Relay 1
External alarm 2 (INT2)
Relay 2
* PIR detector
Relay 3
*Note: the Alarm input function is not supported on Relay 3 on the standard G021/22.
However, the wireless PIR detector works with Relay 3 on the G022P variant. (More details
can be found in the G022P section).
There are two typical ways the external alarm inputs can communicate with G021/22. External alarm devices can be
used as,
1. Switch
2. Alarm input source (low level voltage signal)
Figure 6: External alarm input device connection methods

Quark-elec Manual
https://www.quark-elec.com 10 of 31 2018
V2
9. Relay working modes
9.1. Normal open/ normal closed wiring options
The G021/22 is equipped with three digital output relays for connection to equipment to be controlled. The relays can
be set up in normal open and normal closed positions. This gives the customer the advantage of having it set as a
failsafe if there is a power loss or for timing the relay to open or close with delays.
Figure 7: Relay positions
Normal open position – if common and normal open are wired then relay 1 will be off when powered up. To
activate relay 1 either a message or a command must be received from the user or from input 1. This activates
the relay and closes the circuit turning on the output of relay1.
Normal closed position – if common and normal closed are wired then relay 1 will be active while the G021/22
is powered up. This is for fail safe systems where the power going off in the G021/22 will close relay 1 and
activate the output of relay 1.
Remember, the device processes one command at a time. Each command will have a reply to confirm the
command has been received and executed. You must wait for a reply message before sending another
command. All SMS text commands must always be sent using CAPITAL letters. Do not add spaces or
any other characters.
9.2. Daily timer setting
Daily timer settings are for Relays 1 and 2. They support a daily timer function to control the actions of the output.
This is useful for turning the relays on and off without having to message the device.
The relays will switch to ON/OFF states according to the timer settings. These two relays also support two working
modes, self-lock and latching control.
