Quasar Science Crossfade X User manual

Crossfade X
LED Linear Light
ENGLISH

Table of Contents
Copyright ..................................................................................................................................................... 3
Safety Information ............................................................................................................................................ 4
Overview ..................................................................................................................................................... 6
What’s in the Box ..................................................................................................................................... 6
Crossfade X - Overview .............................................................................................................................. 7
Technical Specifications .............................................................................................................................. 7
Physical Installation .......................................................................................................................................... 9
Control ......................................................................................................................................................10
Photometric data ............................................................................................................................................ 11
Spectral Data & Metrics .....................................................................................................................................13
Troubleshooting T8s and Crossfades ........................................................................................................................15
Warranty ..................................................................................................................................................... 16
Copyright ....................................................................................................................................................19
Crossfade X
2

Copyright
Copyright © 2022
All rights reserved.
Original Instructions: English
All rights reserved throughout the world. No part of this publication may be stored in a retrieval system, transmitted, copied or reproduced in any way, including, but
not limited to, photocopy, photograph, magnetic or other record without the prior agreement and permission in writing of Videndum Plc.
Disclaimer
The information contained in this publication is believed to be correct at the time of printing. Videndum Ltd reserves the right to make changes to the information or
specifications without obligation to notify any person of such revision or changes. Changes will be incorporated in new versions of the publication. We are making
every effort to ensure that our publications are updated on a regular basis to reflect changes to product specifications and features. Should this publication not
contain information on the core functionality of your product, please let us know. You may be able to access the latest revision of this publication from our website.
Videndum Production Solutions Ltd reserves the right to make changes to product design and functionality without notification.
Trademarks
All product trademarks and registered trademarks are the property of Videndum Plc.
All other trademarks and registered trademarks are the property of their respective companies.
Published by:
Videndum Production Solutions Ltd
Email: [email protected]
Crossfade X
3

Safety Information
Important information on the safe installation and operation of this product. Read this information before operating the product. For your personal safety, read these
instructions. Do not operate the product if you do not understand how to use it safely. Save these instructions for future reference.
Warning Symbols Used in these Instructions
Important information on the safe installation and operation of this product. Read this information before operating the product. For your personal safety, read these
instructions. Do not operate the product if you do not understand how to use it safely. Save these instructions for future reference.
WARNING
Where there is a risk of personal injury or injury to others, comments appear supported by the warning triangle symbol. Where there is a risk
of damage to the product, associated equipment, process or surroundings, comments appear supported by the word ‘Caution’.
DANGER
Where there is a risk of electric shock, comments appear supported by the hazardous voltage warning triangle.
Electrical Connection
DANGER
Risk of electric shock. Do not remove cover, no user servicable parts inside the product.
WARNING
Risk of electric shock. Always check cables for signs of damage. Damaged cables can cause personal injury and/or damage the equipment.
DANGER
Refer servicing to qualified service personnel.
Crossfade X
4

Operation
WARNING
Special precautions and handling instructions are contained in this user guide and should be strictly adhered to for safe and reliable operation.
WARNING
Never use flammable or combustible materials and solvents around lights.
CAUTION
The product should not be used outside the operating temperature limits. Refer to the product technical specifi ations for the operating limits
for the product.
WARNING
Protect the product from water, moisture and dust. The presence of electricity near water can be dangerous.
CAUTION
Do not directly look into the light, it can cause harm to your eyes.
CAUTION
Do not look at the LEDs with a magnifying glass or any otheroptical instrument that may concentrate the light output.
Maintenance
DANGER
The fitting of non-approved parts or accessories, or the carrying out of non-approved alterations or servicing can be dangerous and could
affect the safety of the product. It may also invalidate the terms and conditions of the product warranty.
DANGER
Never attempt to service this light. Refer servicing to qualified service personnel.
Crossfade X
5

Overview
WHAT’S IN THE BOX
No. Description QTY
1 2', 4' or 8' Crossfade X Light 1
N/A Q-Boot Shock Absorbers 2
N/A AC Power Cord 1
Crossfade X
6

CROSSFADE X - OVERVIEW
1 Power Side
2 Lens Hatch
3 Slim Diffuser
4 Control Side
5 Heat Sink
*Crossfade X - 2' (921-2302) shown as reference
TECHNICAL SPECIFICATIONS
1. Physical Length, Width Height
a. Q15W2060XG, Q25W2060XG, Q50W2060XG, Q75W2060XG, and Q100W2060XG: Width & height = 1.5” 3.81 cm
b. Q15W2060XG: 1’ / 30.5cm pin tip to pin tip
c. Q25W2060XG: 2’ / 61cm pin tip to pin tip
d. Q50W2060XG: 4’ / 122cm pin tip to pin tip
e. Q75W2060XG: 6’ / 183cm pin tip to pin tip
f. Q100W2060XG: 8’ / 244cm pin tip to pin tip
2. Diffusor Length, Width Height
a. Width = 1.5” 3.81 cm
Crossfade X
7

b. Height = 0.75” 1.91 cm
c. Q15W2060XG length: 9 3/16” / 23.3cm
d. Q25W2060XG length: 20 5/8” / 52.4cm
e. Q50W2060XG length: 44 5/8” / 113cm
f. Q75W2060XG length: 68 5/16’ / 174cm
g. Q100W2060XG length: 92’ / 234cm
3. Illuminant technical data
a. Diode set 1: 2000K, duv = 0.0055 (2/3 to ¾ Minus Green correction required for neutral CCT)
b. Intermediary CCT: 3000K, duv = -0.007 (1/4 Plus Green correction required for neutral CCT)
c. Diode set 2: 6000K, duv = 0.003
Crossfade X
8

Physical Installation
Fixture installation configurations and instructions
1. The crossfade lamps will fit any typical T12 clips as well as Quasar Science T12-sized Q-Block mounting blocks (QBK).
2. Quasar Plates or any other device containing T12 clips or T12 Q-blocks can mount crossfade lamps. 4’ or larger lamps may need zip ties to additionally secure
them into the blocks.
3. To mount T12 lamps in these clips or Q-Blocks, simply insert the lamp into the clips until it is fully secure.
Crossfade X
9

Control
• CCT control
•Turn the analog CCT dial to the desired color temperature:
1. • Color temperatures are shown divided by 100 (2000K/100 = 20, 3000K/100 = 30, etc) for legibility and precision marking on the dial
2. Dimming
a. The Q-LED crossfade lamps are capable of dimming down while maintaining color temperature.
b. The Q-LED crossfade lamps are dimmed by an external TRIAC AC source.
c. To Dim Q-LED crossfade lamps, plug the installed P1G into:
i. AC power wired up to a wall-dimmer switch
ii. AC power wired up to a TRIAC dimmer source
• AC power connected to a stand-a-lone TRIAC dimmer plugged into AC-power
• Dimming Equipment recommendations
a. NOTICE The crossfade lamps must be dimmed with TRIAC AC dimming circuits. VARIAC type dimmers will not work.
b. Reverse-phase (trailing edge) TRIAC AC dimming circuits will enable lower dim levels with less potential strobing issues.
c. CFL/LED TRIAC AC dimming circuits must have a circuit that enables stable low voltage operation.
d. The following dimmers work well with crossfade products:
i. Lutron CF line of household dimmers
ii. ETC Sensor
• RatPac dimmer products
Crossfade X
10

Photometric data
Model Distance (ft) 2000K (FC /Lux) 2800K (FC / Lux) 3000K (FC / Lux) 3200K (FC / Lux) 4400K (FC / Lux) 5600K (FC / Lux) 6000K (FC / Lux)
Q15XG 2 / 0.61 39 / 420 50 / 542 53 / 567 55 / 588 72 / 777 69 / 743 69 / 743
Q15XG 3 / 0.91 17 / 187 22 / 241 23 / 252 24 / 262 32 / 346 31 / 331 31 / 331
Q15XG 4 / 1.22 9.8 / 105 13 / 135 13 / 142 14 / 147 18 / 194 17 / 186 17 / 186
Q15XG 6 / 1.83 4.3 / 47 5.6 / 60 5.9 / 63 6.1 / 65 8 / 86 7.7 / 83 7.7 / 83
Q15XG 8 / 2.44 2.4 / 26 3.1 / 34 3.3 / 35 3.4 / 37 4.5 / 49 4.3 / 46 4.3 / 46
Q15XG 10 / 3.05 1.7 / 19 2.2 / 24 2.3 / 25 2.4 / 26 3.2 / 34 3 / 33 3 / 33
Q15XG 18 / 5.49 0.51 / 5.5 0.66 / 7.1 0.69 / 7.4 0.71 / 7.7 0.94 / 10 0.9 / 9.7 0.9 / 9.7
Q15XG 25 / 7.62 0.29 / 3.1 0.37 / 4 0.39 / 4.2 0.41 / 4.4 0.54 / 5.8 0.51 / 5.5 0.51 / 5.5
Q25XG 2 / 0.61 85 / 919 110 / 1185 115 / 1240 119 / 1286 158 / 1699 151 / 1626 151 / 1626
Q25XG 3 / 0.91 40 / 432 52 / 557 54 / 583 56 / 605 74 / 799 71 / 765 71 / 765
Q25XG 4 / 1.22 22 / 236 28 / 305 30 / 319 31 / 331 41 / 437 39 / 418 39 / 418
Q25XG 6 / 1.83 9.8 / 105 13 / 136 13 / 142 14 / 147 18 / 194 17 / 186 17 / 186
Q25XG 8 / 2.44 5.6 / 60 7.2 / 78 7.6 / 81 7.9 / 85 10 / 112 9.9 / 107 9.9 / 107
Q25XG 10 / 3.05 3.6 / 39 4.6 / 50 4.9 / 52 5 / 54 6.6 / 72 6.4 / 68 6.4 / 68
Q25XG 18 / 5.49 1.2 / 12 1.5 / 16 1.6 / 17 1.6 / 17 2.1 / 23 2 / 22 2 / 22
Q25XG 25 / 7.62 0.6 / 6.5 0.77 / 8.3 0.81 / 8.7 0.84 / 9 1.1 / 12 1.1 / 11 1.1 / 11
Q50XG 2 / 0.61 118 / 1273 153 / 1642 160 / 1718 166 / 1782 219 / 2355 209 / 2253 209 / 2253
Q50XG 3 / 0.91 60 / 642 77 / 829 81 / 867 84 / 899 110 / 1188 106 / 1137 106 / 1137
Q50XG 4 / 1.22 37 / 394 47 / 508 49 / 531 51 / 551 68 / 728 65 / 697 65 / 697
Q50XG 6 / 1.83 16 / 175 21 / 226 22 / 237 23 / 245 30 / 324 29 / 310 29 / 310
Q50XG 8 / 2.44 9.8 / 105 13 / 135 13 / 142 14 / 147 18 / 194 17 / 186 17 / 186
Q50XG 10 / 3.05 6.3 / 67 8.1 / 87 8.4 / 91 8.8 / 94 12 / 124 11 / 119 11 / 119
Q50XG 18 / 5.49 1.9 / 21 2.5 / 27 2.6 / 28 2.7 / 29 3.6 / 38 3.4 / 37 3.4 / 37
Crossfade X
11

Model Distance (ft) 2000K (FC /Lux) 2800K (FC / Lux) 3000K (FC / Lux) 3200K (FC / Lux) 4400K (FC / Lux) 5600K (FC / Lux) 6000K (FC / Lux)
Q50XG 25 / 7.62 1.1 / 12 1.4 / 15 1.5 / 16 1.5 / 17 2 / 22 1.9 / 21 1.9 / 21
Q75XG 2 / 0.61 134 / 1444 173 / 1862 181 / 1949 188 / 2021 248 / 2671 237 / 2555 237 / 2555
Q75XG 3 / 0.91 79 / 853 102 / 1100 107 / 1151 111 / 1194 147 / 1577 140 / 1509 140 / 1509
Q75XG 4 / 1.22 51 / 551 66 / 711 69 / 744 72 / 772 95 / 1020 91 / 976 91 / 976
Q75XG 6 / 1.83 27 / 292 35 / 377 37 / 394 38 / 409 50 / 540 48 / 517 48 / 517
Q75XG 8 / 2.44 16 / 171 20 / 220 21 / 230 22 / 239 29 / 316 28 / 302 28 / 302
Q75XG 10 / 3.05 11 / 118 14 / 152 15 / 159 15 / 165 20 / 218 19 / 208 19 / 208
Q75XG 18 / 5.49 3.4 / 36 4.3 / 47 4.6 / 49 4.7 / 51 6.2 / 67 6 / 64 6 / 64
Q75XG 25 / 7.62 1.7 / 18 2.2 / 24 2.3 / 25 2.4 / 26 3.1 / 34 3 / 32 3 / 32
Q100XG 2 / 0.61 134 / 1444 173 / 1862 181 / 1949 188 / 2021 248 / 2671 237 / 2555 237 / 2555
Q100XG 3 / 0.91 87 / 934 112 / 1205 117 / 1261 122 / 1308 161 / 1729 154 / 1654 154 / 1654
Q100XG 4 / 1.22 61 / 656 79 / 846 82 / 886 85 / 919 113 / 1214 108 / 1161 108 / 1161
Q100XG 6 / 1.83 30 / 327 39 / 422 41 / 441 43 / 458 56 / 605 54 / 579 54 / 579
Q100XG 8 / 2.44 20 / 210 25 / 271 26 / 283 27 / 294 36 / 388 35 / 372 35 / 372
Q100XG 10 / 3.05 13 / 143 17 / 184 18 / 193 19 / 200 25 / 264 24 / 253 24 / 253
Q100XG 18 / 5.49 4.1 / 45 5.3 / 58 5.6 / 60 5.8 / 62 7.7 / 82 7.3 / 79 7.3 / 79
Q100XG 25 / 7.62 2.1 / 23 2.7 / 29 2.8 / 31 2.9 / 32 3.9 / 42 3.7 / 40 3.7 / 40
Crossfade X
12

Spectral Data & Metrics
The following illuminant spectral fingerprint data shows the maximum amount ofspectral change at steady state temperature vs cold strike temperature.
Crossfade X
13

Crossfade X
14

Troubleshooting T8s and Crossfades
Light Flickers at Low Levels
Since Crossfades and T8's are Triac dimmable lights, most Triacs require a certain power draw to function correctly. If you notice your light flickering on dimmers, try
grouping them into larger groups of lights, if possible.
Also try using a "ghost load" to increase the power draw on the dimmer. This can be done using a small incandescent light that is connected to the same dimmer as
the Crossfade or T8 light. Position the incandescent light away from/above the set.
Crossfade X
15

Warranty
In order for a product to be covered under Quasar Sciences warranty, the customer must provide proof of purchase. However, please note that this warranty is
transferable.
3 Year warranty from date of purchase.
Customer must provide proof of purchase.
This warranty is transferable.
Quasar Science will pay for:
The replacement parts, repair and/or labor costs to correct defects in materials and workmanship.
*Service must be provided by Quasar Science or an Authorized Quasar Science Service Center*
Quasar Science will not pay for:
Damage resulting from accident, misuse or abuse. Acts of God. Any failure that occurs for any other reason than materials and workmanship. Any shipping
orhandling costs.
Disclaimer of implied warranties / limitations of remedies:
Implied warranties, including the extent applicable warranties of merchantability or fitness for a particular purpose are excluded to the extent legally permissible.
Any implied warranties that may be imposed by law are limited to 3 years or the shortest period allowed by law. Some states, provinces or countries do not allow
limitations or exclusions on how long an implied warranty of merchantability or fitness lasts, the above limitations or exclusions may not apply to you.
If this product fails to work as warranted, customer's sole and exclusive remedy shall be repair or replacement according to the terms of this limited warranty. Quasar
Science does not assume any responsibility for incidental or consequential damages. This warranty gives you specific legal rights and you may also have other rights
which vary from state to state, province to province or country to country.
Crossfade X
16

Certificates
EU DECLARATION OF CONFORMITY
Videndum Production Solutions Ltd. declares under our sole responsibility, supported by Videndum Production Solutions GmbH - our authorized representative, that the product detailed in this
manual conforms with all relevant provisions of the following EU directives:
• Electromagnetic Compatibility
• Directive 2014/30/EU Low Voltage Directive 2014/35/EU Restriction of Hazardous Substances
• Directive 2011/65/EU
A copy of the declaration is available on request. EU contact: Videndum Production Solutions GmbH, Parkring 29, 85748 Garching, Germany
UK DECLARATION OF CONFORMITY
Videndum Production Solutions Ltd. declares under our sole responsibility that the product detailed in this manual conforms with all relevant provisions of the following UK Regulations:
• The Electromagnetic Compatibility Regulations 2016
• The Electrical Equipment (Safety) Regulations 2016
• The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012
A copy of the declaration is available on request.
UK contact: Videndum Production Solutions Ltd, William Vinten Building, Easlea Road, Bury St. Edmunds, IP32 7BY
Crossfade X
17

FCC COMPLIANCE STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/television technician for help.
Modifications not expressly approved by the manufacturer could void the user's authority to operate the equipment under FCC rules.
ENVIRONMENTAL CONSIDERATIONS
European Union Waste of Electrical and Electronic Equipment (WEEE) Directive (2002/96/EC)
This symbol marked on the product or its packaging indicates that this product must not be disposed of with general household waste. In some countries or European Community regions
separate collection systems have been set up to handle the recycling of electrical and electronic waste products. By ensuring this product is disposed of correctly, you will help prevent
potentially negative consequences for the environment and human health. The recycling of materials helps conserve natural resources. Visit our website for information on how to safely
dispose of this product and its packaging.
In countries outside the EU:
Dispose of this product at a collection point for the recycling of electrical and electronic equipment according to your local government regulations.
Pollution statement
This equipment is designed for operation in Pollution Degree 2 environments.
Crossfade X
18

Copyright
All rights reserved throughout the world. No part of this document may be stored in a retrieval system, transmitted, copied or reproduced in any way, including, but
not limited to, photocopy, photograph, magnetic or other record without the prior agreement and permission in writing of Videndum plc.
DISCLAIMER
The information contained in this manual is believed to be correct at the time of printing. Videndum Production Solutions Inc. reserves the right to make the
changes to the information or specifications without obligation to notify any person of such revisions or changes. Changes will be incorporated in new versions of
the publication. We are making every effort to ensure that our manuals are updated on a regular basis to reflect changes to the product specifications and features.
Should this manual not contain information on the core functionality of your product, please let us know. You may be able to access the latest revision of this manual
from our website. Videndum Production Solutions Inc. reserves the right to make changes to product design and functionality without notification.
TRADEMARKS
All product trademarks and registered trademarks are the property of Videndum Plc. All other trademarks and registered trademarks are the property of the
respective companies.
PUBLISHED BY:
Videndum Production Solutions Inc. Email: [email protected]
Copyright 2022 - Videndum Production Solutions Inc. All rights reserved
Crossfade X
19
