Quest Engineering A3000 Manual

Quest Power Air Mover A3000
Installation, Operation and Maintenance Instructions
– Read and Save These Instructions –
This manual is provided to acquaint you with
the Quest Power Air Mover A3000 air mover
so that installation, operation and mainte-
nance can proceed successfully. Ultimate
satisfaction depends on the quality of set up
and a thorough understanding of this equip-
ment. The Quest Power Air Mover A3000 is
built around tested engineering principles and
has passed a
thorough inspection for quality of
workmanship and function.
Installation, Operation and Maintenance Instructions
4201 Lien Rd. Phone [phone]
Madison, WI 53704 Toll-Free 1-866-933-7486
www.QuestProtect.com [email protected]
– Read and Save These Instructions –
Specifications subject to change without notice. 1
Quest Power Air Mover A3000:
• Less than 2.5 amps
• Automatic hour meter displays site run time
• 20 ft AC cord with cord management
• Units interlock for ease of stacking during
storage and handling
• Weighs 2.5 lbs less than competitive units
• Over 3000 CFM on high Patent 7,331,759
quest
quest TS-955
11/17 Rev. A

quest
quest 1-866-933-7486
Quest Power Air Mover A3000 Installation, Operation and Maintenance Instructions
2
www.QuestProtect.com
[email protected]
Table of Contents
Quest Power Air Mover A3000 Features ..................1
1. Safety Information ............................................3
2. Intended Application........................................4
3. SafetyCertications..........................................4
4. Specications...................................................4
5. Power Requirements.........................................4
5.1 Recommended Use....................................4
5.2 Integrated Cord Wrap.................................4
6. Applications.....................................................5
6.1 Placement ..................................................5
6.2 Orientation of Directional Drying...............5
7. Operating Instructions ......................................6
8. Operator Panel Features ...................................6
8.1 3-Position Drying Selector Switch...............6
9. Maintenance ....................................................6
9.1 Servicing ....................................................6
9.2 Cleaning.....................................................6
10. Replacement Parts and Optional Accessories....7
11. Wiring Diagram ...............................................7
12. Warranty ..........................................................8
Serial No. ______________________________________
Purchase Date ______/______/_____
Dealer’s Name ___________________________________

1-866-933-7486
Quest Power Air Mover A3000 Installation, Operation and Maintenance Instructions
3
quest
quest
1. Safety Information
• Do not operate the unit with a cut or frayed power cord. Replace cord if it becomes damaged.
• Do not unplug the unit by pulling on the cord. Grasp the plug firmly and pull it out of the wall socket or
power receptacle.
• Always use a grounded outlet.
• Never operate electrical equipment in standing water.
• Never operate with the safety grills removed. Personal injury may result.
• Do not stick your fingers or other objects through the safety grills.
• Do not restrict airflow to the unit. This may cause the unit to overheat.
• Unit should never be serviced or cleaned while it is plugged in.
• Do not sit or stand on the unit or use as a shelf or table.
• Before leaving an Axial Air Mover unattended, ensure children do not have access to the equipment. Do
not allow children to play with or near the unit or in its air flow.
• To reduce the risk of fire or electric shock, do not use this air mover with any solid-state speed control
device.
• Do not route cord under furniture or appliances.
LIRE ET CONSERVER CES INSTRUCTIONS
• Risque de choc électrique Peut causer des blessures ou la mort. Débrancher toutes les alimentations en
courant électrique à distance avant l’entretien ou le nettoyage.
• Ne pas utiliser l’appareil avec un cordon d’alimentation coupé ou effiloché.
• Ne pas débrancher l’appareil en tirant sur le cordon. Tenir la fiche fermement et la tirer hors de la prise
murale ou la prise d’alimentation électrique.
• Toujours utiliser une prise mise à la terre.
• Ne jamais utiliser l’équipement électrique dans de l’eau stagnante.
• Ne jamais utiliser sans les grilles de protection. Des blessures risquent d’en résulter.
• Ne pas passer les doigts ou d’autres objets dans les grilles de protection.
• Ne pas diminuer le débit d’air arrivant jusqu’à l’appareil. L’appareil risque de trop chauffer.
• Ne pas s’asseoir ou se tenir debout sur l’appareil; ne pas l’utiliser comme étagère ou table.
• Avant de laisser un appareil aéraulique axial sans surveillance, s’assurer que les enfants n’ont pas accès
à l’équipement. Ne pas laisser les enfants jouer avec l’appareil ou à proximité de l’appareil ou dans l’air
qu’il projette.
• Pour réduire le risque d’incendie ou de choc électrique, ne pas utiliser ce ventilateur avec un dispositif de
commande de vitesse à semi-conducteurs.

quest
quest 1-866-933-7486
Quest Power Air Mover A3000 Installation, Operation and Maintenance Instructions
4
2. Intended Application
The Quest Power Air Mover A3000 has changed the drying industry by minimizing overall drying time
on water restoration jobs. The Quest Power Air Mover A3000 uses patent pending FOCUS Technology to
maximizeairvelocityacrossoorsandalongwallsforlongerdistances.Bymaximizingtheairvelocity,
waterevaporatesmorequicklyfromthecarpet,pad,sub-oor,wall,andsillplate.
3. Safety Certifications
TheQuestPowerAirMoverA3000(P/N4028330)conformstoULSTD507.CertiedtoCAN/CSASTD
C22.2 No. 113.
4. Specifications
Part No. 4028330
Power 1/4 hp 1-phase 110/120 VAC 2-speed
 4-pole,PSCElectricMotor.
CFM Approximately 3000
Cord 20 ft Power Cord
Current Draw 2.5 Amps
Voltage 115 VAC
Warranty Year One - 100% parts and labor
(all components)
Year Two - 100% parts only (all components)
Years Three through Seven - Only materials and workmanship of the housing are covered.
Dimensions
Cabinet
Width 19.9”
Height 19.5”
Depth 15.2”
Weight 29.5 Lbs
5. Power Requirements
5.1 Recommended Use
The Quest Power Air Mover A3000 draws 2.5 amps. .
Note: Standard 115 VAC electrical outlets. Figure 1: Cord wrap

1-866-933-7486
Quest Power Air Mover A3000 Installation, Operation and Maintenance Instructions
5
www.QuestProtect.com
[email protected]
quest
quest
5.2 Integrated Cord Wrap
The Quest Power Air Mover A3000 features integrated cord
management. Wrap the cord around the cord wrap
as shown and secure the cord with the clasp on the plug.
6. Applications
6.1 Placement
Quest Axial Air Movers with FOCUS Technology will allow
placing the Quest Power Air Mover A3000 at an angle nearly
parallel to the wall.
ThetestgraphshowninFigure2depictsimmediateairowattheFOCUSTechnology
corner.TheQuestPowerAirMoverA3000sustainsthisairowformorethan20feet
andmaximizestheairvelocityacrosstheoorandalongthewallwhenplacedtheat
4.5° angle from the wall.
BytouchingthefrontedgeoftheoutputsideoftheQuestPowerAirMoverA3000
againstthewallandrotatingtherestoftheunitagainstthewall,therestoration
professional will place the axial air mover at 4.5° due to the housing’s built-in design.
Industryexpertsagreeplacingairmovers45°angletothewallwastesairowand
reduces the performance by forcing air up the wall.
The best set up angle for quickly and completely drying the sill plate is 4.5°. Set-up
angles greater than 4.5° may be used under unique circumstances
suchascornerairowandstructurevariations.Set-upangle
should never exceed 23°.
6.2 Orienting of Directional Drying System
The Quest Power Air Mover A3000 dries in counter-clockwise and
clockwise directions for optimum ease of use. The Quest Power
Air Mover A3000 ships with rubber feet on one side of the unit for
counter-clockwise drying.
When employing clockwise drying (such as the need to dry a door
jamb),simplyrotatetheaxialairmover90°sotheFOCUSTechnologycornerpointstowardthedoorjamb
andoorfortheclockwisedrying.
2500
2000
1500
1000
500
0
0 Feet 5 10 15 20 25
Air Velocity (fpm)
Figure 2: Airflow of the Quest Power Air Mover
A3000 measured 3.5” parallel to wall.
Figure 3: 4.5° to wall
as shown
Figure 4: Birds eye view of room set-up
Counter
clockwise
airflow
pattern
Clockwise
airflow
pattern
Making use of factory installed feet (4) Making use of user installed feet (2)
Figure 5: Clockwise feet locations
Factory installed feet for use during
counter clockwise drying
Counter
clockwise
airflow
pattern
Clockwise
airflow
pattern
Making use of factory installed feet (4) Making use of user installed feet (2)
User installed feet for
use during clockwise
drying set-ups

quest
quest 1-866-933-7486
Quest Power Air Mover A3000 Installation, Operation and Maintenance Instructions
6
www.QuestProtect.com
[email protected]
7. Operating Instructions
The Quest Power Air Mover A3000 as packaged is ready to be put into service. Inspect the unit completely
foranyshippingdamage.Placetheunitontheground.Orienttheunitsothedesiredairowdirectionisthe
same as the arrow indicator sticker in the FOCUS Technology corner on the interior of the unit. Plug the unit
into a grounded outlet and select the drying mode shown in Figure 6.
CAUTION: The Quest Power Air Mover A3000 consumes 2.5 Amps.
8. Operator Panel Features
8-1 Position Drying Selector Switch
The 3-position drying mode selector switch. This switch is used to select the Quest Power Air Mover A3000’s
modeofoperation.The3modesofoperationareOFF,LOWorHIGH.
OFF - The Quest Power Air Mover A3000 is not drying.
LOW - The Quest Power Air Mover A3000 is in “Normal” Drying mode. This mode provides rapid drying
and very quiet operation.
HIGH - The Quest Power Air Mover A3000 is in “Fast” drying mode. This mode provides the industries most
rapid drying while maintaining low noise operation.
9. Maintenance
WARNING: Disconnect the unit from power before servicing or cleaning. Replace the wire safety grill
after servicing or cleaning.
9.1 Servicing
Beforeeachuseinspectfordamage,blockedinletoroutlet,oranyexcessbuildupofforeignmaterial.
WhentheQuestPowerAirMoverA3000isrstturnedon,checkforexcessivevibration.Iftheunitvibrates
excessivelyorifbladerubsonhousing,turnofftheunitimmediately.Haveaservicetechnicianinspectthe
unit to locate the problem.
9.2 Cleaning
Thehousingismadeofadurableandwashablepolyethylene.Whencleaning,theuseofsolventsisNOT
recommended.
Whenwashinginsidetheunit,disconnecttheunitfromitspowersource.Protectthe3-positionswitchwith
acloth.Cleaninnerbarrel,grillsandblade.Wipedownmotorexteriorwithadampcloth.Ifthemotorgets
wetduringcleaning,simplyallowampletimeformotortodryoutcompletelybeforerestarting.
IfyouwashtheQuestPowerAirMoverA3000anddonotplantouseitwithin24hours,allowthefanto
drip dry for 10 minutes and then let run for 5 minutes.

1-866-933-7486
Quest Power Air Mover A3000 Installation, Operation and Maintenance Instructions
7
www.QuestProtect.com
[email protected]
quest
quest
10. Replacement Parts and Optional Accessories
Contactthefactoryat1-866-933-7486toorderreplacementparts,oroptionalaccessories
11. Wiring Diagram
Part No. Description
4025204 Switch,Rocker,On-Off-On
4025206 Grill,Safety,Intake
4025207 Grill,Safety,Exhaust
4025460 Quest Power Air Mover A3000
Stand
Part No. Description
4025299 Stand Hardware Kit
4036823 Motor
4025095 Blade
BLK
FAN MOTOR
RED
BL
KW
HT
WHT
GRN GRN
MAIN POWER
CORD
LOW (1)
HIGH (3)
(2) OFF

quest
quest 1-866-933-7486
Quest Power Air Mover A3000 Installation, Operation and Maintenance Instructions
8
quest
quest 1-866-933-7486
8
Quest Power Air Mover A3000 Limited Warranty
Warrantor:
Therma-Stor LLC
4201 Lien Rd
Madison,WI53704
Telephone: [phone]
Who Is Covered: This warranty covers Quest Power Air Mover A3000.
First Year Warranty: 100% parts and labor (all components)
Second Year Warranty: 100% parts only (all components)
Years Three through Seven: Only materials and workmanship of the housing are covered.
Ifadefectinmaterialsorworkmanshipoccurswithinthewarrantyperiod,Therma-StorLLCwillrepairor
replace the defect.
End-User Responsibilities: Warranty service must be performed by a servicer authorized by Therma-Stor
Products. To obtain warranty service you must obtain a return material authorization (RMA). To obtain an
RMAyoumustpresentproofofpurchaseor(lease),byuseofawarrantycard,originalsalesreceiptorother
reasonable and reliable means.
To obtain an RMA call Therma-Stor LLC at the above number and ask for the Therma-Stor LLC Service
Department,whichwillthenissueanRMA#andarrangefor,atouroption,eitherrepairorreplacement.
Freight: Freight to and from the servicer is the responsibility of the end-user. The end-user is responsible for
normal care and proper return packaging.
Limitations and Exclusions: Thiswarrantydoesnotcoveranydefect,malfunction,etc.resultingfrommisuse,
abuse,lackofnormalcare,corrosion,freezing,tampering,modication,unauthorizedorimproperrepairor
installation,accident,actsofnatureoranyothercausebeyondTherma-StorLLC’sreasonablecontrol.
IfanyQuestPowerAirMoverA3000partisrepairedorreplaced,thenewpartshallbewarrantedforthe
balanceoforiginalwarranty(butallwarrantyperiodswillbeextendedbytheperiodoftime,ifany,thatthe
Quest Power Air Mover A3000 with FOCUS Technology is out of service while awaiting covered warranty
service).
Warranty service will be performed during normal working hours.
UPONTHEEXPIRATIONOFTHEWRITTENWARRANTYAPPLICABLETOTHEQUEST Power Air
MoverA3000ORANYPARTTHEREOF,ALLOTHERWARRANTIESIMPLIEDBYLAW,INCLUDING
MERCHANTABILITYANDFITNESSFORAPARTICULARPURPOSE,SHALLALSOEXPIRE.ALL
WARRANTIESMADEBYTHERMA-STORLLCARESETFORTHHEREIN,ANDNOCLAIMMAYBEMADE
AGAINSTTHERMA-STORBASEDONANYORALWARRANTY.INNOEVENTSHALLTHERMA-STORLLC,
INCONNECTIONWITHTHESALE,INSTALLATION,USE,REPAIRORREPLACEMENTOFANYQUEST
PowerAirMoverA3000ORPARTTHEREOFBELIABLEUNDERANYLEGALTHEORYFORANYSPECIAL,
INDIRECTORCONSEQUENTIALDAMAGESINCLUDINGWITHOUTLIMITATIONWATERDAMAGE(THE
ENDUSERSHOULDTAKEPRECAUTIONSAGAINSTSAME),LOSTPROFITS,DELAY,ORLOSSOFUSEOR
DAMAGETOANYREALORPERSONALPROPERTY.
Somestatesdonotallowlimitationsonhowlonganimpliedwarrantylasts,andsomedonotallowthe
exclusionorlimitationofincidentalorconsequentialdamages,sooneorbothoftheselimitationsmaynot
apply to you.
Legal Rights:Thiswarrantygivesyouspeciclegalrights,andyoumayalsohaveotherrightswhichvary
from state to state.
