Quest Leisure Products ELITE Bordeaux Pro Lounge F1344 User manual

Welcome
to your instructions
F1344 : Bordeaux Pro Lounge

2Template version: 3
F1344 : Bordeaux Pro lounge full instructions
Thank you for purchasing this product. At Quest we take every care to ensure that the product
fulllies your expectations. We hope you enjoy using this product.
General Use
Failure to follow the general use instructions below could lead to damage to the chair or injury to
your person. Always read and follow these instructions when using the product.
• Always ensure that the frame is locked in position before using the lounge.
• Always ensure all legs remain in contact with the ground and take extra care when using the chair
on uneven ground as this can lead the lounge to move about.
• Children should always be under direct adult supervision when using this product and must not
be allowed to operate any folding or adjustable mechanisms.
• Keep hands away from folding parts to prevent entrapment. Take care when opening, closing and
or adjusting this product.
• Ensure that the side table is folded away before folding the lounge.
• Do not force the product at any time, the product will fold away without the need for undue force.
• Do not leave outside in severe weather conditions.
• Please retain all information for further reference

3Instruction version: 3
F1344 : Bordeaux Pro lounge full instructions
3 Year Warranty
Lounge
• Q-Tex Padded 2D
mesh Soft, breathable
and amazing comfort.
• Extremely lightweight.
• Slide out side table.
• Reclines to at.
• Electro-plated
aluminium frame.
Lounge
Full Instructions
Instructions, warranty and additional information can be
found on the Quest manual download site by using the
QR code or website URL above.
Warranty : 36 Months warranty.
www.questleisure.com
Size: 70 x 175 x 90 cm.
Seat Height: 51 cm.
Length when at: 200 cm.
Folded: 70 x 20 x 82 cm.
Weight: 6.3 kg.
Max Load: 120 kg.
Side Table Max Load: 5 kg.
Quest Elite®Bordeaux Pro range
Quest manual download site
www.questleisure.com/manuals
Lounge bed
Code:F1344
Hang Tag Artwork : Below is a copy of the hang tag that came with your product. This is just
for your reference and you should still keep the original that came with your product.

4Template version: 3
F1344 : Bordeaux Pro lounge full instructions
Folding and Unfolding
• Take the lounge from the bag and stand it upright as shown (image 1).
• Unfold the lounge from both ends as shown in image 2. You will have to unfold each side on its
own.
• Once the lounge has been unfolded, unfold the two end legs as shown in image 5.
• Lock both legs using the leg locks (2 per leg) as shown in images 6 and 7.
• Once the legs are locked turn the lounge the correct way up and it should look like image 8.
• To slide the side table out, rst turn the side pin down as shown in images 9 - 10 (if not already
done).
• Once the side pin is in teh ready position, slide the table from under the lounge rotate and clip onto
the side pin as shown in images 11 - 12.
• When sliding the table away, please ensure the side table is not behind the leg tube (as shown in
images 3 - INCORRECT and 4 - CORRECT) as this can lead to damage on the frame.
• To adjust the recline simply position the back rest using the adjustable positions on the frame as
shown by image 13. There are 4 different positions to choose from.
• You can also adjust the position of the head rest simply by moving it up or down, or it can be
removed completely.
• The head rest can also be tightened by using the adjustable strap located at the back of the head
cushion as shown in images 14 and 15.
Storage
To help keep your product looking newer for longer and prolong the life and use of the product,
we recommended that the product is covered when not in use.
If the product is not going to be used for an extended period (such as a winter period) we
recommend that it is carefully folded away and stored in a clean, dry and free from damp
location.
Care and Cleaning Instructions
Never use and harsh or abrasive cleaners or brushes when cleaning this product as the frame
and fabric may be damaged when doing so.
Never fold and put the product away when wet as this can trap water in the product, which can
lead to mould and mildew build up.
• Fabric : We recommend using a dedicated fabric cleaner for the fabric, if one is not available
simply warm soapy water. After it has been cleaned, rinse with clean water to make sure
there's no soap or cleaner left inside the fabric. Once rinsed allow the product to dry naturally
before folding away and storing.
• Frame : First allow any dirt to dry and brush with a soft brush to remove loose dirt. Once this is
done wipe the frame down with warm soapy water and a soft cloth. Once cleaned allow to dry
naturally before storing away.
• Side Table (If applicable) : Simply wipe the table down with warm soapy water and a soft
cloth. Once cleaned dry with a towel or soft cloth afterwards.

5Instruction version: 3
F1344 : Bordeaux Pro lounge full instructions
image 1 image 2 image 4
image 3
image 5 image 7
image 6
image 8
image 9 image 10 image 11 image 12
image 13 image 14 image 15

6Template version: 3
F1344 : Bordeaux Pro lounge full instructions
Warranty : 36 Months (3 Years) warranty.
Warranty Claim
• In the unlikely event of a warranty claim, you must contact your retailer.
• If you have not registered your product, rst ll out the registration form overleaf and take this
with you when you go to your retailer.
• Take the product to your retailer that you purchased it from along with your proof of purchase and
explain the issue with the retailer.
• The retailer will then check the product and get in touch with the wholesaler or manufacturer.
• The retailer will keep you informed of the progress of the claim.
• The wholesaler or manufacturer will not (unless under special circumstances) get in touch with
you as all information will be passed back directly to the retailer.
Warranty Information
• This product comes with a full 36 month manufacturers defect warranty and covers any
manufacturers defects for three (3) year from the date of the original purchase. It does not cover
any damage occured though:
• The product falling or being dropped.
• The product has been technically changed by the owner or another third party
• Improper use of the product.
• Normal wear and tear - which includes (but is not limited to): colour fading, wearing, stretching.
• The affected part will be replaced or repaired (manufacturers option) if they are found to be
defective within the three (3) year time frame.
• The warranty will be void if the product has been subject to neglect, misuse, improper installation,
misapplication, alteration or accident including, but not limited to, improper installation,
maintenance or use of unauthorised parts or attachments.
• Damage caused by not following the instruction manual in full will invalidate the warranty, if
this results in consequential damages, Quest will not be liable for these damages or any costs
incurred due to these damages.
• Quest will not be liable for material damage or personal injury caused by improper use or if the
safety instructions are not properly executed in full.
• All claims must be made though the retailer you purchased the product from and not direct with
the wholesaler or manufacturer.
• Warranty claims cannot be honoured without an original dated receipt and or proof of purchase.
• By executing repairs the original warranty period of three (3) years will not be extended, nor the
right to a complied new warranty. This warranty is only legal on European soil.
• This warranty does not overrule the European directive 2011/83/EU.
• This product may not be amended or changed.

7Instruction version: 3
F1344 : Bordeaux Pro lounge full instructions
This Bordeaux Pro chair is part of the Quest Elite® Bordeaux Pro range of furniture. This range includes
the following items that are matched with your product.
Cat No F1343 Bordeaux pro relax xl
• Premium, electro-plated, all weather aluminium frame • Adjustable padded head rest • Stepless full recliner
• Soft, breathable, padded for extra comfort, durable and quick dry Q-Tex 2D mesh stretch fabric.
• Size: 80 x 80 x 118 cm • Folded size: 80 x 15 x 95 cm • Seat height: 44 cm • Seat width: 57 cm
• Weight: 9 kg • Max load: 120 kg. • Side table max load: 5 kg.
Padded
For extra
comfort
Exclusive
slide-out
table
Exclusive
Soft & Durable
fabric
Extra
Wide
seat

8Template version: 3
F1344 : Bordeaux Pro lounge full instructions
Cat No F1342 Bordeaux pro easy
• Premium, electro-plated, all weather aluminium frame • Adjustable padded head rest • Ergonomic back
• Soft, breathable, padded for extra comfort, durable and quick dry Q-Tex 2D mesh stretch fabric.
• Size: 63 x 70 x 122 cm • Folded size: 63 x 8 x 115 cm • Seat height: 47 cm • Seat width: 49 cm
• Weight: 6 kg • Max load: 120 kg. • Side table max load: 5 kg.
Exclusive
slide-out
table
Exclusive
Soft & Durable
fabric
Padded
For extra
comfort
This Bordeaux Pro chair is part of the Quest Elite® Bordeaux Pro range of furniture. This range includes
the following items that are matched with your product.

9Instruction version: 3
F1344 : Bordeaux Pro lounge full instructions
This Bordeaux Pro chair is part of the Quest Elite® Bordeaux Pro range of furniture. This range includes
the following items that are matched with your product.
Cat No F1345 Bordeaux pro rest
• Premium, electro-plated, all weather aluminium frame • Ultra lightweight • Turns your chair into a lounger
• All weather, breathable, cushioned, durable and quick dry Q-Tex 2D mesh stretch fabric.
• Size: 48 x 100 x 46 cm • Height: 46 cm • Folded: 48 x 90 x 9 cm
• Weight: 1.5 kg • Max load: 30 kg.
Extremely
light
weight
Exclusive
All weather
fabric

10 Template version: 3
F1344 : Bordeaux Pro lounge full instructions
This Bordeaux Pro chair is part of the Quest Elite® Bordeaux Pro range of furniture. This range includes
the following items that are matched with your product.
Cat No F1344 Bordeaux pro lounge
• Premium, electro-plated, all weather aluminium frame • Adjustable padded head rest • Ultra lightweight
• Soft, breathable, padded for extra comfort, durable and quick dry Q-Tex 2D mesh stretch fabric.
• Size: 70 x 175 x 90 cm • Folded size: 70 x 20 x 82 cm • Seat height: 51 cm
• Seat length (when flat): 200 cm • Weight: 6.3 kg • Max load: 120 kg. • Side table max load: 5 kg.
Padded
For extra
comfort
Exclusive
slide-out
table
Exclusive
Soft & Durable
fabric
Extra high
Easy to
use

11Instruction version: 3
F1344 : Bordeaux Pro lounge full instructions
Along with the other items in the Bordeaux Pro range there are other optional accessories
available for your product.
Cat No 118914DP Clamp on sun shade
• Adjustable position • U.V. protection
• Universal use • Anti glare • Can be used on chairs,
tables, prams, push chairs and more
• Canopy radius: 68.5 cm • Height: 105 cm
• Folded size: 7 x 7 x 94 cm
• Weight: 0.3 kg.
Cat No 124900 Quest Elite®furniture bag
• New improved colour and more durable material
• Premium quality
• Complete with its own carry bag
• Can fit multiple chairs in one bag • Universal use
• Fabric: 600D Fabric • Size: 67 x 18 x 113 cm
• Weight: 1.1 kg
Cat No 124901 Quest Elite spare elastics
• Elasticated cord • Metal end caps
• Fits all relax and comfort chairs
• QTY: 4 cords (2 different lengths)
• Length: 36 inches and 72 inches
