quhwa VP-700A User manual

Instruction Manual
COLOR VIDEO DOOR PHONE KITS
□ VP-700A ID

1.Features 2
2.Outdoor Camera Performance Data 2
3.Indoor Monitor Performance Data 3
4.Indoor Monitor Installation 4
5.Outdoor Camera Installation 4
6.Notices of Wiring Diagram 5
7.Operation Instruction 8
8.Accessories 9
9.Notices 9
CONTENT PAGE

1.Features
1. 21 mm slim fit plastic panel of indoor monitor with simplicity and classic
design style.
2. Anti-oxidation, water-proof, rotating vandal outdoor camera.
3. 7" LED screen, no radiation low power consumption and high definition.
4. Hands free communication.
5. Surface touch function.
6. Outdoor camera or indoor monitor with electric-controlled door release function.
7. Monitoring the outside of house.
8. Fourteen polyphonic melodies.
9. Ring volume, talking volume, chroma and brightness adjustable.
10. Enclosed 15M cable and one adapter for DIY market.
Call
Name Plate
Infrared Light
Camera
Microphone
Speaker
2.Outdoor Camera Performance Data
1 . IR distance more than 4M
2. Automatic gain control
3 . Working temperature: -20°C~50°C
4. Resolution: CMOS more than 380 TV line
CCD more than 420 TV line
5 . Outdoor camera dimension:
112【W】X 158【H】X 38【D】mm
Camera
Rotation Hit
ID Card Touching Zone

3.Indoor Monitor Performance Data
Microphone
Power Indicator Light
Talk Unlock Monitor speaker
Power
Socket
1. Adapter input voltage: AC110-240V, 60Hz/ 50Hz
2. Adapter output voltage, output current: DC15V 1200mA
3. Talking last time: 120s±10%
4. Monitoring last time: 40S±10%
2
5. Working distance: 50M(4 x 0.5mm )
6. Power consumption: standby＜0.5W,
working＜10W
7. Illumination intensity: 2 luces
8. Visual angle: 92° wide-angle
9. Working temperature: -5°C~40°C
10. Relative humidity: 10-90%(RH)
Parameter
Screen Size
Resolution
Active Area
Pixel Size
Screen Figure Dimension
Unit
Inch
Dot
mm
mm
mm
169.4【W】X 100【H】X 5.7【D】
0.107【W】X 0.37【H】
154.1【H】X 86.58【V】
480 X 3 X 234
7.0
Specifications
Performance Parameter
11. Indoor monitor dimension: 232【W】X 140【H】X 21【D】mm
Chroma Adjuster
Brightness Adjuster
Talking Volume Adjuster
Music Volume Adjuster
Music Selection Adjuster

5.Outdoor Camera Installation
1. Take out the screws located at the bottom of the outdoor camera
(picture 1), and take apart the bracket.
2. Take out the four screws in the back cover, and then take apart the front
cover (Picture 1).
1
30.0CM
140~170CM
call within 30cm
32
3. Take off the name plate for marking family name or room name, and then
fix the screws of the back cover (Picture 1).
4. Install the outdoor camera at a height of 1.4m-1.7m, and make sure it
21
Bracket
4.Indoor Monitor Installation
1. Fix the bracket of the video indoor monitor on the wall with screws
(Picture 1).
2. Hang the monitor on the bracket after finishing the wire connection. Plug the
tenclosed adapter into the sockets of AC power and the monitor (Picture 2).

1
2
3
4
5
6
-
+
DC 15V
7
8
9
10
11
12
13
14
VP-700A ID outdoor camera electronic control lock wiring diagram
Indoor Monitor
Outdoor Camera
Lock
1,2,3,4,7 connection terminals of the outdoor camera accordingly.
2. The 5,6 connection terminals of the outdoor camera connect to the electronic
lock.
3. The“﹢”,“﹣”connection terminal of the indoor monitor connect to DC15V power
accordingly.
1. The 7,8,9,10,11 connection terminals of the indoor monitor connect to the
6.Notices of Wiring Diagram
The video door phone kit includes 15 meters wire. If wanting extension to 15-
2
50 meters, please use the 5×0. 5mm wire; If wanting extension to 50-100 meters,
2
please use the 5×0. 75mm wire.
avoiding the direct sunshine or rain (Picture 2).
5. Fix the bracket of the outdoor camera on the wall by tightening screws,
and then fix the screws at the bottom of the outdoor camera (Picture 3).

VP-700A ID outdoor camera electronic control lock wiring diagram
1
2
3
4
5
6
-
+
DC 15V
7
8
9
10
11
12
13
14
1
2
3
4
5
6
-
+
DC 15V
7
8
9
10
11
12
13
14
1
2
3
4
5
6
-
+
DC 15V
7
8
9
10
11
12
13
14
Indoor Monitor A
Indoor Monitor B (option)
Outdoor Camera
Lock
Indoor Monitor C (option)
1. The 1,2,3,4,7 connection terminals of the outdoor camera connect to the
7,8,9,10,13 connection terminals of the indoor monitor A; The 5,6 connection
terminals of outdoor camera connect to the lock.
2. The other group of 1,2,3,4 connection terminals of the indoor monitor A
connect to the 1,2,3,4 connection terminals of the indoor monitor B.
Same connection between monitor B and C.
3. The“﹢”,“﹣” connection terminals of indoor monitor connect to the power of
DC 15 V.

VP-700A ID outdoor camera electronic control lock wiring diagram
1. The 1,2,3,4,5 connection terminals of the outdoor camera A connect to the
1,2,3,4,5 connection terminals of the second camera controller A; the 1,2,3,4,5
connection terminals of the outdoor camera B connect to the 1,2,3,4,5
connection terminals of the second camera controller B.
2. The 7,8,9,10,11,12,13 connection terminals of the indoor monitor A connect
to the 1,2,3,4,5,6,+ connection terminals of the Second camera controller IN;
DC Power
3
4 5
2
15
63
4
21
3
4
2
1
1
5
ABIN
+-
1
2
3
4
5
6
-
+
DC 15V
7
8
9
10
11
12
13
14
1
2
3
4
5
6
-
+
DC 15V
7
8
9
10
11
12
13
14
1
2
3
4
5
6
-
+
DC 15V
7
8
9
10
11
12
13
14
Indoor Monitor B (option) Indoor Monitor A
Indoor Monitor C (option)
Outdoor Camera A Outdoor Camera B (option)
Lock
Lock
Second camera controller
The other group of 7,8,9,10,11,12 connection terminals of the indoor monitor

B connect to the 1,2,3,4,5,6 connection terminals of the indoor monitor A.
Same connection between monitor B and C.
3. The 5,6 connection terminals of outdoor camera connect to the lock; the
“﹢”,“﹣” connection terminals of indoor monitor connect to the power of DC 15V.
7.Operation Instruction
1. Press CALL button of outdoor camera and graceful rings will be heard from
indoor monitor and images of visitors will be seen. Then you can talk with
them and see them just by pressing TALK button of the indoor monitor. The
talking time can last about 120 seconds. Press TALK button to end a
conversation at any time.
2. Press UNLOCK button to release the door.
9. In order to reach the best images result, please take off the protective coating
of the screen.
10. The kit including three cards. If need more user
cards, please do according to the following steps:
Firstly, use the adding card to touch the ID card
Secondly, use the user card to touch the same area.
Thirdly, use the adding card to touch the same area. Then the new user card is
added successfully. At most 1000 user cards can be added.
11. If need to delete any user cards, please do according to the following steps:
touching zone of the outdoor station.
3. Pressing MONITOR button can monitor the outside. The monitoring time lasts
about 40 seconds.
4. Press the MONITOR button of the indoor monitor, then press the TALK button
to talk to the visitor. After talking, press TALK again to end the conversation.
5. The brightness, and chroma can be adjusted by using the button or knob to
reach the best result.
6. Ring volume adjustable by switch.
7. 14 polyphonic melodies for option by using the button at the side of monitor.
8. Talking volume adjustable by using knob.
Firstly, use the delete card to touch the ID card touching zone of the outdoor
station.

first ID card will be adding card, and the second will be delete card.
13. The kit can unlock the door with ID card, and user can install ID card
function accordingly.
Fourthly, turn off the power, and let the jumper wire to be RUN condition. The
8.Accessories
■ One indoor monitor ■ One outdoor camera
■ One adapter ■ One bracket for indoor monitor
■ 15M cable ■ Screws
9.Notices
1. Do not install the indoor monitor at high temperature, high humidity place or
near TV.
2. No touching the monitor screen with wet hands.
3. Please use only soft cloth to clean the monitor screen or camera in order to
get a clear image. Please do not use dishwashing liquid, lacquer diluent, or
corrosive liquid to clean.
4. Please avoid throwing or hitting the units.
5. Image could be illegible if the camera is shined by strong light.
6. If you use internal wireless communication systems, image may be fuzzy
because of interference from radio waves.
■ ID card: user card, adding card, delete card
deleted successfully.
12. The adding card and delete card are set well already. If the user loses the
adding card or delete card, he or she can re-program a new setting by doing
the following steps:
Secondly, please turn off the power, and let the ID unlock PCB jumper wire to
be SET condition.
Thirdly, turn on the power, and use two ID card to touch the ID card touching
zone of the outdoor station accordingly. If there is a long ring sound after the
second ID card touching, the re-setting is successful.
Firstly, open the back cover of outdoor station.
Secondly, use the user card to touch the same area.
Thirdly, use the delete card to touch the same area. Then the user card is
