quhwa VP-K User manual

User Manual
Video Doorbell
VP-K
QUHWA

I. Packing List
A. Video door phone host: 1
B. Mounting wrench: 1
C. Manual: 1
D. Host support: 1
E. Hex screw: 2
F. Screw expansion plug: 5
G. Support screw: 5

II. Product Diagram
1) Front View
1: Microphone 2: Light sensation window
3: Wide-angle high-definition camera and infrared lamp
4: Human model sensing window
5: Indicator light 6: Touch key area
7: Loudspeaker

2) Rear View
A: Support fastener B: Reset button
C: NO (normally open) D: GND (ground)
E:NC(normallyconnected) FG:AC/DC
H: Product Label I: Micro SD
Connection instructions:
(NO + GND): to magnetic lock
(NC + GND): to electric lock
AC/DC: to AC 8-16V or DC 9-24V, without polarity difference
Micro SD: installed/removed in power off state, with a maximum of 64G supported.
Reset button
Operation: Long press the reset button for 5 seconds and release to restore the factory

settings. The device will restart with a prompt tone upon completion.
3) Host support
1: Screw fixing hole; 2:Cordhole
3: Fastener hole.

III. Installation Instructions

IV. Downloading APP
Search in application market for tilvision
V. Registration and login

VI. Adding equipment
1) Power on the device and wait for the system prompt tone. Device startup
completed, before adding the device, make sure the mobile phone has been connected
to the 2.4G WIFI network.
2)Open the tilvision app and click "+"，Click the Setup device button and enter
the Wi-Fi password.

3）Long press the doorbell indicator light, release after the "di-di-di…" tone 
4) Warning tone two times will be presented during the configuration process:
a) The first beep tone indicates success of the device to obtain wifi information;
b) The second whistle indicates success of device configuration.

5) Search the configuration results.
VII.Main function
1) Call answering
When a visitor presses the call button, the indoor ding-dong machine (optional) ring
out, and the mobile terminal receives the call information at the same time. Open the
software, the call window is displayed against the background of a visitor picture.
Operations available are the following: answer, talkback, video, photographing,

unlock and reject.
2) PIR alarm mode
When going out (or at night fortification) and the PRI monitoring mode is turned on,
upon detection of someone stops at the doorway, the mobile terminal will receive the
alarm screen with a screenshot of the visitor as the background, and at the same time
the mobile terminal will emit audio warning to remind the owner to answer or
monitor.
3) History query
In the software main interface, swipe right to enter the menu mode, click the
History icon to enter the archive recording interface (the following is an image of
cloud storage as an example), click on the corresponding icon to view the
corresponding history.
4) New member to add device
"Search" :Search the device which already set up in the same wifi
"Scan QR code" :Scan QR code of device shared by family members.
5)Administrator adds an new username
The administrator needs to add username of the new member in the "Settings - User
Management".
6)Device sharing
click "Home page - Device - Device sharing"

Main product parameters
Product Name: WIFI Video Doorbell
Product Model: VP-T10
Video angle range: 120°
Video compression: H.264
Video pixels: HD720P
Audio: Two-way voice intercom, comes with echo cancellation
Loudspeaker: 1W
PIR distance: 3 meters detection
Day-night mode: Automatic switching between photosensitive sensors and
between IR-CUT dual filtering
Night infrared lamp: 5
Wireless connection: WIFI 2.4GHz, IEEE 802.11 b/g/n
Power input: AC 8-16V, DC 9-24V

Working with auto-learning code wireless indoor
chime
Once the video doorbell and indoor chime are powered in
20seconds,press the call button to complete configuration. The indoor
chime will sound if visitor rings the video doorbell in case the smart
phone is not available.
NamesforParts:




FunctionsInstruction
1.Presstheauto‐learningcodebuttononthesideoftheReceiver
andholdfor2or3seconds,A“beep”soundcomesoutandtheLED
indicationwilllight.Thenpressthecallbuttononthe
video
doorbellonce.TheReceiverwillsoundtoindicatethatnew
operationcodeisregisteredandmemorized.Thusthevideodoorbell
workssuccessfullywiththeindoorchime.Maximum60codes
canbe
matchedandsavedinthechimewithin10seconds.Ifthereisno
codematchedandsavedwithinthe10s,thechimewill
automaticallyexitandtherewillbetwo“beeps”.
2.Thereisamelodyselectorlocatedonthesideofthe
Receiver(seediagram).
SelectableTone:Total36
melodiesavailable.

Note:Youmustselectthedesiredringfirst,thenmatchthevideo
doorbell.
Ifyouwanttochangeringtones,youmust deleteallthe
informationsavedinthechimeandreset.
Pressthemelodyselectorbuttonandholdfor5seconds,youcan
deletealltheinformation
withinthechime.Atthesametime,
theLEDindicatorlightwilllight.
3.ThereisalsoavolumebuttononthesideoftheReceiver(see
diagram).Pressittoadjustthe
soundvolume,totalsixlevels.
4.ThereisaSoundandFlashSwitchButtononthesideofthereceiver.
Pressthisbuttonforthree
options,workingonlywithsound,
onlyLEDflash,soundandLEDflash:
A.Ifa“beep”soundcomesoutandtheLEDindicatordoesnotlight.
thechimewillworkonly
withsound.
B.Ifa“beep”soundcomesoutandtheLEDindicatorlights,the
chimewillworkwithsoundand
LEDflash.
C.IftheLEDindicatorlightswithout“beep”sound,thechime
willworkonlywithLEDflash.

Notes:
Ifthechimesoundsfornoreasonduringthedigitalcodesetting,it
isindicatedthatithasbeeninterferedbyothersimilarDoorbell
nearby,resettheauto‐learningcodeasperpoint1above.

FCC Caution:
This device complies with Part 15 of the FCC rules and Industry Canada
license-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications or change to this equipment. Such modifications or
change could void the user’s authority to operate the equipment.
This radio transmitter (identify the device by certification number or model number if
Category II) has been approved by Industry Canada to operate with the antenna types
listed below with the maximum permissible gain indicated. Antenna types not
included in this list, having a gain greater than the maximum gain indicated for that
type, are strictly prohibited for use with this device.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement.
To maintain compliance with FCC’s RF exposure guidelines, this equipment should
be installed and operated with a minimum distance of 20cm between the radiator and
your body.
