QUICK 854D Infrared Preheater
Instruction Manual
Thank you for purchasing our products. Please keep
the instruction manual properly for future reference.

Contents
1. Safety Instructions............................................................................... 1
2. Overview................................................................................................2
3. Product Characteristics.......................................................................2
4. Product Specifications.........................................................................3
5. Functional Descriptions.......................................................................4
5.1. Dimensions............................................................................. 4
5.2. Part Descriptions....................................................................5
5.3. Key Descriptions.................................................................... 6
5.4. Function Descriptions of the Main Interface......................7
6. Connection............................................................................................ 8
7. Temperature Settings.......................................................................... 8
8. Menu Settings.......................................................................................9
8.1. Channel Settings....................................................................9
8.2. Address Settings.................................................................. 11
8.3. Buzzer Settings.................................................................... 12
8.4. Language Settings...............................................................13
8.5. Password Settings...............................................................14
8.6. Linkage Settings.................................................................. 15
9. Temperature Calibration................................................................... 17

1
1.Safety Instructions
CAUTION
During the installation and use of this product, all electrical safety
regulations of the country and regions must be strictly observed.
The power supply must be disconnected when disassembling the
product. Do not operate with power on.
If the product does not work properly, please contact the supplier or
our company, and do not disassemble or change the product in any
way. We are not responsible for any problems caused by unauthorized
maintenance or modification.
WARNING
The product should be used away from places where there is
magnetic interference.
Don't install the product in a place where the surface is easy to shake
or be impacted, as it may damage the product.
Don't install the product in places where it may be exposed to rain or
moisture.
When using, the surrounding temperature is extremely high, pay
attention to prevent scalding.
Don't use in flammable and explosive environments.
Please place the product on the table covered with fire-proof and
heat-resistant rubber mat to avoid causing fire.
Please unplug the power cord when the product is not used for a long
time.

2
2.Overview
This infrared preheater adopts the far-infrared heating principle and
non-contact heating method to preheat the PCB, and works with other
heating tools such as soldering station or hot air gun to desolder and
rework the components of the PCB.
3.Product Characteristics
Three-channel temperature design, fast temperature switching.
Imported dark infrared ceramic heating element, fast heating,
high efficiency and long life.
External K-type sensor interface, convenient to test the actual
temperature of the heating products.
Sensor closed loop PID control, TFT LCD display, accurate
temperature and sectional preheating temperature setting.
Digital temperature calibration, convenient and fast.
Data communication port, automatic linkage control.

3
4.Product Specifications
Product model
854D
Voltage
AC 220V/230V
Power consumption
400W
Heating area
130mm*130mm
Heater material
Ceramic heater
Temperature sensor
K-type Thermocouple
Preheat temperature range
50～500℃
Temperature stability
±1℃
Sensor measuring range
Room temperature ～600℃
Thermometer accuracy
±5℃
Ambient temperature
0～40℃
Dimensions(L*W*H)
203*271*65mm
Weight
About2.8 kg

4
5.Functional Descriptions
5.1.Dimensions
Unit：mm

5
5.2.Part Descriptions
NO.
Part Descriptions
1
Power switch
2
Preheating area
3
Display part
4
Button
5
External port for K-type sensor
6
RS485 communication port

6
5.3.Key Descriptions
Key
Function Descriptions
1.Press in the main interface to switch between CH1, CH2
and CH3.
2.In the setting interface: Return/Cancel.
1.Press in the main interface to turn on/off.
2.In the setting interface : Advance/Save.
3.In the main interface, long press 2S to enter the setting
interface.
+ and -
Press at the same time to enter temperature calibration
interface.
+
1.In the main interface, press to increase the parameter
value.
2.In the setting interface : Page up.
-
1.In the main interface, press to decrease the parameter
value.
2.In the setting interface : Page down.

7
5.4.Function Descriptions of the Main Interface
Symbols
Descriptions
Symbols
Descriptions
Display channel.
Buzzer off.
1.Red: heating state.
2.Alternately flashing
red and black: the set
temperature is reached.
3.Blue: cooling state.
The current set
temperature value.
Buzzer on.
Press
to turn
off the temperature
control.
Display the temperature
of external K-type
thermometer.
External K-type
thermometer
disconnected.
T1/T2
Temperature zone 1
and temperature zone 2
Countdown

8
6.Connection
1) Insert the power plug into the power socket consistent with the label
value.
2) Turn on the preheater and it will start to heat up.
3) To change the set temperature, adjust the keys on the panel.
4) After a few minutes, the temperature will reach the set value and
stabilizes at the set value.
5) After working, please turn off the power supply. The preheating plate
will no longer be heated, and its temperature will slowly drop to room
temperature.
7.Temperature Settings
The default temporary channel at startup is CH0. Press to switch
to CH1, and press successively to switch to CH2 or CH3. The
temperatures of CH1-CH3 are 200 ℃、300 ℃ and temperature zone. To
change the set temperature and display the set temperature
value , "+" or "-" key can be used to change the temperature
value. The temperature range is 50 - 500 ℃.
Temperature rise
Short press "+" key, the temperature will rise by 1℃. Long press "+" key,
the temperature will rise rapidly. When the required temperature is
reached, release "+" key.
Temperature drop
Short press "-" key, the temperature will drop by 1℃. Long press "-" key,
the temperature will drop rapidly. When the required temperature is
reached, release "-" key.

9
8.Menu Settings
Long press to enter the setting menu.
8.1.Channel Settings
1) Press key to select the channel bar, and continue to press
key to select the parameter bar.
2) Press "+" or "-" key in the channel bar to select channels; In the
parameter bar, set the temperature and press key to save.
3) In CH3, select the temperature zone and press key to enter the
temperature zone setting interface to realize the function of segmented
temperature control. Two temperature ranges can be set, in which the
temperature and time can be adjusted. The range of temperature 1 is 50℃
- 300℃, the range of temperature 2 is 300℃- 500℃, and the range of
time 1 and 2 is 000 - 600 seconds.
When temperature 1 reaches the set temperature, the countdown starts
(time 1 is set according to your requirement), when the countdown ends,
it will enter temperature 2. When temperature 2 reaches the set
temperature, the countdown starts (time 2 is set according to your
requirement), when the countdown ends, it will return to temperature 1
and remains there. If you want to continue the above functions, press
key in the main interface to turn it off and turn it on again.
4) Press key to go back level by level until you return to the main
interface.

10

11
8.2.Address Settings
1) Press "+" and "-" on the main menu to switch the menu to Address.
2) Press to select the parameter and the parameter turns blue, press
"+" or "-" to set the address value, which ranges from 001 to 255.
3) Press to save.

12
8.3.Buzzer Settings
1) Press "+" and "-" on the main menu to switch the menu to Buzzer.
2) Press to select the parameter and the parameter turns blue, press
"+" or "-" to turn the buzzer on or off.
3) Press to save.

13
8.4. Language Settings
1) Press "+" and "-" on the main menu to switch the menu to Language.
2) Press to select the parameter and the parameter turns blue, press
"+" or "-" to select English and Chinese.
3) Press to save.

14
8.5.Password Settings
1) Press "+" and "-" on the main menu to switch the menu to Password.
2) Press to input the old password (default 000000) and enter the new
password setting interface. Press "+" or "-" to change the value,
each time you input a value, you need to press to confirm.
3) After the new password input is completed, the screen will display
"Successfully". Then it will be directly back to the Channel.
4) The new password takes effect after it is shut down and restarted or
return to the main interface.

15
8.6.Linkage Settings
1) Press "+" and "-" on the main menu to switch the menu to Linkage.
2) Double click to select mode 1, M1 turns blue, and press again
to confirm. M1: There is no linkage.
3) Press "-" to select mode 2, press , M2 turns blue. Press again
to confirm. M2: External equipment controls the preheater.
4) Press "-" to select mode 3, press , the value of mode 3
turns blue, press "+" or "-" to select appropriate temperature.
M3: Preheater controls external equipment, with optional temperature r
ange of 50 ~ 350 ℃.
5) Press to return to the main interface.
