Quoizel TF1427T Mounting instructions

Part Description Quantity
A1pc.
1pc.
B
Finial
Package Contents
Quoizel, Inc.
6 Corporate Parkway
Goose Creek, SC
29445
Customer Service
Phone [phone]
Fax [phone]
www.quoizel.com
ToolsRequired:None
EstimatedAssemblyTime:15-20minutes
Preparation:Identify andinspect allparts beforebeginning installation.Check package
contentlist anddiagrams belowto besure allparts arepresent. Ifany partsare missing
ordamaged, donot attemptto assemble,install, oroperate thefixture. Contactcustomer
servicefor replacementparts.
Warnings and Cautions
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing
the fixture. We strongly recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool
before removal. Do not subject glass parts to any shock while in operation or shattering may result.
Assembly Instruction Sheet #IS-TF1427T
For Style TF1427T
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
1of4
BulbRecommended: (2) MediumBase 75WMaximum
Shade
1pc.
CFlat Washer
Big Knurled Nut
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
A
B
D
E
D1pc.
1pc.
E
Check Ring
2012 QuoizelInc. October2012
F
G
H
1pc.
F
Tube
G1pc.
1pc.
HCenter Stem
Socket Assembly
Small Knurled Nut
J
1pc.
I
I
1pc.
JBase
C

TF1427T
1
2
2of4
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"REQ.
NO. REPLACEMENT PART DESCRIPTION
PART NUMBER
(2)75W
Medium Base Bulb
(Not Supplied)
14” Sq.
8”
23”
13.5”
11427TTF BASE TF1427TTF 1
G3427SH 1
GLASS SHADE TIFFANY 16"D X 8"H
1
2
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
3of4
Assembly Instruction Sheet #IS-TF1427T
For Style TF1427T
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
2012 QuoizelInc. October2012
Figure 2
STEP 1 attach Socket Assembly to Base-
A. Thread Socket Assembly (I) to Base (J), hand tighten
until snug.
Figure 1
Base
Socket Assembly
STEP 2 attach Center Stem to Fixture Body-
A. Thread one end of Center Stem (H) into Hex Coupling
on the top of Socket Assembly (I).
B. Please Tube (G) and Check Ring (F) over the Center
Stem (H). Secure by thread Small Knurled Nut (E) onto
the Center Stem (H), hand tighten until snug.
Socket Assembly
Tube
Center Stem
Hex Coupling
Check Ring
Small Knurled Nut

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
4of4
Assembly Instruction Sheet #IS-TF1427T
For Style TF1427T
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
STEP 3 Attach Shade to Fixture Body-
A. Thread Big Knurled Nut (D) onto Center Stem (H). Hand
tighten until snug.
B. Place the Flat Washer (C) and the Shade (B) over
Center Stem (H). Adjust the Big Knurled Nut (D) to
proper location for the Flat Washer (C), the Shade (B)
and Finial (A). Secure by thread Finial (A) onto the
Center Stem (H), hand tighten until snug.
Figure 3
Shade
Big Knurled Nut
2012 QuoizelInc. October2012
Center Stem
Finial
STEP 4 -Install Bulb
A. This fixture uses standard bulb with standard screw
base . Maximum 75 watts.
B. Insert bulb and screw snugly into place.
Your lamp is now assembled and ready to use.
Enjoy!
Figure 4
Bulb
Socket
Flat Washer
