Warnings and Cautions
1of2
Assembly Instruction Sheet #IS-CSE8410_R1
For Styles CSE8410PN and CSE8410EK
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing the fixture. We strongly
recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool before removal.
Pleasegoto forproductcleaningtips.Gotothe selection.
(1)MediumBase150WbulbMaximumor
(1)MediumBaseVintageBulbisrecommendedbutnotsupplied.
20-30minutes
Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtobesureallpartsare
present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomerserviceforreplacement
parts.
www.quoizel.com Care + Maintenance
LightSource:
EstimatedAssemblyTime:
Preparation:
Fixturecanonlybemountedinthedirectionindicatedonpage2.
ToolsRequired: Flathead screwdriver, Phillips screwdriver, pliers, wire cutters, wire strippers, electrical tape, safety glasses.
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-800-645-3184
or visit us on-line at www.quoizel.com
Package Contents
ACrossbar Assembly
x1
C
Fixture
Body
x1
BD
Shade
x1 E
Steel
Collar
x1
Socket
Collar
x1
STEP 1 Install Crossbar Assembly-
A. Pass the supply wires through the Crossbar Assembly (A). Attach
the Crossbar Assembly (A) to the Outlet Box with the head of the
Green Ground Screw facing you. Secure it with Outlet Box Screws
(not included). Tighten until snug.
Figure 1
STEP 2 -Remove Styrofoam
inside of the Fixture Body
A. Remove the Styrofoam and
Shade (C) inside the Fixture
Body (B).
Figure 2
STEP 3 Test Fitting Backplate to Crossbar Assembly-
A. Remove mounting balls from the Crossbar Assembly (A). Fit the
backplate on Fixture Body (B) to the Crossbar Assembly (A) and
secure with mounting balls. Note: The backplate on Fixture Body (B)
should be snug against the wall and the Mounting balls. If not, adjust
the length of the mounting screws on the Crossbar Assembly (A) by
unscrewing the preassembled hex nut and lock washer and then
screwing the mounting screws in or out of the crossbar until the
correct length is achieved. Once the backplate on Fixture Body (B) is
secure, remove the mounting ball and Fixture Body (B).
Figure 3
2017 QuoizelInc. RevisedDate:2017-11-03
B
C
Styrofoam
B
Mounting Ball
A
Backplate
Hex Nut and
Lock Washer
Mounting Screw
Supply Wires with
Ground Wire
Outlet Box Screws
(not included)
Outlet Box
A
2of2
2017 QuoizelInc.
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-800-645-3184
or visit us on-line at www.quoizel.com
RevisedDate:2017-11-03
STEP 4 - Wire Connections
A. Wrap bare or green ground wire around green ground screw on the
crossbar, no less than 2 inches from the end of the wire. Tighten the
green ground screw.
B. Use standard wire connectors (not included) to make all wire
connections. Twist connectors until wires are tightly joined together.
Wrap each connection with approved electrical tape and carefully
stuff all the connected wires into the Outlet Box.
Figure 4
Green Ground Screw
on the Crossbar
White wire
from outlet box White wire
from fixture
Black wire from
outlet box (or Red)
Black wire
from fixture
Bare, or Green
Ground wire
from outlet box
Ground wire
from Fixture
STEP 5 Install Fixture Body-
A. Carefully tuck all wires into
the outlet box and position
the backplate of Fixture
Body (B) over the outlet
box. Align the holes in the
backplate with the mounting
screws. Place caulk (not
supplied) into the
previously removed
mounting balls and then
attach Fixture Body (B)
using the mounting balls.
Hand tighten until snug.
Figure 5
STEP 6 Install Shade and Bulb-
A. Place Shade (C) and Steel
Collar (D) over the Socket,
secure by threading Socket
Collar (E) onto Socket. Hand
tighten until sung.
B. Insert bulb onto socket and
screw snugly into place.
Figure 6
Vintage Bulb
(recommended
but not supplied)
STEP 7 -Apply Silicone Sealer
A. Make sure exterior wall surface and fixture backplate are free of dirt
before applying caulk. Using exterior grade caulk, caulk over top of
backplate and down other side. Do not caulk bottom of fixture
backplate to ensure proper moisture drainage.
Your fixture is now assembled and ready to use. Enjoy!
Figure 7
Exterior
Grade Caulk
Backplate
Exterior
Grade
Caulk
CSE8410PN
NOTE: ALL DIMENSIONS ARE ROUNDED
UP TO THE NEAREST 1/4"
Fixture can
only be
mounted in
the direction
indicated
FINISH: PALLADIAN BRONZE
CSE8410EK
FINISH: EARTH BLACK
B
Mounting Ball
A
Backplate
Mounting Screw
B
D
E
Socket
10” Dia.
5.25”
11.75”
17.75”
8”
7” Dia. 8.5” Dia.
11”
C
