Quooker COMBI User manual

Installation guide COMBI
Before installing read this guide rst

Introduction
The operation of the Quooker COMBI
The Quooker system consists of a vacuum-insulated tank, which is connected to the cold water
supply under the sink and to the Nordic single tap, the Fusion tap or the Flex tap. Both boiling
water and mixer water can be dispensed from the Fusion and Flex tap.
Inside the tank the water is heated electrically to approx. 108°C and is kept at this temperature.
When boiling water is dispensed, cold water ows back into the tank at the same time and is
heated automatically. If the entire content of boiling water (7 litres) is used in one go, the heating
time is ca. 20 min.
Before the water leaves the tank it is puried by the HiTAC® water lter (High Temperature
Activated Carbon). To extend the life of the lter, the water used for mixing the hot water is
not ltered.
In addition to boiling water, the Quooker COMBI also supplies instant hot water. The COMBI
supplies hot water by mixing boiling water from the Quooker tank with cold water from the water
mains inside the mixing valve. A thermostatic control element inside the valve keeps the outgoing
water temperature constant. This temperature can be set between 40 °C and 60°C with the grey
knob on the mixing valve. The mixing valve is suitably protected against a loss in water pressure,
preventing any boiling water from owing out of the mixer tap.
The grooved handle on the tap lights up when the water is running to warn the user that the
water is boiling. As an additional safety feature, the Nordic single tap is height-adjustable and
the Nordic single tap, the Fusion tap and the Flex tap are fully insulated.
Despite all the safety features incorporated in the product, anyone using the Quooker system
must keep in mind the risks of using boiling water in general. Incorrect use can lead to injury.
Therefore always read the manual carefully before use.

Installation, maintenance and warranty
Installing the Quooker requires connections to the mains water supply and the electrical system.
The Quooker is supplied with a handy connection kit for simple installation. You must not connect
the Quooker to a reverse osmosis system or to a water softener that reduces the pH value.
For optimally puried Quooker boiling water, we recommend changing the HiTAC® lter cartridge
every 3 - 5 years. If necessary, the tank can be descaled. In areas with hard water this should be
performed more regularly.
The warranty period is two years, according to our General Terms of Business.
Users
The Quooker tap can be used by children above the age of eight and people with diminished
physical, sensory or intellectual abilities provided they are supervised or have been instructed
on the safe use of the device. Inform people who are unfamiliar with the Quooker system about
safe use and the possible dangers associated with the use of the boiling-water tap. Please note:
incorrect use may result in injury. Prevent children from using the tap as a toy and do not
allow children to clean or maintain the product unsupervised. Keep the plug out of reach
of small children.
The Quooker system is suitable for household use and commercial use such as in sta kitchens
at shops, oces, farms and other business premises and for use by visitors at hotels, motels,
bed & breakfasts and other residential accommodation.
Always follow the installation method described in the manual. Avoid spilling water on the plug.
If defective, the power plug may only be replaced by a qualied technician. Make sure you let
the tank cool o adequately before disconnecting it. The fastest way to do this is as follows: turn
o the Quooker, but leave the plug in the socket. Then open the boiling-water tap and turn it o
once the water runs cold. You can nd a more detailed explanation for disconnecting the tank in
chapter E.
Tips for use and the installation manual can also be found on our website: quooker.ae

Declaration of conformity
Quooker Nederland B.V., Staalstraat 13, 2984 AJ Ridderkerk (The Netherlands) herewith declares,
on our own responsibility, that the products Quooker COMBI and Quooker COMBI+ are in
accordance with the conditions of the following directives:
- 2014/35/EU Low Voltage Directive (LVD)
- 2011/65/EU Restriction of Hazardous Substances (RoHS) Directive
- 2014/30/EU Electromagnetic Compatibility Directive (EMCD)
- 2009/125/EC Ecodesign energy-related products Directive
- 2014/68/EU Pressure Equipment Directive
and are in conformity with the following standards:
General product safety household and similar electrical appliances
EN 60335-1:2012 + AC:2014 + A11:2014
EN 60335-2-15:2002 + AC:2005 + A1:2005 + AC:2006 + A2:2008 + A11:2012 + A11:2012/AC:2013
+ EN 60335-2-15:2016
EN 60335-2-21:2003 + A1:2005 + AC:2007 + A2:2008 + AC:2010
Public exposure to electromagnetic elds (EMF)
EN 62233:2008 + AC:2008
Electromagnetic compatibility (EMC)
EN 55014-1:2017 + EN 55014-1:2006 + A1:2009 + A2:2011
EN 55014-2:2015 + EN 55014-2:1997 + AC:1997 + A1:2001 + A2:2008
EN 61000-3-2:2014
EN 61000-3-3:2013
Restriction of hazardous substances
EN 50581:2012
Ecodesign water heaters
Regulation (EU) 814/2013
The Netherlands, Ridderkerk, December 2021
Niels Peteri, Director

Technical specications
Tank COMBI
Voltage 230 V
Wattage* 2200 W
Capacity 7 litres
Heating-up time* 20 minutes
Standby power consumption* 10 W
Tank height 48 cm
Tank diameter 20 cm
Min. mains pressure 200 kPa (2 bar)
Max. mains pressure 600 kPa (6 bar)
Max. working pressure 800 kPa (8 bar)
Mounting bracket optional yes
Safety features - maximum temperature fuse
- pressure relief valve in solenoid valve 800 kPa (8 bar)
HiTAC® water lter High Temperature Activated Carbon
*These are average values.
Energy label
Declared load prole XXS
Water heating energy
eciency class A
Water heating energy eciency 36%
Annual electricity consumption 511 kWh/A
Warm water temperature
settings of the water heater 40 °C - 60 °C
Sound power level - dB
Tap Nordic Fusion, Flex
single tap and mixer tap
Tap hole size 32 mm 35 mm
Recomm. temp. mixing water - 60 °C
Bezel available yes yes

Contents of the pack
1. - Nordic single tap, packing ring, centring ring, steel ring, brass sink nut and two screws
- or Fusion tap, packing ring, brass xing plate, xing nut, white tap support (for thin work tops)
and two inlet hose screens
- or Flex tap, hoses, bre washer(s), steel washer, screw ring with two screws, coupling with
boiling water hose, white tap support, two inlet hose screens and quick-release tool.
1
Fusion Flex
Nordic single tap

2. COMBI tank
3. T-joint, inlet hose screens and bre washer
4. Isolation valve with lter
6. Mixing valve and check valve
2
4
3
5

Overview of Nordic single tap installation
It is recommended that you install the Quooker in the following order:
A. Drlling hole
B1. Fitting Nordic single tap
C. Connecting water
D. Connecting tank
Note: Bear in mind that the tank, mixing valve and socket must remain accessible for servicing.
For an overview of the Fusion tap installation, please refer to the next page and for the Flex tap to
the page after that.
A B1
C
D
Cold

Overview of Nordic single tap installation
It is recommended that you install the Quooker in the following order:
A. Drlling hole
B2. Fitting Fusion tap
C. Connecting water
D. Connecting tank
Note: Bear in mind that the tank, mixing valve and socket must remain accessible for servicing.
For an overview of the Flex tap installation, please refer to the next page.
A B2
C
Cold
D

Overview of Flex tap installation
It is recommended that you install the Quooker in the following order:
A. Drlling hole
B3. Fitting Flex tap
C. Connecting water
D. Connecting tank
Note: Bear in mind that the tank, mixing valve and socket must remain accessible for servicing.
For an overview of the Flex tap installation, please refer to the next page.
A B3
C
D
Cold

1
3
2
A
Q
M
QM
1. Select position Nordic single tap
Select a suitable position for the Nordic
single tap based on the type of sink and
position of the mixer tap.
2. Drilling hole for Nordic single tap
Using the correct drill bit, drill a hole of
32 mm through the work top for the Nordic
single tap. Note: For the Nordic mixer tap
please refer to the separate guide. In the
case of a hole of 35 mm or larger, use the
centring ring provided.
3. Drilling hole for Fusion or Flex tap
Select a suitable position for the tap.
Using the correct drill bit, drill a hole of
35 mm through the work top. In this, take
account of the range of the tap’s spout
from the centre of the tap hole.
Drilling hole
• Note: The tap hole for the Nordic single tap should be 32 mm in diameter.
The Fusion and Flex tap hole should be 35 mm in diameter.
• The Nordic single tap should ideally be positioned at the corner of the sink to enable use
above the sink or the work top.
• Note: It must be possible to move the spout of the Nordic single tap freely up and down.
When the spout is in its lowest position it projects ca. 25 cm below the work top. Bear this in
mind when tting the inlet combination, sockets and the like.
• Note: The Flex tap coupling must be able to move freely. When the hose is not withdrawn it
hangs approximately 40 cm below the work surface top. Make allowances for this when tting
the inlet combination, power sockets and so forth.
Dimensions in mm
Max. thickness 60
Ø52
Hole
Ø35
225
±70
Dimensions in mm
Max. thickness 50
Ø50
Hole
Ø32
±70
160
Dimensions in mm
Max. thickness 50
Ø50
Hole Ø35
225
±70
Nordic single tap
Mixer tap

1
3
21. Tap through work top
Push the tap through the hole in the work
top. Note: When tting the tap in a 32 mm
hole, the black plastic ring needs to be
removed from the tap rst.
2. Securing the tap
Set the tap to the desired position and
secure it with the metal ring and screw ring
supplied.
3. Securing tap screws
Tighten the screws in the screw ring.
Fitting Nordic single tap
• The total length of the hose between the boiling-water tap and tank is only 70 cm. The tank
must therefore be tted close to the tap. Extension hoses are available in dierent lengths but
are not normally required.
• The small bre washers supplied with the tap rings are not required yet at this point. One will
be used for connecting the tap and tank hose (see section E), the second one is a spare.
B1

1
3
2
4
Fitting Fusion tap
B2
1. Mount the hoses
Mount the hot water and cold water hoses
on the tap.
2. Tap through work top
Push the tap through the hole in the
work top.
3. Securing tap
Position the brass xing plate around the
hoses. Screw the xing nut onto the tap
thread. Adjust the position of the tap to
ensure that the Quooker logo is facing
the user. When the handle is in the cold
position, it will be parallel to the edge of
the work top. Tighten the xing nut with a
pipe wrench, socket wrench or spanner.
4. Fitting to thin work top
When tting to a thin work top, use the
white tap support underneath the brass
xing plate.

1. Fit hoses
Fit the hot, cold and mixer water hose to
the tap.
2. Tap through work top
Push the tap through the hole in the work
top.
3. Tighten the brass plate
Put the tap in the required position and
fully tighten the brass plate.
4. Securing tap screws
Tighten the screws in the screw ring.
Fitting Flex tap
• When installing the tank it is necessary to take into account that the Flex tap counterweight
must be able to move up and down freely. When the hose is not withdrawn it hangs
approximately 40 cm below the work surface.
• Note: When tting the tap to a thin work top use the white tap support before placing the
metal washer and threaded ring around the hoses.
B3
1
3
2
4

65 5. Attach the coupling
Click the pull-out hose into the coupling’s
quick-release tting while ensuring that
the hose pillar is fully inserted.
6. Fit the mixer water hose
Click the mixer water hose into the
coupling’s quick-release tting while
ensuring that the hose pillar is fully
inserted.
If necessary
Detach coupling. Use the quick-release
tool to detach the mixer water hoses from
the coupling. Press the quick-release tool
at against the coupling to hold it still.
This enables the hose to be extracted.

Cold
Connecting water
• The Quooker operates under mains water pressure and must always be tted to the water pipe
with the supplied inlet valve.
• The Nordic single tap, the Fusion tap or de the Flex tap must be installed according to the
locally applicable regulations.
1
3
2
4
1. Connecting T-joint and hoses
Prior to installation, close the corner
shut-o tap or turn o the water supply to
the main tap. If necessary, t the supplied
corner shut-o tap. Use an inlet hose
screen to connect the T-joint to the corner
shut-o tap. Use the inlet hose screen to
connect the cold water hose to the T-joint.
2. Fitting the mixing valve
Use the supplied bre washer to connect
the mixing valve to the T-joint. Make sure
that the temperature setting knob of the
mixing valve remains accessible. This
can be turned to adjust the temperature
(between 40 °C and 60 °C). Connect the
Fusion or Flex mixer tap hot water hose
to the mixing valve using an inlet hose
screen.
3. Installing the hose
Put the Quooker reservoir in place and
connect the hose to the mixing valve
as indicated in the adjacent image.
The connection is equipped with a
compression tting so no gasket is
required.
4. Installing the check valve and hose
Fit the check valve to the remaining
mixing valve connection. Then t the
other Quooker reservoir hose to this.
The connections are equipped with
compression ttings so no gasket is
required.
C
Cold

Connecting tank to tap
• The Quooker tank is supplied with a UK 3 pin plug and requires a standard 13 amp earthed
socket.
• The light ring on the boiling-water tap will light up to indicate when the water is being heated
inside the tank.
• If the mains lead is damaged, it must be replaced by the manufacturer, their agent or a
qualied technician.
• The ‘Q’ on the lid is the on/o switch.
1
3
2
4
1. Connecting tank and tap
Position the tank. Using size 12 and 14
socket spanners, connect tap hose to
tting at the top of the tank.
2. Electrical connection
Insert the LED cable into the hole provided
at the back of the tank cover. Connect the
tank to an earthed socket. Do not switch
on until the tank is lled with water.
3. Filling tank
Open tap and isolation valve. Check for
leaks. Rinse Quooker for a few minutes,
until the water is clear. The initial black
colouring is activated carbon from the
lter and completely harmless.
4. Switching on
Switch the tank on.
D
12
14
On/off

Disconnecting tank
• In case of service.
1
3
2
4
1. Switching o
Press the on/o switch at the top of the
tank to switch it o. Do not unplug the tank
from the power socket yet.
2. Draining
Open the boiling-water handle of the tap
and leave the water running until it runs
cold. Then close the tap again. Note: At
rst, the water is very hot.
3. Isolating
Close the main shut-o valve or the
isolation valve. Check that the Quooker
is depressurized by opening the boiling-
water handle again. If it is depressurized,
no water should ow out of it.
4. Disconnecting
Unplug the LED cable from the lid. Release
the hose connections and pull the plug
out of the socket. Remove the inlet valve
and reconnect the cold water hose to
the isolation valve using the bre washer.
Open the main shut-o valve or the
isolation valve.
E
On/off
Cold

Quooker Emirates LLC
15A Street, Showroom 17
Al Joud Center
Al Quoz, Dubai (UAE)
[phone]
[e-mail]
www.quooker.ae
AEENG | 30.690.11 | V03
