Qware QW TB-1040 User manual

QW TB-1040
TABLET PC Pro

User Manual
Table of Contents
1. Notes
2. Hardware Specifications
3. Startup and shutdown
4. esktop
5. Button
6. Main Menu Operation
7. System Settings
A. Wireless & networks
B. isplay
- Output settings
- Brightness
- Screen timeout
C. ate & time
8. Internet
9. Music
10. Video
11. Gallery
12. Wallpaper
13. Sound Recording
14. Camera
15. Market
16. Email
17. Connect to PC
* USB connection
* USB Keyboard and Mouse
19. Firmware upgrade

1. Notes:
* This is a high precision electronic product. o not disassemble.
* Avoid dropping or collision of the product.
* Avoid using this product under the following conditions: high and low temperature,
moisture, dust, strong magnetic fields and long-term exposure to sunlight.
* Please use a wet cotton cloth and gently wipe the product shell, do not use other
chemical cleaning solutions. This product should not be exposed to dripping or
splashing water.
* Using the headphone with high volume may cause permanent hearing damage.
* o not cross the road, drive a motor vehicle or bicycle when using headphones to
avoid traffic accidents.
* Please only use permitted chargers and accessories. If you use any other type of
products, it would violate the warranty regulations and may be dangerous.
* Please follow the relevant local environmental regulations to deal with obsolete
machines and accessories.
* When your have any questions, contact your local dealer, or contact the help desk.
* The Company assumes no responsibility when the product is damaged, repaired
or other causes of memory loss and data. Please follow the user manual for standard
operation procedure.
* o not open the product, this will violate the warranty regulation and is
dangerous.

2. Hardware specification :
Product specification
Processor
Cortex-A9 AMLogic 8762-M High-performance processor Frequency
1GHz.
Memory 512MB R2 RAM
Storage Memory built-in 4GB
Support Micro S card to expand memory upto 32GB
Wireless 802.11b/g/n wireless network
USB USB2.0 OTG high speed interface and USB1.1
Video output H MI 1.3 Full H Video Output Interface
Audio
3.5mm headphone jack
High-quality stereo loud speaker
3.5mm External microphone input jack
Headset maximum output power of 40mW
Frequency response: 20Hz-20KHz
SNR: greater than 90db
Screen
Size 10.1 inch
Resolution WVGA 1024*600
Color 16 million colors
Operating
Capacitive multi-touch panel
Other
Size 262 * 160 * 17mm
Color Black casing
Weight 710g
Battery Built-in lithium polymer battery 3400mAH
Accessories
1pc Power adapter ( C9.0 V/2.0A)
1pc USB cable
1pc Instruction manual

3. Startup and shutdown
Press and hold the power button, the system will enter the startup process
Startup Screen
After the system has been started, the android OS will be loaded :

The system displays the standby screen, press the key-lock logo and slide it outside
the circle in order to unlock. Then the desktop will appear

Shutdown: Press and hold the power button, a pop-up window will appear and
select POWER OFF to shut down the device
Press the power button short to go to stand-by mode.
To activate the unit, press the Return or power button.

4. esktop:
After the completion of the startup, you can see the Android4.0 esktop.(See below
picture)
The default desktop contains: Status Bar、Quick Search Bar、Main menu tabs and a
number of shortcut icons.
- At the Left bottom side of the status bar are 3 main buttons : Return, Home and
shortcut keys
- At the Right bottom side of the status bar, the current system status of network,
battery and time are displayed.
- At the Top Left corner is a Quick search icon for Web searches by typing key words.
- At the Top Right corner is an Application icon which when pressed will go to the
applications screen.

5. Buttons:
The Android system uses in the following:
1) Volume keys: the buttons on top Volume +, Volume- to adjust the volume.
2) Power key: To turn on and off of the unit or by short pressing it to enter or leave
the standby mode.
3) Menu button: isplays the menu items (if any).
4) Home button: Back to the home screen
5) Return button: Return to previous screen.
6) Search button: Quick search function

6. Main Menu Operation:
Click the application screen button of the main menu tab, the application screen
appears:
In the application screen, your can choose to start any installed application or by
pressing and holding the icon move it to the desktop.

7. System Settings:
Click the setting icon in the main menu tab, the main system setting screen will
appear :
Select the appropriate operation of the relevant items, such as:
WIRELESS & NETWORKS
* WiFi
EVICE
* Sound
* isplay
* Storage
* Battery
* Apps
PERSONAL
* Accounts & sync
* Location services
* Security
* Languages & input
SYSTEM
* ate & time
* Backup & Reset
* Accessibility
* eveloper options
* About Tablet

A. Wireless and Networks :
Click the WiFi icon to “ON” to enable WiFi function if necessary
Select the preferred network, and below Window will appear in case the network is
protected, enter the password and press connect in the screen.
If the password is entered correct, you will see on the screen that you are connected
to the network.

B. isplay :
- Output settings
This product supports H MI output and LC output.
efault setting is LC output, this means all video output will be displayed on the
screen of the unit.
If you want to use H MI output, please connect the H MI cable to device and the
external monitor. The output will automatically switch to the external monitor.

- Brightness
In the menu, choose brightness to adjust the brightness of the screen.
- Screen timeout :
To adjust the time before the screen turns off, press the “Sleep” button and choose
the desired time.

C. ate and time settings:
It is easy for date & time settings by enable “Automatic date & time” and “Automatic
time zone”
Otherwise, it can be set by manually as below :
- Set date - Set time
- Select time zone - Use 24-hour format - Select date format
Select arrow up: to increase with 1 unit,
Select arrow down -: to reduce with 1 unit.
Or you can input the date by pressing the calendar’s date window.

8. Internet :
By clicking the web browser icon on the main menu tabs, enter the website
address to enjoy internet.

9. Music:
Click the "music" icon in the application screen, you will enter the music player
interface. Here you can find all audio files which are available on the device.
You can copy files via USB drive or Micro S card or download from the internet. If
your play a song, below screen appears :

10. Video Player:
Click the “Super-H Player” icon in the application screen, the available video files
be shown as below :
Click the video file directly and it will be played automatically as below :

11. Gallery :
Click the "Super-H Player” " icon in the application screen, the pictures files and
video files will appear as shown below :
Select a picture file, the picture will be shown as below. You can zoom in/out, and
rotate etc operation.
