Qware QW TB-G100 User manual

QW TB-G100
GAMING TABLET PC

User Manual
Table of Contents
1. Key Features
2. Packaging contents
3. Pro uct layout
4. Har ware Specifications
5. Startup an shut own
6. Desktop
7. Main Menu Operation
8. System Settings
A. Wireless & networks
B. Display
- Output settings
- Brightness
- Screen timeout
C. Date & time
9. Internet
10. Music
11. Vi eo
12. Gallery
13. Wallpaper
14. Soun Recor ing
15. Camera
16. Market
17. Email
18. Connect to PC
* USB connection
* USB Keyboar an Mouse
19. Firmware upgra e

Notes:
* This is a high precision electronic pro uct. Do not isassemble.
* Avoi ropping or collision of the pro uct.
* Avoi using this pro uct un er the following con itions: high an low temperature,
moisture, ust, strong magnetic fiel s an long-term exposure to sunlight.
* Please use a wet cotton cloth an gently wipe the pro uct shell, o not use other
chemical cleaning solutions. This pro uct shoul not be expose to ripping or
splashing water.
* Using the hea phone with high volume may cause permanent hearing amage.
* Do not cross the roa , rive a motor vehicle or bicycle when using hea phones to
avoi traffic acci ents.
* Please only use permitte chargers an accessories. If you use any other type of
pro ucts, it woul violate the warranty regulations an may be angerous.
* Please follow the relevant local environmental regulations to eal with obsolete
machines an accessories.
* When your have any questions, contact your local ealer, or contact the help esk.
* The Company assumes no responsibility when the pro uct is amage , repaire
or other causes of memory loss an ata. Please follow the user manual for stan ar
operation proce ure.
* Do not open the pro uct, this will violate the warranty regulation an is
angerous.

Introduction
Congratulations on your purchase of the Qware QW TB-100G 7” tablet PC. The QW
TB-100G uses the An roi 4.0 operating system an is base on a powerful Cortex
A8 1.2Ghz processor.
The QW TB-100G has 4GB of internal memory of which 2GB is allocate for irect
application ownloa s. The other memory part is free to use for storage of pictures,
music, movies an other ata files. A micro SD car slot enables you to even
enhance the memory capacity further. Fast 1GB DDR III RAM memory improves the
performance of the QW TB-100G.
The unit has a 7” multi touch capacitive touch screen, which makes it possible to
very easily control evice by using only your fingertips.
The fast 802.11N buil -in wireless network a apter enables fast web surfing an
ownloa ing. The QW TB-100G further has a mini-usb port which enables the
connection of accessories, an a mini HDMI port for vi eo output.

1. Ke features_____________________________
Feature A vantage
Incre ible ata rate upto 150MBPS* Fast web surfing and Down loading
Sensitive capacitive touch screen Accurate touch control of the tablet
PC
4GB buil in memory Sufficient storage space for apps,
pictures, music and other files
Powerful Cortex A8 processor Fast execution of Commands
and programs
Mali 400 graphics processor unit fast 3D graphics, Decoding,
ideal for Pla ing games
* Theoretical standard based on IEEE standard of 802.11 b,g,n chipset used. Actual Throughput may
vary. Network conditions and environmental factors lower actual throughput rate. All specifications
are subject to change without notice.

2. Packaging Contents________________________
Open the package carefully, an make sure that none of the items liste below are
missing. Do not iscar the packing materials, in case of return; the unit must be
shippe back in its original package :
1. The Tablet evice QW TB-100G
2. A 100~240V Power A aptor
3. A USB cable
4. An Earphone
3. An User Manual

3. Product La out____________________________
The An roi system uses the following keys:
1) Volume keys: the buttons on top Volume +, Volume- to a just the volume.
2) Power key: To turn on an off of the unit or by short pressing it to enter or leave
the stan by mo e.
3) Menu button: Displays the menu items (if any).
4) Home button: Back to the home screen
5) Return: Return to previous screen.

4. Hardware specification_____________________
Pro uct specification
Processor
A10 Cortex A8 Multi-Core ARM v7 processor Frequency 1.2GHz
Memory 1GB DDR3 RAM
Storage Memory built-in 4GB
Support Micro SD car to expan memory up to 32GB
Wireless IEEE802.11b/g/n wireless network
USB USB2.0 OTG high spee interface an USB1.1
Vi eo output HDMI 1.4 Full HD Vi eo Output Interface
Au io
3.5mm hea phone jack
High-quality lou speaker
Built-in microphone
Hea set maximum output power of 40mW
Frequency response: 20Hz-20KHz
SNR: greater than 90 b
Screen
Size 7.0 inch
Resolution WVGA 800*480
Color 16 million colors
Operating
Capacitive multi-touch panel
Other
Size 238 * 122 * 15mm
Color Blue casing
Weight 420g
Battery Built-in lithium polymer battery 3400mAH

5. Startup and shutdown______________________
Press an hol the power button, the system will enter the startup process
Startup Screen
After the system has been starte , the an roi OS will be loa e :

The system isplays the stan by screen, press the key-lock logo an sli e it outsi e
the circle in or er to unlock. Then the esktop will appear.

Shut own : Press an hol the power button, a pop-up win ow will appear an
select OK to shut own the evice
Press the power button short to go to stan -by mo e.
To activate the unit, press the power button again.

6. Desktop_________________________________
After the completion of the startup, you can see the An roi 4.0 Desktop.(See below
picture)
The efault esktop contains: Status Bar、Quick Search Bar、Main menu tabs an a
number of shortcut icons.
- At the Left bottom si e of the status bar are 3 main buttons : Return, Home an
shortcut keys
- At the Right bottom si e of the status bar, the current system status of network,
battery an time are isplaye .
- At the Top Left corner is a Quick search icon for Web searches by typing key wor s.
- At the Top Right corner is an Application icon which when presse will go to the
applications screen.

7. Main Menu Operation_______________________
Click the application button, the application screen appears:
In the application screen, your can choose to start any installe application or by
pressing an hol ing the icon move it to the esktop.

8. S stem Settings___________________________
Click the setting icon in the main menu tab, the main system setting screen will
appear :
Select the appropriate operation of the relevant items, such as:
WIRELESS & NETWORKS
* WiFi
DEVICE
* Soun
* Display
* Storage
* Battery
* Apps
PERSONAL
* Accounts & sync
* Location services
* Security
* Languages & input
SYSTEM
* Date & time
* Backup & Reset
* Accessibility
* Developer options
* About Tablet

A. Wireless & Networks
Click the WiFi icon to “ON” to enable WiFi function if necessary
Select the preferre network, an below Win ow will appear in case the network is
protecte , enter the passwor an press connect in the screen.
If the passwor is entere correct, you will see on the screen that you are connecte
to the network.

B. Displa
- Output settings
This pro uct supports HDMI output an LCD output.
Default setting is LCD output, this means all vi eo output will be isplaye on the
screen of the unit.
If you want to use HDMI output, please connect the HDMI cable to evice an the
external monitor. The output will automatically switch to the external monitor.

- Brightness
In the menu, choose brightness to a just the brightness of the screen.
- Screen timeout :
To a just the time before the screen turns off, press the “Sleep” button an choose
the esire time.

C. Date and time settings
It is easy for ate & time settings by enable “Automatic ate & time” an “Automatic
time zone”
Otherwise, it can be set by manually as below :
- Set ate - Set time
- Select time zone - Use 24-hour format - Select ate format
Select arrow up: to increase with 1 unit,
Select arrow own -: to re uce with 1 unit.
Or you can input the ate by pressing the calen ar’s ate win ow.

9. Internet ___________________________
By clicking the web browser icon an enter the website a ress to enjoy internet.
