R2 WM-FM PLT7010.X User manual

PLATFORM
WALL MOUNTED & FLOOR MOUNTED UNITS
Please retain for future use
Customer Services: R2, Brassmill Lane Trading Estate, Bath, BA1 3JF
Tel:[phone] | Fax: [phone]
Email: [email protected] | Web: www.r2bathrooms.co.uk
PAGE 1 OF 4
R2- REV : FS/07/2019
REPLACEMENT COMPONENTS
Should you require any replacement components for this product please use the contact details below.
FURNITURE AFTERCARE INSTRUCTIONS
As with all wooden furniture, this product should be treated with care.
We recommend...
Wipe away any water splashes or condensa-
tion after use. Excessive exposure to water will
deteriorate the furniture.
All bathrooms should be well ventilated with a
suitable extractor fan.
Clean with a soft damp cloth only.
For removal of lime scale deposits use a
suitable proprietary cleaner. If necessary test
on an inconspicuous area first.
WIPE AWAY
Please DO NOT...
BLEACH
CLEANER
CREAM
CLEANER
Do not scrub or scour
Do not use abrasive cleaning agents
The unit and basin should be fully secured to a suitably reinforced wall to ensure stability. The wall plugs supplied are only suitable for solid
stone/brick walls. For plasterboard walls use specialist wall plugs along with supplementary wall strengthening as units can be very heavy.
Seek advice from a specialist about the suitability of fixings to be used.
Wear suitable eye protection when drilling. Take care when using power tools near water - the use of a residual current device (RCD) is
recommended. Beware of hidden pipes or cables. Take care when drilling tiled surfaces as the drill might slip. Use a piece of masking tape
to prevent the drill from wandering.
SAFTEY NOTICE
• Apply a bead of silicone to the basin / worktop on 2 sides to fix to
and protect the side panel edges as per figure above.
• Typically the basin also has a silicone bead along the back edges
where it meets the wall (not shown)
• The basin should be held in place while the silicone cures.
BASIN INSTALLATION

PLATFORM
WALL MOUNTED & FLOOR MOUNTED UNITS
Please retain for future use
Customer Services: R2, Brassmill Lane Trading Estate, Bath, BA1 3JF
Tel:[phone] | Fax: [phone]
Email: [email protected] | Web: www.r2bathrooms.co.uk
PAGE 2 OF 4
R2- REV : FS/07/2019
To secure the floor mounted units to the wall use the provided kit to screw the unit through the back top brace.
FIXING TO THE WALL - FLOOR MOUNTED UNITS
1
FIXING TO THE WALL - WALL MOUNTED UNITS
2
Mark the location of each of the wall
mounting plates ensuring that they are
positioned inside the sidewalls of the
unit. For each mounting plate drill two
holes in the marked positions using a
8mm drill bit to a depth of 55mm.
Remove the cover cap from the
hangers.
Locate the hangers onto the wall
mounting plates. Wall hangers tighten
the unit against the wall (Screw A) and
have up/down adjustment to level the
unit (Screw B). Replace cover cap


height
1
1
3
2
B
A
REMOVING DRAWER
The drawer and drawer fascia can be removed if necessary using the mechanism under the interior cover caps. When replacing the
drawer, ensure that the runners fully engage at the back of the drawer and an audible click is heard.
CLICK
CLICK

Customer Services: R2, Brassmill Lane Trading Estate, Bath, BA1 3JF
Tel:[phone] | Fax: [phone]
Email: [email protected] | Web: www.r2bathrooms.co.uk
PAGE 3 OF 4
R2- REV : FS/07/2019
PLATFORM
WALL MOUNTED & FLOOR MOUNTED UNITS
Please retain for future use
21
SECONDARY FASCIA FIXING
Before making any fascia adjustments or removals please remove the secondary fixing underneath the drawer as below.
1
5
3
4
2
REMOVING FASCIA
ADJUSTING DRAWER FASCIA

FITTING BASINS
Customer Services: R2, Brassmill Lane Trading Estate, Bath, BA1 3JF
Tel:[phone] | Fax: [phone]
Email: [email protected] | Web: www.r2bathrooms.co.uk
PAGE 4 OF 4
R2- REV : FS/07/2019
PLATFORM
WALL MOUNTED & FLOOR MOUNTED UNITS
Please retain for future use
Once the basin is plumbed in, finish by securing it to the furniture unit along the top face of the side panel with silicone sealant (not supplied).
HINGE ADJUSTMENT
To make adjustment 1
simply turn screw A
To make adjustment 2
simply turn screw B
To make adjustment 3
simply turn screw C
2
2
1
1
3
3
C
Door Furniture Frame
B
A
INSTALLING HANDLES
1 2
Slot chosen handle into the pre-cut groove in the fascia panel.
Use screws provided to attach the chosen handles to the fascia.
Tighten using a screwdriver.
