Rack Solutions 1UKYB-126-USB User manual

Rack Mount
Keyboard Tray
Installation Instructions
Kit P/N: 1UKYB-126-USB
Kit P/N: 1UKYB-126-PS2
Patent(s) Pending

Page 2
Kit Contents
(1) Partially Assembled Shelf
(1) Mini Black Keyboard (USB or PS2)
(2) Rear Brackets
(1) Cable Management Bracket
(2) Cable Management Arms
Assembly Hardware Kit:
(6)8-32 x 3/8" Phil Flat Screws
(6)8-32 Nuts
(1)30” +RRNDQG/RRS
(1)11/16” Cotterless Hitch Pin with Pull Ring
(3)1/4” x 1 3/8" Clevis Pin
(3).059” x 1 1/8" Cotter Pin
Rack Mount Hardware Kit:
(8) 12-24 x 1/2” Pan Head Screws Zinc
(8) 10-32 x 1/2” Pan Head Screws
(8) 12-24 Cage Nuts
(8) 12-24 Square Nuts
Installation Instructions (4 Post)
Step 1. Mounting Depth: Measure the “Mounting-Depth” for your rack from the front of
the “Front-Mounting-Surface” to the back of the “Back-Mounting-Surface”.
For 4Post racks go to Page 3.
For 2Post Flush racks go to Page 4.
4Post Cabinet Double 2Post
FRONT
REAR
MOUNTING DEPTH
FRONT
REAR
MOUNTING DEPTH

Installation Instructions (4Post)
Page 3
Step 3. Attach Cable Management: Cable Management can be mounted on either side of
shelf. Attach the cable management bracket using (2) 8-32 screws and (2) 8-32
nuts. Using cotter pins and clevis pins, attach in desired configuration.
Proceed to Final Assembly on page 4.
Cotter Pin
Clevis Pins
Clevis Pin
Step 2. Adjust Depth: Adjust the rear brackets to fit your rack mounting depth and attach
to slide rails using (4) 8-32 screws and (4) 8-32 nuts.
Note: You must extend the slide rails to install the nuts.
Rear Brackets
Mounting Depth
Cable
Management
Arms
Cable
Management
Bracket

Warranty Statement
Innovation First, Inc. warrants our products against defects in material and workmanship for a
period of one (1) year from the date of purchase. Innovation First, Inc. liability shall be limited to
repairing or replacing, at our option, any defective product.
Installation Instructions (2 Post Flush)
Step 1. Set Up for 2Post Flush: Rotate rear brackets 90° and mount and attach cable
management as shown below (see Cable Management step 3) to mount in 2post
flush configuration.
Proceed to Final Assembly below.
Rear Brackets
Final Assembly
Hitch Pin
+RRN
DQG
/RRS
169 170 288
