PS/2 DB-15 Cat5 KVM User Manual
CV-401 / CV-801 / CV-1601

Installation
C
e
b
yr
V
e
iw
C
e
b
yr
V
ei w
■Install each bracket using screws pro-
vided shown in Figure 1.
■Fix the KVM into the rack
* Hardware for fixing the mounting bracket
to the rack is not provided
Figure 1. Installing the bracket to the KVM.
Figure 2. Fixing the KVM into the rack.
AB
screw A: M3.2 x 4.5 mm
screw B: M4 x 10 mm
CV-401 / CV-801 / CV-1601 PS/2 DB-15 KVM

CV-401 / CV-801 / CV-1601 PS/2 DB-15 KVM
Package Content (only for rackmount KVM)
KVM switch x 1 pc
Screw M3.2 x 4.5mm x 4 pcs
Screw M4 x 10mm x 8 pcs
Bracket x 1 set
User manual x 1 pc
Power cord x 1 pc
5
4
2
6
1
3
User
Manual
1
6
5
4
32

CV-401
CV-801
Local Console
Cascade
Connection
CV-1601
CV-401 / CV-801 / CV-1601 PS/2 DB-15 KVM
CD-6
KVM cable
CD-6
KVM cable
Connection
Rackmount KVM
Connection
KVM modules
back

Cascade
■With the CV-401 cascade up to 116 servers. With the CV-801 cascade up to 120 servers. With the
CV-1601 cascade up to 128 servers.
■Cascading multiple KVM by CA-6 cable
Local Console
Bank 1
CA-6 cascade cable
Cascade
Bank 2
Bank 1
Bank 8
Bank 2
Bank 8
CV-401 / CV-801 / CV-1601 PS/2 DB-15 KVM
Cascade
KB MS VGA
back
Cascade
Rackmount KVM
Cascade
KVM modules
CA-6 cascade cable
KB MS VGA

KVM Membranes
Power ON
■Turn off all servers and KVM switches
■Make sure all cables / connectors are properly connected
■Recommend Power ON sequence is monitor, KVM switch finally computer
4 ports (only for CV-401)
16 ports
Bank
No.
Online Channel
Channel Select Button Shift
Button
Online Channel Green LED on indicating a PC is connecting to the port
Selected Channel RED LED on indicating a selected channel
Bank Button Select the bank from1 to 8
Channel Select Button Press to select channel from 1 to 8
Shift Button Press & hold follow with a channel button to select channel from 9
to 16
Bank No. 7-Segment BANK LED indication
Front Panel - Port LED Indications
8 ports
Bank Button
Selected Channel

Password
Password for CV-401 / CV-801 / CV-1601
The password is enabled by default, the default password is “00000000” eight zeros (Do not use “0” on
number pad)
■Set your own user name & password
1. Call KVM OSD menu by pressing the KVM hotkey Scroll Lock + Scroll Lock + Space Bar
2. Select “CHANGE PASSWORD”
3. Enter “00000000” eight zeros in password field
(Do not use “0” on number pad)
4. Set your own password in “ENTER NEW PASSWORD” field
5. Retype your own new password in “RETYPE NEW PASSWORD” field
Remark: a. Blank has underscore. SPACE does not have underscore.
b. Press any alphanumeric key to move to next input item.
■Change your password
1. Call KVM OSD menu by pressing the KVM hotkey Scroll Lock + Scroll Lock + Space Bar
2. Select “CHANGE PASSWORD”
3. Enter your own password
4. Change your password in “ENTER NEW PASSWORD” field
5. Retype your new password in “RETYPE NEW PASSWORD” field
Remark: a. Blank has underscore. SPACE does not have underscore.
b. Press any alphanumeric key to move to next input item.
■Forget your password
Please contact your supplier for further support
Remark:
■You must press the KVM hotkey within 2 seconds
■A beep sound will be heard for successful entering KVM hotkey

KVM OSD
OSD Menu for CV-401 / CV-801 / CV-1601
OSD operation
next to the system name The PC is powered on
next to the system name The PC is selected
OSD OSD menu on screen time
SCAN
Scan interval from one PC port to next PC when
applying auto scan
CHANGE PASSWORD Change to a new password
Console ON/OFF
ON - quit the OSD menu without password
OFF - password is requested while quitting the
OSD menu
ESC QUIT
TAB NEXT
Select port for destination PC name and press
“Enter” to select
PgUp / PgDn To switch previous or next bank
ENTER Complete
INSERT Edit

KVM Hotkey
Hotkey Function
Scroll Lock + Scroll Lock + Space Bar Calling OSD menu
Scroll Lock + Scroll Lock + Switch to previous port
Scroll Lock + Scroll Lock + Switch to next port
Scroll Lock + Scroll Lock + PgUp Switch to previous bank
Scroll Lock + Scroll Lock + Bank no. + Port no. Switch to specific port
Scroll Lock + Scroll Lock + PgDn Switch to next bank
Scroll Lock + Scroll Lock + SAuto scan for powered on PC
Scroll Lock + Scroll Lock + RReset to factory default setting
Scroll Lock + Scroll Lock + BEnable / Disable beeper sound
Scroll Lock + Scroll Lock + FFind port by name
Hotkey for CV-401 / CV-801 / CV-1601
Remarks:
Example of “Scroll Lock + Scroll Lock + Bank no. + Port no.”
■Bank No. : 1 to 8
■Port No. : 01 to 16
■e.g. Bank 1 Port 4 : Scroll Lock + Scroll Lock + 1+ 0+ 4
■e.g. Bank 2 Port 16 : Scroll Lock + Scroll Lock + 2+ 1+ 6

Optional Accessories
1. PS/2 3-in-1 KVM cable
1.1 CD-6 6 feet
1.2 CD-10 10 feet
1.3 CD-15 15 feet
1.4 CD-33 33 feet
2. USB 2-in-1 KVM cable
2.1 CB-6 6 feet
2.2 CB-10 10 feet
2.3 CB-15 15 feet
3. PS/2 KVM cascade cable
3.1 CA-2 2 feet
3.2 CA-6 6 feet
3.3 CA-10 10 feet
3.4 CA-15 15 feet
4. USB KVM cascade cable
4.1 CBC-6 6 feet
5. SUN / iMAC USB to PS/2 adapter
5.1 SUN-31 kit
5. Power cord
5.1 IEC power cord
5.2 NEMA 5-15 power cord (US)
5.3 BS 1363 power cord (UK)
5.4 CEE 7/4 power cord (German)
5.5 AS 3112 power cord (Australia)

DC Power 12V, 24V, 48V Input
V84V42V21ledoM
Input rating
tloV-84tloV-42tloV-21:egatlovtupnI
V57~63V63~81V81~9:egnartupnI
Input current
Am05Am05Am05daoloN-
Am0221Am0542Am0594daollluF-
Output rating
tloV-21tloV-21tloV-21:egatlovtuptuO
A61.4A61.4A61.4:tnerructuptuO
Ef?ciency 84% 85% 85%
Remarks:
■Package does not include power cord

CV-401 / CV-801 / CV-1601
▀KVM Port
Number of ports: 4 or 8 or 16
Connector: HDDB 15-pin
Connectivity: CD-6 / 10 / 15 / 33 6' / 10' / 15' / 33' 3-in-1 PS/2 KVM cable
▀Console
Graphic connector: HDDB15-pin VGA
Resolution: Up to 1920 x 1440
Bandwidth 200MHz
Input device: PS/2 mini-din 6-pin mouse, PS/2 mini-din 6-pin keyboard
▀On Screen Display
Port name: Up to 10 characters long
Port select: Front membrane button, Hotkey & On screen menu
Security: Support eight character password
Auto scan: 5~99 seconds
▀Expansion: Up to 128 servers by 8-level cascade
▀Compatibility
Multi-platform: Mix PCs, SUNs, IBMs, HPs, DELLs Server
Support: Windows Vista / 2003 / XP / 2000, Linux, Netware, Unix, DOS
▀Power
retpadaCAaivzH06ro05taCAV042ro001:tupnI
Option DC: 12V / 24V / 48V DC input
▀Regulatory Approval: FCC, CE
▀Environmental
Operating: 0 to 50°C
Storage: -5 to 60°C
Relative humidity: 90%, non-condensing
Shock: 50G peak acceleration (11ms, half-sine wave)
Vibration: 58~100Hz / 0.98G (11ms / cycle)
▀Product Information
Dimension (W x D x H): CV-401 : 443 x 200 x 44 mm / 17.4 x 7.9 x 1.73 inch
CV-801 / CV-1601 : 443 x 180 x 44 mm / 17.4 x 7.1 x 1.73 inch
Net weight: CV-401 / CV-801 : 3.5 kg / 8 lb
CV-1601 : 4 kg / 9 lb
▀Packing Information
Dimension (W x D x H): 510 x 400 x 77 mm / 20.1 x 15.7 x 3 inch
Gross weight: CV-401 : 4 kg / 9 lb
CV-801 / CV-1601 : 4.5 kg / 10 lb
Speci?cation

General
1. How do the KVM switches allow the user to switch ports?
There are two ways to switch ports. One is the membrane buttons on the front and the other way is
with Hot-key commands.
2. What operating systems do the KVMs support?
The KVMs support multi-platform support allows you to control Windows-based computers, Sun So-
laris systems, Linux, or even Macs by a single KVM switch. The KVM switches support multi-platform
operating systems including but not limited to DOS, Windows 95/98/ME/NT/2000/XP, Linux, Solaris
and Mac OS.
3. Do I have to power down the KVMs to add a new server ?
The KVMs are hot-pluggable and allows servers or devices to be added or removed without power-
ing down the switch, but components of connected devices, such as the servers, may not be hot-
pluggable. We suggest that turn off power to all devices before connecting them.
4. Why I can’t login with default password on KVM switch
The default username and password for the KVM switch is eight zeros - “00000000”. Please check
i. The “Num lock” is not turned on. (for notebook type keyboard)
ii. The numeric (number) keys on the number pad are not accepted by KVM, only the main
number keys.
5. Can I disable the KVM password ?
Yes, for Cat5 KVM, USB KVM, two console PS/2 KVM & IP PS/2 KVM, user can disable/ enable the
KVM password by hotkey.
No, for PS/2 KVM, user can’t disable the KVM password.
6. What do I do if I forget the password?
If the user change the default password and lose the password, pls contact the supplier for further
support.
7. How many levels of KVM cascade are supported?
8 levels are supported.
8. Can I cascade the different types KVM switches together ?
No, only same type KVM can cascade together. (e.g. PS/2 to PS/2, USB to USB,..)
9. Why am I getting ghosting images or shadowing?
i. Check that all video cables are inserted properly.
ii. Check whether the KVM supports the resolution and refresh-rate on your servers.
iii. Check whether the graphics card you are using supports the resolution and refreshrate on
your server or not.
iv. Connect the monitor directly into the servers you are having trouble with to see if problem
still appears.
FAQ

10. The server VGA resolution does not match the resolution of monitor ?
The KVM supports DDC function which will dynamically detect and the DDC data.
The problem may come from the power on sequence.
- For KVM switch
The recommended power on sequence is - monitor, KVM switch and then servers.
- For remote console box
It supports DDC function but does not support hot-plug, the recommend power on se
quence is – monitor, remote console box and then servers.
PS/2 KVM
Can I connect to Suns (USB type) and/or Macs system to PS/2 KVM switches ?
Yes. Use PS/2 to USB converter (SUN-31 kit) to converter the keyboard & mouse of PS/2 KVM ca-
ble (CD-6) to USB interface. The SUN-31 kit includes the built-in mapping of all the Suns & Macs
system hotkey.
FAQ Chapter 10

1. There is no LED display on KVM membrane switch
i. Make sure the power adapter plugged into the KVM Switch, if the LED’s still off, perform soft
reset to KVM switch.
ii. Power cycle KVM switch.
2. I can power on the KVM, but I am not getting any picture at all, how can I solve this?
Switching to another port and checking if this port has the same problem
a. If you switch to another port, please check the screen resolution is the same.
b. Check the OSD menu is available on the hot keys “Scroll lock + Scroll lock + space bar”.
If the problems persist, please make sure the cables are inserted properly and the boot up
sequence is followed.
3. The screen is on but the keyboard and mouse don’t work
i. Check the server by using a different keyboard and mouse.
ii. For PS/2 servers
The keyboard and mouse are not hot pluggable.
iii. For USB servers
Unplug and plug allowing a few seconds for the bus emulation process to complete.
iv Do not press any keys on the keyboard whilst the server is booting up. This can cause a
keyboard error or cause the keyboard not to detect the KVM switch.
v. Try a different keyboard, but use only 101/102/104-key keyboard
vi. Avoid moving the mouse whilst switching the KVM ports.
4. There is no LED display on the Cat5 dongle
The LED on the Cat5 dongle will flash when plugged into the USB or USB server. The light will then
become steady when the KVM switch has connected. If the LED light is on and not flashing when
plugged into server, please unplug the USB or PS/2 and try again. Or try another good Cat5 dongle
to verify if problem still appears. If the problem persists, please contact your supplier.
Troubleshooting
