Radio Bridge RBS306-HW5800-US User manual

Honeywell 5800 to LoRaWAN Bridge
User Guide
VERSION 1.1
FEBRUARY 2020

HONEYWELL 5800 TO LORAWAN BRIDGE
COPYRIGHT ©2019, RADIO BRIDGE INC.HONEYWELL 5800 TO LORAWAN BRIDGE PAGE 1OF 8
TABLE OF CONTENTS
1. QUICK START....................................................................................................................... 2
2. OVERVIEW .......................................................................................................................... 2
2.1. Sensor Overview ........................................................................................................................2
2.2. Revision History .........................................................................................................................3
2.3. Document Conventions ..............................................................................................................3
2.4. Part Numbers.............................................................................................................................3
3. TECHNICAL SPECIFICATIONS................................................................................................ 3
3.1. Absolute Maximum Ratings........................................................................................................3
4. TEST MESSAGES .................................................................................................................. 4
5. MESSAGE PROTOCOL .......................................................................................................... 4
5.1. Common Messages.....................................................................................................................4
5.2. Uplink Messages ........................................................................................................................5
5.3. Downlink Messages....................................................................................................................5
6. MECHANICAL DRAWINGS.................................................................................................... 6
6.1. ARMORED OUTDOOR/INDUSTRIAL RBSX06 SENSORS ....................................................... 6
7. REGULATORY AND COMPLIANCE......................................................................................... 7
7.1. Federal Communications Commission (FCC) ................................................................................7
7.2. Harmonized Commodity Description (HS Code)...........................................................................7
7.3. Export Control Classification Number (ECCN)...............................................................................7
8. CUSTOMER SUPPORT .......................................................................................................... 8
9. DISCLAIMERS....................................................................................................................... 8
10. LEGAL NOTICES ................................................................................................................ 8
11. TRADEMARKS AND COPYRIGHT ........................................................................................ 8

HONEYWELL 5800 TO LORAWAN BRIDGE
COPYRIGHT ©2019, RADIO BRIDGE INC.HONEYWELL 5800 TO LORAWAN BRIDGE PAGE 2OF 8
1. QUICK START
To start using your sensor, simply go to:
https://console.radiobridge.com
From here you can register your device and immediately start receiving messages.
The sensor configuration, message monitoring, and setting up alerts is usually self-explanatory
through the user interface. For further explanations of any sensor features, you may refer to this
user guide
2. OVERVIEW
2.1. Sensor Overview
The wireless sensors designed and manufactured by Radio Bridge provide full sensor to cloud
solutions for Internet of Things (IoT) applications. The Honeywell 5800 to LoRaWAN Bridge
translates wireless Honeywell sensor data to LoRaWAN payloads that can be interpreted by
the end application. This bridge product uses the proprietary Radio Bridge RBM101-HW5800
module to decode the wireless Honeywell sensor data. More information about the RBM101-
HW5800 radio module can be found on the Radio Bridge website.
Features include:
•Built-in radio that talks directly with LoRaWAN wireless networks
•Enclosure tamper detection that will send an alert if the packaging of the sensor itself is
opened or broken.
•Over the air sensor configuration in the field
•Automatic low battery reporting and supervisory messages

HONEYWELL 5800 TO LORAWAN BRIDGE
COPYRIGHT ©2019, RADIO BRIDGE INC.HONEYWELL 5800 TO LORAWAN BRIDGE PAGE 3OF 8
2.2. Revision History
Table 1 Revision History
Revision
Date
Description
1.0
December 2019
Initial release of the document
1.1
February 2020
Updated downlinks section
2.3. Document Conventions
Table 2 Document Conventions
Font / Icon
Meaning
Important notes
Warnings and cautions
2.4. Part Numbers
Table 3 Part Numbers
Part Number
Rating
Wireless
Region
RBS306-HW5800-US
Outdoor/Industrial
LoRaWAN
North America
3. TECHNICAL SPECIFICATIONS
3.1. Absolute Maximum Ratings
Table 4 Absolute Maximum Ratings
Parameter
Rating
Units
Operating ambient temperature
-40 to +70
°C
Storage ambient temperature
-40 to +100
°C

HONEYWELL 5800 TO LORAWAN BRIDGE
COPYRIGHT ©2019, RADIO BRIDGE INC.HONEYWELL 5800 TO LORAWAN BRIDGE PAGE 4OF 8
4. TEST MESSAGES
The device can be triggered to send test messages by placing a magnet next to the side of the
enclosure. The location of the magnet is indicated by the triangular notch on the side of RBSx01
and RBSx05 sensors. RBSx04 sensors do not have this capability. There is a small magnetic Hall
effect sensor that will detect the presence of a magnet and send a message. This can be used for
diagnostic purposes to ensure the sensor is within range and connected to the network.
5. MESSAGE PROTOCOL
This section defines the protocol and message definitions for the device.
If the standard Radio Bridge console (console.radiobridge.com) is not used, refer to this section
to decode the device data and configure the device through downlink messages.
Radio Bridge provides a web-based console at console.radiobridge.com
to configure and monitor devices. Usage of this console is highly
recommended for most customers rather than implementing the
protocols defined in this section.
5.1. Common Messages
There are common messages across all wireless devices that are defined in the document
“Common Sensor Messages” which is available on the Radio Bridge website.
Common messages include basic error messages, tamper, supervisory, and downlink ack. It is
important to refer to that document prior to decoding the messages defined in this section.
Refer to the document “Common Sensor Messages” for definitions of all
common messages. Common messages are not defined in this document.

HONEYWELL 5800 TO LORAWAN BRIDGE
COPYRIGHT ©2019, RADIO BRIDGE INC.HONEYWELL 5800 TO LORAWAN BRIDGE PAGE 5OF 8
5.2. Uplink Messages
The uplink message (sensor to web application) specific to the bridge is defined in following
table. The common uplink messages are not included in this section (see common messages
document).
Table 5 Uplink Message 0x17: Honeywell Sensor Event
Bytes
Description
0-2
Honeywell Sensor ID (usually located on a sticker on the sensor)
3
Event identifier
4-5
Event payload
The events in byte 3 are defined in the following table.
Table 6 Honeywell Sensor Events
Event Identifier
Description
0x00
Status code
0x01
Error code
0x02
Sensor data payload
The Event Payload definitions for status codes, error codes, and sensor data payload are
described in the document “Honeywell 5800 BridgeBee User Guide” located on the Radio
Bridge website.
5.3. Downlink Messages
The only downlink messages available for the HW5800 bridge are defined in the common
messages document, and are not included in this section.

HONEYWELL 5800 TO LORAWAN BRIDGE
COPYRIGHT ©2019, RADIO BRIDGE INC.HONEYWELL 5800 TO LORAWAN BRIDGE PAGE 6OF 8
6. MECHANICAL DRAWINGS
The mechanical drawings provided in this section are for the main body of the sensor. All
dimensions are inches unless otherwise noted.
6.1. ARMORED OUTDOOR/INDUSTRIAL RBSX06 SENSORS

HONEYWELL 5800 TO LORAWAN BRIDGE
COPYRIGHT ©2019, RADIO BRIDGE INC.HONEYWELL 5800 TO LORAWAN BRIDGE PAGE 7OF 8
7. REGULATORY AND COMPLIANCE
7.1. Federal Communications Commission (FCC)
Per FCC 15.19(a)(3) and (a)(4) This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Per FCC 15.21, Changes or modifications not expressly approved by Radio Bridge could void
authority to operate the devices.
Sigfox RBS101, RBS104, and RBS105 sensors FCC ID: 2APNUSFM10R2
LoRaWAN RBS301, RBS304, and RBS305 sensors FCC ID: 2APNUCMABZ
LoRaWAN RBS306 sensors: This device contains FCC IAU792U13A16858
This device contains equipment certified under IC: 125A-0055
7.2. Harmonized Commodity Description (HS Code)
The Harmonized Commodity Description and Coding System generally referred to as
“Harmonized System” or simply “HS” is a multipurpose international product nomenclature
developed by the World Customs Organization (WCO).
HS Code: 8531.90.9001
7.3. Export Control Classification Number (ECCN)
ECCNs are five character alpha-numeric designations used on the Commerce Control List (CCL)
to identify dual-use items for export control purposes. An ECCN categorizes items based on the
nature of the product, i.e. type of commodity, software, or technology and its respective
technical parameters.
ECCN: 5a992.c

HONEYWELL 5800 TO LORAWAN BRIDGE
COPYRIGHT ©2019, RADIO BRIDGE INC.HONEYWELL 5800 TO LORAWAN BRIDGE PAGE 8OF 8
8. CUSTOMER SUPPORT
Radio Bridge offers free technical support at:
https://support.radiobridge.com
Radio Bridge also offers technical support plans and service packages to help our customers get
the most out of their Radio Bridge products.
9. DISCLAIMERS
Information in this document is subject to change without notice and does not represent a
commitment on the part of Radio Bridge. Radio Bridge provides this document “as is,” without
warranty of any kind, expressed or implied, including, but not limited to, the implied warranties
of fitness or merchantability for a particular purpose. Radio Bridge may make improvements
and/or changes in this manual or in the product(s) and/or the software described in this manual
at any time.
10. LEGAL NOTICES
See the Legal Notices section of the website for up to date information on Radio Bridge’s
warranty, returns policy, privacy statement, terms of sale, and terms of service.
11. TRADEMARKS AND COPYRIGHT
Radio Bridge™, SubGig®, Armored Sensor™ and BridgeBee® are trademarks of Radio Bridge Inc in
the United States.
© 2019 Radio Bridge Inc. All rights reserved
