Radio Shack TRC-509 User manual

Cat. No. 21-409
OWNER’S MANUAL
Please read before using this equipment
TRC-509
FM Walkie-Talkie
21-409.fm Page 1 Thursday, August 5, 1999 3:31 PM

2
FEATURES
Your RadioShack TRC-509 FM Walkie-Talkie is a
compact, portable 2-wayFMradio. Youcancommu-
nicate with another TRC-509 or any FM transceiver
operating on the same frequency (49.830 MHz).
Use your walkie-talkie to add to your fun when you
are at sporting events, on camping trips, biking, or
hiking with your friends.
The walkie-talkie is also practical for use on the job.
Use it when taking inventory in a warehouse, keep-
ing track of your staff in a large building, or talking to
your crew on a construction site. The uses for your
walkie-talkie are practically unlimited.
Your walkie-talkie’s special features include:
Up to 1/4-Mile Transmission — provides clean,
noise-free reception through its double-conversion
superheterodyne circuit.
Lightweight — weighs only five ounces, so it’s easy
to carry.
©1996, 1998 Tandy Corporation.
All Rights Reserved.
RadioShack is a registered trademark used by Tandy Corporation.
21-409.fm Page 2 Thursday, August 5, 1999 3:31 PM

3
Belt Clip — lets you clip the walkie-talkie to your
belt or pocket so you can keep your hands free.
Antenna — provides clear reception.
Note: To power your TRC-509, you need one 9 volt
alkaline battery (not supplied).
21-409.fm Page 3 Thursday, August 5, 1999 3:31 PM

4
PREPARATION
INSTALLING/REPLACING THE
BATTERY
Your walkie-talkie uses one 9 volt battery (not sup-
plied) for power. For the longest life and best perfor-
mance, we recommend you use an alkaline battery
such as RadioShack Cat. No. 23-553.
Caution: Use only a fresh battery of the required
size and recommended type.
Follow these steps to install a battery.
1. Slide the battery compartment cover in the
direction of the arrow to remove it.
2. Snap the battery onto the battery connector
inside the compartment. The connector only
fits on the battery one way.
Fig. 1
21-409.fm Page 4 Thursday, August 5, 1999 3:31 PM

5
3. Replace the cover.
When the BATTERY LOW indicator lights, replace
the battery.
Cautions:
• Always remove an old or weak battery. Batter-
ies can leak chemicals that can destroy elec-
tronic parts.
• Dispose of old batteries promptly and properly.
Do not bury or burn them.
21-409.fm Page 5 Thursday, August 5, 1999 3:31 PM

6
INSTALLING THE BELT CLIP
Your walkie-talkie comes with a belt clip. To install it,
slide the clip into the slot on the back of the trans-
ceiver until it locks into place.
To remove the belt clip, lift up on the locking tab and
slide the clip out.
Fig. 2 Slot Belt Clip Locking
21-409.fm Page 6 Thursday, August 5, 1999 3:31 PM

7
OPERATION
USING THE WALKIE-TALKIE
1. Pull out and fully extend the antenna for maxi-
mum range.
2. Turn on the walkie-talkie by rotating OFF/VOL
up until you hear a click.
3. To transmit, press PUSH-TO-TALK and speak
into the microphone (MIC). Or, press CALL to
transmit a tone signal, which alerts the other
person to your call.
Fig. 3
Fig. 4
21-409.fm Page 7 Thursday, August 5, 1999 3:31 PM

8
4. When you finish talking, release PUSH-TO-
TALK.
5. Adjust OFF/VOL for the most comfortable lis-
tening level.
6. To turn off the walkie-talkie, rotate OFF/VOL
down until you hear a click.
Fig. 5
21-409.fm Page 8 Thursday, August 5, 1999 3:31 PM

9
CARE AND MAINTENANCE
Your RadioShack TRC-509 FM Walkie-Talkie is an
example of superior design and craftsmanship. The
following suggestions will help you care for your
walkie-talkie so you can enjoy it for years.
Keep the walkie-talkie dry. If it gets
wet, wipe it dry immediately. Liquids
might contain minerals that can cor-
rode the electronic circuits.
Use and store the walkie-talkie only in
normal temperature environments.
Temperature extremes can shorten
the life of electronic devices, damage
batteries, and distort or melt plastic
parts.
Keep the walkie-talkie away from dust
and dirt, which can cause premature
wear of parts.
Handle the walkie-talkie gently and
carefully. Dropping it can damage cir-
cuit boards and cases and can cause
the walkie-talkie to work improperly.
21-409.fm Page 9 Thursday, August 5, 1999 3:31 PM

10
Use onlya fresh batteryoftherequired
size andrecommended type. Batteries
can leak chemicals that damage your
walkie-talkie’s electronic parts.
Wipe the walkie-talkie with a damp
cloth occasionally to keep it looking
new. Do not use harsh chemicals,
cleaning solvents, or strong deter-
gents to clean the walkie-talkie.
Modifying or tampering with the walkie-talkie’s inter-
nal components can cause a malfunction and might
invalidate your walkie-talkie’s warranty and void
your FCC authorization to operate it. If your walkie-
talkie is not performing as it should, take it to your lo-
cal RadioShack store for assistance.
