RadiSys EPC-2102 P5000HX2 Series User manual

SERVICE MANUAL
© 2001 RadiSys Corporation
All Rights Reserved
Printed in USA
EPC®-2102
P5000HX2(-M) Series SBC
P/N 007-01247-0000 July 2001
StockCheck.com

ECP-2102 Single-Board Computer
ii Service Manual
Limited Warranty
A. RadiSys Corporation warrants that the item sold by it hereunder will be free from defects
in materials or workmanship, under normal use and service, for a period of 2 years from
date of shipment. Said item will meet the specifications in effect at the time of
manufacture. The sole obligation of RadiSys under this warranty shall be, at its option, to
repair or replace, without charge, any defective component of said item, within a
reasonable period of time.
B. RadiSys Corporation shall not be liable under this warranty for (i) the item that the Buyer
alleges to be defective and was repaired or altered by someone other than an authorized
representative of RadiSys, unless such repair or alteration was effected pursuant to prior
written approval of RadiSys, or (ii) where the Buyer fails to notify RadiSys of any alleged
defect within the period of warranty, or (iii) where the Buyer fails to return the allegedly
defective item to RadiSys Corporation, in Houston, Texas, USA, freight prepaid, or (iv)
where the item was altered or damaged in a way which RadiSys reasonably determines to
affect the performance and reliability of the item, or (v) where the item was subject to
misuse, neglect, or accident. The rights and remedies granted to the Buyer under this
paragraph constitute the Buyer's sole and exclusive remedy against RadiSys Corporation,
its officers, agents, and employees, for negligence, inexcusable delay, breach of warranty,
express or implied, or any other default relating to the item or the duties of RadiSys to
eliminate any errors.
This warranty supersedes any other warranty, whether expressed, implied, or statutory,
including but not limited to any warranty for fitness of purpose, merchantability, or freedom
from infringement or the like, and any warranty otherwise arising out of any proposal,
specifications, or sample. Furthermore, RadiSys Corporation neither assumes nor authorizes
any person to assume for it any other liability.
The software included with this equipment is warranted only in accordance with the terms of
its license agreement. Except as warranted in that license agreement, the manufacturer of the
software disclaims all warranties and conditions with regard to the software, including all
implied warranties and conditions of merchantability, fitness for a particular purpose, title, and
non-infringement.
Every effort has been made to ensure that the information provided in this manual is complete
and accurate. However, technical inaccuracies or typographical errors may be inadvertently
included. RadiSys assumes no responsibility for any errors that may be contained in this
document. RadiSys makes no promise to update or keep current the information contained in
this document. Information in this document, including product specifications, is subject to
change without notice.
All tradenames referenced are the service mark, trademark, or registered trademark of the
respective manufacturer.
StockCheck.com

Service Manual iii
Important
Always use caution when handling or operating the equipment. Only qualified and trained
electronics service personnel should access the equipment. Use extreme caution when
installing or removing components. For additional information, please contact RadiSys
Technical Support at 800–627–8700 or 713–541–8200 Monday through Friday between
8:00 a.m. and 5:00 p.m., Central Time, continental USA.
Wichtig
Arbeiten am System bzw. Betrieb des Systems, sollten immer mit der nötigen Vorsicht
vorgenommen werden. Nur qualifiziertes und ausgebildetes Fachpersonal sollte am Inneren
des Gerätes arbeiten. Beim Installieren und Entfernen von Komponenten ist besondere
Vorsicht geboten.
Für weitere Informationen wenden Sie sich bitte an den Technical Support von RadiSys:
•USA: 800–627–8700 oder 713–541–8200 Montags bis Freitags von
0800 Uhr bis 1700 Uhr, Central USA.
•International: [phone] Montags bis Freitags von 0830 Uhr bis 1700 Uhr.
(CET GMT +1.00)
Changes or modifications not expressly approved by RadiSys Corporation could void the
product warranty and the user’s authority to operate the equipment.
StockCheck.com

ECP-2102 Single-Board Computer
iv Service Manual
Notice
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment.
This equipment generates, uses, and can emit radio frequency energy and, if not installed and
used in accordance with this instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case, the user will be required to correct the interference at the user’s
expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
conditions:
•This device may not cause harmful interference
•This device must accept any interference received, including interference that may cause
undesired operation
Any change or modification not expressly approved by the manufacturer is prohibited and
could void the user’s authority to operate the equipment.
This product also meets requirements for compliance with EN55022, Class B ITE.
StockCheck.com

Service Manual v
Symbols
Notice:
This symbol indicates an item for special consideration.
Warning:
This symbol indicates the presence of a potential hazard that can
cause personal injury or damage to the equipment. Only qualified and
trained electronics service personnel should access the equipment.
StockCheck.com

ECP-2102 Single-Board Computer
vi Service Manual
Customer Support
Accessing the Web Site
In-depth printable service manuals and other documentation are available for download from
the RadiSys Web site:
http://www.radisys.com
Then click on Support to access a link to the documentation, drivers, and BIOS.
Documentation is available at this Web site in Adobe® Acrobat® .PDF format, and may be
viewed and printed using the free Acrobat®Reader™software. BIOS files are available as self-
extracting disk image files. Links are provided to various partners’ web sites where any files
and tools needed to install drivers are available for download.
Calling Technical Support
1. Have the RadiSys product model and serial number available.
2. Call Technical Support:
•In the continental USA, Monday – Friday, 8:00 a.m. – 5:00 p.m., Central Time, dial
800–627–8700.
•Outside the USA, dial 713–541–8200 (add long distance/international access codes).
•In Europe, Monday – Friday, 8:30 a.m. – 5:00 p.m., dial [phone].
Inspection of Contents / Packaging of Product
The packaging for this product has been tested to assure that it will withstand responsible
handling by the carrier.
Caution: Inspect contents immediately and file a claim with the delivering carrier for any
damage. Save the shipping box and packaging material to use for any further shipment of this
equipment.
However, if the packaging is damaged and is not suitable for shipment, call RadiSys Technical
Support to obtain new packaging. The warranty may be void if the product is returned using
unapproved or damaged original packaging.
Returning Your Product
A Returned Material Authorization (RMA) number must be written on the outside of the
shipping carton of all equipment returned to RadiSys for service and/or repair. It is
recommended that any correspondence included with the carton contents also refer to the
RMA number.
Note: The factory will refuse the shipment if it is sent freight collect or if it does not display
an RMA number.
StockCheck.com

Service Manual vii
Table of Contents
Chapter 1 Introduction 1
EPC-2102 (P5000HX2(-M)) Series .......................................................................................2
Chapter 2 7 Steps to Operation 5
Handling the EPC-2102..........................................................................................................6
Step 1: Check Jumper Settings ...............................................................................................8
Step 2: Check Switch Settings..............................................................................................10
Step 3: Install the SBC .........................................................................................................12
Step 4: Attach Peripherals to Headers ..................................................................................14
Step 5: Attach Peripherals to Connectors.............................................................................16
Step 6: Power-On the System...............................................................................................18
Step 7: Run the Setup Utility................................................................................................19
Chapter 3 Technical Data 25
Specifications .......................................................................................................................26
Pin Signals ............................................................................................................................28
Installing Memory ................................................................................................................32
StockCheck.com

EPC-2102 Single-Board Computer
viii Service Manual
List of Figures
Figure 1. EPC-2102 Components and Layout ................................................................... 3
Figure 2. Safely Handling the SBC ................................................................................... 7
Figure 3. Jumper Block Locations ..................................................................................... 9
Figure 4. Switch Block Location ..................................................................................... 11
Figure 5. Installing the SBC ............................................................................................ 13
Figure 6. Peripheral Header Locations ............................................................................ 15
Figure 7. Peripheral Connector Locations ....................................................................... 17
Figure 8. Setup Utility Main Menu.................................................................................. 20
Figure 9. The EPC-2102 Series SBC............................................................................... 26
Figure 10. Serial and Parallel Headers and Connectors..................................................... 29
Figure 11. Peripheral Headers ........................................................................................... 31
Figure 12. Memory Combinations..................................................................................... 32
StockCheck.com

Service Manual ix
List of Tables
Table 1. Jumper Block Settings ........................................................................................... 8
Table 2. Jumper Functions................................................................................................... 9
Table 3. Switch Settings .................................................................................................... 10
Table 4. Installing the SBC................................................................................................ 12
Table 5. Basic Options....................................................................................................... 21
Table 6. Advanced Options................................................................................................ 22
Table 7. PCI Options.......................................................................................................... 23
Table 8. Environmental Tolerances ................................................................................... 26
Table 9. System Specifications .......................................................................................... 27
Table 10. Serial and Parallel Port Pin Signals ..................................................................... 28
Table 11. Peripheral Header Pin Signals ............................................................................. 30
Table 12. Memory Combinations ........................................................................................ 33
StockCheck.com

EPC-2102 Single-Board Computer
xService Manual
Notes
StockCheck.com

Service Manual 1
Introduction Chapter 1
This chapter discusses the primary features of the EPC-2102 Single-Board
Computer.
If you are familiar with the primary components and functions of the EPC-2102,
and you wish to quickly begin operating the SBC, go to Chapter 2, “7 Steps to
Operation,” page 5. Then read this chapter later at your convenience.
1
StockCheck.com

EPC-2102 Single-Board Computer
2Service Manual
EPC-2102 (P5000HX2(-M)) Series
Overview
The RadiSys EPC-2102 single-board computer (SBC) provides the following features:
•Intel™Pentium®processor:
•100/133/166 MHz, 64-bit Classic Pentium (P54C) or
•166/200/233 MHz, 64-bit Pentium with MMX™(P55C)
•Intel 430HX PCIset
•82439HX System Controller (TXC, or North-Bridge)
•82371SB PCI I/O IDE Xcelerator (PIIX3, or South-Bridge)
•Intel 82091AA Advanced Integrated Peripheral (AIP)
•4 Mb (512 KB x 8) flash memory
•Level 2 write-back cache socket for 256 or 512 KB pipeline burst COAST SRAM
•Four SIMM sockets for up to 256 MB scaleable DRAM
Note: The EPC-2102 supports Parity/FPM or Non-Parity, ECC, or up to 128 MB EDO
•Two serial ports (one RS-232 only; one RS-232 or RS-422)
•Parallel port (AT-compatible/bi-directional/enhanced operations)
•Floppy drive controller
•PCI EIDE hard disk drive controller
•PCI Adaptec AIC-7880 UltraSCSI controller
For more information on the components of the EPC-2102, contact:
Company Telephone Website
Intel Corporation [phone] http://www.intel.com
Adaptec, Inc. [phone] http://www.adaptec.com
PCI Special Interest Group [phone] http://www.pcisig.com
PICMG [phone] http://www.picmg.com
StockCheck.com

Service Manual 3
Chapter 1: Introduction
Figure 1. EPC-2102 Components and Layout
A. Intel Pentium P54C/P55C Processor
B. Pentium Processor with Heatsink
C. Level 2 SRAM Cache Socket
D. DRAM SIMM Sockets
E. Intel 82439HX System Controller (TXC,
or North-Bridge)
F. Adaptec AIC-7880 UltraSCSI Controller
G. Speaker
H. Intel 82371SB PCI I/O IDE Accelerator (PIIX3,
or South-Bridge)
I. Flash Device
J. Auxiliary BIOS
K. Dallas DS12887 Real-Time Clock
L. Intel 82091AA Advanced Integrated Peripheral (AIP)
M. DIP Switch Block
1. SCSI Drive Header
2. IDE/SCSI Activity LED Header
3. EIDE Drive Header
4. Floppy Drive Header
5. Serial Port 2 Header
6. I/O Bracket
7. Serial Port 1 Connector
8. Parallel Port Connector
9. Auxiliary CPU Fan Header
10.Keyboard Header
11. USB Port 0 Header
12.USB Port 1 Header
13. PS/2 Mouse Header
$
'
&
%
(
)
+
.
/
,
-
*



    0
 



StockCheck.com

EPC-2102 Single-Board Computer
4Service Manual
Notes
StockCheck.com

Service Manual 5
7 Steps to Operation Chapter 2
This chapter describes basic precautions for handling the EPC-2102.
This chapter then outlines the basic steps for setting up the SBC:
1. Check jumper settings
2. Check switch settings
3. Install the SBC
4. Attach peripheral devices to headers
5. Attach peripheral devices to connectors
6. Power-on the system
7. Run the Setup Utility
2
StockCheck.com

EPC-2102 Single-Board Computer
6Service Manual
Handling the EPC-2102
Overview
This section suggests basic precautions when handling the EPC-2102 series SBC.
Static Electricity
The EPC-2102 is designed to protect against ESD (electro-static discharge) and excessive
voltage. However, excessive static electricity can damage components.
Before you handle the SBC, use the grounding wrist strap provided with the system to
discharge static electricity. Instructions for using the wrist strap are printed on the strap's
envelope.
Safety
It is important to protect yourself and your equipment before you perform any of the
procedures outlined in this manual.
You should check the configuration before you install the SBC. If the SBC is already installed
in your system and you need to change the configuration, power-off the system and disconnect
all power cords from their source. Follow all safety precautions as outlined by the chassis
manufacturer.
Next...
Before you install the SBC in a chassis, check the following:
•Jumper settings, outlined in Step 1, page 8
•DIP switch settings, outlined in Step 2, page 10
Pay particular attention to the switch settings. The jumper settings are preconfigured at the
factory and are appropriate for most applications.
Always handle the SBC by the edges to help prevent accidental damage that
can be caused by static discharge (Figure 2).
!
To avoid damage or injury, always power-off the system and disconnect all
power cords from their power source before handling the equipment.
To help prevent accidental damage that can be caused by static discharge,
always use a grounding wrist strap or other static-dissipating device when
accessing the interior of the chassis and handling the equipment.
!
Only qualified, experienced electronics personnel should access the interior
of the chassis and handle the equipment.
!
StockCheck.com

Service Manual 7
Chapter 2: 7 Steps to Operation
Figure 2. Safely Handling the SBC
Always handle the SBC by the edges.
To avoid damage or injury, always power-off the system and disconnect all
power cords from their power source before handling the equipment.
To help prevent accidental damage that can be caused by static discharge,
always use a grounding wrist strap or other static-dissipating device when
accessing the interior of the chassis and handling the equipment.
!
StockCheck.com

EPC-2102 Single-Board Computer
8Service Manual
Step 1: Check Jumper Settings
Overview
Before you install the EPC-2102 onto a passive backplane in a chassis, check the jumper
settings on the SBC (Figure 3).
Definition
A jumper is a small "bridge" that connects two pins on a jumper block. The position of a
jumper affects the device's operational parameters.
Jumper Blocks
The EPC-2102 contains:
•Four two-pin jumper blocks (JP6, JP8, JP9, and JP10)
•Five three-pin jumper blocks (JP2, JP3, JP4, JP5, and JP7)
Settings
Table 1. Jumper Block Settings
2-Pin Jumper Blocks
JP9 JP10 Host Bus Speed
None 1—2 66.6 MHz (default)
1—2 None 60.0 MHz
1—2 1—2 50.0 MHz
JP6 JP8 Bus/Core
Ratio†CPU Speed
None None 2/3 100 MHz
None 1—2 1/2 133 MHz
1—2 1—2 2/5 166 MHz
1—2 None 1/3 200 MHz
None None 2/7 233 MHz
The Bus Core Ratio is based on the Host Bus Speed at 66.6MHz.
3-Pin Jumper Blocks
JP2, JP3, JP5
Serial 2 Configuration
2—3 RS-232 (default)
1—2 RS-422
JP4
Watchdog Timer
2—3 Inactive (default)
1—2 Active
JP7
Next Step OS Configuration
2—3 Normal Operation (default)
1—2 Use this setting when running
Next Step OS and experiencing
problems with PS/2 mouse
StockCheck.com

Service Manual 9
Chapter 2: 7 Steps to Operation
Figure 3. Jumper Block Locations
Table 2. Jumper Functions
Jumpers Function
2-Pin JP6, JP8 CPU Speed
JP9, JP10 Host Bus Speed
3-Pin
JP2, JP3, JP5 Serial Port 2 Configuration
JP4 Watchdog Timer
JP7 Next Step OS Configuration
-3
-3
-3
-3
-3 -3
-3 -3
-3
To avoid damage or injury, always power-off the system and disconnect all
power cords from their power source before handling the equipment.
To help prevent accidental damage that can be caused by static discharge,
always use a grounding wrist strap or other static-dissipating device when
accessing the interior of the chassis and handling the equipment.
!
StockCheck.com

EPC-2102 Single-Board Computer
10 Service Manual
Step 2: Check Switch Settings
Overview
After you check the jumper settings, check the switch block on the EPC-2102 for proper
settings (Figure 4).
Switch Block
The switch block contains four DIP switches that you can configure to affect the following
items:
•Default monitor type
•On-board ROM access
•CMOS RAM
•Configuration ports
Settings
Table 3. Switch Settings
SW1-1
Default Monitor Type
Open Monochrome monitor
Closed (default) Color monitor
SW1-2
On-Board ROM Access
Open (default) Flash memory enabled;
auxiliary ROM mode disabled
Closed Flash memory disabled;
auxiliary ROM mode enabled
SW1-3
CMOS RAM
Open (default) Normal operation of CMOS RAM
Closed Factory default values for the
Setup Utility are loaded into
CMOS RAM
SW1-4
Configuration Ports
Open (default) Configuration ports are mapped to
I/O address 270/271
Closed Configuration ports are mapped to
I/O address 370/371
StockCheck.com
