RADWIN 2000 Alpha INT,
RADWIN 5000 SU-Air INT,
RADWIN 5000 SU-Pro INT
5 GHz Outdoor PtP/PtMP High Gain Radio Unit
REFERENCE GUIDE

Regulatory Compliance
FCC/ISED - Compliance
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules and ISED RSS standards. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications to this equipment not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
Outdoor units and antennas should be installed ONLY by experienced
installation professionals who are familiar with local building and safety codes
and, wherever applicable, are licensed by the appropriate government
regulatory authorities. Failure to do so may void the product warranty and
may expose the end user or the service provider to legal and financial
Caution liabilities. Resellers or distributors of this equipment are not liable for injury,
damage or violation of regulations associated with the installation of outdoor
units or antennas. The installer should configure the output power level of
antennas according to country regulations and antenna type.
RADWIN 2000 Alpha INT, RADWIN 5000 SU-Air INT, RADWIN 5000 SU-Pro INT Reference Guide i

This equipment should be installed and operated with a minimum distance of
70 cm between the radiator and your body.
Warning
The module is granted to operate under FCC Rules in the 2.4 / 5.1 / 5.8
GHz bands.
Warning
The module is granted to operate under ISED Standards in the 2.4 / 5.8
GHz bands.
Warning
This device complies with Part 15 of the FCC rules and with ISED license-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may
cause undesired operation.
This Class B digital apparatus complies with Canadian ICES-003.
RADWIN 2000 Alpha INT, RADWIN 5000 SU-Air INT, RADWIN 5000 SU-Pro INT Reference Guide ii

Overview
The RADWIN 2000 Alpha INT, RADWIN 5000 SU-Air INT and RADWIN 5000 SU-Pro INT are
model names for a high gain, integrated 2x2 MIMO XP antenna, outdoor radio transceiver
device that comes in various software configurations depending on installation purpose.
The RADWIN 2000 Alpha INT is a point to point radio unit providing wireless backhaul for
variety of applications, as well as wireless access for enterprise customers. It provides
aggregate capacity up to 350 Mbps.
The RADWIN 5000 SU-Air INT is a Point to MultiPoint subscriber unit built for residential
customers and provides aggregate capacity up to 100 Mbps.
The RADWIN 5000 SU-Pro INT is a Point to MultiPoint subscriber unit for enterprise
customers and can provide aggregate capacity up to 250 Mbps while guarantying minimum
level of capacity in case of traffic overload over the air.
All units support 10, 20, 40, 80 MHz channel bandwidths in the frequency ranges 5.15-5.25
GHz*, 5.725-5.85 GHz using OFDM transmission technique in TDD scheme.
All units include a high gain cross polarized integrated 2x2 MIMO antenna.
The units are equipped with an on-board 2.4 GHz WiFi interface module supporting HT20,
HT40 modes of operation.
The RADWIN 2000 Alpha INT, RADWIN 5000 SU-Air INT, RADWIN 5000 SU-Pro INT is
certified under the identification numbers FCC ID: Q3K-5XACULCHG and IC: 5100A-
5XACULCHG.
* Only supported under FCC Rules
Condition of Use
The RADWIN 2000 Alpha INT, RADWIN 5000 SU-Air INT, RADWIN 5000 SU-Pro INT is a
proprietary radio device and can only be deployed and maintained by RADWIN professional
installers or its authorized subcontractors
FCC Rules and ISED Regulation Restrictions
The ODU firmware is factory programmed to operate under the FCC rules and ISED
regulation restrictions. The firmware is locked and inaccessible by any third party. As a
result of the above the user interface allows both the installer and the user to control the
ODU only within the boundaries of the regional restrictions.
Antenna
The RADWIN 2000 Alpha INT, RADWIN 5000 SU-Air INT, RADWIN 5000 SU-Pro INT is
certified with a 22 dBi integrated flat crossed dual pole antenna type.
RADWIN 2000 Alpha INT, RADWIN 5000 SU-Air INT, RADWIN 5000 SU-Pro INT Reference Guide 1

Certified Antenna
Following is the antennas certified for use with the ‘RADWIN 2000 Alpha INT, RADWIN 5000
SU-Air INT, RADWIN 5000 SU-Pro INT’:
Antenna Type
Manufacturer
Model
Number
Antenna Max
Gain (dBi)
Dual FP Cross Pole
Integrated
RADWIN Ltd.
MR0204670
22
Maximum Output Power
5725 –5850 MHz band - FCC/ ISED
The maximum output power can be set as follows, when operating in the 5.8 GHz band,
under FCC 47 CFR Part 15.407 New Rules and ISED RSS-247 regulations. The power values
are for PtP systems and PtMP systems.
For PtMP systems the total EIRP is limited to 36 dBm. Therefore the conducted output
power of these systems will be limited to 14 dBm.
For PtP systems the highest conducted power shall be limited to 27 dBm.
5150 –5250 MHz band –FCC
The maximum output power can be set as follows when transmitting in the 5.1 GHz band,
under FCC 47 CFR Part 15.407 New Rules and regulations.
The total EIRP limit for PtP applications is 45 dBm.
The total EIRP limit for PtMP applications is 36 dBm.
2400 –2483.5 MHz band - FCC/ISED
The maximum output power can be set as follows, when operating in the 2.4 GHz band,
under FCC 47 CFR Part 15.247 and ISED RSS-247 regulations. The power values are for Wi-
Fi systems for HT-20 and HT-40 Channel BW.
The highest conducted output power shall be limited to 17 dBm in HT-20 and to 15 dBm in
HT-40
Radio parameters accessed by end-user
The following parameters can be accessed by user:
1. Output Power
2. Frequency channel
3. Channel bandwidth
RADWIN 2000 Alpha INT, RADWIN 5000 SU-Air INT, RADWIN 5000 SU-Pro INT Reference Guide 2

Channel Bandwidths and Carrier Frequency Ranges
RADWIN 2000 Alpha INT, RADWIN 5000 SU-Air INT, RADWIN 5000 SU-Pro INT Reference Guide 3
Channel BW
[MHz]
Center Freq. Range
[MHz]
10
5730 - 5845
20
5735 - 5840
40
5745 - 5830
80
5765 - 5810
10
5175 - 5245
20
5180 - 5240
40
5190 - 5230
80
5210
20
2412 - 2462
40
2422 - 2452
